Oriental motor NX Series User manual

1
Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should
work with the product.
Use the product correctly after thoroughly reading the section“Safety
precautions”on p.2. In addition, be sure to observe the contents described
in warning, caution, and note in this manual.
The product described in this manual is designed and manufactured to
be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any compensation for
damage caused through failure to observe this warning.
Related operating manuals
For operating manuals not included with the product, contact your nearest
Oriental Motor sales oce or download from Oriental Motor Website
Download Page.
Operating manual name Included or not included
with product
NX Series OPERATING MANUAL Motor Edition Included
NX Series OPERATING MANUAL Driver Edition
(this document) Included
NX Series USER MANUAL Not included
Regulations and standards
UL Standard and CSA Standard
This product is recognized by UL under the UL and CSA Standards.
zApplicable Standards
Applicable Standards Certication Body Standards File No.
UL 61800-5-1
CSA C22.2 No.274 UL E171462
zWARNING FOR UL MARKING ON DRIVER
yFor UL Standard (UL 61800-5-1), the product is recognized for the condition
of Maximum Surrounding Air Temperature 50 °C (122 °F).
ySuitable For Use On A Circuit Capable Of Delivering Not More Than
5,000 A rms Symmetrical Amperes, 120 Volts or 240 Volts Maximum.
yIntegral solid state short circuit protection does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with
the National Electric Code and any additional local codes.
yIs used UL Listed Inverse Time Circuit Breaker rated 240 Vac, 15 A.
ySolid State motor overload protection is provided in each model.
(NXD20-A/C)
ySolid State motor overload protection reacts at 150 % FLA or less.
(NXD75-S)
yDrives have no provision for motor over temperature protection. Motor
over temperature protection is required at end application.
yDo not touch the connection terminals on the driver while the power is
supplied or for at least 10 minutes after turning o the power. Doing so
may result in electric shock.
HM-60051-7
OPERATING MANUAL Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
Tuning-free AC servo motor
NX Series Driver Edition
EU Directives
zCE Marking
This product is axed the CE Marking under the Low Voltage Directive and
EMC Directive.
•Low Voltage Directive
This product is certied by TÜV Rheinland under the EN 61800-5-1. (NXD20-A
and NXD20-C only)
Applicable Standards EN 50178, EN 61800-5-1
Installation conditions
(EN Standard)
To be incorporated in equipment.
Overvoltage category: II
Pollution degree: 2
Protection against electric shock: Class I
yThis product cannot be used in IT power distribution systems.
yInstall the product within the enclosure in order to avoid contact with
hands.
yBe sure to maintain a protective ground in case hands should make contact
with the product.
Be sure to connect the Protective Earth wire of the cable for motor to the
Protective Earth Terminal on the driver, and ground the driver’s Protective
Earth Terminal.
yTo protect against electric shock using an earth leakage breaker (RCD),
connect a type B earth leakage breaker to the primary side of the driver.
yWhen using a circuit breaker (MCCB), use a product conforming to EN
Standards or IEC Standards.
yIsolate the motor cable, power-supply cable and other drive cables from the
signal cables (CN1, CN4 to CN7) by means of double insulation.
•EMC Directive
This product is conducted EMC testing under the conditions specied in
"Example of installation and wiring" on the USER MANUAL. The conformance
of your mechanical equipment with the EMC Directive will vary depending
on such factors as the conguration, wiring, and layout for other control
system devices and electrical parts used with this product. It therefore must
be veried through conducting EMC measures in a state where all parts
including this product have been installed in the equipment.
Applicable standards
EMI
EN 55011 group 1 class A
EN 61000-6-4
EN 61800-3
EMS EN 61000-6-2
EN 61800-3
This equipment is not intended for use in residential
environments nor for use on a low-voltage public network
supplied in residential premises, and it may not provide
adequate protection to radio reception interference in
such environments.
RoHS Directive
The products do not contain the substances exceeding the restriction values
of RoHS Directive (2011/65/EU).

2
Safety precautions
The precautions described below are intended to ensure the safe and correct
use of the product, and to prevent the customer and others from exposure
to the risk of injury. Use the product only after carefully reading and fully
understanding these instructions.
Handling the product without observing the instructions
that accompany a“WARNING”symbol may result in
serious injury or death.
Handling the product without observing the instructions
that accompany a“CAUTION”symbol may result in injury
or property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure the
safe use of the product.
General
yDo not use the product in explosive or corrosive environments, in the
presence of ammable gases, in places subjected to splashing water, or
near combustibles. Doing so may result in re, electric shock, or injury.
yAssign qualied personnel to the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product. Failure to do so
may result in re, electric shock, or injury.
yDo not transport, install, connect, or inspect the product while the power is
supplied. Always turn the power o before carrying out these operations.
Failure to do so may result in electric shock.
yThe terminals on the driver’s front panel marked with symbol
indicate the presence of high voltage. Do not touch these terminals while
the power is on to avoid the risk of re or electric shock.
yWhen an alarm is generated in the driver (any of the driver's protective
functions is triggered), take measures to hold the moving part in a specic
position since the motor stops and loses its holding torque. Failure to do so
may result in injury or damage to equipment.
yWhen an alarm is generated in the driver (any of the driver's protective
functions is triggered), remove the cause before clearing the alarm
(protective function). Continuing the operation without removing the cause
of the problem may cause malfunction of the motor and driver, leading to
injury or damage to equipment.
Installation
yThe driver is Class I equipment. When installing the driver, install it inside
an enclosure so that it is out of the direct reach of users. Be sure to ground
if users can touch it. Failure to do so may result in electric shock.
yInstall the driver inside an enclosure. Failure to do so may result in electric
shock or injury.
