ORIGO FH-M48 User manual

*使用暖風機前，請先細閱使用說明，並請妥善保存以便將來翻閱。
*Read all instructions carefully before using the FAN HEATER, and keep this instruction for
furture reference when necessary .
.
FH-M48
使用說明書
Instruction Manual
陶瓷暖風機
Ceramic Heater

Ceramic Heater
陶 瓷 暖 風 機
Important Safety Information
重要安全提示
1
本機不是為體質、感覺或智力有障礙人
士或8歲以下小孩或缺乏經驗及知識者
使用，除非他們曾經接受負責安全人士
的監督或指示，大人應指導小孩不可把
玩電器。除非在負責安全人士的監督或
指示，8歲以下小孩不可清潔及維護本
機。
Thisappliance can be used by
children agedfrom 8years and
above andpersonswith reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge, if they have been
given supervision or instruction
concerning use of the appliance in
a safe way and understand the
hazards involved. Children shall
not play the appliance. Cleaning
and user maintenance shall not
bemade by children unless they
are older than 8 and supervised.
切勿使用可使暖風機自動開機的外加管
理程式、時間制、遙控系統或任何其他
裝置，以免因暖風機被覆蓋或擺放位置
不當而發生火警。
The Heater is not intended to be
operated by means of an external
programmer, timer, seperate
remote-control system or any other
device that switches the Heater on
automatically, since a fire risk exists
if Heater is covered or positioned
incorrectly.
本機及其電源線應擺放於8歲以下小
孩不能觸及的地方。
Keep the appliance and its cord
out of reach of children less than 8
years.
如本產品的電源 線有損壞痕跡，為保
障安全，請立即停止使用並聯絡供應
商更換。
使用暖風機前，請先細閱使用說明。
Read all instructions carefully
before using the heater.
If the supply cord is damaged, it
must be replaced by manufacturer,
its service agent or similary qualified
persons in order to avoida hazard.
警告：為防暖風機過熱，切勿覆蓋暖風
機的出、入風口。使用中的暖風機出口
會發出高熱，切勿觸踫。暖風機應與易
燃物品(如傢俱、枕頭、床舖、毛巾或窗
簾等)保持安全距離。
出風口安全距離：不少於3英尺(0.9米)
入風口安全距離：不少於1英尺(0.3米)
WARNING: In order to avoid over
heating, do not cover the Heater.
The Heater is hot when in use. To
avoid burns, do not let bare skin
touch hot surface. Keep
combustible materials, such as
furniture, pillows,beddings, clothes
and curtains at least 3 feet (0.9m)
from air outlet and 1 feet (0.3m)
from air inlet of the Heater.
暖風機不可擺放於有潛在危險的地方使
用(例如：非常潮濕環境、易燃物品或化
學品倉庫)
The Heater must NOT be used in
potentially dangerous location such
as flammable explosive, chemic
alladen or wet atmospheres.

Ceramic Heater
陶 瓷 暖 風 機
Important Safety Information
重要安全提示
2
警告；清理前必須先拔除電源插頭。
WARNING: To avoid danger of electric
shock, unplug from outlet when not in
use and before cleaning.
暖風機設有發聲警報裝置，當機身溫度過熱，
警報器自動發聲提示，應立即關機檢查並立即
停止使用此機。
The Heater includes an audible alarm to
warn when the Heater are overheat. If the
alarm sounds, immediately turn the
Heater off and inspect the Heater .
DO NOT OPERATE THE HEATER WITH THE
ALARM SOUNDING!
暖風機不可擺近水盆、浴缸、花灑、泳池、潮
濕或有積水的周邊環境使用。
The Heater is not intended for use in the
immediate surroundings of a basin, a
bath, a shower, a swimming pool, a wet
or damp locations.
暖風機不適用於室外及作工業用途。
Heater is intended for household use
ONLY, not for industrial or outdoor use.
切勿將任何異物放入機內；或阻擋機身出風口
及入風口；或將暖風機放置在柔軟或不穩固的
表面上(例如床舖)，皆因以上一切行為均會導
致機身過熱，引發短路或火警。
本產品含有可回收材料，不可把本產品作
為未分類廢物。請聯繫當地就近指定回收
點。
This product contains recyclable
materials. Do not dispose this
product as unsorted municipal
waste. Please contact your local
municipality for the nearest
collection point.
220-240V~ 50Hz
使用暖風機前，請確定規格標貼上所示的額定
電壓與當地供電電壓相同。如有疑問可向供應
商查詢。
Before using the Heater, check if the
voltage marked on the rating label
corresponds to the mains in your home.
包裝物料並非玩具，不可讓小孩玩耍。
Do not let children play parts of package.
打開包裝，檢查產品。如發現產品有損壞，請
勿使用及即時聯絡供應商。
Remove the package and ensure that the
Heater is undamaged. In case of doubt
do not use the Heater and contact your
supplier.
拔除插頭時不可拉扯電源線，必須緊握插頭，
把插頭拔出。
Do not pull the power cord to disconnect
with power source. Always grasp the plug
to pull out.
請使用獨立插座。使用萬能插頭或拖板，容易
發生危險。
Avoid using extension cord as the extension
cord may overheat and casue fire.
切勿把暖風機擺放於電源插座之下。
The Heater must not be located
immediately below a socket outlet.
Do not insert any objects into the Heater
as it may cause an electric shock or fire
or damage to the Heater. Do not block or
tamper with the Heater in any manner
while it is in operation, To prevent
apossible fire, do not block air inlet or
oultet in any manner. Do not place on
soft surfaces, like a bed, where opening
may become blocked.
警告：總電源開/關鍵不應作為切斷電源用途。
WARNING: The Main Power Switch and
the On/Off switch should not be used as
the sole means of disconnecting power.

