Onyx ONYX-1521 User manual

Slim Medical Panel PC ONYX-1521
ONYX-1521
15.6” Intel®Atom D525 Dual Core Processor
High Brightness
Slim Medical Panel PC
ONYX-1521 Manual
October, 2012

Slim Medical Panel PC ONYX-1521
Copyright Notice
This document is copyrighted, 2011. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor
for any infringements upon the rights of third parties, which may
result from its use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, ONYX, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
ONYX reserves the right to make changes in the product design
without notice to its users.

Slim Medical Panel PC ONYX-1521
Acknowledgments
zIntel®, CoreTM 2 Duo / Celeron are registered trademarks of
Intel®Corporation.
zIBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
zMicrosoft®Windows is a registered trademark of Microsoft®
Corporation.
zRTL is a trademark of Realtek Semi-Conductor Co., Ltd.
zC&T is a trademark of Chips and Technologies, Inc.
zUMC is a trademark of United Microelectronics Corporation.
zITE is a trademark of Integrated Technology Express, Inc.
All other product names or trademarks are properties of their
respective owners.

Slim Medical Panel PC ONYX-1521
Packing List
Before you begin installing your Slim Medical Panel PC, please
make sure that the following items have been shipped:
ONYX-1521 Slim Medical Panel PC
VESA Screws (M4 x 0.7 x 12mm)
Utility CD-ROM which contains Drivers and Utilities
If any of these items are missing or damaged, you should contact
your distributor or sales representative immediately.
Headquarters
Onyx Healthcare Inc.
2F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist.,
New Taipei City 231, Taiwan (R.O.C.)
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
http://www.onyx-healthcare.com
Worldwide Offices:

Slim Medical Panel PC ONYX-1521
Onyx Healthcare, USA Inc.
2663 Saturn street, Brea, CA92821, USA
Tel : [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare EUROPE B.V.
Ekkersrijt 4002, 5692 DASon, The Netherlands
Tel : [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare Technology GmbH
An der Trift65d
63303 Dreieich , Germany
TEL: [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare (Nanjing) INC.

Slim Medical Panel PC ONYX-1521
Room 1318, Metallurgy Building , East Zhongshan Road,
Nanjing, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
Onyx Healthcare Singapore PTE LTD
57 Genting Lane, #07-00, Singapore 349564
Tel: [phone]
Fax [phone]
Email: [email protected]

Slim Medical Panel PC ONYX-1521
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Do not use liquid or spray detergents for cleaning. Use a damp
cloth.
4. For pluggable equipment, the power outlet must be installed
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect
the equipment from overheating. DO NOT COVER THE
OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from
the power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified

Slim Medical Panel PC ONYX-1521
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it
to work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.
16. External equipment intended for connection to signal
input/output or other connectors, shall comply with
relevant UL / IEC standard (e.g. UL 60950-1 for IT equipment
and ANSI/AAMI ES 60601-1 / IEC 60601-1 series for systems –
shall comply with the standard IEC 60601-1-1, Safety
requirements for medical electrical systems. Equipment not
complying with ANSI/AAMI ES 60601-1 shall be kept outside the
patient environment, as defined in the standard.)
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

Slim Medical Panel PC ONYX-1521
Classification
1. Degree of production against electric shock: Not classified.
TYPE B APPLIED PART for Isolation card function (RS-232)
2. Degree of protection against the ingress of water: IPX0
3. Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment
6. No Applied part, No AP / APG

Slim Medical Panel PC ONYX-1521
FCC
This device complies with Part 15 FCC
Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and (2)
this device must accept any interference
received including interference that may
cause undesired operation.

Slim Medical Panel PC ONYX-1521
UL Module Description
Onyx-1521 AC modules are developed to
suitable for the Classification Mark
requirement

Slim Medical Panel PC ONYX-1521
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with ANSI/AAMI ES 60601-1:
2005 AND CAN/CSA-C22.2 No.
60601-1:08
Attention, consult ACCOMPANYING
DOCUMENTS.
Stand-by (Green light)
Ground wire
Protective Ground wire.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1

Slim Medical Panel PC ONYX-1521
Below Table for China RoHS Requirements
產品中有毒有害物質或元素名稱及含量
ONYX Panel PC/ Workstation
部件名稱
有毒有害物質或元素
鉛
(Pb)
汞
(Hg)
鎘
(Cd)
六價鉻
(Cr(VI))
多溴聯苯
(PBB)
多溴二苯醚
(PBDE)
印刷電路板
及其電子元件 ×○○○○○
外部信號
連接器及線材 ×○○○○○
外殼 ×○○○○○
中央處理器
與記憶體 ×○○○○○
硬碟 ×○○○○○
液晶模組 ×○○○○○
光碟機 ×○○○○○
觸控模組 ×○○○○○
電源 ×○○○○○
O：表示該有毒有害物質在該部件所有均質材料中的含量均在
SJ/T 11363-2006 標準規定的限量要求以下。
X：表示該有毒有害物質至少在該部件的某一均質材料中的含量超出
SJ/T 11363-2006 標準規定的限量要求。
備註：
一、此產品所標示之環保使用期限，系指在一般正常使用狀況下。
二、上述部件物質中央處理器、記憶體、硬碟、光碟機、觸控模組為選購品。

