optris S20 User manual

OptrisS20
Infrared Sensor
Operator manual

Introduction
Thank you for choosing the optris® S20 infrared sensor.
Infrared thermometers measure the object surface temperature without touching it.
They calculate the surface temperature on the basis of the emitted infrared radiation
from an object. The most important feature of infrared thermometers is that they
enable the user to measure objects contactless. Consequently, these products help
to measure the temperature of inaccessible or moving objects without difficulties.
Temperature Range：0°~ 500°C 
Optical Resolution D：S ＝ 15：1
Accuracy：+/- 1% or +/- 1.5°C
Response Time：300ms
Signal Output：4 ~ 20mA (2-wires)
Power Supply：24VDC


Optical Charts
The following optical charts show the diameter of the measuring spot in dependence
on the distance between measuring object and sensing head. The spot size refers to
90 % of the radiation energy.

Connection Diagrams
It connecting the 4 to 20 mA current loop.
4-20mA
Current loop (+) Red
Current loop (-) Black
Ground ( ) Bare
Measurement Specifications

Temperature Range 0 ~ 500°C
Optical Resolution D：S ＝15：1
Signal Output 4~ 20 mA
Accuracy +/- 1% or +/- 1.5°C
Repeatability +/- 0.5% or +/- 1°C
Spectral Range 8 ~ 14 um
Temperature Resolution 0.1°C
Response Time 500 ms (95%)
Emissivity Fixed at 0.95
Power Supply 24 VDC @ 20mA
Environmental Rating IP65 (NEMA - 4)
Ambient Temperature 0 ~ 60°C
Relative Humidity 10 ~ 95%
Cable Length 1.8m (standard)
Dimensions Φ38.5mm X 35mm
Weight 200g