3
Ceramic Heater
陶 瓷 暖 風 機
Main Parts
各部名稱
開關/功率旋鈕
出風口
前殼
Plug
Power Knob
Air Outlet
Front Housing
插頭
Rear Housing
後殼
OSC Switch Button
左右搖擺開關鍵
電源顯示燈
Power Indicator
溫控旋鈕
Thermostat Knob
Base
底座
Bathroom Use
浴室使用
本暖風機已通過IP21防滴要求，可放置於任何室內位置(包括浴室)使用。
如在浴室中使用本暖風機，則必須擺放於與水源(洗手盤/浴缸)及使用者(伸手不能達到)
的0.6米以外位置。
This is a “IP21” heater which is constructed for protection against
splashing and allowed to be in all rooms, including bathroom.
The appliance must be placed 0.6 meter away from water sources, such as
washbasin and bathtub, and out of reach of hands.

Function Setting
功能設定
4
暖風機可使用機身頂部控制旋鈕操作。
1. 小心從包裝取出暖風機。
2. 將暖風機擺放於穩固的平面上。
3. 將開關/功率旋鈕旋轉至關機位置，將插頭插入電壓220-240V的獨立插座。
The Heater may be operated by the control knob located on the Heater.
1. Carefully remove the Heater from the plastic bag and the carton.
2. Place the Heater on a stable flat surface.
3. Set the Power knob to 'OFF' position. Plug the Power Cord into a a.c. 220-240V
electrical outlet.
4. Turn the Power Knob to set the Heater into different MODE: LOW HEAT(750W),
HIGH HEAT(1500W) and FAN.
4. 旋轉開關/功率旋鈕，選擇不同模式運作：低熱(750W)、高熱(1500W)及風扇。
陶 瓷 暖 風 機
Ceramic Heater
5. 溫控操作 - 溫控器可自動控制暖爐開啟或暫停，達到維持於某一溫度的效果。
- 溫控旋鈕調整至最大位置；
- 當室溫達至理想溫度，將溫控旋鈕逆時針方向旋轉，直至電源顯示燈熄滅(暖爐
暫停加熱)；
- 待室內溫度降低後，暖爐自動重新開啟直至達到設定溫度，暖爐再次暫停加熱；
- 暖爐將不斷循環開啟/暫停工作。
5. Thermostat control - The thermostat can control on and off of the Heater to
keep the room temperature at a desired level.
- Turn the Thermostat knob to the maiximun position.
- Once the desired room temperature has reached, turn the knob anti-clockwise
unit the power indicator turn off (the Heater is temporary cut off).
- When the room temperature has decreased, the Heater will turn on automatically,
and will turn off again when the desired temperature has reached.
- It is normal for the Heater to cycle ON and OFF as it maintains the SET TEMP.
6. 按左右搖擺開關鍵，暖風機自動左右搖擺運作。再按左右搖擺開關鍵，暖風機停止
左右搖擺運作。
6. Press the OSC switch button, the heater will start oscillation. To stop the oscillation,
press the OSC switch button again.

