OPERTIS eLOCK ES7670 User manual

Operating instructions
APS Comfort system for framed doors
ES7670, ES6670, ES7671, ES6671
ES7672, ES6672, ES7673, ES6673

eLOCK GB
Operating instructions APS Comfort System for Framed Doors
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
09/2013 OPERTIS 3
Contents
1Introduction ..................................................................................................................4
About these instructions...............................................................................................4
Explanation of the symbols and signal words used .....................................................4
Target group................................................................................................................. 4
OPERTIS Support........................................................................................................4
Up-to-date information ................................................................................................. 5
2Product description......................................................................................................6
Component parts.......................................................................................................... 6
Functional principle......................................................................................................7
Detailed information.....................................................................................................7
3Intended use .................................................................................................................8
Area of use...................................................................................................................8
Condition of the product...............................................................................................8
Ambient conditions.......................................................................................................8
Power supply................................................................................................................8
Residual risk.................................................................................................................8
4Safety instructions.......................................................................................................9
5Use and operation......................................................................................................11
Programming fittings and identifiers...........................................................................11
Change the battery.....................................................................................................11
Acoustic signals .........................................................................................................12
6Servicing, cleaning and maintenance.......................................................................13
Intervals......................................................................................................................13
Cleaning and maintenance ........................................................................................13
Servicing .................................................................................................................... 14
7Problems and solutions.............................................................................................16
8Product specifications...............................................................................................18
Declaration of conformity ...........................................................................................18
Dimensions ................................................................................................................18
Technical data............................................................................................................19
9Disposal ......................................................................................................................20
Product.......................................................................................................................20
Batteries.....................................................................................................................20
Product packaging .....................................................................................................20
Notes:.........................................................................................................................20

GB eLOCK
APS Comfort System for Framed Doors Operating instructions
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
4 OPERTIS 09/2013
1 Introduction
About these instructions
This manual contains important information for operating the APS Comfort
System for Framed Doors ES7670, ES6670, ES7671, ES6671, ES7672,
ES6672, ES7673 and ES6673.
Read the manual thoroughly and carefully.
Store the manual and pass on to each next user of the APS Comfort
System for Framed Doors.
Explanation of the symbols and signal words used
WARNING Indicates hazards that can lead to death or serious
injury.
CAUTION Indicates hazards that can lead to minor or
moderate injury.
CAUTION Indicates hazards that can lead property damage.
Note Highlights hints and tips for optimum use of the
manual and product.
Target group
This manual is intended for specialist staff, who are responsible for the
service, maintenance, disposal and continued fault-free operation of the
APS Comfort System for Framed Doors, and can prove that they have the
suitable training or relevant experience for these activities.
OPERTIS Support
Should you have any questions, which are not covered in this manual,
please contact:
OPERTIS GmbH
Prof.-Bier-Straße 1-5
D-34454 Bad Arolsen
Tel.: [phone]
Fax: [phone]
Email: [email protected]

eLOCK GB
Operating instructions APS Comfort System for Framed Doors
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
09/2013 OPERTIS 5
Up-to-date information
All information on the product, images, dimensions and lists correspond to
the status at the time of product delivery. We reserve the right to make
changes as a result of technical progress, and the resulting improvement
product processes.
You can also find the current version of this manual and other information
on our website - www.opertis.de.
Status 09/2013

GB eLOCK
APS Comfort System for Framed Doors Operating instructions
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
6 OPERTIS 09/2013
2 Product description
Component parts
The following drawing shows the component parts of the APS Comfort
System for Framed Doors:
1 Stainless steel cover
2 Battery
3 M3x6 screws
4 Housing with electronics
5 M5x8 screws
6 M3x9 threaded pins
7 Mounting plate
8 APS lock
9 Fixing screw M5x50
10 Profile cylinder adapter with antenna cable
11 M4 countersunk screw (door thickness dependent)
12 Profile cylinder housing
13 Plastic profile cylinder cover with antenna

eLOCK GB
Operating instructions APS Comfort System for Framed Doors
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
09/2013 OPERTIS 7
Functional principle
Self-locking motor panic lock with integrated electronics according to DIN
18251-2.
The OPERTIS locking system, eLOCK, ensures durchgängige
Objektausstattung. Special fittings are available for different types of door.
The APS Comfort System for Framed Doors contains a self-locking lock,
which automatically locks when the door is closed. Conventional locking
with knobs or keys is no longer needed; nor is mechanical closing.
With the APS Comfort System for Framed Doors, the inside handle is
always coupled. Through the integrated anti-panic function, the latch and
release lever are retracted by pushing the inside handle; the door can
always be opened again from the inside. The panic function cannot be
switched off.
With the APS Comfort System for Framed Doors, the outside handle is
non-functional when it is decoupled. It can be pushed, but it is not
connected to the the lock latch or release lever. In this state, the door
cannot be opened using the outside handle. Access is gained by brief
coupling of the otherwise neutral outside handle after holding an
authorised identifier in front of the antenna. Upon actuation of the coupled
outside handle, the latch and release lever are retracted.
Conventional locking with knobs or keys is no longer needed; nor is
mechanical closing.
Administration and programming, as well as the granting of access rights
is done over the eLOCK Center administration software. Optional
programming with eLOCK LernLösch over three programming keys
without additional software is possible.
To access the fittings, passive identifiers without their own power supply
are available in different designs, such as key rings, cards or custom
designs.
Detailed information
You can find further information on the product in section 8 "Product
specification“.

