Optoma Pico PK320 User manual

FOCUS
Pico Pocket Projector
User ManUal

2
1. Do not block any ventilation openings.
To ensure reliable operation of the
projector and to protect from over
heating, it is recommended to install
the projector in a location that does not
block ventilation. As an example, do not
place the projector on a crowded coffee
table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book
case or a cabinet that restricts air ow.
2. Do not use the projector near water or
moisture. To reduce the risk of re and/
or electric shock, do not expose the
projector to rain or moisture.
3. Do not install near heat sources such as
radiators, heaters, stoves or any other
apparatus such as ampliers that emits
heat.
4. Do not use the projector in direct
sunlight.
5. Do not use near any appliance
generating a strong magnetic eld.
6. Do not use the projector in areas
susceptible to excessive dust and dirt.
7. Turn off the product before cleaning.
8. Turn off the product before removing
the battery.
9. Disconnect the battery if the product is
not being used for a long period of time.
10. Ensure that the ambient room
temperature is within 5- 35°C.
11. Relative Humidity is 5 - 35°C, 80%
(Max.), non-condensing.
12. Do not expose the battery to
temperatures above +60°C (+140°F)
13. New or idle batteries can have short-
term reduced capacity. Fully charge the
battery before initial use.
14. Do not put the battery into your mouth.
15. Do not let the battery contacts touch
another metal object.
16. Do not drop, throw or try to bend your
product.
17. May explode if disposed of in re.
18. Clean only with dry cloth.
19. Only use attachments/accessories
specied by the manufacturer.
20. Do not use the unit if it has been
physically damaged or abused. Physical
damage/abuse would be (but not
limited to):
▀■ Unit has been dropped.
▀■ Charger or plug has been damaged.
▀■ Liquid has been spilled on to the
projector.
▀■ Projector has been exposed to rain or
moisture.
▀■ Something has fallen in the projector
or something is loose inside.
Do not attempt to service the unit
yourself. Opening or removing covers
may expose you to dangerous voltages
or other hazards. Please contact your
local reseller or service center before you
send the unit for repair.
21. Do not let objects or liquids enter the
projector. They may touch dangerous
voltage points and short out parts that
could result in re or electric shock.
22. See projector enclosure for safety related
markings.
23. The unit should only be repaired by
appropriate service personnel.
24. Do not touch the projector for a long
time while the projector is used.
25. CAUTION: Risk of Explosion if Battery
is replaced by an Incorrect Type.
26. Dispose of Used Batteries According to
the Instructions.
Important Safety InStructIon
eye Safety WarnIngS
Avoid staring/facing directly into the projector beam at all times. Keep your back
to the beam as much as possible.
A stick or laser pointer is recommended to avoid the need for the user to enter
the beam.
When projector is used in a classroom, adequately supervise students when they
are asked to point out something on the screen.
In order to minimize power, use room blinds to reduce ambient light levels.
CLASS 1 LED PRODUCT
This appendix lists the general notices of
your Projector.
FCC notice
This device has been tested and found to
comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This device generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruc-
tions, may cause harmful interference to
radio communications.
However, there is no guarantee that inter-
ference will not occur in a particular instal-
lation. If this device does cause harmful
interference to radio or television reception,
which can be determined by turning the
device off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
device and receiver.
• Connect the device into an outlet on
a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/television technician for help.
Notice: Shielded cables
All connections to other computing
devices must be made using shielded
cables to maintain compliance with
FCC regulations.
Caution
Changes or modications not
expressly approved by the manufac-
turer could void the user’s authority,
which is granted by the Federal
Communications Commission, to
operate this device.
Operation conditions
This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions:
1. this device may not cause harmful
interference, and
2. this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian
ICES-003.
Remarque à l’intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la
norme NMB-003 du Canada.
Declaration of Conformity for EU countries
• EMC Directive 2004/108/EC (including
amendments)
• Low Voltage Directive 2006/95/EC
• R & TTE Directive 1999/5/EC (if product has
RF function)
regulatIon & Safety notIceS DISpoSal of olD electrIcal & electronIc
equIpment
(Applicable throughout the European Union and other European countries with
separate collection programs)
This symbol found on your product or on its packaging, indicates that this product should
not be treated as household waste when you wish to dispose of it. Instead, it should be
handed over to an applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences to the environment and human health, which could
otherwise be caused by inappropriate disposal of this product. The recycling of materials
will help to conserve natural resources.
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or
dealer and ask for the correct method of disposal.
The requirements for the gloss of housing apply to peripheral devices used
at the visual display workplace according to BildscharbV. Peripheral devices
intended for use outside the visual display workplace can receive a GS-Mark
if the scope is indicated in the User’s Manual as well as the certicate.
That means the following wording is possible in situations where the use
within the eld of view is not intended and where sufcient hints are given
in the User’s Manual for the avoidance of such situations to ensure that
display work is not affected.
Wording in the certicate: “This device is not intended for use in the direct
eld of view at visual display workplaces. To avoid incommoding reexions
at visual display workplaces this device must not be placed in the direct
eld of view.”
a.2.9.31
gloSS of houSIng of perIpheral
DevIceS (15th / 22 meetIng ag1 eK1):
2

