Optimus H-6011 Installation instructions

FULL ONE-YEAR WARRANTY
Applica warrants this product against any defects that are due to faulty material or
workmanship for a one-year period after the original date of consumer purchase. This
warranty does not include damage to the product resulting from accident or misuse. If
the product should become defective within the warranty period, we will repair it or elect
to replace it free of charge.
This warranty gives you specific legal rights and you may also have other rights which
vary from state to state or province to province. Answers to any questions regarding
warranty or service locations may be obtained by calling Consumer Assistance and
Information: 203-926-3230.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or similarly qualified person in order to avoid a hazard.
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following.
“DO NOT COVER” heater. Do not place any object on this heater.
■READ AND SAVE ALL INSTRUCTIONS BEFORE USING.
■This heater is hot when in use. To avoid burns, do not let bare skin touch hot surface.
Unplug and let heater cool down for at least ten (10) minutes before moving it.
Use handles, if provided.
■To reduce the risk of fire, keep combustible materials, such as furniture, pillows,
bedding, papers, clothes and curtains at least 3 feet (0.9m) from the front, sides and
rear of the heater.
■Extreme caution is necessary when any heater is used by or near children or invalids,
and whenever the heater is left operating. Avoid leaving an operating heater
unattended.
■Always unplug from electrical outlet (receptacle) whenever heater is not in use.
■To disconnect heater, turn control to OFF, then remove plug from outlet (receptacle).
REMOVE BY PULLING ON THE PLUG — not the cord.
■Do not operate any heater with a damaged cord or plug or after a malfunction, or after
it has been dropped or damaged in any manner. Return heater to the nearest
authorized service repair center for examination, electrical or mechanical adjustment
or repair.
■This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate heater where it may come in contact with water, such as near
a bathtub or sink. If the heater does become wet, unplug it from the wall receptacle
before touching it, as a wet heater may create an electrical shock hazard even if the
heater is turned off.
■Do not use outdoors.
■To avoid overheating of the cord, do not cover any part of the cord with carpet, throw
rugs, runners, newspapers, magazines, furniture, etc. Arrange cord away from
trafficked areas, so it will not be tripped over or stepped on.
■Do not insert or allow foreign objects to enter any ventilation or exhaust opening,
as this may cause an electrical shock, fire or damage to the heater.
■To avoid a fire hazard, do not cover this heater in any manner. Do not use on soft
surface (such as a bed) where openings may be blocked or heater can fall over.
■A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint or other volatile or flammable liquids are used or stored.
■Avoid the use of an extension cord because the extension cord may overheat and
cause a risk of fire. However, if an extension cord must be used, it shall be of a
minimum size of 14 AWG and rated not less than 1500 watts. Use only an extension
cord that is UL listed.
■To prevent electrical overload and blown fuses, be sure that no other appliances are
plugged into the same outlet (receptacle) or into another outlet (receptacle) wired
into the same circuit.
■Do not place the heater near a bed, because objects such as pillows or blankets can
fall off the bed and be ignited by the heater.
■Do not use this heater as an integral part of any life support or equipment protection
system, where a functional failure or misapplication of the heater could jeopardize the
people or things being protected.
■Avoid using heater while sleeping.
■Do not use heater in any other orientation other than upright as shown in this manual.
■Use heater only as described in this manual. Any other use is not recommended by
the manufacturer and may cause fire, electric shock or injury to persons.
SAVE THIS USE AND CARE BOOK
OIL-FILLED HEATER
Copyright © 2001 Applica Consumer Products, Inc.
Printed in Hong Kong
2001/1-12-79E WOFH-7
PUB No. 177139-00
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). As a safety
feature, this plug fits in a polarized outlet only one way. If the plug does not fit into the
outlet, reverse the plug and try again. If it still does not fit, contact a qualified
electrician. Do not attempt to defeat this safety feature.
2001_1_12_79_HE 4/9/01 3:58 PM Page 1

OPERATING INSTRUCTIONS
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATIONS
LINE CORD SAFETY TIPS
1. Never pull or yank on the cord or the appliance.
2. To insert plug, grasp it firmly and guide it into outlet.
3. To disconnect appliance, grasp plug and remove it from outlet.
4. Before each use, inspect the line cord for cuts and/or abrasion marks. If any
are found, this indicates that the appliance should be serviced and the line
cord replaced. The line cord may be replaced by qualified service personnel.