Connection
yAlways keep the power supply voltage of the driver within the specied
range. Failure to do so may result in re or electric shock.
yConnect the cables securely according to the wiring diagram. Failure to do
so may result in re or electric shock.
yDo not forcibly bend, pull, or pinch the cable. Doing so may result in re or
electric shock.
Operation
yTurn o the driver power supply in the event of a power failure. Otherwise,
the motor may suddenly start when the power is restored, causing injury or
damage to equipment.
yDo not remove the motor excitation during operation. Doing so may cause
the motor to stop and lose the holding force, resulting in injury or damage
to equipment.
Maintenance and inspection
yDo not touch the connection terminal of the driver while the power is
supplied. Turn o the power to check the CHARGE LED being turned o
before starting connection or inspection. Failure to do so may result in
electric shock.
Repair, disassembly and modication
yDo not disassemble or modify the driver. This may cause electric shock or
injury. Refer all such internal inspections and repairs to the Oriental Motor
sales oce from which you purchased the product.
General
yDo not use the driver beyond its specications. Doing so may result in
electric shock, injury, or damage to equipment.
yKeep your ngers and objects out of the openings in the driver. Failure to
do so may result in re, electric shock, or injury.
yDo not touch the driver during operation or immediately after stopping.
The surface is hot, and this may cause a skin burn(s).
Installation
yDo not leave anything around the driver that would obstruct ventilation.
Doing so may result in damage to equipment.
Connection
yThe data edit connector (CN4) and the analog I/O connector (CN6) on the
driver are not electrically insulated. When grounding the positive terminal
of the power supply, do not connect any equipment (PC, etc.) whose
negative terminal is grounded. Doing so may cause the driver and these
equipment to short, damaging both.
Operation
yProvide an emergency-stop device or emergency-stop circuit external to
the equipment so that the entire equipment will operate safely in the event
of a system failure or malfunction. Failure to do so may result in injury.
yBefore supplying power to the driver, turn all input signals to the driver to
OFF. Otherwise, the motor may suddenly start when the power is turned
on, leading to injury or damage to equipment.
yWhen moving the moving part manually, put the motor into a non-
excitation state. Continuing the work while the motor is in an excitation
state may result in injury.
yUse a 24 VDC power supply that has been given reinforced insulation
between the primary side and secondary side. Failure to do so may cause
electric shock.
yImmediately when a problem occurred, stop operation and turn o the
driver power supply. Failure to do so may result in re, electric shock, or
injury.
yTo prevent electric shock, use only an insulated screwdriver to adjust the
driver’s switches.
Maintenance and inspection
yDo not touch the terminals while conducting the insulation resistance
measurement or the dielectric strength test. Doing so may cause electric
shock.
Disposal
yDispose the product correctly in accordance with laws and regulations, or
instructions of local governments.

3
Precautions for use
•Be sure to use our cable to connect the motor and the driver.
If a exible cable or cable longer than 3 m (9.8 ft.) is to be used, be sure to
purchase our cable separately. Check on the Oriental Motor Website for the
model name of cables.
•When conducting the insulation resistance measurement or
the dielectric strength test, be sure to separate the connection
between the motor and the driver.
Conducting the insulation resistance measurement or the dielectric strength
test with the motor and the driver connected may result in damage to the
product.
•Noise elimination measures
Refer to the USER MANUAL for noise elimination measures.
•Saving data to the non-volatile memory
Do not turn o the main power supply or 24 VDC power supply while writing
the data to the non-volatile memory, and also do not turn o for 5 seconds
after the completion of writing the data. Doing so may abort writing the data
and cause an EEPROM error alarm to generate. The non-volatile memory can
be rewritten approximately 100,000 times.
•Preventing leakage current
Stray capacitance exists between the driver’s current-carrying line and other
current-carrying lines, the earth and the motor, respectively. A high-frequency
current may leak out through such capacitance, having a detrimental eect
on the surrounding equipment. The actual leakage current depends on the
driver’s switching frequency, the length of wiring between the driver and
motor, and so on.
When providing a leakage current breaker, use the following products, for
example, which have high-frequency signal protection:
Mitsubishi Electric Corporation: NV series
•Motor excitation at power ON
When the driver has been set to lock the servo after the motor stops in the
position control mode or speed control mode: Turning on the power supply
will not excite the motor. To excite the motor, you must turn the S-ON input
ON.
You can set the motor to be excited automatically after the power has been
turned on, by changing the applicable driver parameter using the support
software MEXE02 or the data setter OPX-2A.
•If vertical drive (gravitational operation) such as elevator
applications is performed or if sudden start-stop operation
of a large inertial load is repeated frequently, connect our
regeneration resistor.
The factory setting is to use the internal regeneration resistor. Note, however,
that the internal regeneration resistor does not support continuous
regenerative operation, gravitational operation or other operations involving
up/down movements, or frequent repeating of sudden starting/stopping of
a large inertial load. If any of these operations must be performed, use our
regeneration resistor. Check on the Oriental Motor Website for the model
name.
•Note on connecting a power supply whose positive terminal is
grounded
The data edit connector (CN4) and the analog I/O connector (CN6) on the
driver are not electrically insulated. When grounding the positive terminal of
the power supply, do not connect any equipment (PC, etc.) whose negative
terminal is grounded. Doing so may cause the driver and these equipment to
short, damaging both. Use the OPX-2A to set data, etc.