proDuct overvIeW
pacKage overvIeW
1
2
3
InStall the Battery
StandardAccessory
1. Power adaptor withAC plug
2. VGAcable
3. USB to micro USB cable
4. Battery
5. AV cable
6. Remote control
OptionalAccessory
7. Mini HDMI cable
8. iPod connection kit
a. USB cable for iPod connector
b. iPod cable
c. iPod connector
9. Component cable
10.USBcable(forashdrive)
4
5
6
33
FOCUS
Universal
I/O
mini
HDMI AV IN
DC IN Audio out
Micro
USB
micro SD
7
1
21
15
23
22
10
16
17
18
19
20
9
812
13
14
11
3
2
6
4
5
1. Lens
2. Right Button ( )
3. Cancel / ESC Button ( )
4. Up Button ( )
5. OK Button ( )
6. Left Button ( )
7. Focus Dial
8. Down Button ( )
9. Home Button ( )
10.LED Indicator
11.Lanyard
12.Speaker
13.DC Input
14.Audio Out Connector
15.MicroSD Card Slot
16.IRReceiver
17.UniversalI/OConnectort
18.Mini HDMI Connector
19.AV Input Connector
20. Micro USB Port
21.Power Button
22.BatteryCover
23 ScrewHoleforTripodConverter
proDuct overvIeW
pacKage overvIeW
1.Removethebatterycover.(~)
2.Align the battery contacts with
the contacts in the battery
compartment. ()
3. Push the battery to secure it in
place. ()
4.Slidethebatterycoverbackinto
place. ()
1
5
8b
<Note>
Thestandardaccessoriesmayvaryineach
region due to different applications.
6
8c
2
7
3
8a
9
4
<Note>
Theinclusivepowerplugheadvariesper
region.
<Note>
Items 2~6 and 8 are also function buttons.
Functionsvarydependingonthecurrent
mode.
10
Bright
OFF
VideoVGA HDMI

4
C
harge the Battery poWer on/ off
4
PUSH
1
1. Make sure the projector is turned
off.
2. Insert the plug. ()
3. Connect the charger. (~)
4. During charging, the LED indicator
lights red. ()
5. The LED indicator turns green
when the battery is fully charged.
This process may take up to 2.5
hours.
3
2
Press the Power button to turn the
projector on or off.
Forrsttimeuse,theLanguage
screen appears.
1. Highlight the desired language.
()
2. Select the item. ( )
<Note>
1. The battery will not charge while the
projector is operating.
2. For LED indicator information, see page
23.
3. After the projector is turned off, the battery
may not start charging right away due to
overtemperatureprotection.Theprojector
will automatically start charging once it
cools off.
4.Thebatteryhasalifespanandagesevery
time it is charged and discharged. It will
gradually loose its charging capability as it
ages. Replace the battery at the end of its
lifespan.
When the LED indicator lights red,
the battery is low. Replace the battery
immediately or connect the power
adapter to charge the battery.
4
connect
I
nput
S
ource - vga / compoSIte / hDmI
1
2
Connect the VGA/ Component /
HDMIdeviceusinganappropriate
cable. (~)
Inserttheuniversalconnector
with the arrow mark facing down.
1
2
1
2
or
or
connect
I
nput
S
ource - vIDeo In / auDIo In
1. Connect theAV input source.
(~)
2. Connect external speakers to the
audio out connector of the projector.
()
<Note>
1.All other brand and product names are
trademarks or registered trademarks of
theirrespectivecompanies.
2.Thecablesconnectingthevideooutput
devicesarenotsupplied,pleasecontact
thedevicevendor.
3. iPod nano/iPod touch/iPhone/iPod classic
(version5andabove)
4. Designed for iPod/iPhone/Mobile phone/
PMP with TV out functions. Using with
deviceswithaudiosignalvoltage>0.3Vrms
is not recommended.
5. The optional USB cable for iPod Connector
isusedtochargetheiPoddeviceusinga
computer.
3
1
2
1
2
1
2
or
or
Audio input
only
Forvideoand
audio input
<Note>
Component and HDMI cables are not
included in the package.

