Osprey SF Eco User manual

© 2013 OspreyDeepclean Ltd
No part of this publication should be reproduced, duplicated or be made public in any form
whether electronically or otherwise without the express prior permission of OspreyDeepclean
EU Declaration of Conformity
In accordance with the EU Directive on Electromagnetic Compatibility
89/336/EU) in version 93/31/EU
We hereby declare that the machines described below both in their basic design
and construction and in the version marketed by us con orms to the relevant
sa ety and health-related requirements o the appropriate EU Directive.
This declaration shall cease to be valid i modi ications are made to the machine
without our approval.
SF Eco, SF3 / Vac, Dry Steam Cleaner
It is ensured through internal measures that series-production units con orm at
al times to the requirements o current EU Directives and relevant standards.
"The buyer shall take responsibility or the environmentally sa e and legal disposal o
the product at the end o li e and in accordance with the requirements o the WEEE
Regulations 2006. In the case o the UK as described in Regulation 9 (2) o the WEEE
Regulations 2006 the buyer agrees to be responsible or providing disposal acilities or
non household products."
INSTRUCTION MANUAL
SteamForce Range
SF Eco SF3 SF3Vac

1
USER/MAINTENANCE INSTRUCTIONS
IMPORTANT— SAFETY FIRST
Be ore carrying out any installation, connection, or operation o your machine, please
read this manual care ully. It contains important in ormation on how to operate your
machine sa ely and e iciently.
Always keep this manual safe and handy.
The SteamForce range is built in accordance with the “Machine Sa ety Community
Directive 89/392” and subsequent amendments in orce in the European Economic
Community.
GENERAL DESCRIPTION
The SF steam cleaners are designed to clean. degrease and sanitise e ectively using just
clean water hence reducing the use o detergents, disin ectants or solvents.
With super-heated steam ranging between 160º and 185ºC (nominal) delivered at 6 to
10 bar pressure (depending on model) these machines are supreme all-round cleaners,
without the need or chemicals or detergents. Steam cleaning with the SF is easy, e i-
cient, and completely environmentally riendly.
WHAT MAKES THE SF RANGE SO EFFECTIVE
• Reduction o solvents, detergents, disin ectants and residuals
• Reduction o labour costs through increased productivity
• Use only clean water
• Environmentally riendly
SF RANGE SAFETY FEATURES
• Boiler pressure sa ety valve
• Pressure gauge
• Boiler thermostat
• Auto thermostat cut out
• Stainless steel build quality or durability
10

9
Nylon Detail
Brush
A00072
Brass Detail
Brush
A00155
300mm Floor
tool
A00063
Cotton cloth
A03028
Short Nozzle
A03034
Hand Tool 15cm
A00078
Squeegee insert or
hand tool 15cm
A00080
Brush insert or
hand tool 15cm
A00079
Extension tubes
A00055
Squeegee insert
or loor
tool
A00066
Brush insert
or loor
tool
A00068
Suction tool
A00081
Long suction
tool
A00075
Steam & vac hose
3m
A03058
Squeegee Tool
25cm
A00077
Vac Kit A03154
includes :
• 1000W Wet & dry
vaccum
• Metal support
bracket
• Hose and
accessories as
above
A03154 Optional Vacuum kit for SF3 only
Upholstery Tool
(black)
A00173
Carpet insert
or loor
tool
A00065
2
1. Water Tank Filler Cap (rear top)
2. Detergent Containers
3. Main Switch
4. Boiler Switch
5. Ready Light
6. Low Water Indicator
7. Detergent indicator
8. Hose Connecting Socket
9. Steam Volume Regulator
10.Pressure Gauge
DESCRIPTION
2
1
3
4
5 6
8
9
7
10
B
C
A
Pistol grip SF Eco & SF 3
Steam only hose
A - Orange Detergent release switch
B - Red Steam on/o switch
C - Steam release trigger
SF Eco & SF 3
Pistol grip SF 3
Steam & vac hose
A - Detergent release switch
B - Vacuum on/o switch
C - Steam release trigger
D - Steam trigger locking button
A
C
B
D

3
STEAMFORCE MACHINE RANGE SPECIFICATIONS
WARNING: NEVER PULL THE MACHINE BY THE STEAM HOSE. ALWAYS
MANOEUVRE USING THE HANDLES PROVIDED. BREAKDOWNS DUE TO
INCORRECT HANDLING ARE NOT COVERED BY THE WARRANTY.
CONSUMABLES, ACCESSORIES AND STEAM HOSES ARE ALSO NOT COVERED
BY ANY WARRANTY.
MODEL SF3 ECO SF3 VAC
Boiler Capacity 2.3 Litre 3.6 Litre
Water Tank Capacity 5 Litre 5 Litre
Chemical Tank Capacity 2x5 2x5
Heating Up Time (Min) 5 12
Pressure in Use (nominal) 6.0 Bar 8.0 Bar
Max. nominal
temperature
160°C 170°C
Maximum Power 3000w/1700w 3000w
Power Requirement 230v/50Hz 13Amp
(120V 60Hz 14Amp)
230V 50 Hz
13Amp
SF3 Eco and SF3 Standard Steam Accessories
Squeegee Tool
24cm
A03063
Steam only
hose 4m
A03057
Nylon Detail Brush
A03081
50mm Round
Nylon Brush
A03074
Stainless Steel
Detail Brush
A03083
Copper Detail
Brush
A03082
Extension Tubes
A03060 Floor Tool
A03061
Cover or Floor Tool
A03071
Large
Triangular
Brush
A03072
Cotton Cloth
A03028
Short curved
nozzle
A03069
8

