Opencockpits B737 MAX AFT Overhead Instruction Manual

P
www.opencockpits.com
Manual de Instalación y uso
Installation &user`s Manual
B737 MAX AFT Overhead

Índice / Index
Datos Técnicos
Technical
Data
Introducción
Introduction
Configuración
Configuration
Precaución /Caution
Mantenimiento /Maintenance
Montaje
Assembly

Introducción /Introduction
Nuevo módulo AFT Overhead completamente montado y desarrollado
bajo altos estándares de calidad, incluyendo los nuevos paneles IDC
completamente retroiluminados.
New fully assembled AFT Overhead module developed under high quality
standards including the new fully backlit IDC panels.
El Overhead se puede integrar tanto en nuestro Armazón cabina B737
[MEC-SHELL73], como en la estructura metálica para Overheads 737
[MEC-ESTDBOV7] y muestra total compatibilidad con el resto de módulos
y tarjetas Opencockpits.
The Overhead can be integrated both in our Opencockpits cabin frame
B737 [MEC-SHELL73] and in our metallic structure for Overheads 737
[MEC-ESTDBOV7] and shows full compatibility with the rest of
Opencockpits modules and cards.
Las principales características del AFT Overhead son:
The main features of the AFT Overhead are:
1-Panel LE Devices completamente funcional con indicadores
individuales. Retroiluminación BKI y conexión IDC.
Panel LE Devices fully functional with individual indicators. BKI
backlight and IDC connection.

2- Indicador IRS con retroiluminación BKI y conexión IDC, teclado
retroiluminado, display de 7 segmentos con sus indicadores
decimales y de grados, así como carácteres especiales para
N,W,S,E.
IRS indicator with BKI backlight and IDC connection, backlit
keyboard, 7-segment display with decimal and degree indicators, as
well as special characters for N, W, S, E.
3- Panel de audio con retroiluminación BKI y conexión IDC.
Audio panel with BKI backlight and IDC connection.
4- Chasis metálico robusto y completamente pintado y curado al horno.
Robust and fully painted and oven-cured metal chassis.
5- Conmutadores, e indicadores/pulsadores tipo Korry con guardas
incluidas, tal como el real.
Switches, and indicators / pushbuttons Korry type with guards
included just like the real one.
6- Retroiluminación de todo el conjunto incluida la gauge en color
blanco caliente.
Backlighting in warm white of the entire set including the
gauge.

7- Conjunto de tarjetas IOCards para gestionar todo el módulo con 2
conectores tipo USB.
Set of IOCards to manage the entire module with 2 USB type
connectors.
8- Caja de madera reforzada para transporte de 76X44X28 cm con
un peso total embalado de 22 Kg.
Reinforced wooden box for transport of 76X44X28 Cm. and total
weight packed of 22 Kg.
9- Fuente de alimentación de 5V, 12V y 3,3 V.
Power supply of 5V, 12V and 3,3V.

Los paneles incluídos son: The panels included are:
-1 Panel Le Devices.
-1 Panel ELT.
-1 Panel IRS.
-1 Panel Audio.
-1 Panel Engines.
-1 Panel Oxygen.
-1 Flight recorder y
Mach airspeed.
-1 Panel Stall Warning.
-1 Panel IRU.
-1 Panel Elevator jam
Landing assist.
NO INCLUYE / DOES NOT INCLUDED:
Software de simulación de los sistemas 737 (Compatible con
prácticamente todos los del mercado).
737 systems simulation software (Compatible with practically all those
on the market.
- 1 Le Devices Panel.
- 1 ELT Panel.
- 1 IRS Panel.
- 1 Audio Panel.
- 1 Engines Panel.
- 1 Oxigen Panel.
- 1 Flight recorder and
Mach airspeed Panel.
- 1 Stall warning Panel.
- 1 IRU Panel.
- 1 Elevator jam
Landing assist Panel.

Datos técnicos / Technical data
Aspecto y medidas / Appearance, Measurements:
Las medidas del modulo (ancho x alto x profundidad) son: 66 cm x 34 cm
x 11 cm. Aproximadamente 18 cm de profundidad con IOCards y
componentes.
The measurements of the module (width x height x depth) are: 66 cm x
34 cm x 11 cm. Approximately 18 cm deep with IOCards and components.