55
FOCUS
Screw a standard tripod into the screw
hole on the projector.
B
Projection Distance (A) Screen Size - Width (B) Screen Size - Height (C) Screen Diagonal (D)
Meter inch (mm) (inch) (mm) (inch) (mm) (inch)
0.2 0.66 110 4.3 62.7 2.5 127 5
0.4 1.31 221 8.7 125.4 4.9 254 10
0.6 1.97 331 13.0 188.1 7.4 381 15
0.8 2.62 448 17.4 250.8 9.9 508 20
2.4 7.87 1325 52.2 752.3 29.6 1524 60
4.8 15.75 2651 104.4 1504.5 59.2 3048 120
FOCUS
1
Adjust the focus ()untiltheimageis
clear.
<Note>
The tripod is an optional accessory.
uSe atrIpoD StanD aDjuSt the projecteD Image
By default, the projector displays from
theinternalmemory.Howeverifa
microSD card is inserted, the projector
readsfromthemicroSDcardrst.
Insert a microSD card into the slot with
the gold contacts facing down.
<Note>
• ToremovethemicroSDcard,pushthe
card to eject it from the slot.
• DonotremovethemicroSDcardwhile
the projector is projecting image from
the card. This can cause data loss or
damage the card.
• Supports microSD card size up to 32GB.
• The microSD card is not included in the
package.
InSert Data Source - mIcroSD carD connect computer for Data tranSfer
1
2
MOLEX
You can transfer data to the projector
internal memory or the microSD
card.
1. If turned on, turn off the projector.
2. Connect a laptop or PC using the
supplied USB to micro USB cable.
3. Turn on the projector.
See"HowtoTransferDatavia
USB" on page 23.
<Note>
The laptop/PC can only detect the input
source when the projector is switched on.
The projection will stop when this connection
is made.
The projector reads data from the
USBashdriverstifoneisinserted.
ConnecttheUSBashdrivetothe
projectorusingaUSBcable(forash
drive).(~)
InSert Data Source - uSB (external Source)
<Note>
1.USBcable(forashdrive)isnotincluded
in the package.
2.TheprojectoronlysupportsUSBash
drive(upto5V/150mA)withFAT32format.
3.USBharddiskdriveisnotsupported.
2
1
Theprojectorprojectsmediales
directly from data sources: internal
memory, microSD card, or external
source(USB).

66
Home menu
Submenu Items
Video menu
hoW to uSe the menu
<Note>
Abuttonguideappearsonthelowerleftcornerofmostscreens(seebelow).Theguide
variesdependingonthecurrentmode.Pressthecorrespondingbuttontoselecttheoptionor
operation.
• Press the corresponding button of the desired option.
• Press togobackapreviousscreen.
Enter Video menu
Select input
source signal
Enter Photo menu
Enter Setup menu
Enter Music menu EnterOfceViewermenu
Return to the Home
menu
Press the corresponding button of the menu item that you want to access.
For example, to access Video, press .
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Music menu
Video
Internal
Memory
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
Music
Internal
Memory
1/1
Summer.mp3 03:31
Rainbow.mp3 04:28
Blue.mp3 03:20
Cat.mp3 03:45
Black Sheep.mp3 03:02
Video menu
Internal
Memory
1/2
Photo menu
Input menu
Office Viewer
Internal
Memory
1/1
Summer.doc 128 KB
Rainbow.ptt 1,211 KB
Blue.xls 143 KB
Cat.doc 165 KB
Black Sheep.doc 256 KB
Video VGA Back
HDMI
Input
OfceViewermenu
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
Setup menu
Video
Internal
Memory
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
Submenu
Data source icon
The projector reads from memory sources in the following order:
Externalsource(USB)»microSDcard»internalmemory.
External source Internal memory
MicroSD card
Button guide
Press the corresponding button to
select the option or operation.

