osann move-X User manual

Enjoy ●Walking
User Manual

EN
EN Instruction
FOLDING PROCEDURE
6. Push the button of folding webbing on the seat tube button to fix the folding position.
7. Pull up the safety lock on outer side of the handles to release the safety lock.
8. Pull the X folding handle: Use your fingers to pull up the X-folding handle at each side of the rollator
handle.
9. Fold down the rollator frame.
10. After folding, use the buckle webbing to fix the rollator: Put the webbing on the rivet each side to
secure the folded position
1. Pull up the front castor lock to fix the direction of caster(better but not a must).
2. Take off the shopping bag (better but not a must): To grab the bag handle and take off the bag.
3. Push in the bag holding rod (better but not a must): When bag is taken off, push the holding rod inside.
When bag is taken off, push the holding rod inside
4. Adjust the handle to the lowest position.
5. Pull up the folding webbing : The folding webbing is knitted at the left hand side of the seat. Pull it to
fold the rollator horizontally to the Storage status.
How to fold:
How to unfold:
1. Release the folding webbing button.
2. Hold the handle and pull up until a click sound to ensure it’s good to be used.
3. Push the safety lock down to lock the folding handle.
4. Push the seat side tubes down until a click sound.
5. Adjust the handle to the proper position.
6. Pull out the bag holding rod.
7. Clip the bag on the bag holding rod and attach the Velcro on the seat Velrco loop.
8. Push down the castor lock to free the castor .

EN Instruction
.
1. Pull up the fixation lock to release.
2. Pull the fixation knob and turn 90 degree.
3. Adjust the handle to proper position.
4. Turn the fixation knob 90 degree and let
go the knob to fixation position and a click
sound. (If no click sound, fine tune the
handle for a click sound and it shows the
handle is fixed at proper position )
5. Try the handle to ensure it doesn't move
6. Push back the fixation lock to tighten the handle.
Handle height adjustment
Brake
Pull up the brake lever to activate running brake.
Push down the brake lever to activate parking brake.
Folding mechanism
Pull to disengage the rollator frame to start folding.
The safety lock
Up position: prepare to fold the rollator
Down position: After unfolded, push down the
safety lock to secure the folding handle
1. Pull out both tubes attached to the seat and hook the basket up.
2. Hear the click sound to ensure the basket is secured onto the tube.
3. Attach the Velcro on the seat Velcro loop.
Installation of Basket
FEATURES
Fixation Lock
Fixation Knob
Reflector
Cane & Umbrella Holder
Folding mechanism Safety lock

EN Instruction
SPECIFICATION
390 mm
Test according to ISO11199-2
Weight Capacity : 125kg
Bag Capacity: 5kg
Overall Dimension:
L580 X W640 X H775~895mm
Folded Dimension:
L640 X W280 X H390mm
Seat Dimension:
W425 X D190 X H580mm
Backrest:L365 X W255mm
Osann Move X

EN
EN Instruction
• For your health and comfort, be sure to use good posture and hold the rollator so that you can operate
the brakes with ease.
• Please store the rollator in a safe environment.
• Unfold the rollator completely into the locked position before use.
• Possible risk of finger trapping - do not put fingers or hands into the hinge of the rollator when folding or
opening for use.
• Ensure that the wheels are stable and on the ground before using.
• Ensure the brakes are adjusted properly and tested before using.
• Ensure that the seat is locked in position before sitting.
• Always sit in the center or the seat, with the seat adjusted that the user has their feet on the floor.
• Always have the parking brakes locked in position before sitting.
• Never sit on the rollator when it is folded for storage.
• Never stand on the rollator, or use it as a step.
• Never transport a person on the seat of the rollator.
• Use caution when lifting and carrying the rollator.
There is a comprehensive twelve-month warranty form the date of delivery of your new rollator. the
warranty covers the rollator for repairs and replacement during this period. More detailed warranty
information as follows:
1. Any work or replacement part installation must be carried out by an authorized dealer or service agent.
2. Warranty claims must be placed at the outlet form which the rollator was purchased.
3. Any parts of the rollator that require repair or replacement as a result of manufacturing or material defect
within the warranty period will be supplied free of charge.
4. Any repaired or replaced parts will be covered by the balance of the warranty period on the rollator.
5. Under normal circumstances, warranty claims will not be accepted where the following situations occur:
a) The rollator has not been maintained in accordance with the manufacturer's recommendation.
b) Failure to use the manufacturer's specified parts.
c) The rollator is damaged duo to neglect, accident, or improper use.
d) The rollator or parts having been altered form the manufacturer's specification or repairs having been
attempted before the dealer is notified.
The manufacturer reserves the right to alter without notice any weights, measurements, or other technical
data shown in this manual. All figures, measurements, and capacities shown here are approximate and do
not constitute exact specifications. All rights reserved.
WARNINGS
FOR PERSONAL SAFETY
WARRANTY
1. Wipe down your equipment weekly (or more often as needed) with a cloth dampened in a mild
detergent/ water solution.
2. Allow the equipment to dry before using or storing.
3. Store your equipment safely away in a clean, dry location when not in use.
CLEANING METHOD

76-413100-EN01-1503
