Opera OUVERTURE EXIT User manual

ELECTRIC HANDLE
“OUVERTURE EXIT”

TECHNICAL SPECIFICATIONS
Art. 40620 Art. 40621 Art. 40820 Art. 40821
OPERATION CONDITION
WITHOUT CURRENT Handle Activated Handle Activated Handle Disabled Handle Disabled
HAND Non handed Non handed Non handed Non handed
SPINDLE DRIVE 9 mm 9 mm 9 mm 9 mm
SPINDLE DRIVE
ROTATION
Adjustable at
45° or 60°
Adjustable at
45° or 60°
Adjustable at
45° or 60°
Adjustable at
45° or 60°
POWER SUPPLY 12 / 24 ac/dc 12 / 24 ac/dc 12 / 24 ac/dc 12 / 24 ac/dc
START UP CURRENT
(I max)
700 mA 700 mA 700 mA 700 mA
MAINTENANCE
CURRENT (I max) 500 mA 500 mA 500 mA 500 mA
TIME DELAY NO Adjustable from 0
to 60 seconds NO Adjustable from 0 to 60 seconds
EXTERNAL SIGNALING
(OPEN COLLECTOR) NO YES NO YES
WHITE/BLUE LOWER
LIGHTING NO YES NO YES
OPEN RELEASE LEVER Both electrical
and mechanical
Both electrical
and mechanical
Both electrical
and mechanical
Both electrical
and mechanical
The electric handle can be fitted with rim type exit panic devices with visible latch.
The coupling is possible thanks to the fixing plate serie 00428 (to order separately
according to the specific bar).
ersions:
- activated without current (Items 40620 – 40621)
It is disabled (handle in neutral position) with power supply
- disabled (handle in neutral position) without current (Items 40820 - 40821)
It is enabled with power supply
Attention: not suitable for outdoor exposure.

INSTALLATION
•Check the bar is correctly installed and the
holes for the handle frame and fixing screws
are present on the door.
•Insert the handle as shown in the figure and
rotate it in the desired direction.
NB : for versions 40620 and 40621 this
operation must be performed when power is
ON; for versions 40820 and 40821 when
power is OFF.
•
•Fix the handle with the appropriate supplied
screw and split washer (Grower).
•Before completing the installation, it is
necessary to select the rotation of the spindle
drive using the appropriate selector on the back
of the handle. It can be of 45° or 60°,
depending on the bar to fit with the electric
handle.
To change the selection, use a flat screwdriver,
press and rotate the spindle selector until the
the cut lines up with the desirered degrees (see
figure). Release the spindle selector in the
desidered position.
60° Rotation 45° Rotation

•Using the key, it is possible to mechanically
enable the electric handle.
To activate the mechanic open release lever,
remove the grub screw that prevents the
complete rotation (see figure).
In this configuration, the key enables the
permanent mechnical activation of the electric
handle. To disconnect the open release lever,
use the key manually.
•Fix the back plate with the appropriate screws
and make sure the fixing bushes are in the
correct position in front of the fixing holes on
the bar.
•If one of the fixing bushes is placed to the
cylinder height, tighten the supplied nylons
gauge in the back part of the bush (see figure).
•Reduce the spindle and the fixing screws as
per the indications supplied with 00428
instructions
•Block the spindle with the appropriate grub
screw only if necessary.

•Tighten the screws previosuly reduced to
complete the installation. Make sure the striking
parts are free to move and do not hit parts of
the door or obstruct the bar mechanism.
Cable has not to be damaged or pressed.
MODE OF OPERATION
Direct activation with power supply (without time delay)
40620 serie
When the electric handle is disabled (in neutral), the red LED is on. Without power,
the LED turns off and the handle enables the door opening as long as power is OFF.
40820 serie
When the electric handle is disabled (in neutral), the green LED is off. Power supply
enables the door opening and green LED turns on as long as power is ON.
Attention: time delay has to be set at 0 seconds for items code 40621 and 40821.
It is possible to use both the lead cover and the pressure contacts.
Activation with dry contact (with time delay)
40621 – 40821 series
When the electric handle is disabled (in neutral), the red LED is on. Handle enables
door opening once the opening switch is pressed and released and the green LED is
on for the setted time (from 5 to 60 seconds) or until the first activation of the handle.
To reopen the door, the opening swicth has to be pressed again.
The use of a lead cover si recommended.