77
Playing Videos from the Internal Memory, MicroSD Card, or External Source
hoW to play vIDeoS - Source: Internal memory / mIcroSD carD / external Source
Ifanexternalsource(USB)isinserted,the
external memory is read first. If you want to read
data from the microSD card or internal memory,
press in the appropriate screen to change the
data source. See steps below.
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Play from start?
Iftheselectedvideo
leisunnishedfrom
apreviousplayback.
Playback
from start
No
Playback
from start
Playback from
last point
Video Playback mode (seepage8)
Yes
No
Yes
Video
External
Memory
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
Video
MicroSD
Card
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
Video
Internal
Memory
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
Change data
source
Change data
source
Change data
source
<Note>
Thedisplayedscreenmayvarydependingonthe
selecteddatasourceonthepreviousstep.
Video
Internal
Memory
Travel
Travel Day1.mkv
Travel Day2.mkv
Travel Day3.mkv
1. Select "Video"
2. Select Data Source
3. Select Video File
4. Playback File
or
The screen, the source icon on the button guide,
andthesequenceinwhichscreensappearvary
dependingontheavailabledatasource.Ifthe
external source or microSD card is not inserted,
its screen is skipped when is pressed and the
source icon on the button guide is not shown.

88
Repeat all
Repeatcurrentvideo
Repeat off
Repeat Icons
<Note>
To change repeat settings, see Video
Settings below.
<Note>
Video format does not support content with
B-Frame function.
File Format Video
Decoder Audio or Speech Decoder
.3gp H.263
H.264
MJPEG
HE-AAC
AMR-NB
AMR-WB
.avi
H.263
H.264
MJPEG
MPEG4
MP3
HE-AAC
PCM/G.711
compatIBIlIty: vIDeoS
File Format Video
Decoder Audio or Speech Decoder
.cmb H.264 HE-AAC
.v Soreson
Spark MP3
.mp4
H.263
H.264
MPEG4
MP3
HE-AAC
AMR-NB
AMR-WB
File Format Video
Decoder Audio or Speech Decoder
.mov
H.263
H.264
MJPEG
MPEG4
MP3
HE-AAC
PCM/G.711
AMR-NB
AMR-WB
.wmv
.asf
MPEG4 SP
VC-1
(WMV9)
WMA
Compatible Video Format
hoW to play vIDeoS - vIDeo playBacK moDe
vIDeo SettIngS
Repeat all
Repeat one
Repeat disabled
Browser display
small icon
Browser display
large icon
Repeat Browser Display Back
Video Setting
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
<Note>
The button guide disappears when the
keypad is not used for 3 seconds.
To display the button guide, press any key
except or .
 Adjustvolume
Pause/Play
Fast forward
Rewind
Return to Home menu
Backtoprevious
screen
1. Select "Setup" 2.
Select "Video Setting"
3. Adjust Settings

99
Playing Music from the Internal Memory, MicroSD Card, or External Source
hoW to play muSIc - Source: Internal memory / mIcroSD carD / external Source
Ifanexternalsource(USB)isinserted,the
external memory is read first. If you want to read
data from the microSD card or internal memory,
press in the appropriate screen to change the
data source. See steps below.
Music
External
Memory
1/1
Summer.mp3 03:31
Rainbow.mp3 04:28
Blue.mp3 03:20
Cat.mp3 03:45
Black Sheep.mp3 03:02
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Music
MicroSD
Card
1/1
Summer.mp3 03:31
Rainbow.mp3 04:28
Blue.mp3 03:20
Cat.mp3 03:45
Black Sheep.mp3 03:02
Music
Internal
Memory
1/1
Summer.mp3 03:31
Rainbow.mp3 04:28
Blue.mp3 03:20
Cat.mp3 03:45
Black Sheep.mp3 03:02
Next Song: Rainbow.mp3
Summer
Unknow
Unknow
Music Playback mode (seepage10)
Change data
source
Change data
source
Change data
source
<Note>
Thedisplayedscreenmayvarydependingonthe
selecteddatasourceonthepreviousstep.
Music
Internal
Memory
1/1
Summer.mp3 03:31
Rainbow.mp3 04:28
Blue.mp3 03:20
Cat.mp3 03:45
Black Sheep.mp3 03:02
1. Select "Music"
2. Select Data Source
3. Select Music File
4. Playback File
or
The screen, the source icon on the button guide,
andthesequenceinwhichscreensappearvary
dependingontheavailabledatasource.Ifthe
external source or microSD card is not inserted,
its screen is skipped when is pressed and the
source icon on the button guide is not shown.

