ORIGO CF1523 User manual

Instruction Manual
CF1523
使用說明書
充電式立體搖擺對流扇
Rechargeable 3D convection fan
*使用風扇前，請先細閱使用說明，並請妥善保存以便將來翻閱。
***本說明書可於本公司網站下載 www.origin.hk。
*Read all instructions carefully before using the FAN, and keep this instruction for furture
reference when necessary.
***This instruction manual can be acquired at www.origin.hk.

Important Safety Information
重要安全提示
1
拔除插頭時不可拉扯電源線，必須緊握插頭
，把插頭拔出。
Do not pull the power cord to disconnect
from power source. Always grasp the plug
to pull out.
請使用獨立插座。使用萬能插頭或拖板，容
易發生危險。
Avoid using extension cord as it may
overheat and casue fire.
包裝物料並非玩具，不可讓小孩玩耍。
Do not let children play parts of
package.
打開包裝，檢查風扇。如發現產品有損壞
，請勿使用及即時聯絡供應商。
Open the package and ensure that the
Fan is undamaged. In case of doubt
do not use the FAN Cooler and contact
your supplier.
必須按照使用說明指示操作本風扇，否則
可能引致產品損壞、短路、火警或人命損
傷。
Use this Fan only as described in
this manual. Any other use not
recommended by the manufacturer
may casue fire, electrical shock or
injury to persons.
使用本風扇前，請先細閱使用說明。
Read all instructions carefully before
using the Fan.
本機不是為體質、感覺或智力有障礙人士(包
括小孩)或缺乏經驗及知識者使用，除非他們
曾經接受負責安全人士的監督或指示，大人應
指導小孩不可把玩電器。
充電式立體搖擺對流扇
Rechargeable 3D convection fan
如電源適配器的電源線有損壞痕跡，為保
障安全，請立即停止使用並聯絡供應商或
代理商或合資格人員作更換。
If the power cord of power adaptor is
damaged, it must be replaced and
repaired by service centre.
本產品內置充電池，請使用本產品提供的
電源適配器替產品進行完全充電。
This Fan is driven by batteries. Please
use the power adaptor provided to
fully charge the product before use.
The appliance is not to be used by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they
have been given supervision or instruction.
Children being supervised not to play with
the appliance.

Important Safety Information
重要安全提示
2
不可在潮濕或有積水的環境使用，不可將風
扇擺放於浴缸或大型容器上面。
The Fan is not intended for use in wet
or damp locations. Never locate the
Fan where it may fall into a bathtub or
other water container.
請保持清潔以維持風扇處於良好狀態
(詳細請參閱清理及維護部份)。
Keep the Fan clean to maintain in good
condition (refer to maintenance
section).
切勿將 風扇 擺放在發熱源頭或火源附近。
Do not place the Fan near a source
of heat or fire.
警告；清理前必須先拔除電源插頭。若電
源線損壞，必須交由製造商或其代理指定
維修服務中心檢查及修理。
WARNING: To avoid danger of electric
shock, unplug from outlet when not
in use and before cleaning. If the
power cord is damaged, it must be
replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid hazard.
本風扇不適用於室外及作工業用途。
This Fan is intended for household
use ONLY and not for industrial
or outdoor use.
非使用風扇時請拔除插頭，切斷電源。
Do not leave the Fan unattended.
Always unplug the Fan Cooler when
not in use.
切勿將任何異物放入風扇內；或阻擋風扇
出風口及入風口，皆因以上一切行為均可
能導致風扇損壞。
Do not insert any objects into the Fan
as it may cause an electric shock or
damage. Do not block or tamper with
the Fan in any manner while it is in
operation.
警告：開/關鍵不應作為切斷電源的用途。
WARNING: The On/Off switch should
not be used as the sole means of
disconnecting power. Always unplug
the power cord before servicing or
moving the unit.
如須移動風扇，請先拔除插頭切斷電源。
Always disconnected the Fan from the
power supply when moving it from
one location to another.
本產品含有可回收材料，不可把本產
品作為未分類廢物。請聯繫當地就近
指定回收點。
This product contains recyclable
materials. Do not dispose this
product as unsorted municipal
waste. Please contact your local
municipality for the nearest collection
充電式立體搖擺對流扇
Rechargeable 3D convection fan
移除網罩前 ，必須確保風扇已拔掉電源。
Ensure that the fan is switched off from
the supply mains before removing the
guard.