TIME DELAY CONFIGURATION
(Only for 40621 – 40821 versions)
The electric handle has a time delay system inside which enables to keep the handle
enabled for the time selected by the user.
Time delay configuration at 0 seconds
1. Connect the N.O. programming switch (not included) to the blue wire and to the
green wire of the ground signals.
2. Connect the handle to the power supply (grey and white wires).
3. Plate has a red LED light. Press the programming switch until the LED becomes
blue. Release the programming switch immediately. LED turns on for about one
second to confirm programming. Electric handle remains enabled for the duration
of the electrical pulse only.
Time delay configuration from 5 to 60 seconds
1. Connect the N.O. programming switch (not included) to the blue wire and to the
green wire of the ground signals (GND).
2. Connect the handle to the power supply (grey and white wires).
3. Plate has a red LED light. Press the programming switch until the LED becomes
blue. Keep the switch pressed and the LED double flashes, each flesh
corresponding to 5 seconds. Once the desired timing is achieved, release the
programming switch. LED confirms set timing flashing. Electric handle remains
enabled for the selected time or until the first activation.
ELECTRIC HOLD OPEN DEVICE
To keep the door enabled for a time set by the user, it is necessary to install a switch
in parallel with the opening switch. It will keep the door open until its disconnection.

ACTIVATION AND DEACTIVATION OF THE LOWER WHITE/BLUE LED's
LIGHTING
(40621 – 40821 versions only)
Electric handle serie 40621 and 40821 has a blue (electric handle disabled) and a
white LED (electri handle activated) on the lower part which create a light beam near
the floor.
White/blue LED's deactivation
1. Connect the N.O. programming switch (not included) to the blue and to the green
wire of the ground singals (GND).
2. Press the programming switch when the electric handle is deactivated.
3. Connect the handle to the power supply, keeping the switch pressed.
4. Blue LED light will flash twice and it will then become red. Releasing the
programming switch, LED will flash twice confirming the white/blue lower lighting
deactivation.
White/blue LED's activation
1. Connect the N.O. programming switch (not included) to the blue and to the green
wire of the ground singals (GND).
2. Press the programming switch when the electric handle is deactivated.
3. Connect the handle to the power supply, keeping the switch pressed.
4. Blue LED light will flash twice and it will then become red. Releasing the
programming switch, LED will flash twice confirming the white/blue lower lighting
activation.

CYLINDER REPLACEMENT
•Unscrew the cylinder locking screw
•Pull the cylinder out
•Move the grub screw from the old to the new
cylinder
•Insert the cylinder back again
•Tighten the cylinder locking screws
•The electric handle is suitable for a Euro profile
half cylinder
Cylinder lenght = 40mm (30+10)

INSTALLATION EXAMPLES
Electric handle with Push Bar.
Electric handle with Touch Bar.

CONNECTING DIAGRAM
“DC” power supply with direct electricity activation
for items 40620 – 40621* – 40820 40821*
Power supply
230 Vac
In the 406 version, use a
N.C. switch
WHITE (POWER SUPPLY) 12 / 24 Vdc
GREY (POWER SUPPLY)
“AC” power supply with direct electricity activation
for items 40620 – 40621* – 40820 40821*
Transformer
230 Vac
In the 406 version, use a
N.C. switch
WHITE (POWER SUPPLY) 12 / 24 Vac
GREY (POWER SUPPLY)
* Bring timing to 0 seconds

“DC” power supply and opening by contact
for items 40621 40821
Power Supply
230 Vac
WHITE (POWER SUPPLY) 12 / 24 Vdc
GREY (POWER SUPPLY)
RED (OPENING)
GREEN (GND) NO POWER SUPPLY
LIGHT BLUE (PROGRAMMING) POSITIVE
POWER SUPPLY
ORANGE (OPEN COLLECTOR)
12/24 Vdc
MAX 30 mA
“AC” power supply and opening by contact
for items 40621 40821
Transformer
230 Vac
WHITE(POWER SUPPLY) 12 / 24 Vac
GREY (POWER SUPPLY)
RED (OPENING)
GREEN (GND) NO POWER SUPPLY
LIGHT BLUE (PROGRAMMING)
ORANGE (OPEN COLLECTOR)

Intercom electric handle connection
Power Supply
230 Vac
WHITE (POWER SUPPLY) 12 / 24 Vdc
GREY (POWER SUPPLY)
RED (OPENING)
GREEN (GND)
LIGHT BLUE(PROGRAMMING)
ORANGE (OPEN COLLECTOR)
COM. N.O.
RELAY MODULE
ITEM 05258
(to order separately)
12 Vac from INTERCOM
OPERA s.r.l.
Tel. [phone]
www.opera-italy.com – [e-mail]
n° 1506/ 1926 Rev.0 del 09/06/15