10
Next Song: Rainbow.mp3
Summer
Unknow
Unknow
10
compatIBIlIty: muSIc
hoW to play muSIc - playBacK moDe
muSIc SettIngS
Repeat Shuffle Back
Music Setting
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
Repeat/ShufeIcons
Repeat all
Repeat current music
Repeat off
Shufeon
Shufeoff
<Note>
Tochangerepeatorshufesettings,see
Music Settings below.
CompatibleAudio Format
File Format Audio Decoder
.aac HE-AAC
.adif HE-AAC
.adts HE-AAC
.amr AMR-NB
.ape APE
.ape G.726
.asf WMA9
.awb AMR-WB
Repeat all
Repeat one
Repeat disabled
Shufeon
Shufeoff
File Format Audio Decoder
.ac FLAC
.m4a HE-AAC
.mp3 MP3
.ogg Vorbis
<Note>
The button guide disappears when the
keypad is not used for 3 seconds.
To display the button guide, press any key
except or .
 Adjustvolume
Pause/Play
Next track
Previoustrack
Return to Home menu
Backtoprevious
screen
Fastforward(pressandhold)
Rewind(pressandhold)
1. Select "Setup" 2.
Select "Music Setting"
3.
Adjust Settings

1111
Viewing Photos from the Internal Memory, MicroSD Card, or External Source
hoW to vIeW photoS - Source: Internal memory / mIcroSD carD / external Source
Ifanexternalsource(USB)isinserted,the
external memory is read first. If you want to read
data from the microSD card or internal memory,
press in the appropriate screen to change the
data source. See steps below.
Full Screen mode (seepage12)
External
Memory
1/2
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
MicroSD
Card
1/2
Internal
Memory
1/2
Change data
source
Change data
source
Change data
source
Internal
Memory
2/2
Page indicator
Internal
Memory
1/2
<Note>
Thedisplayedscreenmayvarydependingonthe
selecteddatasourceonthepreviousstep.
1. Select "Photo"
2. Select Data Source
3. Select Page
4.
Enter Current Page
or
5. Browse Thumbnails
6. Preview File
The screen, the source icon on the button guide,
andthesequenceinwhichscreensappearvary
dependingontheavailabledatasource.Ifthe
external source or microSD card is not inserted,
its screen is skipped when is pressed and the
source icon on the button guide is not shown.

1212
hoW to vIeW photoS - full Screen moDe
In Slideshow mode, photos are played
continuouslyataspeciedinterval
time while playing music stored in the
internal memory as background.
<Note>
• Make sure that background music setting is
"On" to enable this feature.
• Savethemusicles(*.mp3format)under
the "Slideshow Music" folder in the internal
memory.
• Onlymusiclesstoredintheinternal
memory "Slideshow Music" folder can be
played as background music.
<Note>
Tochangeslideshowintervalsettingsand
enable/disable background music, see
Slideshow Settings below.
Play slideshow
Next photo
Previousphoto Return to Home menu
Rotate 90°
counter-clockwise
Rotate 90° clockwise
Full screen mode Slideshow mode
Internal
Memory
1/2
Exit slideshow
<Note>
The button guide disappears when the keypad is not used for 3 seconds.
To display the button guide, press any key except or .
Pause/Play slideshow
Next photo
Previousphoto Return to Home menu
Volume down
Volume up
Exit slideshow
hoW to vIeW photoS - SlIDeShoW moDe
1. Enter Slideshow Mode 2. View Slideshow 3. Exit Slideshow Mode

13
Timer Background Music Back
Slide Show
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Timer: 2-second
interval
Timer: 5-second
interval
Timer: 10-second
interval
Background music on
Background music off
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
13
SlIDeShoW SettIngS
1. Select "Setup" 2. Select "Slideshow" 3. Adjust Settings
compatIBIlIty: photo
Compatible Photo Format
File Format File Extension
BMP
JPG
JPEG
*.bmp,
<Note>
The projector supports the following photo
resolution:
• Bitmapleupto2M(megapixels)each
• Jpegleupto10M(megapixels)each
Ifaphotoresolutionisovertheselimitations,
thelewillnotbeshownintheledirectory
screen.
<Note>
For optimum display performance of
static photos or slide show playback, it is
recommendedtousesmallerlesizeand
lower resolution photos.

