Optoma HD25-LV User manual

The Optoma HD25-LV delivers outstand-
ing high-denition 1080p video and
graphics with unsurpassed color
accuracy and incredibly sharp detail.
The Optoma HD25-LV will dazzle your
audience with its stunning image clarity.
Its 3000 ANSI lumens and 20,000:1
contrast ratio provide the brightness you
need for your most demanding home
theater installation.
It offers full 3D compatibility for seamless
integration with your favorite Blu-ray 3D
player, Xbox, PS3 and other gaming
consoles.
Designed for maximum performance and
reliability, the Optoma HD25-LV features
industry-leading energy saving features
and whisper quiet operation to help you
create the most magnicent home theater.
DIGITAL
CAMERAS
CAMCORDERS
GAME
CONSOLES
TABLETS
SMART
PHONES
COMPUTERS SET TOP BOXES
3D BLU-RAY/DVD PLAYERS
3D HOME THEATER PROJECTOR
HD25-LV
EXTRAORDINARY IMAGE CLARITY
CONNECTIVITY (May require optional accessories)
Deliver powerful high-resolution home
theater experience
Native 1080p resolution for the sharpest,
most visually stunning image quality
Full 3D compatibility; immerse yourself
in your favorite 3D movie or video game
Comprehensive connectivity to satisfy
your current and future needs
SRS WOW HD™ Surround Sound
technology built-in for rich deep bass
and exceptional sound quality
HD
SRS

3D HOME THEATER PROJECTOR — HD25-LV
OPTICAL/TECHNICAL SPECIFICATIONS
Display Technology Single 0.65ʺ DC3 DMD DLP®Technology by
Texas Instruments™
Native Resolution HD 1920 x 1080
Maximum Resolution WUXGA 1920 x 1200
Brightness 3000 ANSI lumens (Preliminary)
Contrast Ratio 20,000:1 (full on/full off)
Displayable Colors 1.07 Billion
Lamp Life and Type* 6000/5000/3500 Hours (ECO+/ECO/
normal) 240W Philips
Projection Method Front, rear, ceiling mount, table top
Keystone Correction ±20° Vertical
Uniformity >80%
Offset 116%
Aspect Ratio 16:9 Native, 4:3 compatible
Throw Ratio 1.5–1.8 (distance/width)
Projection Distance 3.9ʹ–32.8ʹ (1.5–10 m)
Image Size 37.6ʺ–301.1ʺ (0.7–7.62 m)
Projection Lens F=2.55–2.86, f=22.37–26.73 mm,
1.2x manual zoom and focus
Digital Zoom 1.0 ~ 2.0
Audio 16-Watt stereo speaker system
Noise Level 26dB
Remote Control IR remote control
Operating Temperature 41–113°F (5–45°C), 85% max humidity
Power Supply AC Input 100–240V, 50–60Hz, auto-switching
Power Consumption Max 339W (Normal), Min 241W
(Eco+), <0.5W (standby-ECO)
COMPATIBILITY SPECIFICATIONS
Computer Compatibility WUXGA, UXGA, SXGA+, WXGA+, WXGA,
SXGA, XGA, SVGA, VGA resized, VESA,
PC and Macintosh compatible
Video Compatibility NTSC, PAL, SECAM, SDTV (480i), EDTV
(480p), HDTV (720p, 1080i/p)
3D Compatibility** Supports all HDMI 1.4a mandatory 3D
format, side-by-side format and top and
bottom format
Vertical Scan Rate 24–85Hz, 120Hz
Horizontal Scan Rate 15.375–91.146KHz
User Controls Complete on-screen menu, adjustments
in 28 languages
I/O Connection Ports HDMI v1.4a, two VGA-in, VGA-out, 3D
VESA Port, composite video, two audio-in,
audio-out, RS-232C, USB-B
Loop Through (Audio, VGA) Monitor: D-Sub 15 pin VGA output
(functional in both normal and standby modes)
Audio: VAO audio out, HDMI VAO audio out
supported (VAO in normal mode, xed in
Standby)
PHYSICAL SPECIFICATIONS
Security Kensington® lock, security bar and
keypad lock
Weight 6.4 lb (3.1 kg)
Dimensions 12.7ʺ x 3.8ʺ x 9.2ʺ
**3D content can be viewed with active LCD shutter glasses or RF glasses when
projector is used with compatible 3D player. Please visit www.optoma.com for
more information.
*Lamp life is dependent on many factors, including lamp mode, display mode,
usage, environmental conditions and more. Lamp brightness can decrease over time.
Warranty
1-Year Limited Parts and Labor, 90-Days on Lamp
In the Box (Standard Accessories)
AC power cord, remote control, batteries for remote, lens cap, multilingual
CD-ROM user’s manual, quick start card, and warranty card
Optional Accessories
HDMI cable, ceiling mount, component to VGA cable, composite video cable,
RS-232 cable, Optoma screen, DLP Link 3D glasses
Accessory Part Numbers
Lamp: BL-FU240A Remote: BR-3067B
RF Emitter: BG-BC100B RF Glasses: BG-ZF2100GLS
Power Cord (11M): BC-PUPIXY11 DLPLink Glasses: BG-ZD301
VGA to component adaptor: BC-VGCRXY00 Mount: BM-5001U
UPC: 796435 81 202 7
www.OptomaUSA.com
Copyright © 2013 Optoma Technology, Inc. DLP® and the DLP logo are registered trademarks
of Texas Instruments™. All other trademarks are the property of their respective owners.
All specications subject to change at any time.
Power/Standby Off