Los componentes electrónicos incluidos son los siguientes:
Included electronics are as follows:
Fuente de alimentación con salidas de 3.3V, 5V y 12V.
Power supply with 3.3V, 5V and 12V outputs.
1 USB Expansion Card.
2 Master Card.
1 AFT Card.
1 USB DimmControl Card.
1 Servo plus Card.
1 Input Card.
1 Output Card.
Montaje / Assembly
Una vez visto los datos técnicos del AFT Overhead, procedemos al
montaje del mismo en su ubicación.
El AFT Overhead lo podemos instalar tanto en la estructura metálica para
Overheads 737 [MEC-ESTDBOV7] como en nuestro Armazón cabina B737
[MEC-SHELL73].

Once we have seen the technical data of the AFT Overhead, we proceed
to assemble it in its location.
The AFT Overhead can be installed both in the metallic structure for
Overheads 737 [MEC-ESTDBOV7] and in our cabin frame B737 [MEC-
SHELL73].
1-MONTAJE EN ESTRUCTURA METALICA PARA OVERHEADS 737
MOUNTING ON A METALLIC STRUCTURE FOR OVERHEADS 737
El chasis de nuestro AFT Overhead viene provisto de cuatro orificios, dos
en la parte superior y dos el la inferior.
The chassis of our AFT Overhead is provided with four holes, two on the
top and two on the bottom.

En los orificios se colocan los tornillos incluidos y a su vez, se introducen
en las ranuras de los soportes de la Estructura de overhead y se desplazan
lateralmente.
The included screws are placed in the holes and in turn are inserted into
the slots of the supports of the Overhead Structure and moved laterally.
Finalmente, se aprientan los tornillos una vez colocado el Aft overhead
en la posición deseada.
Finally, tighten the screws once the Aft overhead has been placed in the
desired position.

2-MONTAJE EN ARMAZON CABINA 737
FRAME CAB 737 MOUNT
El chasis de nuestro AFT Overhead viene provisto de cuatro orificios, dos
en la parte izquierda y dos el la derecha.
The chassis of our AFT Overhead is provided with four holes, two on the
left and two on the right.
En los orificios se colocan los tornillos incluidos, seguidamente, se coloca
el AFT Overhead en su ubicación en el armazón cabina 737.
Los tornillos se introducen en las ranuras de los refuerzos del armazón de
cabina y se desplaza lateralmente.

Por último, se aprietan los tornillos una vez colocado el AFT Overhead en
la posición deseada.
The included screws are placed in the holes, then the AFT Overhead is
placed in its location in the 737 cabin frame.
The screws are inserted into the grooves of the cockpit frame stiffeners
and moved laterally.
Finally, the screws are tightened once the AFT Overhead has been placed
in the desired position.
A continuación vamos a explicar el cableado de la electrónica y montaje
de los panels IDC.

Next we will explain the wiring of the electronics and assembly of the
IDC panels.
El AFT Overhead lleva integrado una Expansión Card con dos Master Card.
La Master Card 1 gestiona las Input Card y el conector output 2 de la
Tarjeta Overhead AFT. La Master Card 2 gestiona la Output Card, el
conector output 1 y conector Input de la Tarjeta Overhead AFT.
The AFT Overhead has an integrated one Expansion Card with two Master
Cards. Master Card 1 manages the Input Cards and the output connector
2 of the Overhead AFT Card. Master Card 2 manages the Output Card,
the output connector 1 and Input connector of the Overhead AFT Card.
De forma independiente, integra una USB DimControl Card que gestiona
la retroiluminación de los modulos IDC y una USB Servo Plus que controla
el gauge de Oxigeno.
Independently, it integrates a USB DimControl Card that manages the
backlighting of the IDC modules and a USB Servo Plus that manages the
oxygen gauge.
Cableado tarjetas IOCards / IOCards wiring.
Seguidamente se detallan los esquemas de la configuración que
utilizamos de forma estándar en el AFT Overhead 737 Max:
We are going to detail the diagrams of the configuration we use as
standard in the AFT Overhead 737 Max:

Para esta configuración, las variables de entradas y salidas serían las
siguientes (el listado pertenece a la definición del 6_13_MAX_B737_
OVHAFT_PROSIM de Opencockpits basado en la tarjeta OVERHEAD AFT).
For this configuration, the input and output variables would be the
following (the list belongs to the definition of 6_13_MAX_B737_
OVHAFT_PROSIM from Opencockpits based on the OVERHEAD AFT card).

