Oriental motor LIMO EZS Series User manual

HL-0121-4
EZS/EZC Series Controller
EZMC36A /EZMC36I
ORIENTAL MOTOR CO., LTD.
USER MANUAL

4
● This product must be handled by qualified personnel with expert knowledge of elec-
trical and mechanical engineering. Before using the product, please read Chapter
1, “Safety”, carefully to ensure correct use.
● This product is designed and manufactured for use as an internal component for
general industrial equipment. Do not use the product for any other purpose. Oriental
Motor shall not be liable whatsoever for any damage arising from a failure to ob-
serve this warning.
● Should you require the inspection or repair of internal parts, please contact the
Oriental Motor branch or sales office from which you purchased the product.
● The figures and tables provided in this document are intended to help you under-
stand the content of the text. They should not be construed in any way as guar-
anteeing the resultant operation.
● Oriental Motor shall not be liable whatsoever for any patent-related problem aris-
ing in connection with the use of any information, circuit, equipment or device de-
scribed in this document.
● The technical specifications are subject to change without prior notice for the pur-
pose of improvement in product performance.
● This document is protected under the applicable copyright laws. No part of this
document may be reproduced, stored, changed, duplicated or transmitted digitally
(via printing, copying, microfilming or any other manner) without prior written con-
sent from Oriental Motor.
● and are trademarks of Oriental Motor Co., Ltd.
● Other product names and company names are the trademarks or registered trade-
marks of their respective companies. The products by other manufacturers referred
to in this installation manual are mentioned for reference purposes only; their use
is not enforced in any way. Oriental Motor shall not be liable whatsoever for the
performance of another manufacturer’s product or any problem arising from the use
thereof.
© Copyright ORIENTAL MOTOR CO., LTD. 2003
Notes to the User

EZS/ EZC Series Controller EZMC36 USER MANUAL
i
Table of Contents
Introduction ………………………………………………………… vi
Intended Reader of the Manual …………………………… vi
Purpose of the Manual …………………………………… vi
Receipt, Storage and Disposal of the Product …………… vi
Product Support …………………………………………… vi
Technical Assistance Regarding the Product …………… vi
Structure and Contents of the Manual …………………… vii
Contents of the Manual …………………………………… vii
Rules of Notation …………………………………………… viii
Chapter Safety ………………………………………………… 1-1
1.1 Safety Precautions …………………………………… 1-1
1.2 Potential Dangers ……………………………………… 1-1
1.2.1 Electric Shock ………………………………… 1-1
1.2.2 Electrical Fire …………………………………… 1- 1
1.2.3 Danger Posed by the Machine ……………… 1- 2
1.2.4 Electromagnetic Disturbance ………………… 1-2
1.3 General Safety Guidelines …………………………… 1- 3
1
Chapter Unpacking, Inspection
and Storage …………………………………… 2-1
2.1 Unpacking the Controller……………………………… 2-1
2.2 Explanation of Unit Model …………………………… 2-2
2.2.1 Slider …………………………………………… 2-2
2.2.2 Cylinder ………………………………………… 2-2
2.3 Inspection Procedure ………………………………… 2-3
2.4 Storing the Controller ………………………………… 2-3
2
Chapter
Controller Overview ………………… 3-1
3.1 Overview………………………………………………… 3-1
3.2 Functions ……………………………………………… 3-3
3.2.1 Operation ……………………………………… 3-3
3.2.2 Electromagnetic Brake………………………… 3-3
3.2.3 Position Holding (absolute type) …………… 3-3
3.2.4 Setting …………………………………………… 3-4
3.3 Operating Requirements ……………………………… 3-6
3.3.1 Axis Number (ID) ……………………………… 3-6
3.3.2 Pendant Switch ………………………………… 3-6
3.3.3 Power Cutoff During Controller
Communication ………………………………… 3-7
3.3.4 Battery Backup (absolute type) ……………… 3-8
3