Control Panel
控制面板
Rear Grille
後網
Front Grille
前網
Remote Control Dock
遙控器儲存盤
Remote Receiver
遙控信號接收窗
Main Parts
各部名稱
3
Air Oulet
出風口
Air Inlet
入風口
圖片只供參考 ， 一切以實物為準
The picture is for reference only, everything in kind shall prevail.
充電式立體搖擺對流扇
Rechargeable 3D convection fan
Power Socket
電源插座
Power Adapter
電源適配器

Function Setting
功能設定
4
1.
1. Place the Fan on a stable and flat surface. Plug the power adaptor to the power
socket, then plug the power cord into electrical outlet or charging use.
5. 左右送風: 按下左右送風鍵 ，風扇以自動左右搖擺模式送風。如欲停止自動左右搖
5. OSC(LEFT/RIGHT): Press the key to allow the Fan to LEFT/RIGHT oscillate the
擺送風，再按此鍵一次。
wind direction. To stop the oscillation, press the button again.
將風扇擺放於穩固的平面上，將電源適配器接駁到風扇底座電源插座，再把插頭
插入獨立插座或充電使用。
3. 風速: 按風速設定鍵 ，設定所需風速：低、中、高、或超強。LED顯示燈將會顯示風速。
風扇可使用控制面板按鍵操控，或改用遙控器操控。
3. SPEED: Adjust the Fan speed to the desired level: Low, Medium, High or Gale
by pressing key. The speed setting is displayed on the LED light.
2.
2. POWER: Turn the Fan ON by pressing the key, the Fan start at low speed.
開/關:按開/關鍵 ，風扇以低檔啟動。
6. 定時設置: 按下定時設置鍵 ，選定 7個不同的自動關機時間，分別由1至7小時，
LED顯示燈將會亮起。
6. TIMER: Pressing the key to set desired auto power off time, There are 7 time
intervals, from 1-hour to 7-hour.
The Fan may be operated by the control panel or by your remote control.
7. 送風模式: 按送風模式鍵 ，設定所需送風模式：自然風、或睡眠風。LED顯示燈將
會亮起。
7. MODE: Press the key to set the Fan as Natural, or Sleep mode. The mode is
displayed on the LED light.
4. 上下送風: 按下上下送風鍵 ，風扇以自動上下搖擺模式送風。如欲停止自動上下搖
4. OSC(UP/DOWN): Press the key to allow the Fan to UP/DOWN oscillate the
擺送風，再按此鍵一次。
wind direction. To stop the oscillation, press the button again.
圖片只供參考 ， 一切以實物為準 。/ The picture is for reference only, everything in kind shall prevail.
充電式立體搖擺對流扇
Rechargeable 3D convection fan
Hour
11
44
22
NN
SS
開/關
定時 風速 左右送風
上下送風 送風模式 TIMER ON/OFF SPEED L/R OSCU/D OSC MODE
電源顯示燈 Power Indicator Light

Remote Control
遙控器



Function Setting
功能設定
1.遙控器操作方式與機身按鍵操作方式相同。
2.更換電池 : 使用一枚3伏特鋰電池。
1. All functions performed by the Remote Control work are identical
to the Manual.
2. Battery replacement:Install one 3V Lithium battery.
警告
1) 請把電池放在兒童碰不到的地方，如果孩子吞下電池，需立即致電咨詢醫生。
2) 不要對電池進行充電或隨意棄置在有火源的地方。
3) 應保持電池存放於乾燥，陰涼的地方。
4) 以正確的方向插入電池。
電池的處理 - 請按相關地區的法律規定處理曾經使用的電池。
WARNING
1. Keep batteries out of reach of children. Should a child swallow a
battery, consult a doctor immediately.
2. Do not recharge or dispose in fire.
3. Keep in a dry and cool place.
4. Insert battery in rigdt direction.
Battery disposal - Please dispose the used battery per municipal or
provincial law.
5
充電式立體搖擺對流扇
Rechargeable 3D convection fan
8. 充電 : 當低電量時，將電源適配器連接至電源插座，並將另一端插入風扇底座電源插座。
- 首次充電時間: 最少充電5小時。
- 充電時電源顯示燈會不斷閃爍，充電完成時會長亮。
(提示:只可使用提供的DC15V,2.1Max.電源適配器充電，否則會使充電池的壽命縮短。)
8. CHARGING: On low power, connect the power adaptor to power supply and insert the
other end into the power socket, of the Fan.
- First charging time: At least 5 hours.
- The Power Indicator Light will be flash on when charging and light on continuously
when fully charged.
(Reminder : Use the provided power adaptor only with DC15V, 1.5A to charge,
otherwise, the life of rechgeable battery inside will be shortened.)
充電完成
Fully Charged
充電中
Charging
CF1523CF1523