//****************
//* OUTPUTS-LEDS *
//****************
// *******
// * ELT *
// *******
VAR 6000, NAME ELT_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 93
// **************
// * LE DEVICES *
// **************
VAR 6002, NAME SLAT1TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 11
VAR 6004, NAME SLAT1EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 12
VAR 6006, NAME SLAT1FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 13
VAR 6008, NAME SLAT2TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 14
VAR 6010, NAME SLAT2EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 15
VAR 6012, NAME SLAT2FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 16
VAR 6014, NAME SLAT3TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 17
VAR 6016, NAME SLAT3EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 18
VAR 6018, NAME SLAT3FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 19
VAR 6020, NAME SLAT4TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 20
VAR 6022, NAME SLAT4EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 21
VAR 6024, NAME SLAT4FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 22
VAR 6026, NAME SLAT5TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 31
VAR 6028, NAME SLAT5EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 32
VAR 6030, NAME SLAT5FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 33
VAR 6032, NAME SLAT6TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 34
VAR 6034, NAME SLAT6EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 35
VAR 6036, NAME SLAT6FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 36
VAR 6038, NAME SLAT7TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 37
VAR 6040, NAME SLAT7EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 38
VAR 6042, NAME SLAT7FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 39
VAR 6044, NAME SLAT8TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 40
VAR 6046, NAME SLAT8EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 41
VAR 6048, NAME SLAT8FULL, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 42
VAR 6050, NAME FLAP1TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 23
VAR 6052, NAME FLAP1EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 24

VAR 6054, NAME FLAP2TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 25
VAR 6056, NAME FLAP2EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 26
VAR 6058, NAME FLAP3TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 27
VAR 6060, NAME FLAP3EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 28
VAR 6062, NAME FLAP4TRANS, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 29
VAR 6064, NAME FLAP4EXT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 30
// *******************************
// * ELEVATOR JAM LANDING ASSIST *
// *******************************
VAR 6066, NAME ASSISTON, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 89
// *************************************************************
// * IRS DISPLAY DOTS FROM RIGHT TO LEFT LOOKING AT THE SCREEN *
// *************************************************************
VAR 6068, NAME IRS_DOT1R, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 43
VAR 6070, NAME IRS_DOT2R, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 44
VAR 6072, NAME IRS_DOT3R, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 45
VAR 6074, NAME IRS_DOT1L, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 46
VAR 6076, NAME IRS_DOT2L, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 47
VAR 6078, NAME IRS_DOT3L, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 48
// ************
// * IRS MODE *
// ************
VAR 6080, NAME IRS_GPS_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 95
VAR 6082, NAME IRS_ALIGN_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 96
VAR 6084, NAME IRS_FAULT_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 97
VAR 6086, NAME IRS_ONDC_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 98
VAR 6088, NAME IRS_DCFAIL_L_, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 99
VAR 6090, NAME IRS_ALIGN_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 100
VAR 6092, NAME IRS_FAULT_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 101
VAR 6094, NAME IRS_ONDC_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 102
VAR 6096, NAME IRS_DCFAIL_R_, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 103
// *********
// * AUDIO *
// *********

VAR 6098, NAME AO1_MIC_VH1, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 75
VAR 6100, NAME AO1_MIC_VH2, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 76
VAR 6102, NAME AO1_VOL_VH1, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 77
VAR 6104, NAME AO1_VOL_VH2, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 78
VAR 6106, NAME AO1_VOL_NV1, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 79
VAR 6108, NAME AO1_VOL_NV2, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 80
VAR 6110, NAME AO1_VOL_AD1, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 81
VAR 6112, NAME AO1_VOL_AD2, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 82
VAR 6114, NAME AO1_VOL_MKR, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 83
// *********
// * MAINT *
// *********
VAR 6118, NAME O_MAINT, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 94
// **********
// * ENGINE *
// **********
VAR 6120, NAME ENG_RVRSER_L_, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 104
VAR 6122, NAME ENG_RVRSER_R_, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 105
VAR 6124, NAME ENG_CONTR_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 91
VAR 6126, NAME ENG_CONTR_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 90
VAR 6128, NAME ENG_ALTN_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 84
VAR 6130, NAME ENG_ON_L_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 85
VAR 6132, NAME ENG_ALTN_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 86
VAR 6134, NAME ENG_ON_R_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 87
VAR 6136, NAME ENG_RVR_LML, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 106
VAR 6138, NAME ENG_RVR_LMR, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 107
// ***************
// * PASS OXYGEN *
// ***************
VAR 6140, NAME PASS_OXY_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 108
// *************