ii
Chapter
Installation and Wiring …………… 4-1
4.1 Installing the Controller ……………………………… 4-1
4.1.1 Required Installation Conditions …………… 4-1
4.1.2 Mounting on a Wall …………………………… 4-2
4.1.3 Mounting to a DIN Rail………………………… 4-3
4.1.4 Installing the Battery…………………………… 4-5
4.2 Front Panel……………………………………………… 4-7
4.2.1 Connectors ……………………………………… 4-7
4.2.2 Controller Panel Layout ……………………… 4-8
4.3 User I/O Specification ………………………………… 4-11
4.3.1 COM Input ……………………………………… 4-11
4.3.2
+
COM/
-
COM Inputs ………………………… 4-11
4.3.3 START Input …………………………………… 4-12
4.3.4 M0 to M5 Input ………………………………… 4-12
4.3.5 HOME Input …………………………………… 4-13
4.3.6 STOP Input……………………………………… 4-14
4.3.7 PAUSE Input …………………………………… 4-15
4.3.8 ACL Input ……………………………………… 4-16
4.3.9 CW/CCW (PLS / DIR) Inputs ………………… 4-17
4.3.10 C.OFF Input ………………………………… 4-19
4.3.11 RUN0 to RUN2 Input………………………… 4-19
4.3.12 STOP0 to STOP2 Input …………………… 4-20
4.3.13 READY Output ……………………………… 4-21
4.3.14 END Output…………………………………… 4-21
4.3.15 MOVE Output ………………………………… 4-21
4.3.16 AREA Output ………………………………… 4-21
4.3.17 T-UP Output ………………………………… 4-23
4.3.18 ALM Output …………………………………… 4-24
4.3.19 ALM0 to ALM4 Output ……………………… 4-24
4.3.20 TIM Output …………………………………… 4-25
4.4 Sensor I/O Specification ……………………………… 4-26
4.4.1
+
LS Input ……………………………………… 4-26
4.4.2
-
LS Input ……………………………………… 4-26
4.4.3 HOMELS Input ………………………………… 4-26
4.4.4
+
24 V/GND Outputs ………………………… 4-26
4.4.5 Return-to-Home Operation Sequence ……… 4-27
4.5 Emergency Stop Specification ……………………… 4-28
4.6 Wiring the Power Cable ……………………………… 4-30
4.6.1 Supplied Power ………………………………… 4-30
4.6.2 Power-Supply Protection ……………………… 4-30
4.6.3 Insulation Resistance
Measurement /Dielectric Strength Test……… 4-30
4.6.4 Grounding Work ……………………………… 4-30
4.7 Wiring the Emergency Stop Cable ………………… 4-31
4.8 Wiring /Charging the Battery ………………………… 4-31
4

EZS/ EZC Series Controller EZMC36 USER MANUAL
iii
4.9 Wiring the Slider /Cylinder Cables …………………… 4-32
4.9.1 Connecting the Slider/Cylinder ……………… 4-32
4.9.2 Cable Wiring Length…………………………… 4-32
4.9.3 Protecting the Motor …………………………… 4-32
4.10 Wiring the Communication Connector Cables …… 4-33
4.10.1 Teaching Pendant ………………………… 4-33
4.10.2 Controller …………………………………… 4-33
4.11 Wiring the I/O Cable ………………………………… 4-34
4.12 Wiring the Sensor Cables ………………………… 4-35
4.13 Compliance with the EC Directives ……………… 4-36
4.13.1 EMC Directives
(89/ 336 / EEC, 92/31/ EEC ) ……………… 4-36
4.13.2 Installation/Wiring Methods ……………… 4-37
4.14 Wiring Diagrams……………………………………… 4-39
4.14.1 Power Wiring Diagram …………………… 4-39
4.14.2 I/O Wiring Diagrams ……………………… 4-40
4.14.3 Example of EMC-Compliant Wiring……… 4-42
Chapter Startup and Troubleshooting …5-1
5.1 Turning on the Power to the Controller……………… 5-1
5.2 Starting the Slider /Cylinder (I/ O) …………………… 5-2
5.3 Starting the Slider /Cylinder (teaching pendant)…… 5-3
5.4 Troubleshooting………………………………………… 5-4
5
Chapter Controller Operation ………………… 6-1
6.1 Positioning Operation ………………………………… 6-1
6.1.1 Single-Motion Positioning Operation………… 6-2
6.1.2 Linked-Motion Positioning Operation ……… 6-2
6.1.3 Sequence-Forward Operation ……………… 6-3
6.2 Push-Motion Operation ……………………………… 6-5
6.3 Return-to-Home Operation …………………………… 6-6
6.4 Manual Operation ……………………………………… 6-6
6.5 Stop Operation ………………………………………… 6-7
6.5.1 Pause (PAUSE) ……………………………… 6-7
6.5.2 Softlimit Stop …………………………………… 6-7
6.5.3 Stop (STOP) …………………………………… 6-7
6.5.4 Emergency Stop (EMG) ……………………… 6-8
6.6 Coordinate Position Management …………………… 6-8
6