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or
damaged items to the Oriental Motor sales oce from which you purchased
the product.
yDriver................................................................................................... 1 unit
yCN1 connector (6 pins)................................................................. 1 pc.
yCN2 connector (3 pins)................................................................. 1 pc.
yCN3 connector (7 pins)................................................................. 1 pc.
yCN7 connector (36 pins)............................................................... 1 pc.
yConnector wiring lever (for CN2, CN3).................................... 1 pc.
yOPERATING MANUAL Driver Edition (this document)....... 1 copy
Included connector model
The CN2 connector and the CN3 connector are made by either of two
manufacturers, WAGO Corporation and Molex Incorporated.
The CN7 connector is made by either of two manufacturers, 3M Company and
Molex Incorporated.
About each connector (CN2, CN3, CN7), either one of two connectors is
included with a product. Check the manufacturer name with the connector
case.
Type Model number (Manufacturer)
CN1 connector MC1,5/6-STF-3,5 (PHOENIX CONTACT GmbH & Co. KG)
CN2 connector
721-203 (WAGO Corporation)
or
54928-0370 (Molex Incorporated)
CN3 connector
721-207 (WAGO Corporation)
or
54928-0770 (Molex Incorporated)
CN7 connector
Case: 10336-52A0-008 (3M Company)
Connector: 10136-3000PE (3M Company)
or
Case: 54331-1361 (Molex Incorporated)
Connector: 54306-3619 (Molex Incorporated)
Combinations of motors and drivers
The box () in the model name indicates the cable length.
The box () in the model name indicates the gear ratio.
zStandard type
Model Motor model Driver model
NX45AA-
NXM45A NXD20-A
NX45AC-NXD20-C
NX410AA-
NXM410A NXD20-A
NX410AC-NXD20-C
NX620AA-
NXM620A NXD20-A
NX620AC-NXD20-C
NX640AS-NXM640A NXD75-S
NX975AS-NXM975A
zStandard type with electromagnetic brake
Model Motor model Driver model
NX45MA-
NXM45M NXD20-A
NX45MC-NXD20-C
NX410MA-
NXM410M NXD20-A
NX410MC-NXD20-C
NX620MA-
NXM620M NXD20-A
NX620MC-NXD20-C
NX640MS-NXM640M NXD75-S
NX975MS-NXM975M

4
zPS geared type
Model Motor model Driver model
NX65AA-PS-
NXM65A-PSNXD20-A
NX65AC-PS-NXD20-C
NX610AA-PS-
NXM610A-PSNXD20-A
NX610AC-PS-NXD20-C
NX920AA-PS-
NXM920A-PSNXD20-A
NX920AC-PS-NXD20-C
NX940AS-PS-NXM940A-PSNXD75-S
zPS geared type with electromagnetic brake
Model Motor model Driver model
NX65MA-PS-
NXM65M-PSNXD20-A
NX65MC-PS-NXD20-C
NX610MA-PS-
NXM610M-PSNXD20-A
NX610MC-PS-NXD20-C
NX920MA-PS-
NXM920M-PSNXD20-A
NX920MC-PS-NXD20-C
NX940MS-PS-NXM940M-PSNXD75-S
zPJ geared type
Model Motor model Driver model
NX810AA-J-
NXM810A-JNXD20-A
NX810AC-J-NXD20-C
NX820AA-J-
NXM820A-JNXD20-A
NX820AC-J-NXD20-C
NX1040AS-J-NXM1040A-J
NXD75-S
NX1075AS-J-NXM1075A-J
zPJ geared type with electromagnetic brake
Model Motor model Driver model
NX810MA-J-
NXM810M-JNXD20-A
NX810MC-J-NXD20-C
NX820MA-J-
NXM820M-JNXD20-A
NX820MC-J-NXD20-C
NX1040MS-J-NXM1040M-J
NXD75-S
NX1075MS-J-NXM1075M-J

5
Input/output power ratings
yThe box () in the model name indicates A(single shaft) or M(with electromagnetic brake).
yThe box () in the model name indicates the cable length.
yThe box () in the model name indicates the gear ratio.
yThe motor model (UL recognized) apply to the condition before a gearhead is assembled.