Safety Features
特殊安全裝置
5
1. A thermal overload protector is built-in to prevent overheating.
2. When the Heater is overheat, it will be shut off automatically.
2.1. To RESET the Heater: Unplug the Heater and wait for 30 minutes to cool down.
2.2. Turn ON the Heater again to resume operation.
1. 暖風機內置恆溫保護裝置，防止機身過熱。
2. 當機內溫度超出限定溫度，暖風機將自動停止操作。需要重新設置才可恢復正常。
2.1. 拔除插頭，等待30分鐘，讓機內溫度降低。
2.2. 重新插上插頭，讓暖風機正常繼續操作。
警告：不使用本機時，經常保持拔除電源，及切勿將此機浸於水或其他液體中。
清潔前應確保暖風機處於冷卻狀態。
清理：清理時切勿將此機浸於水或其他液體中。
使用吸塵機毛刷將入風口的塵埃及雜物吸走。機身使用濕潤軟布抹擦清潔。
注意：切勿使用含有腐蝕性的清潔劑或溶液清理此機。
儲存：連同使用說明，把暖風機存放於清涼及乾爽的地方。
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO
NOT IMMERSE THE HEATER IN WATER!
MAKE SURE THE HEATER IS COMPLETELY COOL DOWN BEGORE CLEANING
CLEANING: Clean the protective mesh with the vacuum brush attachment on your
vacuum cleaner. Clean the body of the Heater with a soft cloth.
CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners, etc., as they will
damage the Heater. NEVER use ALCOHOL or any other SOLVENTS.
STORAGE: Store the Heater with these instructions in the original box in a cool and
dry place.
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING.
DO NOT IMMERSE THE HEATER IN WATER!
MAKE SURE THE HEATER IS COMPLETELY COOL DOWN BEFORE CLEANING
CLEANING: Clean the Air Inlet with the vacuum brush attachment on your vacuum.
cleaner. Clean the body of the Heater with a soft cloth.
CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners, etc., as they will
damage the Heater. NEVER use ALCOHOL or any other SOLVENTS.
STORAGE: Store the Heater with these instructions in the original box in a cool and
dry place.
Maintenance
清理及維護
陶 瓷 暖 風 機
Ceramic Heater

陶 瓷 暖 風 機
Ceramic Heater
6
Specifcation
技術規格
型號 Model Number
電源 Power Supply
額定功率 Rated Power
產品尺寸 Package Dimension
FH-M48
220-240V~ 50Hz
1500W
90 x 300 x 195 mm
Origin Map
源澤地圖
辦公時間
10:30am - 12:30pm (星期一至五)
02:30pm - 05:30pm (星期一至五)
10:30am - 12:30pm (星期六)
(星期日及公眾假期休息)
OFFICE HOURS
10:30am - 12:30pm (Mon to Fri)
02:30pm - 05:30pm (Mon to Fri)
10:30am - 12:30pm (Saturday)
(Closed on Sunday and Holiday)

陶 瓷 暖 風 機
Ceramic Heater
產品保用証(一年自攜服務)
產品: 陶瓷暖風機
型號: FH-M48
此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享為3個月):
1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，
可獲免費維修和/或零件更換。
2. 以下情況不被包括在保養範圍內：
-若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；
-未經授權之自行處理、維修及/或改裝；
-任何機殼、面蓋，以及配件。
3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。
4. 更換後之任何損壞零件，均屬本公司所有。
5. 本保養服務只適用於香港特別行政區。
6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。
*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途
除外)。請即登入網站: www.origo.hk
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室
電話: 2156 8238
www.origo.hk
Warranty Card(1year carry-in)
Item : Ceramic Heater
Model : FH-M48
Service Centre
ORIGIN MARKETING LIMITED
Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street), 403 Castle Peak Road,
Kwai Chung, N.T., Hong Kong.
Tel: [phone]
www.origo.hk
This product is warranted for 1year (commercial use for 3 months) from the date of purchase under the
following conditions:
1. For any defect, in the judgment of our technician, if it is caused under normal use, we are responsible for
repairing the product, and/or replacing parts at free of charge.
2. This warranty DOES NOT apply to:
- If the product has been damaged through abuse, misuse, negligence or accidents;
- Unauthorized repair, alteration/modification;
- The housing, cover or accessories, is excluded from this warranty.
3. The customer is requested to bring the unit to and from our Service Centre whenever
service is needed.
4. Any defective parts, which had been replaced, shall be of our property.
5. This warranty is valid in H.K.S.A.R. only.
6. Please show the Invoice to get free service.
***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from the date of
receipt, free warranty will be extended to 15 months (not applicable to commercial use). Please enter our
website: www.origo.hk