iv
Appendix Specifications…………………………………A-1
A.1 General Specifications …………………………………A-1
A.1.1 Insulation Specifications ………………………A-1
A.1.2 Installation Conditions …………………………A-1
A.1.3 Operating Environment ………………………A-1
A.2 Configuration of Equipment Connected
to the EZMC36 …………………………………………A-1
A.2.1 Slider/ Cylinder …………………………………A-1
A.2.2 Encoder …………………………………………A-1
A.2.3 Electromagnetic Brake…………………………A-1
A.2.4 Teaching Pendant ………………………………A-1
A.2.5 Battery……………………………………………A-1
A.3 Common Specifications ………………………………A-2
A.3.1 Power Supply, Operating Environment………A-2
A.3.2 LED Indication …………………………………A-2
A.3.3 Battery……………………………………………A-2
A.4 Control Specifications …………………………………A-2
A.4.1 Mode ……………………………………………A-2
A.4.2 Controller Mode…………………………………A-3
A.4.3 Driver Mode ……………………………………A-4
A.5 I /O Setting ………………………………………………A-5
A.5.1 Area ………………………………………………A-5
A.5.2 Soft limit …………………………………………A-5
A.5.3 Stop ………………………………………………A-5
A.6 Emergency Stop ………………………………………A-5
A.7 Protective Functions……………………………………A-6
A.8 Functions Available in Combination
with the Teaching Pendant ……………………………A-8
A.8.1 External Mode …………………………………A-8
A.8.2 Program Mode …………………………………A-9
A.8.3 Parameter Mode ………………………………A-9
A.8.4 Test Mode ………………………………………A-9
A
Chapter
Maintenance …………………………………… 7-1
7.1 External Check ………………………………………… 7-1
7
Chapter Repair ………………………………………………… 8-1
8.1 Scope of Warranty Repair …………………………… 8-1
8.2 Warranty Period ……………………………………… 8-1
8.3 How to Receive Repair ……………………………… 8-1
8.4
Repair Following Expiration of the Warranty Period … 8-1
8

EZS/ EZC Series Controller EZMC36 USER MANUAL v
Appendix
Optional Parts and
Accessories ……………………………………B-1
B.1 Teaching Pendant ………………………………………B-1
B.2 I /O Cable ………………………………………………B-1
B.3 Controller Link Cable …………………………………B-1
B.4 DIN Rail Mounting Plate ………………………………B-1
B.5 Cable Set ………………………………………………B-2
B.6 Sensor Set ………………………………………………B-2
B.7 Sensor Cable ……………………………………………B-2
B.8 Data Editing Software …………………………………B-3
B.9 Battery……………………………………………………B-3
B

vi
Please read this “Introduction ” section and familiarize yourself with the key aspects
of the manual.
This section covers the following:
● Intended reader of the manual
● Purpose of the manual
● Receipt, storage and disposal of the product
● Product support by Oriental Motor
● Rules of notation used in the manual
This manual is intended for qualified personnel with expert knowledge of electrical
and mechanical engineering.
Those in charge of the design, installation, wiring, setting, maintenance and trou-
bleshooting of EZS/EZC Series products should read this manual.
This manual explains the installation, wiring, setting and troubleshooting procedures
for EZS/EZC Series controllers.
The customer should inspect the exterior of the equipment before accepting the prod-
uct. Check the delivered product by verifying it against the specification on the order
sheet. If the product is damaged, please contact the Oriental Motor branch or sales
office from which you purchased the product.
Leave the product in the packing carton until immediately before installation. If the
product is not to be used for an extended period of time, store it in a place that sat-
isfies the following conditions:
● A clean place not subject to excessive humidity or salt
● A place away from direct sunlight
● An ambient temperature of 0°C to
+
50°C (
+
32˚F to
+
122˚F) (nonfreezing)
● A relative humidity of 85% or below (noncondensing)
● A place not exposed to corrosive gases
● A place not subject to continuous vibration
When disposing of the product, treat it as industrial waste.
Engage a certified waste-disposal service to carry out the disposal.
The product uses nickel-cadmium batteries. Dispose of the used batteries in accor-
dance with local laws and regulations. If you have any questions regarding disposal
of the product, please contact any Oriental Motor branch or sales office.
Should you require any of the following services, please contact any Oriental Motor
branch or sales office.
● Sales information and assistance for product selection
● Technical support regarding the product
● Warranty repair
Should you require technical assistance from Oriental Motor, first check the applica-
ble information in Chapter 5, “Startup and Troubleshooting ”. If the problem persists
after the appropriate measures have been taken, call our Technical Support Line. So
that we can promptly respond to your inquiry, please have the product model ready
when you call.
Introduction
Intended Reader of the
Manual
Purpose of the Manual
Product Support
Receipt, Storage and
Disposal of the Product
Technical Assistance
Regarding the Product