Model Motor model Motor model
(UL recognized)
Driver
model
Input Output
Voltage Frequency Current Voltage Frequency Current Output
NX45A-
NXM45NXM45
NXD20-A Single-phase
100-115 V
50/60 Hz
1.9 A
Three-phase
0-119 V
0-150 Hz
0.91 A 50 W
NX45C-NXD20-C
Single-phase/
Three-phase
200-230 V
1.2 A/
0.7 A
NX410A-
NXM410NXM410
NXD20-A Single-phase
100-115 V 2.9 A
Three-phase
0-144 V 1.12 A 100 W
NX410C-NXD20-C
Single-phase/
Three-phase
200-230 V
1.8 A/
1.0 A
NX65A-PS-
NXM65-PSNXM45
NXD20-A Single-phase
100-115 V 1.9 A
Three-phase
0-119 V 0.91 A 50 W
NX65C-PS-NXD20-C
Single-phase/
Three-phase
200-230 V
1.2 A/
0.7 A
NX610A-PS-
NXM610-PSNXM410
NXD20-A Single-phase
100-115 V 2.9 A
Three-phase
0-144 V 1.12 A 100 W
NX610C-PS-NXD20-C
Single-phase/
Three-phase
200-230 V
1.8 A/
1.0 A
NX620A-
NXM620NXM620
NXD20-A Single-phase
100-115 V 4.6 A
Three-phase
0-152 V
0-300 Hz
1.8 A 200 W
NX620C-NXD20-C
Single-phase/
Three-phase
200-230 V
2.8 A/
1.6 A
NX640S-NXM640NXM640NXD75-S Three-phase
200-230 V 2.8 A Three-phase
0-162 V 3.2 A 400 W
NX810A-J-
NXM810-JNXM610-J
NXD20-A Single-phase
100-115 V 2.8 A
Three-phase
0-141 V 1.1 A 100 W
NX810C-J-NXD20-C
Single-phase/
Three-phase
200-230 V
1.8 A/
1.0 A
NX820A-J-
NXM820-JNXM620-J
NXD20-A Single-phase
100-115 V 4.6 A
Three-phase
0-152 V 1.8 A 200 W
NX820C-J-NXD20-C
Single-phase/
Three-phase
200-230 V
2.8 A/
1.6 A
NX920A-PS-
NXM920-PSNXM620
NXD20-A Single-phase
100-115 V 4.6 A
Three-phase
0-152 V 1.8 A 200 W
NX920C-PS-NXD20-C
Single-phase/
Three-phase
200-230 V
2.8 A/
1.6 A
NX940S-PS-NXM940-PSNXM640
NXD75-S Three-phase
200-230 V
2.8 A Three-phase
0-162 V 3.2 A 400 W
NX975S-NXM975NXM9754.7 A Three-phase
0-160 V 5.9 A 750 W
NX1040S-J-NXM1040-JNXM940-J 2.9 A Three-phase
0-127 V 5.1 A 400 W
NX1075S-J-NXM1075-JNXM975-J 4.7 A Three-phase
0-160 V 5.9 A 750 W

6
Names and functions of parts (Example: NXD20-C)
LED
SW1
Internal potentiometers
(VR1, VR2)
Mechanical rigidity
setting switch (SW2)
Analog I/O connector (CN6)
Encoder connector (CN5)
Data edit connector (CN4)
Motor connector (CN2)
CHARGE LED
I/O signal connector (CN7)
Battery connector (bottom)
Protective Earth
Terminals
Electromagnetic brake
terminals (CN1)
Regeneration register
thermal input terminals
(CN1)
24 VDC power supply
input terminals (CN1)
Regeneration resistor
terminals (CN3)
Main power supply input
terminals (CN3)
Control mode setting switches
(SW1-1, 1-2)
Absolute system setting switch
(SW1-3)
Pulse input mode selector switch
(SW1-4)
Name Description
Control mode setting
switches (SW1-1, 1-2)
These switches are used to set the control mode of the
driver (position control, speed control, torque control
or tension control).
Absolute system setting
switch (SW1-3)
This switch is eective in the position control mode. Set
the switch when the absolute function of the driver is
used by connecting our battery BAT01A.
ON: Enable the absolute function
OFF: Disable the absolute function
The factory setting is “OFF.”
Pulse input mode
selector switch (SW1-4)
In the position control mode, this switch toggles the
driver between the 1-pulse input mode and 2-pulse
input mode according to the pulse output mode of the
controller.
ON: 1-pulse input mode, negative logic
OFF: 2-pulse input mode, negative logic
The factory setting depends on the destination country.
LED
These LEDs indicate the status of the driver.
POWER (green): This LED is lit while the main power
supply or 24 VDC power supply is input.
ALARM (red): This LED will blink when an alarm
generates (a protective function is
triggered).
POS (green): This LED is lit in the position control mode.
SPD (green): This LED is lit in the speed control mode.
TRQ (green): This LED is lit in the torque control mode.
TEN (green): This LED is lit in the tension control mode.
Mechanical rigidity
setting switch (SW2)
yPosition control mode or speed control mode
This switch sets the gain adjustment level according
to the mechanical rigidity. The factory setting is“6.”
yTorque control mode
Not used.
yTension control mode
This switch sets the minimum speed in the simple
mode. The factory setting is“6.”The switch is not used
in high function mode I or high function mode II.
Name Description
Internal potentiometers
(VR1, VR2)
yPosition control mode
VR1: This potentiometer sets the damping control
frequency.
VR2: Not used.
ySpeed control mode
VR1: This potentiometer sets the speed command
value.
VR2: This potentiometer sets the acceleration/
deceleration time.
yTorque control mode
VR1: This potentiometer sets the torque command
value.
VR2: This potentiometer sets the speed limit.
yTension control mode
VR1: This potentiometer sets the tension command
value.
VR2: This potentiometer sets the speed limit.
Data edit connector
(CN4)
Connects a PC in which the MEXE02 has been
installed, or the OPX-2A.
Encoder connector (CN5) Connects the motor encoder via a cable for encoder.
Analog I/O connector
(CN6) Connects the analog I/O signals.
I/O signal connector
(CN7) Connects the I/O signals of the controller.
24 VDC power supply
input terminals
(CN1) [24V]
Connects a 24 VDC power supply. Once a 24 VDC power
supply is connected, you can check the contents of
alarms that have generated even when the main power
supply is cut o. When an electromagnetic brake motor
is used, be sure to connect a 24 VDC power supply for
the electromagnetic brake.
Regeneration resistor
thermal input terminals
(CN1) [TH1, TH2]
Connects our regeneration resistor. If no regeneration
resistor is connected, insert the CN1 connector to short
the TH1 and TH2 terminals.
Electromagnetic brake
terminals
(CN1) [MB1, MB2]
Connects the cable for electromagnetic brake (24 VDC).
MB1: Electromagnetic brake − (black)
MB2: Electromagnetic brake + (white)
CHARGE LED (red)
This LED is lit while the main power supply is input.
After the main power supply has been turned o, the
LED will turn o once the residual voltage in the driver
drops to a safe level.
Motor connector (CN2)
Connects the motor.