// * AFT GEARS *
// *************
VAR 6142, NAME AFT_LGEAR_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 109
VAR 6144, NAME AFT_RGEAR_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 92
VAR 6146, NAME AFT_NOSEGEAR_, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 111
// *******************
// * FLIGHT RECORDER *
// *******************
VAR 6148, NAME AFT_RECOFF_O, STATIC, LINK IOCARD_OUT, DEVICE 6, OUTPUT 112
//*********************
//* INPUTS - SWITCHES *
//*********************
// *******
// * ELT *
// *******
VAR 6150, NAME ELT_ON_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 85
// **************
// * LE DEVICES *
// **************
VAR 6152, NAME LE_TEST_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 68
// *******************************
// * ELEVATOR JAM LANDING ASSIST *
// *******************************
VAR 6154, NAME ASSIST_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 99
// IRS DISPLAY
VAR 6156, NAME IRS_TEST_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 48
VAR 6158, NAME IRS_TKGS_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 49
VAR 6160, NAME IRS_PPOS_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 50
VAR 6162, NAME IRS_WIND_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 51
VAR 6164, NAME IRS_HDGSTS_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 52
VAR 6166, NAME IRS_SYSL_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 53

VAR 6168, NAME IRS_KEY1_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 36
VAR 6170, NAME IRS_KEY2_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 44
VAR 6172, NAME IRS_KEY3_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 42
VAR 6174, NAME IRS_KEY4_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 38
VAR 6176, NAME IRS_KEY5_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 40
VAR 6178, NAME IRS_KEY6_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 46
VAR 6180, NAME IRS_KEY7_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 43
VAR 6182, NAME IRS_KEY8_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 37
VAR 6184, NAME IRS_KEY9_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 45
VAR 6186, NAME IRS_KEYENT_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 47
VAR 6188, NAME IRS_KEY0_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 39
VAR 6190, NAME IRS_KEYCLR_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 41
// ************
// * IRS MODE *
// ************
VAR 6192, NAME IRS_LOFF_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 72
VAR 6194, NAME IRS_LALIGN_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 73
VAR 6196, NAME IRS_LNAV_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 74
VAR 6198, NAME IRS_LATT_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 75
VAR 6200, NAME IRS_ROFF_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 76
VAR 6202, NAME IRS_RALIGN_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 77
VAR 6204, NAME IRS_RNAV_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 78
VAR 6206, NAME IRS_RATT_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 79
// **********************
// * SERVICE INTERPHONE *
// **********************
VAR 6208, NAME AFT_PHONE_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 86
// **************
// * DOME WHITE *
// **************
VAR 6210, NAME AFT_DIM_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 81
VAR 6212, NAME AFT_BRIGHT_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 82
// *********
// * AUDIO *

// *********
VAR 6214, NAME AI1_MIC_VH1, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 54
VAR 6216, NAME AI1_MIC_VH2, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 55
VAR 6218, NAME AI1_VOL_VH1, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 56
VAR 6220, NAME AI1_VOL_VH2, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 57
VAR 6222, NAME AI1_VOL_NV1, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 58
VAR 6224, NAME AI1_VOL_NV2, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 59
VAR 6226, NAME AI1_VOL_AD1, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 60
VAR 6228, NAME AI1_VOL_AD2, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 61
VAR 6230, NAME AI1_VOL_MKR, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 62
VAR 6232, NAME AI1_RT, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 65
VAR 6234, NAME AI1_IC, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 66
VAR 6236, NAME AI1_SEL_V, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 64
VAR 6238, NAME AI1_SEL_R, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 63
VAR 6240, NAME AI1_INT_NRM, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 67
// **********
// * ENGINE *
// **********
VAR 6242, NAME REVERSEON_L_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 69
VAR 6244, NAME REVERSEON_R_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 70
// ***************
// * PASS OXYGEN *
// ***************
VAR 6246, NAME PASS_OXY_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 83
// *******************
// * FLIGHT RECORDER *
// *******************
VAR 6248, NAME FLTREC_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 84
// MACH AIRSPEED WARNING TEST
VAR 6250, NAME MACHWT1_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 87
VAR 6252, NAME MACHWT2_I, STATIC, LINK IOCARD_SW, DEVICE 6, INPUT 88
// STALL WARNING TEST