EZS/ EZC Series Controller EZMC36 USER MANUAL vii
Introduction
This manual serves as a user’s guide for EZS / EZC Series controllers.
Operating any EZS/EZC Series slider or cylinder requires the slider/cylinder and the
controller, as well as the setup of an optional teaching pendant or data editing soft-
ware and the programming of operation data. Please refer to the following manuals
for the EZS/EZC Series, and follow the instructions:
● EZS/EZC Series Controller User Manual (this document)
● EZS/EZC Series Controller Data Setting Manual
This manual explains the process of creating operation data, setting parameters
and performing troubleshooting using the teaching pendant.
● EZS/EZC Series Slider/Cylinder Installation Manual
This manual explains the installation and troubleshooting of sliders and cylinders.
● Teaching Pendant EZT1 User Manual
This manual explains the key layout of the teaching pendant.
● Data Editing Software EZED1
This manual explains the installation and operating method of the data editing soft-
ware.
This manual consists of chapters 1 through 8 and appendixes A and B. The table be-
low gives a brief explanation of the content of each chapter and section. The rules
of notation, as well as warnings and precautions specific to the controller, are also
explained.
Chapter
Chapter 1
Safety
Description
Read this chapter carefully in order to understand the safety precautions. The information
provided in this chapter is designed to ensure safety at the customer’s site and help pro-
tect the controller against damage.
Chapter 2
Unpacking, Inspection
and Storage
This chapter lists the items included in the controller package and explains the basic in-
spection procedure to be performed prior to installation or storage.
Chapter 3
Controller Overview
This chapter gives an overview of the controller and explains the functions set by the var-
ious switches, as well as the operating requirements.
Chapter 4
Installation and Wiring
This chapter explains how to install the controller in the machine and connect the slider/cylin-
der, power supply, emergency stop circuit and I / Os.
Chapter 5
Startup and
Troubleshooting
This chapter explains the procedure to be taken before actually operating the slider/cylin-
der using the controller, as well as troubleshooting.
See the Controller Data Setting Manual for the method used to program operation data.
Chapter 6
Controller Operation
This chapter explains the operating functions of the controller and how to operate each func-
tion.
Chapter 7
Maintenance This chapter explains the minimum maintenance required for the controller.
Chapter 8
Repair This chapter explains the warranty repair period and scope of repair for the controller.
Appendix A
Specifications This section explains the specifications of the controller.
Appendix B
Optional Parts and
Accessories
This section introduces the optional parts and accessories used with the controller.
Structure and Contents
of This Manual
Contents of the Manual

viii
The following symbols are used throughout this manual to indicate safety warnings,
precautions, important notes and tips:
Warning
Handling the product without observing the in-
structions that accompany a “Warning” symbol
may result in death or serious bodily injury.
Caution
Handling the product without observing the in-
structions that accompany a “Caution” symbol
may result in bodily injury or property damage.
These notes appear throughout the manual and
describe items that must be observed by the
user in certain situations to ensure correct use
of the product.
Notation
The description of text in this manual follows the notation rules specified below:
● A sentence starting with a filled circle provides information, not an operating pro-
cedure.
● A sentence starting with a number indicates an operating procedure or a step in a
procedure.
● Referenced titles are denoted in italics.
Terms
The meanings of key terms used in this manual are explained below:
Active
An ON state of the photocoupler in a controller I/O circuit
With the ALM output, “active” refers to the OFF state of the photocoupler.
Non-active
An OFF state of the photocoupler in a controller I/O circuit
With the ALM output, “non-active” refers to the ON state of the photocoupler.
Profile
A positioning operation control using the M0 to M5 (data select) inputs and the
START input
Motor
A motor used to drive the slider/cylinder
Rotor
A motor part that rotates (and is directly connected to an encoder)
Communication connector
A general term for the teaching-pendant connector and controller-link connector
Note
Rules of Notation