Phase U: Red
Phase V: White
Phase W: Black
Regeneration resistor
terminals (CN3)
[RG1, RG3]
When using the internal regeneration resistor, short the
RG2 and RG3 terminals using a jumper wire included
with the CN3 connector.
If our regeneration resistor is used, remove the jumper
wire which has shorted the RG2 and RG3 terminals, and
connect the lead wires to the RG1 and RG3 terminals.
Main power supply input
terminals (CN3)
ySingle-phase 100-115 VAC
L, N: Connects single-phase 100-115 VAC.
ySingle-phase 200-230 VAC
L1, L2: Connects single-phase 200-230 VAC.
L3: Not used.
yThree-phase 200-230 VAC
L1, L2, L3: Connects three-phase 200-230 VAC.
yNC: Not used.
Protective Earth
Terminals
Ground this terminal using a grounding wire of AWG16
(1.25 mm2) or larger.
Battery connector Connects our battery BAT01A when using the absolute
function of the driver in the position control mode.

7
Installation
Installation location
The driver is designed and manufactured to be incorporated in equipment.
Install it in a well-ventilated location that provides easy access for inspection.
The location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
yOperating ambient humidity 85 % or less (non-condensing)
yArea free of explosive atmosphere or toxic gas (such as sulfuric gas) or
liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rain, water droplets), oil (oil droplets),
or other liquids
yArea free of excessive salt
yArea not subject to continuous vibrations or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power
machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
y1,000 m (3,300 ft.) or lower above sea level
Installation direction
The driver is designed so that heat is dissipated via air convection and
conduction through the enclosure. When two or more drivers are to be
installed side by side, provide 20 mm (0.79 in.) and 50 mm (1.97 in.) clearances
in the horizontal and vertical directions, respectively. When installing the
driver inside an enclosure, use two screws (three screws for NXD75-S) to
secure the driver through the mounting holes.
Screws (M4) are not included. Please provide separately.
20 (0.79) or more
• NXD20-A, NXD20-C
35
(1.38) 20 (0.79) or more
• NXD75-S
60 (2.36)
150 (5.91) 150 (5.91)
50 (1.97) or more 50 (1.97) or more
Unit: [mm (in.)]
yInstall the driver inside an enclosure whose pollution degree is
2 or better environment, or whose degree of protection is IP54
minimum.
yDo not install any equipment that generates a large amount of heat
or noise near the driver.
yDo not install the driver underneath the controller or other
equipment vulnerable to heat.
yIf the ambient temperature of the driver exceeds 50 °C (122 °F),
reconsider the ventilation condition.
yBe sure to install the driver vertically (vertical position).
Connection
Connection method for connectors
zCN1 connector
yApplicable lead wire: AWG28 to 16 (0.08 to 1.25 mm2)
yStripping length of wire insulation: 7 mm (0.28 in.)
yNominal size: M2
yTightening torque: 0.22 to 0.25 N·m (31 to 35 oz-in)
Insert each lead wire into the CN1 connector and
tighten the screw using a slotted screwdriver.
Lead wires
zCN2/CN3 connectors
yApplicable lead wire: AWG16 to14 (1.25 to 2.0 mm2)
yStripping length of wire insulation: 8 to 9 mm (0.31 to 0.35 in.)
1. Insert the connector wiring lever.
2. Insert the lead wire while pushing down
the connector wiring lever.
Lead wire
You can also use a slotted screwdriver.
Insert the lead wire while
pushing down the slotted
screwdriver.
Slotted screwdriver insertion port
[Cutting edge width:
3.0 to 3.5 mm (0.12 to 0.14 in.)]
zCN6/CN7 connectors
yApplicable lead wire: AWG28 to 24 (0.08 to 0.2 mm2)
The tightening torque of a screw varies depending on the manufacturer
of the connector. Check the manufacturer and tightening torque of the
connector before tightening the screw. Check the manufacturer name with
the connector case.
I/O signal cable
Cable clamp
Place the spring
washer outside
the case.
C
onnector
Screws (M2) *1
Align the washer in the
depression in the case.
Case
Sc
rews (M2.5) *2
*1 The tightening torque is shown in the table.
Manufacturer of connector Tightening torque [N·m (oz-in)]
3M Company 0.15 to 0.25 (21 to 35)
Molex Incorporated 0.3 to 0.35 (42 to 49)
*2 The tightening torque is shown in the table.
Manufacturer of connector Tightening torque [N·m (oz-in)]
3M Company 0.16 to 0.2 (22 to 28)
Molex Incorporated 0.5 to 0.55 (71 to 78)

8
Connecting the motor
•Connection example (The electromagnetic brake motor)
Connect to CN2 *1
CN1 connector
Connect to CN1 *1
Connect to CN5 *1
Cable for
electromagnetic brake *2
Cable for
encoder *2 *3 Encoder cable
Electromagnetic
brake cable
Cable for motor *2
Motor cable
24 VDC±10 %
-
+
MB1
MB2
24 V+
24 V
-
CN2 connector
U
V
W
Tightening torque: 1.2 N·m (170 oz-in)
Black
White
Red
White
Black
Phase
Required
Required
24 VDC power supply
Required
*1 Keep 20 m (65.6 ft.) or less for the extension length between the motor and
driver.
*2 These cables are provided as our products. These cables are included with the
product or sold separately.
*3 Use the cable for encoder when the length of the encoder cable of motor is not
enough.
yThe lead wires of the cable for electromagnetic brake have
polarities, so connect them in the correct polarity. If the lead wires
are connected with their polarities reversed, the electromagnetic
brake will not operate properly.
yConnect the connectors securely. Insecure connector connection
may cause malfunction or damage to the motor or driver.
yWhen connecting or disconnecting the connector, turn o the
power and wait for the CHARGE LED to turn o before doing so. The
residual voltage may cause electric shock.