1414
Viewing Documents from the Internal Memory, MicroSD Card, or External Source
hoW to vIeW DocumentS - Source: Internal memory / mIcroSD carD / external Source
compatIBIlIty: Document
The projector uses Picsel File Viewer
toopenandviewMicrosoft®Wordles
andAdobe®PDFles.
Supported Versions
Version
Microsoft
®
Word 95
Microsoft
®
Word 97
Microsoft
®
Word 2000
Microsoft
®
Word 2003
Microsoft
®
Word 2007
Adobe
®
PDF 1.0 ~ 1.4
<Note>
• OfceViewersupportsembedded
fonts inAdobe®PDF documents but not
in Microsoft®Word documents.
• Embedded fonts are used in priority
overtheprojectorsystemfonts.
Compatible Document Format
File Format File Extension
Microsoft
®
OfceApplication
(Word,Excel,PowerPoint)
HTML
Adobe
®
PDF
.doc
.docx
.ppt
.pptx
.xls
.xlsx
.htm
.html
.pdf
Font / Language Support
The projector has limited font
support. When a document with
unsupportedfontisopened,Ofce
Viewer automatically substitutes the
unsupported font with default system
fonts. This may cause the document
layout to look different.
Font / Language
Dutch
English
French
German
Italian
Japanese
Korean
Polish
Portuguese
Spanish
Swedish
Traditional Chinese
SimpliedChinese
Russia
Greek
The projector supports one default
font for each language.
Ifanexternalsource(USB)isinserted,the
external memory is read first. If you want to read
data from the microSD card or internal memory,
press in the appropriate screen to change the
data source. See steps below.
Office Viewer
External
Memory
1/1
Summer.doc 128 KB
Rainbow.ptt 1,211 KB
Blue.xls 143 KB
Cat.doc 165 KB
Black Sheep.doc 256 KB
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Office Viewer
MicroSD
Card
1/1
Summer.doc 128 KB
Rainbow.ptt 1,211 KB
Blue.xls 143 KB
Cat.doc 165 KB
Black Sheep.doc 256 KB
Office Viewer
Internal
Memory
1/1
Summer.doc 128 KB
Rainbow.ptt 1,211 KB
Blue.xls 143 KB
Cat.doc 165 KB
Black Sheep.doc 256 KB
Change data
source
Change data
source
Change data
source
FOCUS
View mode (seepage14)
<Note>
Thedisplayedscreenmayvarydependingonthe
selecteddatasourceonthepreviousstep.
Office Viewer
Internal
Memory
1/1
Summer.doc 128 KB
Rainbow.ptt 1,211 KB
Blue.xls 143 KB
Cat.doc 165 KB
Black Sheep.doc 256 KB
1.
Select "Office Viewer"
2. Select Data Source
3. Select File
4. View File
or
The screen, the source icon on the button guide,
andthesequenceinwhichscreensappearvary
dependingontheavailabledatasource.Ifthe
external source or microSD card is not inserted,
its screen is skipped when is pressed and the
source icon on the button guide is not shown.

1515
hoW to vIeW DocumentS - vIeW moDe
LED Mode Color Mode Back
Aspect Ratio Gamma Projection
Display Setting
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
DISplay SettIngS
<Note>
The button guide disappears when the
keypad is not used for 3 seconds.
To display the button guide, press any key
except or .
FOCUS
Zoom in 1x ~ 4x
Pan up, down,
left, right
(inzoommode)
Page up Moveright 
Moveleft 
Page down Exit View mode
Return to Home menu
LEDMode:Movie
(availableonlywhenthe
poweradapterisplugged)
LED Mode: Bright
(availableonlywhenthe
poweradapterisplugged)
LED Mode: Standard
LED Mode: Economic
Color Mode: Extended
Color Mode: Standard
Gamma: Standard
Gamma: Presentation
Gamma: Bright
Gamma:Movie
Aspect Ratio:Auto
Aspect Ratio: 4:3
Aspect Ratio: 16:9
Projection: Front Desktop
Projection:FrontInverted
Projection: Rear Desktop
Projection:RearInverted
1. Select "Setup" 2. Select "Display Setting" 3. Adjust Settings