EZS/ EZC Series Controller EZMC36 USER MANUAL
1-1
Chapter 1 Safety
Read this manual before installing or wiring the controller. By reading the manual you
can better understand the installation methods and procedures and gain an under-
standing of how to operate the controller and slider/cylinder both safely and effec-
tively.
Always observe the items listed under “General Safety Guidelines ” on p. 1-3. Warnings
and precautions specific to the controller are explained in connection with the rele-
vant items throughout this manual.
The EZS/EZC Series products are designed for use in an electrical system or ma-
chine as an internal component. During operation and immediately after the power
supply is cut off, the parts continue to operate and remain hot, thus posing a risk of
bodily injury or property damage.
It is prohibited to start the slider/cylinder (i.e., to operate the device in accordance
with the specified purpose) when the machine does not satisfy any relevant safety
standards.
The factory safety manager or safety personnel in charge of the applicable machine
must ensure that the machine is operated only by qualified personnel who are famil-
iar with the operation of electronic equipment, and thereby prevent injury or damage
to the equipment.
The term “qualified personnel” refers to persons who have received the necessary
training or education and have pertinent experience; who are familiar with the rele-
vant standards, regulations, accident-prevention rules and inspection conditions; who
are authorized by the factory safety manager to engage in the necessary activities;
and who have the ability to discern and prevent potential dangers.
Dangers that may arise in connection with the use of this product are as follows:
● Electric shock
● Electrical fire
● Danger posed by the machine
● Electromagnetic disturbance
These dangers must be controlled properly by providing safety design for the machine,
adopting specific local regulations, and observing the standard safety guidelines and
specific precautionary notes supplemental thereto. This product poses no danger as-
sociated with chemical products or radiation.
1.2.1 Electric Shock
To prevent electric shock, as the power supply for your EZS/EZC Series product use
only a DC power supply that has passed the necessary tests and provides reinforced
insulation on the primary and secondary sides. For maximum safety, provide a pro-
tective grounding for the ground terminal of the DC power supply.
1.2.2 Electrical Fire
Electrical fire can be avoided by conforming to the general procedures implemented
in industrial power-equipment works. It is essential that appropriate qualified personnel
conduct the electrical work. Please note that a safe distance must be ensured from
the machine in which the slider/cylinder is installed, so that only appropriate qualified
personnel can access the slider/cylinder.
Chapter 1
1.1 Safety Precautions
1.2 Potential Dangers
Safety

1-2
1.2.3 Danger Posed by the Machine
Danger posed by the machine relates to unexpected movement of the slider/cylinder
(table/rod) in an uncontrolled situation. If the machine is subject to such an unex-
pected movement of parts, the slider/cylinder must be electrically disconnected from
the controller using an appropriate preventive measure whenever the operating part
of the machine is to be accessed by a person. Note that the mounting parts of the
slider/cylinder must under all circumstances not be loose.
Provide a safety measure external to the controller so that the entire machine will op-
erate safely when an abnormality occurs due to a failure in the controller or slider/cylin-
der, or due to any other external factor.
● The controller cuts off the motor’s output current and stops the slider/cylinder when
its protective function is actuated or upon the occurrence of a CPU error.
● Upon the detection of an EMG (emergency stop) input, the controller cuts off the
motor’s output power and stops the slider/cylinder (stop category 0: non-controlled
stop). If the motor is equipped with an electromagnetic brake, the electromagnet-
ic brake will be actuated in order to produce the necessary holding brake force.
Provide a measure on the machine side so that it will operate safely if the slider/cylin-
der stops.
The stop action is specified in 9.2.2 and 9.2.5.3 of EN60204-1.
The following three stop actions are available:
Category 0: The power supply to the drive device is stopped by direct means ( e.g.,
non-controlled stop).
Category 1: The power supply to the drive device continues during the stopping ac-
tion and stops when the stopping action is complete. Controlled stop
mode.
Category 2: The power supply to the drive device continues. Controlled-stop mode.
The safety precautions described above are by no means comprehensive.
Please contact ORIENTAL MOTOR concerning any question or problem you might
have.
1.2.4 Electromagnetic Disturbance
Appropriate measures must be taken to suppress the EMI (Electromagnetic
Interference) caused by the slider/cylinder, controller and teaching pendant in the near-
by control systems equipment and to address the EMS (Electromagnetic Susceptibility)
of the slider/cylinder, controller and teaching pendant. Failure to do so may result in
a serious impairment of the machine’s performance.
Provide EMC (Electromagnetic Compatibility) measures when installing/wiring the
product.
The safety precautions described above are by no means comprehensive.
Please contact Oriental Motor concerning any question or problem you might have.