When installing the motor on a moving part, use our exible cable
oering excellent exibility. Check on the Oriental Motor Website for
the model name of cables.
Connecting the I/O signals
Solder the I/O signal cable (AWG28 to 24: 0.08 to 0.2 mm2) to the CN7
connector (36 pins). Use a shielded cable for I/O signals.
Connector pin assignment
(viewed from soldering
side)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
•Connecting the connector (CN7)
Insert the CN7 connector into the I/O
signal connector (CN7) on the driver,
and tighten the screws.
The tightening torque of a screw
varies depending on the manufacturer
of the connector. Check the
manufacturer and tightening torque
of the connector before tightening
the screw. Check the manufacturer
name with the connector case.
CN7
Sc
rews
(M2.5)
Manufacturer of connector Tightening torque [N·m (oz-in)]
3M Company 0.15 to 0.25 (21 to 35)
Molex Incorporated 0.3 to 0.35 (42 to 49)
Be certain the I/O signal cable is as short as possible. The maximum
input frequency will decrease as the cable length increases.
zConnector function table (Position control mode)
Pin
No. Signal name Name
1 − −
2 GND Ground connection
3 ASG+ A-phase pulse line-driver output
4 ASG−
5 BSG+ B-phase pulse line-driver output
6 BSG−
7 ZSG1+ Z-phase pulse line-driver output
8 ZSG1−
9 ALM+ Alarm output
10 ALM−
11 WNG+/MOVE+*/
MBC+*Warning output/
Motor moving output*/
Electromagnetic brake control signal output*
12 WNG−/MOVE−*/
MBC−*
13 END+ Positioning complete output
14 END−
15 READY+/AL0+*/
P-OUTR+ Operation ready complete output/
Alarm code output bit0*/
Position data output ready output
16 READY−/AL0−*/
P-OUTR−
17 TLC+/AL1+*/
P-OUT0+ Torque limit output/
Alarm code output bit1*/
Position data output bit0
18 TLC−/AL1−*/
P-OUT0−
19 ZSG2+/NEAR+*/
AL2+*/P-OUT1+
Z-phase pulse open-collector output/
Near position output*/
Alarm code output bit2*/
Position data output bit1
20 ZSG2−/NEAR−*/
AL2−*/P-OUT1−
21 GND Ground connection
22 IN-COM Input common

9
Pin
No. Signal name Name
23 S-ON Servo on input
24 CLR/ALM-RST/P-CK
Deviation clear input/
Alarm reset input/
Position data transmission clock input
25 P-REQ Position data request input
26 TL Torque limit enable input
27 M0 Data selection input
28 M1
29 P-PRESET Position preset input
30 FREE Shaft free input
31 CW+/PLS+ CW pulse input/Pulse input
32 CW−/PLS−
33 CW+24 V/PLS+24 V CW pulse/Pulse input for 24 V
34 CCW+24 V/DIR+24 V CCW pulse input/Direction input for 24 V
35 CCW+/DIR+ CCW pulse input/Direction input
36 CCW−/DIR−
* The signal will become eective if the applicable setting has been changed using
the MEXE02 or OPX-2A.
Functions of the connector vary depending on the control mode.
Check the USER MANUAL for other control modes except position
control mode.
Connecting the analog I/O signals
About the connector (20 pins) for the analog I/O connector (CN6), use our
accessory set. Check on the Oriental Motor Website for the model name.
Solder the analog I/O cable (AWG28 to 24: 0.08 to 0.2 mm2) to the CN6
connector. Use a shielded cable for analog I/O signals.
Connector pin assignment
(viewed from soldering side)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
zConnecting the connector (CN6)
Insert the CN6 connector into the
analog I/O connector (CN6) on the
driver, and tighten the screws.
The tightening torque of a
screw varies depending on the
manufacturer of the connector.
Check the manufacturer and
tightening torque of the connector
before tightening the screw. Check
the manufacturer name with the
connector case.
CN6
Sc
rews
(M2.5)
Manufacturer of connector Tightening torque [N·m (oz-in)]
3M Company 0.15 to 0.25 (21 to 35)
Molex Incorporated 0.3 to 0.35 (42 to 49)
zConnector function table
Pin No. Signal
name Name Description
1 V-REF Analog speed
(command/limit) input
Terminal used to input an
analog speed (command/limit).
2 SG Signal ground Ground for analog I/O signals.
Pin No. Signal
name Name Description
3 P-VREF
Reference voltage
output for analog speed
(command/limit) input
A power supply output used to
connect a variable resistor to
the analog speed (command/
limit) input.
4 P-TREF
Reference voltage
output for analog torque
(command/limit) input
Power supply output used to
connect a variable resistor to
the analog torque (command/
limit) input.
5 T-REF Analog torque
(command/limit) input
Terminal used to input an
analog torque (command/
limit).
6 SG Signal ground Ground for analog I/O signals.
7 V-MON Analog speed monitor
output
Voltage corresponding to the
monitored analog speed is
output from here.
8 SG Signal ground Ground for analog I/O signals.
9 T-MON Analog torque monitor
output
Voltage corresponding to the
monitored analog torque is
output from here.