5. Never wrap the cord tightly around the appliance, as this could place undue
stress on the cord where it enters the appliance and cause it to fray
and break.
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE, OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
HOW TO USE
CARE AND CLEANING
This appliance is for HOUSEHOLD USE ONLY. It may be plugged into any AC
electrical outlet (ordinary household current). Do not use any other type of
outlet.
SPECIAL ATTENTION:
The use of an extension cord is not recommended. However, if it is absolutely
necessary, be sure that the cord is (1) No. 14 AWG minimum size and rated no
less than 1500 watts; (2) UL Listed; (3) as short as possible (long cords can
overheat, as well as trip circuit breakers); (4) not used for operating more than
one appliance at a time.
CASTER ASSEMBLY INSTRUCTIONS
Heater is packed with two caster assemblies that must be installed between
the radiator fins at each end of base pipe to make unit portable and convenient
to use.
TO ASSEMBLE (Refer to Figures 1 and 2)
1. Be sure Heater is unplugged and power switches are Off.
2. Keep cord out of the way by winding it around cord storage on side of unit.
3. Set Heater upside down.
4. Place the two metal connecting screws of caster assembly over base pipe,
between radiator fins on one side of heater, so that threads on screws project
beyond pipe.
5. Insert one screw into each hole on wheelbase of caster assembly.
6. Fasten wing nut securely on threaded end of each connecting screw.
7. Repeat procedure on other side of unit with the other caster assembly.
8. Set Heater upright and plug in.
CHOOSING A LOCATION
This heater is intended for use only on the floor.
• This Heater radiates heat in all directions, so always leave ample space
around it.
• Do not place too close to a wall or any furniture.
• Keep all combustible materials such as furniture, pillows, bedding, paper,
clothes and curtains at least 3 feet away from heater.
• Do not place anything on top of Heater.
• Do not use in wet or moist locations; for example, bathrooms or laundry areas,
or in areas where paint or other flammable or volatile liquids are used
or stored.
This appliance contains no user serviceable parts. Refer service to qualified service
personnel.
SPECIAL NOTE:
Before unplugging unit, be sure all controls are in the Off position.
TO CLEAN: Always unplug heater from outlet and allow it to cool thoroughly before
attempting to clean. Accumulated dust may be removed from heater surfaces with a soft
cloth. For more thorough cleaning, use a cloth that has been moistened with a solution of
mild detergent and water. Dry the heater casing thoroughly with a soft, dry cloth before
operating the unit again. DO NOT immerse heater in water.
TO STORE: When storing heater during the off season, be sure to keep it in a dry area.
Coil the cord around the cord storage at the side of the unit.
IMPORTANT: Close supervision must be maintained at all times when this Heater is used
near children or invalids or pets. Do not touch or attempt to move Heater when it is
plugged in. Always unplug and allow Heater to cool before handling. NEVER pull unit by
the cord. Use the handle provided.
CAUTION:
Be sure that no other appliances are plugged into the same circuit with this Heater.
A circuit overload could occur.
REMEMBER: Portable electric heaters are designed for space heating or as a
supplementary heat source. They are not intended to be a main source of heat.
TO USE
This Heater features two power switches with indicator lights plus a thermostat control.
(See Figure 1.) It offers three heat settings.
1. Select heat setting.
• For LOW heat (600 watts), press the switch on the left (I).
• For MEDIUM heat (900 watts), press the switch on the right (II).
• For HIGH heat (1500 watts), press BOTH switches (I and II).
2. Once you choose the heat setting, turn the selected thermostat control clockwise
as far as it will go. The indicator light on the selected power switch illuminates.
3. Leave the thermostat control at its maximum position until the desired temperature
is reached.
4. Carefully lower the thermostat control until the Heater shuts off. (Indicator light
goes off.)
5. Leave thermostat control at this position. As the Heater automatically cycles on and
off to maintain the chosen room temperature, the indicator light also cycles on and off
to indicate when Heater is operating. As long as the selected power switch is on,
the Heater operates, even if the indicator light is off.
NOTE: OIL IN THE UNIT IS PERMANENTLY SEALED. YOU DO NOT NEED TO REFILL IT.
Radiator Fins
Handle
Thermostat Control
Power Switch
II (Medium)
Power Switch
I (Low)
Vents
Cord Storage
Caster Assemblies (2)
Wheelbase with Casters
FIG. 1
FIG. 2
Connecting
Screw
Wing Nut
Wheelbase