EZS/ EZC Series Controller EZMC36 USER MANUAL
Chapter 1 Safety
1-3
1.3 General Safety Guidelines
This section explains the general safety guidelines applicable to the EZS/EZC Series.
Safety information specific to the controller is provided in connection with the relevant
items throughout the manual.
To prevent bodily injury, please observe the following points.
Warning
● Be sure that personnel with expert knowledge of elec-
trical and mechanical engineering perform the instal-
lation, connection, operation, maintenance and trou-
bleshooting. Failure to do so may result in fire, elec-
tric shock or injury.
● Always turn off the power supply before connecting or
disconnecting the product to/from the machine. Failure
to do so may result in electric shock.
● If the controller’s protective function has been actuat-
ed, remove the cause and then reconnect the power
source. If the slider/cylinder operation is continued
without removing the cause, the controller may mal-
function and cause injury or equipment damage.
● Always turn off the power supply to the controller be-
fore performing maintenance or repair of the machine.
Failure to do so may result in injury.
● Do not disassemble or modify the slider/cylinder. When
maintaining the slider, do not disassemble parts other
than those specified in this manual. Doing so may re-
sult in injury.
● When the product is used in a lifting application, choose
a type equipped with an electromagnetic brake.
Without an electromagnetic brake the slider/cylinder
will lose its holding brake force when the power is cut
off or upon actuation of the controller’s protective func-
tion or emergency stop function. When this happens,
the moving part may drop, causing injury or equipment
damage.
● Do not use the electromagnetic brake to decelerate,
nor use it as a safety brake. The electromagnetic brake
is designed to hold the slider/cylinder position. Failure
to observe this precaution may result in injury or equip-
ment damage.
● If the product is of the absolute type, perform a return-
to-home operation or absolute positioning operation
immediately after recovery of the power supply. Failure
to do so may result in injury or equipment damage.
● If an incremental positioning operation is performed
immediately after recovery of the power supply, the
following accidents may occur:
●
If the moving part of the slider/cylinder has shift-
ed during the battery backup period due to an
external force, the new position of the moving
part will be recognized as the origin in the posi-
tioning operation and the stopping position will
deviate accordingly.

1-4
Caution
● Do not use the controller and slider/cylinder beyond
their specified values. Doing so may result in injury or
equipment damage.
● No one should come close to the slider/cylinder be-
yond the safety distance, except for qualified person-
nel. To do so may result in injury.
● When transporting the slider/cylinder, do so by hold-
ing the body of the slider/cylinder. Holding the slid-
er/cylinder by the cables, table or rod may result in in-
jury.
● Do not supply power to the machine when the slid-
er/cylinder covers are not installed in their specified
positions. Doing so may result in electric shock or in-
jury.
● Do not touch the table or rod while the slider/cylinder
is in operation. To do so may result in injury.
● Connect the slider/cylinder cables to the appropriate
connectors on the controller. Failure to do so may re-
sult in equipment damage.
● Precautionary note on emergency stop
When the emergency stop button on the teaching pen-
dant is pressed or an EMG input to the controller is de-
tected, the controller cuts off the motor’s output current
and stops the motor. If the slider/cylinder is equipped
with an electromagnetic brake, the brake is actuated and
the position is held. However, if there is no electromag-
netic brake, the holding brake force is lost and it may take
longer to stop. If the load installed on the table or rod is
likely to contact other equipment during this period, pro-
vide a safety mechanism on the machine side. Failure
to do so may result in injury or equipment damage.
● Precautionary note on static electricity
Static electricity may cause the controller to malfunction
or sustain damage. Do not touch the controller while the
power is being supplied. When adjusting the controller’s
axis-number setting switch, electromagnetic brake re-
lease switch, pendant switch or DIP switches while the
power supply is active, always use an insulated screw-
driver.