Slim Medical Panel PC ONYX-1521
Contents
Chapter 1 General Information
1.1 Introduction ....................................................................1-1
1.2 Features ..........................................................................1-2
1.3 Specification...................................................................1-3
1.4 Dimension.......................................................................1-7
Chapter 2 Hardware Installation
2.1 Safety Precautions.........................................................2-1
2.2 A Quick Tour of the ONYX-1521...................................2-2
2.3 Removing the rear maintenance cover........................2-4
2.4 VESA Mounting Holes.............................................…...2-4
Chapter 3 Driver Installation
3.1 Installation ......................................................................3-2
Appendix A Miscellanea
A.1 General Cleaning Tips..................................................A-2
A.2 Cleaning Tools..............................................................A-3
A.3 Scrap Computer Recycling ........................................A-5

Slim Medical Panel PC ONYX-1521
General
Information
Chapter
1

Slim Medical Panel PC ONYX-1521
Chapter1 General Information 1-1
1.1 Introduction
The ONYX-1521 is a Slim Medical Panel PC with Intel®Atom
D525 1.8GHz Dual Core processor-based computer that is
designed to serve as a point of care station. It is a PC-based
system with 15.6” true color TFT LCD display, Zero Noise solution;
integrated multimedia functions make them the perfect platforms to
build comprehensive lifestyle computing applications.
The ONYX-1521 includes all the features of a powerful computer
into a slim and attractive chassis. ONYX-1521 has 300 nits 15.6”
TFT LCD with 1366 x 768 resolution. It supports 2.5” Hard Disk
Drive/SSD storage function and one Mini Card slot for WLAN
expansion. Moreover, it features flexible I/O ports such as six
USB2.0, two isolated RS-232 ports and two isolated Gigabit LANs.
Convenient operation, Silent, compact, mobility and highly
integrated multimedia system let you to focus on healthcare utility,
interactive information displays, automation control systems,
general desktop usage, multimedia recreation, and other medical
requirements.

Slim Medical Panel PC ONYX-1521
Chapter1 General Information 1-2
1.2 Features
z15.6” 1366x768 TFT LCD Display
zEasy To Use, Compact, Simple Design
zFanless, Zero Noise
z500 : 1 Contrast Wide View Angle
z300 nits High Brightness
zIntel®Atom™ D525 1.8GHz Processor
z5-wire Resistive Touch Screen
z802.11 b/g/n Wireless LAN (Optional)
zWeight: 4.3Kg

Slim Medical Panel PC ONYX-1521
Chapter1 General Information 1-3
1.3 Specification
Hardware Specifications
Display ONYX-1521: 15.6” TFT LCD
System
Memory 204-pin DDRIII SODIMM x 2, Max. 4GB
CPU Board Intel® Atom D525 1.8GHz Dual Core Processor
Drive Bay 2.5” Hard Disk Drive/SSD (SATA)
Expansion Mini-Card x 2
Button Brightness: “+” / ”-“; Sound: “+” / ”-“; Power SW
I/O USB 2.0 x 6
Isolated RS-232 x 2
Isolated Gigabit LAN x 2
Line-out, Mic-in
Speaker 3W x 2
Power
Requirement
DC 24V
LCD Specifications
Display Type 15.6” TFT LCD
Max. Resolution 1366 x 768
Max. Colors 16.7M
Pixel Pitch (mm) 0.252 x 0.252
Luminance (cd/m2) 300 (TYP)
Viewing Angle 170°(H)
160°(V)

Slim Medical Panel PC ONYX-1521
Chapter1 General Information 1-4
Contrast Ratio 500 : 1
Brightness Control Yes
Back Light Life Time 50,000 Hrs
Note: All ONYX's LCD products are manufactured with High
precision technology. However, there are a small number of
defective pixels in all LCD panels that are not able to change color.
This is a normal occurrence for all LCD displays from all
manufacturers and should not be noticeable or objectionable under
normal operation. ONYX LCD panels are qualified for industry
standard conditions in the following: total 7 dead pixels on a screen
or if there are 3 within 1 inch square area of each other on the
display.
Mechanical Specifications
Architecture Close-frame
Front Bezel Plastic bezel with resistive touch screen
Color White
Mounting / Holder VESA 75/100mm
Construction 3mm ABS + PC TYPE Plastic housing
Dimension
(W x H x D)
15.7” x 10.2” x 2.6” (400mm x 260mm x 66mm)
Net Weight 9.5lb(4.3 kg)
Power Supply Specifications
Model No. GMPU70A-6 (Eljintek Inc)
WD Part No. GMPU70A-6-L

Slim Medical Panel PC ONYX-1521
Chapter1 General Information 1-5
Input Voltage 100 ~ 240 Vac, 50/60 Hz, 1.8~0.8A
Output Voltages 24VDC-2.91A, 70W MAX
MTBF 61320 Calculated Hours (7 years)
Environmental Specifications
Operating Temperature 0˚C to 40˚C (32˚F ~104˚F)
Storage Temperature -20˚C to 60˚C (-4˚F ~140˚F)
Storage Humidity 5% to 95%@ 40˚C, non-condensing
Vibration 0.5G / 5 ~ 500Hz (Random) / operation
Shock 15G peak acceleration (11 msec. duration) /
operation
Drop 76cm (1 Corner, 3 Edge, 6 Surface)
EMI / Safety CE / FCC Class B / EN 60601-1
Noise Zero noise
Touch Screen
Type 5-wire, Analog Resistive
Interface USB Interface
Resolution 2048 x 2048
Light Transmission > 80% ± 2%
Life Time 35 million times