10 SG Signal ground Ground for analog I/O signals.
11 to 20 − − −
Connecting the main power supply
Use the CN3 connector (7 pins) to connect the power supply cable (AWG16 to
14: 1.25 to 2.0 mm2) to the main power supply connector (CN3) on the driver.
yDo not wire the power supply cable of the driver in the same cable
duct with other power line or motor cable. Doing so may cause
malfunction due to noise.
yWhen connecting or disconnecting the CN3 connector, turn o the
power and wait for the CHARGE LED to turn o before doing so. The
residual voltage may cause electric shock.
The current capacity of the power supply as shown below is the value
when operating the motor in the continuous duty region. When
operating in the limited duty region, the current will ow maximum
three times as much as the continuous region. Refer to the USER
MANUAL for the continuous duty region and limited duty region.
zThe current capacity of the power supply
Model Single-phase
100-115 V
Single-phase
200-230 V
Three-phase
200-230 V
NX45 1.9 A or more 1.2 A or more 0.7 A or more
NX410 2.9 A or more 1.8 A or more 1.0 A or more
NX65 1.9 A or more 1.2 A or more 0.7 A or more
NX610 2.9 A or more 1.8 A or more 1.0 A or more
NX620 4.6 A or more 2.8 A or more 1.6 A or more
NX640 − − 2.8 A or more
NX810 2.8 A or more 1.8 A or more 1.0 A or more
NX820
NX920 4.6 A or more 2.8 A or more 1.6 A or more
NX940
− −
2.8 A or more
NX975 4.7 A or more
NX1040 2.9 A or more
NX1075 4.7 A or more
Single
-phase
100-115 V
50/60 Hz
• Single-phase
100-115 V
• Single-phase
200-230 V
• Three-phase
200-230 V
L
N
R
S
T
Three-phase
200-230 V
50/60 Hz
Single-phase
200-230 V
50/60 Hz L1
L2

10
Grounding the driver
Two Protective Earth Terminals (nominal size:
M4) are provided on the driver. Be sure to
ground one of the Protective Earth Terminals.
yGrounding wire: AWG16 to 14
(1.25 to 2.0 mm2)
yTightening torque: 1.2 N·m (170 oz-in)
Protective Earth Terminal
(Ground either of the terminals.)
Connect the Protective Earth wire of the cable for motor to a terminal that is
not grounded.
When grounding the Protective Earth Terminal, use a round terminal and
secure the grounding point near the driver.
Do not share the grounding wire with a welder or any other power
equipment.
Connecting the 24 VDC power supply input,
regeneration resistor and electromagnetic brake
Use the CN1 connector (6 pins) to connect the 24 VDC power supply input,
regeneration resistor thermal input and electromagnetic brake. Connect the
lead wire (AWG28 to 16: 0.08 to 1.25 mm2) to the connector while checking in
the table.
Display Description
24V+ 24 VDC power supply input
(Be sure to connect these terminals when an electromagnetic brake
is used.)
24V−
TH1 Regeneration resistor thermal inputs
(If these terminals are not used, short them using a jumper wire.)
TH2
MB1 Electromagnetic brake −
(Connect the black lead wire of the electromagnetic brake.)
MB2 Electromagnetic brake +
(Connect the white lead wire of the electromagnetic brake.)
zConnecting the connector (CN1)
Tightening torque:
0.4 N·m (56 oz-in)
Nominal size: M2.5
zConnecting the 24 VDC power supply input
Once a 24 VDC power supply is connected, you can check the contents of
alarms that have generated even when the main power supply is cut o. Since
the 24 VDC power supply is not used for operating the motor, connect it as
necessary.
When the electromagnetic brake motor is used, be sure to connect the
24 VDC power supply of the following capacity.
Model Voltage
Current capacity
Without
electromagnetic
brake
With
electromagnetic
brake
NX45, NX410
NX65, NX610
NX620, NX640
NX810, NX820
NX920, NX940
24 VDC±10 % 0.4 A or more
0.7 A or more
NX975, NX1040
NX1075 0.8 A or more
zConnecting the regeneration resistor
•When the internal regeneration resistor is used
The driver has an internal regeneration resistor. The driver is shipped with the
TH1 and TH2 terminals of CN1, and RG2 and RG3 terminals of CN3, shorted
respectively to enable the internal regeneration resistor.
•When our regeneration resistor is used
Use our regeneration resistor if gravitational operation or other operation
involving up/down movement, or sudden starting/stopping of a large inertia
load, will be repeated frequently. Check on the Oriental Motor Website for the
model name.
Regeneration resistor
AWG22
(AWG20 for RGB200)
To TH1 and TH2
terminals on CN1
To RG1 and RG2
terminals on CN3
AWG18
R
yWhen connecting our regeneration resistor, be sure to remove the
jumper wires from the CN1 connector and CN3 connector.
yIf the current consumption of the regeneration resistor exceeds the
allowable level, the thermostat will be triggered and a regeneration
resistor overheat alarm will generate. If a regeneration resistor
overheat alarm generates, turn o the power and check the content
of the error.
zConnecting the electromagnetic brake
Refer to“Connecting the motor”on p.8.
Connecting the battery
1. Hold the driver with its bottom facing up and connect the connector
attached at the end of the battery lead wires into the battery connector.
2. Hook the tabs on the battery connector onto the mating parts on the
driver.
3. Push in the battery holder carefully by ensuring that the lead wires are
not pinched.
L
ead wires with
connector
Batter
y holder
Hook
Step 1
Step 3
Step 2

11
yInstalling or removing the battery must be performed by qualied
personnel with expert knowledge of the handling of the driver and
battery.
yRemove the battery if the driver is not turned on for an extended
period exceeding the data retention period. Failure to do so may
cause the battery uid to leak or battery performance to drop.
yWhen installing or removing the battery, cut o the main power
supply and 24 VDC power supply of the driver.
yOnce the battery is disconnected, the absolute motor position
stored in the driver will be lost. After the battery has been installed,
be sure to set the absolute motor position again.