EZS/ EZC Series Controller EZMC36 USER MANUAL
2-1
EZC Series
● Cylinder 1 unit ● Hexagonal nut 1 pc.
● Controller 1 unit ● I/O connector (plug) 1 set
● Installation manual 1 copy ● Power cable 1 pc.
● User manual for controller 1 copy ● Battery 1 pc. (absolute type only)
(this document)
● Battery holder 2 pcs. (absolute type only)
● Data setting manual for controller 1 copy
EZS Series
● Slider 1 unit ● Hexagonal socket-head screw 4 pcs. (M5)
● Controller 1 unit ● I/O connector (plug) 1 set
● Installation manual 1 copy ● Power cable 1 pc.
● User manual for controller 1 copy ● Battery 1 pc. (absolute type only)
(this document)
● Battery holder 2 pcs. (absolute type only)
● Data setting manual for controller 1 copy
Chapter 2 Unpacking, Inspection and Storage
2.1 Unpacking the Controller
This chapter explains the receiving procedures that must be carried out in order to
ensure that the controller will function as specified.
These procedures include the following:
● Unpacking the EZS/EZC Series controller
● Inspecting the controller for damage sustained during shipment
● Checking the combination of controller and slider/cylinder
● Storage guidelines for the controller
Each EZS/EZC Series product comes with a controller and a slider or cylinder packed
in the same carton.
1. Remove the EZS/EZC Series controller from the shipping carton and remove all
packing materials from around the product. You may keep the packing materials
and shipping carton for storage or shipment of the controller at a later time.
2. Check all items in the carton against the packing list. The nameplate on the prod-
uct indicates the following information:
●
Product model
●
Serial number
●
Manufacture date code
Packing list
Chapter 2Unpacking, Inspection
and Storage

2-2
2.2 Explanation of Unit Model
The unit-model codes for the EZS/EZC Series are shown in figures 2-1 and 2-2.
However, a given combination of these numbers and letters does not always provide
a valid unit model. Refer to “Combination List ” on p. A-1.
2.2.1 Slider
EZC4 : Maximum transportable mass
in the vertical direction: 4.5 kg (9.9 lb.)
EZC6 : Maximum transportable mass
in the vertical direction: 10 kg (22 lb.)
Stroke
05 : 50 mm (1.97 inch)
10
: 100 mm (3.94 inch)
20
: 200 mm (7.87 inch)
30 : 300 mm (11.81 inch)
Electromagnetic brake
None: Without electromagnetic brake
M : With electromagnetic brake
C :With controller
A : Absolute type
I : Incremental type
EZS3 : Maximum transportable mass
in the horizontal direction: 5 kg (11 lb.)
EZS4 : Maximum transportable mass
in the horizontal direction: 15 kg (33 lb.)
EZS6 : Maximum transportable mass
in the horizontal direction: 30 kg (66 lb.)
Stroke
05 : 50 mm (1.97 inch)
10 : 100 mm (3.94 inch)
15 : 150 mm (5.91 inch)
20 : 200 mm (7.87 inch)
25 : 250 mm (9.84 inch)
30 : 300 mm (11.81 inch)
40 : 400 mm (15.75 inch)
50 : 500 mm (19.69 inch)
Electromagnetic brake
None: Without electromagnetic brake
M : With electromagnetic brake
C : With controller
A : Absolute type
I : Incremental type
2.2.2 Cylinder
■ Figure 2-1 Unit Model of Slider
■ Figure 2-2 Unit Model of Cylinder
EZS4 - 05 M C A
EZC4 - 05 M C A

EZS/ EZC Series Controller EZMC36 USER MANUAL
2-3
Chapter 2 Unpacking, Inspection and Storage
2.3 Inspection Procedure
2.4 Storing the Controller
It is recommended that you check the following points upon receipt of the product:
● Inspect the controller for any physical damage sustained during shipment.
● Check the combination of the controller and the slider or cylinder.
To check the combination, see “Combination List ” on p. A-1 of the Slider/Cylinder
Installation Manual and check the unit model and corresponding models of individual
controller and slider/cylinder.
If the product is found to be damaged during the unpacking process, or if the combi-
nation is wrong or the controller does not operate properly when tested, please con-
tact theOriental Motor branch or sales office from which you purchased the product.
Report problems to Oriental Motor as soon as possible after your receipt of the prod-
uct.
For the warranty period of the controller and whether or not the applicable defect qual-
ifies for a warranty repair, see “Repair ” on p. 8-1.
Use the product packing materials to wrap the controller and put it back into the ship-
ping carton. Store the controller in a place that satisfies the following conditions:
● A clean place not subject to excessive humidity or salt
● A place away from direct sunlight
● An ambient temperature of 0°C to
+
50°C (
+
32˚F to
+
122˚F) (nonfreezing)
● A relative humidity of 85% or below (noncondensing)
● A place not exposed to corrosive gases
● A place not subject to continuous vibration
Some of the parts used in the controller
are sensitive to static electricity. When
touching the controller, provide an an-
tistatic measure. Also, place the metal
surface of the controller on a conduc-
tive material. A failure to provide an ap-
propriate antistatic measure may dam-
age the controller.
Note