GB eLOCK
APS Comfort System for Framed Doors Operating instructions
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
8 OPERTIS 09/2013
3 Intended use
Area of use
The APS Comfort System for Framed Doors matches the installation
dimensions of a mortice lock in accordance with DIN 18251-2, and is
designed for indoor use on narrow tubular framed doors. Use of external
doors is permissible only if the electronics are installed in a protected
internal area. Use on fire safety doors or outdoors, such as in fencing, is
not permitted.
The lock meets the requirements for doors in escape and rescue routes
according to DIN EN 179 and 1125. Used in approved and tested fittings.
Condition of the product
The APS Comfort System for Framed Doors may only be used in a
technically sound condition.
Unauthorised conversions or alterations of the product are not permitted.
Ambient conditions
Use in particularly harsh environments, e.g. corrosive gases, high
humidity, extreme temperatures or very dusty conditions, is not permitted.
Please contact OPERTIS Support if you have any questions.
Power supply
Enable all battery-powered fittings activate audible low battery warnings,
and controlled failure closures when the battery power in the fitting is
coming to an end. The battery must then be replaced immediately.
Repeated disregard for the low battery warning permanently decouples
the APS Comfort System for Framed Doors from the handle (Active Power
Off). The Active Power Off state is indicated by an acoustic warning (see
operating manual, chapter 5 - Use and operation). This state is maintained
until the battery is replaced or, if relevant, an external power source was
connected to the outside of the door.
Residual risk
This product supports the security of your property when used as
intended, and in compliance with the maintenance instructions.
The following residual risks, however, cannot be ruled out.
If the electromechanical components fail, there is the risk of being
locked out.

eLOCK GB
Operating instructions APS Comfort System for Framed Doors
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
09/2013 OPERTIS 9
If the battery suddenly completely discharges, the APS Comfort
System for Framed Doors will be non-functional. It will send no battery
warning, and will not enter the Active Power Off state. It is then only
possible to open the door from the outside with the external power
supply ES6781 for ES5000 plus systems or ES7781 for eLOCK and
eLOCK LernLösch systems.
4 Safety instructions
The safety notes are to be read prior to use! OPERTIS accepts no liability
for any personal injury or property damage resulting from failure to follow
this manual!
WARNING
Risk of personal injury from the batteries
Improper handling of the batteries can be harmful to health.
The following notes must be observed:
Only use types of batteries, which are delivered or
approved by OPERTIS.
Do not open, solder or weld batteries.
Do not throw batteries into fire.
Do not recharge batteries.
Immediately remove empty batteries from the fitting.
Keep batteries out of the reach of children.
Do not touch leaking batteries without appropriate
protection. Avoid contact with eyes and mouth.
CAUTION
Risk of property damage
Using non-approved types of battery can result in
malfunction. In this case, the fitting would send no battery
warning, and would not enter the secure final state of Active
Power Off.
Only use types of batteries, which are approved by
OPERTIS.

GB eLOCK
APS Comfort System for Framed Doors Operating instructions
ES7670, ES6670, ES7671, ES6671, ES7672, ES6672, ES7673, ES6673
10 OPERTIS 09/2013
CAUTION
Risk of being locked out
The door cannot be opened without a functional fitting, if the
latch is in the lock.
Leave the door open during installation and battery
replacement, or ensure that the door can be opened at all
times without using the fitting.
CAUTION
Unauthorised access
The inside handle of the APS Comfort System for Framed
Doors is basically coupled as an anti-panic lock. This makes
it possible to open the door at all times using the inside
handle. Be especially aware of this when using the fitting on
publicly accessible doors, and on doors with inside handles,
which can be easily reached from the outside.
CAUTION
Unauthorised access
The APS Comfort System for Framed Doors is delivered with
factory settings. Access is also possible with all non-
programmed OPERTIS identifiers.
Programme the authorisations immediately following
installation to prevent unauthorised access; see eLOCK
system documentation software; meanwhile, check the time
and reset if necessary.