1616
Select menu language
Language Information Back
Firmware Update Reset
System
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
Select your preferred menu language.
Options are: English, French, Spanish, Portuguese
(Brazilian),German,Italian,Russian,Polish,Dutch,
Swedish,Greek,TraditionalChinese,Simplied
Chinese, Korean, Japanese
vIeW projector InformatIon
Language Information Back
Firmware Update Reset
System
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly MicroSD card
capacity
Internal memory
capacity
External memory
(USB)capacity
Battery charging
Power adapter
connected
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
1. Select "Setup" 2. Select "System" 3. Select "Language"
4. Select Language
1. Select "Setup" 2. Select "System" 3.
Select "Information"
4. View Information 5.
Return to Home Menu
5. Confirm language /
Return to Home menu

1717
upgraDe fIrmWare
Language Information Back
Firmware Update Reset
System
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
New firmware 1.2 found.
Upgrade the firmware?
Software updates can be obtained from the OPTOMAwebsite
( www.optoma.com / www.optoma.eu / www.optoma.com.tw ).
1. On your computer, create a folder named "upgrade".
2. Downloadthelatestrmwarefromwww.optoma.comandsaveitinthe"upgrade"
folder.
3. Copy the "upgrade" folder to the root folder of the microSD card.
4. Insert the microSD card into the microSD card slot of the projector.
5. Follow the steps below.
Yes
No
<Note>
• Do not touch any buttons or turn off the
projector while upgrading is in progress.
Otherwise, this may damage the projector.
• DonotremovethemicroSDcarduntilthe
upgrade is complete.
<Note>
A"Nonewrmwareisfound"message
appearsifthereisnoupdateleinthe
microSD card.
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Upgrade may take a while
to complete, do not touch any keys
1. Select "Setup" 2. Select "System"
4. Confirm Upgrade 3. Select "Firmware Update"
6. Turn Off the Projector
5. Wait to Complete
When the screen below appears, update is
complete. Press and hold the Power button for
6 seconds to turn off the projector
7.
Turn On the Projector

1818
reSet the SyStem
<Note>
Whenthesystemisreset,alllesstoredin
the internal memory will be deleted. Ensure
alllesarebackedupbeforeresetting.
Resetting the System by Reset Menu
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Language Information Back
Firmware Update Reset
System
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
Video Setting Music Setting Back
Display Setting Slideshow System
Setup
Yes
No
Reboot the projector
1. Select "Setup" 2. Select "System"
4. Confirm Reset 3. Select "Reset"

1919
hoW to uSe external Input Source: vga / compoSIte av / hDmI
Select Input Source
Video Music Photo
Input Office Viewer Setup
Press matched symbol to enter specific function directly
VGA
800 x 600
or
Video VGA Back
HDMI
Input
Video
VGA
HDMI
Return to Home menu
<Note>
Thesignalmessageboxbrieyappearson
screen;itslabelvariesdependingonthe
selected input signal.
Display
button guide
Settings
Volume up
Hide button guide
Aspect ratio
Volume down
Return to Home menu
Display mode
To exit
display mode
Yes No
Ifmorethanoneexternaldevicesareconnectedtotheprojectororthe
projectorcannotautomaticallydetecttheexternaldevice.Youhavetomanually
select the input source. To do this, perform the following steps below.
Selecting Input Source Manually
1. Select "Input" 2. Select Input Source
3. Enter Display Mode
4. Adjust Volume / Settings
View Source Content
5. Exit Display Mode

2020
Adjusting Contrast Settings
Input Source SettIngS
Display mode
Display
button guide
16:9
AUTO
Scroll option
Scroll option
Scroll option
<Note>
When no key is pressed within 10 seconds, the
aspect ratio icon automatically disappears and its
setting is applied.
ChangingAspect Ratio Settings
Display mode
Display
button guide
<Note>
When no key is pressed within 10 seconds, the
contrast icon automatically disappears and its
setting is applied.
Exit contrast settings
Scroll other settings: Sharpness,
Color, LED, Brightness
Return to Home menu
4:3
2. Select "Aspect Ratio"
1. View Source Content
-
3. Scroll Aspect Ratio Setting
16:9
4:3
AUTO
4. Confirm Setting
1. View Source Content 2. Select "Settings" 3. Select "Contrast"
4. Adjust Setting