2-4

EZS/ EZC Series Controller EZMC36 USER MANUAL
3-1
■ Figure 3-1 System Configuration ( incremental type)
E
M
E
R
G
E
N
C
Y
S
T
O
P
F1 F2 F3 F4
789
65
4
123
0
+/-
BS
SATART
STOP
ENT
SHIFT
ESC
TEACHING PENDANT
EZT1
ON
1234
MB
LINEAR m OTION CONTROLLER
EZ
m C 36
ID
SW
ENC
MOTOR
BAT
EMG
I/O
LINK
PENDANT/PC
PENDANT
ONOFF
ON
RDY
PWR
ALM
OFF
24V DC
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
ON
1234
MB
LINEAR m OTION CONTROLLER
EZ
m C 36
ID
SW
ENC
MOTOR
BAT
EMG
I/O
LINK
PENDANT/PC
PENDANT
ONOFF
ON
RDY
PWR
ALM
OFF
24V DC
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
ON
1234
MB
LINEAR m OTION CONTROLLER
EZ
m C 36
ID
SW
ENC
MOTOR
BAT
EMG
I/O
LINK
PENDANT/PC
PENDANT
ONOFF
ON
RDY
PWR
ALM
OFF
24V DC
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
ON
1234
MB
LINEAR m OTION CONTROLLER
EZ
m C 36
ID
SW
ENC
MOTOR
BAT
EMG
I/O
LINK
PENDANT/PC
PENDANT
ONOFF
ON
RDY
PWR
ALM
OFF
24V DC
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
ON
1234
MB
LINEAR m OTION CONTROLLER
EZ
m C 36
ID
SW
ENC
MOTOR
BAT
EMG
I/O
LINK
PENDANT/PC
PENDANT
ONOFF
ON
RDY
PWR
ALM
OFF
24V DC
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
Teaching pendant
Controller
Controller link cable (optional)
Axis number
ID: 0
ID: 1 ID: 2 ID: 14 ID: 15
Slider/ cylinder 0
Slider/ cylinder 1
Slider/ cylinder 2 Slider/ cylinder 14
Slider/ cylinder 15
Chapter 3 Controller Overview
This chapter explains the basic controller functions and operating requirements that
must be understood and observed in order to ensure correct use of the controller.
The EZS/EZC Series controller is equipped with a communication function, encoder
feedback function, and other functions needed to operate the slider/cylinder using pro-
grammed data, and to perform positioning controls such as home-position detection.
The data and parameters used in the slider/cylinder positioning control are set in the
controller via the teaching pendant (optional). The teaching pendant can set and main-
tain data for up to 16 controllers. However, in the manual operation mode the teach-
ing pendant can only access one selected controller. Figure 3-1 shows the configu-
ration of a system comprised of EZS/EZC Series controllers and sliders/cylinders, as
well as a teaching pendant.
The absolute type controller provides a position-remembering function whereby the
movement of the slider table or cylinder rod is monitored via the encoder when the
power supply to the controller is cut off.
Chapter 3Controller Overview
3.1 Overview

3-2
The encoder installed in the slider/cylinder constantly feeds back to the controller the
position of the moving part (table/rod). The controller monitors the encoder signal
and controls the motor so as to prevent any deviation in the position of the moving
part. There are two controller types: the absolute type, which provides a position-re-
membering function, and the incremental type without the position-remembering func-
tion. If your controller is of the incremental type, always perform a return-to-home
operation of the slider/cylinder after turning on the power.
The controller operates in two modes: the controller mode, in which the positioning
of the slider/cylinder is performed using operation data; and in the driver mode, in
which the slider/cylinder is operated via the pulse train input from a user-defined con-
troller.
The available I/O functions vary, depending on the operation mode setting. It is rec-
ommended that you select the controller mode when performing slider/cylinder op-
eration.
The controller cuts off the motor’s output current and stops the slider/cylinder when
its protective function is actuated or upon the occurrence of a CPU error.
