OpeMed Monarch Configuration guide

Cleaning and Maintenance Schedule
(To Be Retained by Owner After Installation by Authorised OpeMed Dealer)
Part No. 1700130 / 1700133
v01.1.16
Monarch Portable Ceiling Hoist

30
Operator Maintenance Schedule
Perform the following checks/actions as indicated. Ifany of the checks fail,
contact your Authorised OpeMed Dealer for service or replacement of
parts.
Operator Check/Action Frequency
Charge the battery Before every use
Check the hoist strap for wear Before every use
Check the sling material and straps for wear Before every use
Check for any defects or loose threads in the stitched areas
of the sling
Before every use
Check the carabiner for any damage Before every use
Check the operation of the hoist control buttons Before every use
Check the operation of the hand control buttons Before every use
Check the track and hardware for any damage Before every use
Ensure the track end stops are securely in place Before every use
Ensure the hoist moves freely along the track Before every use
Clean the hoist casing As required
Clean the track Every 4 months
Check the emergency stop function (turning the power
switch Off functions as the emergency stop)
Every 4 months
Check the hoist casing for any damage Every year
Check the support hooks, carabiner and hoist strap for
any damage
Every year
Check the track, hardware, and trolley wheels for damage Every year
Monarch Portable Ceiling Hoist Owner’s Manual Part No. 01700130 / 1700133, v01.1.16

31
Dealer Maintenance Schedule
Perform the checks/actions listed in the Operator Maintenance Schedule as
well as those listed in the table below.
Toavoid potential injury, use ONLY OpeMed parts
when replacing parts.
Toprevent the user from falling (or objects from falling)
that may cause injuries to the user, the operator or
other persons, always reinstall the track end stops if
they were removed for servicing. Note that the
recommended tightening torque is 20 N-m (15 lb-ft).
Figure 15
Dealer Check/Action Frequency
Check the hoist casing for any damage Every year
Check the hoist transmission Every year
Check the hoist connecting joints Every year
Check that the emergency brake is turning freely Every year
Check that all emergency devices are working properly Every year
Perform a load test on the hoist and track system with the
Safe Working Load
Every year
Replace the hoist strap Every 2 years
Lubricate the roller and spool shaft Every 2 years
Lubricate the transmission spool gear Every 2 years
DANGER
Monarch Portable Ceiling Hoist Owner’s Manual
Part No. 01700130 / 1700133, v01.1.16

32
Inspection and Cleaning
To clean the Monarch Ceiling Hoist, wipe down the casing with a damp cloth
using warm water and a cleaner. You can also use wipes that have a 70% v/v
solution of isopropyl alcohol.
Do not use phenol, chlorine orany other type of solvent that may damage the
finish.
Rub the hoist vigorously with the cloth or wipe toensure thorough cleaning
of the entire surface.
Do not splash, drench or immerse the unit in water as the
unit could malfunction causing injuries to occur.
To ensure a better rolling surface for the trolley wheels, clean the inside of the
track every 4 months. To do this, insert a damp cloth in the opening and slide it
from one end of the track to the other.
CAUTION
Monarch Portable Ceiling Hoist Owner’s Manual Part No. 01700130 / 1700133, v01.1.16

Monarch Portable Ceiling Hoist
OWNER’S MANUAL
Part No. 01700130 / 1700133,
Document No. M920303 rev.001
Copyright2016
OpeMed (Europe) Ltd.
Clockhouse, Dogflud Way
Farnham, Surrey, GU9 7UD
www.OpeMed.net
For service or questions about this product,please contact your installing
dealer.
DEALER NAME: _________________________________________________
DEALER PHONE: _________________________________________________
Authorised OpeMed Dealer