Connecting the data setter
Connect our communication cable for the support software or the OPX-2A
cable to the CN4 on the driver.
Communication cable for the suppor
t
software or the OPX-2A cable
The data edit connector (CN4) and the analog
I/O connector (CN6) on the driver are not electrically
insulated. When grounding the positive terminal of the
power supply, do not connect any equipment (PC, etc.)
whose negative terminal is grounded. Doing so may cause
the driver and these equipment to short, damaging both.
Setting
SW1
Internal potentiometers (VR1, VR2)
Mechanical rigidity setting switch (SW2)
Co
ntrol mode setting switches (SW1-1, 1-2)
Absolute system setting switch (SW1-3)
Pulse input mode selector switch (SW1-4)
The new setting of the absolute system setting switch (SW1-3) and the
pulse input mode selector switch (SW1-4) will become eective after
the power is turned on again. If a 24 VDC power supply is used, also
turn on the 24 VDC power supply again.
Control mode (SW1-1, 1-2)
These switches are used to set the control mode of the driver (position
control, speed control, torque control or tension control).
Position control
mode
Speed control
mode
Torque control
mode
Tension control
mode
Absolute system (SW1-3)
Install our battery BAT01A. When the battery is connected,
the current position will be retained even in the event of
power outage or after the driver power is cut o.
ON: Enable the absolute function
OFF: Disable the absolute function (factory setting)
Pulse input mode (SW1-4)
ON: 1-pulse input mode, negative logic
OFF: 2-pulse input mode, negative logic
Each mode can only be set with a negative logic using the
pulse input mode selector switch. To select a positive logic,
set the applicable parameter using the MEXE02 or OPX-2A.
The factory setting depends on the destination country.
Mechanical rigidity (SW2)
What is set with this switch varies depending on the control mode.
Control mode Description
Position control mode The switch sets the gain adjustment level according
to the mechanical rigidity.
Speed control mode
Torque control mode Not used.
Tension control mode
The switch sets the minimum speed in the simple
mode. The switch is not used in high function mode I
or high function mode II.
Internal potentiometers (VR1, VR2)
What is set with these potentiometers varies depending on the control mode.
Control mode Internal
potentiometers Description
Position control
mode
VR1 This potentiometer sets the damping
control frequency.
VR2 Not used.
Speed control mode
VR1 This potentiometer sets the speed
command value.
VR2 This potentiometer sets the
acceleration/deceleration time.
Torque control mode VR1 This potentiometer sets the torque
command value.
VR2 This potentiometer sets the speed limit.
Tension control
mode
VR1 This potentiometer sets the tension
command value.
VR2 This potentiometer sets the speed limit.
Inspection
It is recommended that periodic inspections be conducted for the items listed
below after each operation of the motor. If an abnormal condition is noted,
discontinue any use and contact your nearest Oriental Motor sales oce.
zInspection item
yCheck if the openings in the driver are clogged.
yCheck if any of the screws having installed a driver is loose.
yCheck if any of the connection parts of the connector is loose.
yCheck if the driver has unusual smells or appearance defects.
The driver uses semiconductor components. Static electricity may
damage the semiconductor components of the driver, so be extremely
careful when handling driver.

12
yUnauthorized reproduction or copying of all or part of this manual is
prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating
to industrial property rights arising from use of any information, circuit,
equipment or device provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without
notice.
yWhile we make every eort to oer accurate information in the manual,
we welcome your input. Should you nd unclear descriptions, errors or
omissions, please contact your nearest Oriental Motor sales oce.
yis a registered trademark or trademark of Oriental Motor
Co., Ltd., in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2012
Published in December 2020
T
echnical Support Tel:[phone]
8:30am EST to 5:00pm PST
（M-F）
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:[phone]
www
.oriental-motor.co.uk
T
el:[phone]
www
.orientalmotor.fr
T
el:[phone]
www
.orientalmotor.it
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:[phone]
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone] (For English)
1800-121-4149 (For Hindi)
www.orientalmotor.co.in
General specications
Operation
environment
Degree of
protection IP20
Ambient
temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
Humidity 85 % or less (non-condensing)
Altitude Up to 1,000 m (3,300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Storage
environment
Ambient
temperature −25 to +70 °C (−13 to +158 °F) (non-freezing)
Humidity 85 % or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Shipping
environment
Ambient
temperature −25 to +70 °C (−13 to +158 °F) (non-freezing)
Humidity 85 % or less (non-condensing)
Altitude Up to 3,000 m (10,000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
yMaximum Surrounding Air Temperature +40 to +50 °C (+104 to
+122 °F). When the surrounding air temperature exceeds +40 °C
(+104 °F), continuous motor output power shall be within the
derating curve. (NXD20-A and NXD20-C)
yMaximum Surrounding Air Temperature +50 °C (+122 °F). When the
surrounding air temperature exceeds +45 °C (+113 °F), continuous
motor output power shall be within the derating curve. (NXD75-S)
• Derating curve for continuous motor output;
Rated output: 100 W
20
40
60
80
100
01020304
05
0
Ambient temperature [°C]
Continuous motor output [W]
0
25
50
75
100
125
150
175
200
10 20 30 40 50
Ambient temperature [°C]
Continuous motor output [W]
• Derating curve for continuous motor output;
Rated output: 200 W
• Derating curve for continuous motor output;
Rated output: 750 W
150
300
450
600
750
01020304
05
0
Ambient temperature [°C]
Continuous motor output [W]