立體搖擺對流扇
4D convection fan
6
Maintenance
清理及維護
Specification
技術規格
警告：不使用風扇時，經常保持拔除電源，及切勿將風扇浸於水或其他液體中。在清潔本風扇前，先將
風扇關掉及把電源線從插座拔出。
Housing & Rear Grille: Clean the outside and grille of the Fan with a soft cloth. To remove
presistent dirt, wipe down with a cloth that has been dampened with warm soapy water.
外殼及後網：清理時切勿將風扇浸於水或其他液體中。使用濕潤軟布抹擦清潔，頑固污垢可用軟布沾上含
肥皂的溫水抹擦。
注意：切勿使用含有腐蝕性的清潔劑或溶液清理風扇。
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO NOT IMMERSE
CAUTION: Do NOT use gasoline, benzene, thinner, harsh
扇葉：將前網下方螺絲鬆脫後逆時針旋轉前網並取出，使用
濕潤軟布抹擦清潔扇葉。清潔後，放回前網並用螺絲鎖緊，
才可使用風扇。
Blade: Loose the screw, turn the front grille anti-clockwise
and pull it out. Clean the blade with a soft damp cloth,
place back and fix the front grille with the screw after cleaning
THE FAN IN WATER! BEFORE CLEANING, MAKE SURE THAT THE UNIT HAS BEEN SWITCHED OFF
AND IT IS UNPLUGGED FROM THE MAIN OUTLET.
cleaners, etc., as they will damage the Fan. NEVER use
ALCOHOL or any other SOLVENTS.
儲存：連同使用說明，把風扇存放於清涼及乾爽的地方。
STORAGE: Store the Fan with these instructions in the original box in a cool and dry place.
充電式立體搖擺對流扇
Rechargeable 3D convection fan
型號 Model Number
輸入 Input
產品尺寸 Product Dimension
CF1523
15V---2.1A Max.
270 x 260 x 360 mm (約/Approx.)
額定功率 Battery Li-ion 2800mAh
充電時間 Charging Time 5小時/hours (約/Approx.)
使用時間 Operating Time
45分鐘-10小時/minutes-hours (約/Approx.)
(跟據不同風速/Depending on different speeds)

7
Origin Map
源澤地圖
辦公時間
10:30am - 12:30pm (星期一至五)
02:30pm - 05:30pm (星期一至五)
10:30am - 12:30pm (星期六)
(星期日及公眾假期休息)
OFFICE HOURS
10:30am - 12:30pm (Mon to Fri)
02:30pm - 05:30pm (Mon to Fri)
10:30am - 12:30pm (Saturday)
(Closed on Sunday and Holiday)
充電式立體搖擺對流扇
Rechargeable 3D convection fan

充電式立體搖擺對流扇
Rechargeable 3D convection fan
產品保用証(一年自攜服務)
產品: 充電式立體搖擺對流扇
型號: CF1523
此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享為3個月):
1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，
可獲免費維修和/或零件更換。
2. 以下情況不被包括在保養範圍內：
-若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；
-未經授權之自行處理、維修及/或改裝；
-任何遙控、機殼、面蓋、扇葉，以及配件。
3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。
4. 更換後之任何損壞零件，均屬本公司所有。
5. 本保養服務只適用於香港特別行政區。
6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。
*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途
除外)。請即登入網站: www.origo.hk
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室
電話: 2156 8238
www.origo.hk
Warranty Card(1 year carry-in)
Item : Rechargeable 3D Convection Fan
Model : CF1523
Service Centre
ORIGIN MARKETING LIMITED
Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street), 403 Castle Peak Road,
Kwai Chung, N.T., Hong Kong.
Tel: [phone]
www.origo.hk