7
VACUUM MODELS ONLY
The pistol grip and extension tubes have double locking clips.
Insert the selected accessory ully into the locking clip, rotate it anticlockwise to secure
and slide the secondary lock orward to close the lock.
Check that both parts are tightly connected by gently pulling them apart.
DO NOT USE i the tools are not tightly and correctly connected.
When using the Steam & Vacuum hose or Steam only, DO NOT use Steam Only or
more than 10 minutes at a time. A ter 10 minutes, switch on the vacuum or a ew
minutes to cool the hose and prevent hose deterioration.
EMPTYING THE SOILAGE TANK DURING CLEANING (VACUUMATED ONLY)
It will be necessary to empty the waste tank a ter each use . This will prevent any
blockages or unnecessary interruptions whilst the machine is in use.
I the waste tank is not emptied regularly, an automatic cut o loat mechanism will
activate. Switch o the heating, then the main on/off switch. It is recommended also
to disconnect unit rom the mains power supply.
Open the Vac housing to gain access to the waste tank and remove the lid. Use resh
tap water to rinse out the waste water tank and the tap. Remove any items rom inside
the tank that are likely to cause a blockage. Replace the waste tank and re it the motor
housing. Reconnect the power, switch on the main on/o switch and wait or the
pump to cease operating and then switch on the Heating.
Ensure that the lid and the locking clips are always installed correctly and keep all
other objects out o the area. Never put anything on or around the tank as this may
a ect the per ormance o the unit.
Unclip and
remove the
vacuum
motor head
Ensure
switch on vac
head is in the
on position
Empty the
waste bucket
and clean
thoroughly also
cleaning the
Remove vac
unit rom
the support
rame
B
I vacuum is required press right
on/o switch (B) on the pistol grip
handle o the steam & vac hose
4
SAFETY INSTRUCTIONS
SAFETY
The environment in which you use your machine must meet basic sa ety requirements
i.e. do not use within range o potentially dangerous chemical vapours.
Machine positioning, environment, and overall workspace are also important actors.
Make sure you leave enough space all round to com ortably manoeuvre the machine.
Working in a tight space leaving little or no room imposes poor working posture, makes
movement di icult, and can create hazardous situations.
For the steam unit to work e iciently the ambient temperature should be between 10°
C and 40°C with humidity lower than 90%.
USE OF DETERGENTS DISCLAIMER
WE RECOGNISE THAT IN CERTAIN SITUATIONS THE ADDITION OF A DETERGENT CAN
ASSIST THE POWER OF STEAM AND SPEED UP THE CLEANING PROCESS. WE CAN ONLY
SUGGEST AS A GENERAL GUIDELINE THE USE OF NON -CLASSIFIED DETERGENTS
ACCORDING TO COSHH REGULATIONS, OF NEUTRAL PH VALUE, FROM REPUTABLE
MANUFACTURERS.
OSPREYDEEPCLEAN WILL NOT ACCEPT ANY RESPONSIBILITY AND WILL NOT BE LIABLE
FOR ANY DAMAGES RESULTING FROM THE USE OF ANY AGGRESIVE DETERGENTS OR
CHEMICAL AGENT WITH OUR MACHINES AND THE USER REMAINS SOLELY RESPONSI-
BLE FOR ANY POTENTIAL DAMAGES.
NEVER ADD DETERGENTS INTO THE BOILER OR WATER CONTAINERS INTENDED FOR
BOILER REFILLING
MAINTENANCE
As the machine is operated with tap water, it should be de-scaled regularly in order to
maximise its use ul li e and maintain top operating per ormance. The requency with
which this is done will depend upon the degree o water hardness and the amount the
appliance is used. With an average water hardness we recommend that the unit be
de-scaled at least every six to twelve months.
DISCLAIMER
Neither OSPREYDEEPCLEAN Ltd., nor its a iliates shall be liable to the purchaser/hirer
or third parties or damages, losses, costs or expenses incurred by the purchaser/hirer
or third parties as a result o : accident, misuse or abuse o the product(s) or
unauthorised modi ications, repairs or alterations to the product(s), or ailure to
comply with OSPREYDEEPCLEAN’s operating and maintenance instructions.

5
SF — OPERATING PROCEDURE
Please check all items and surfaces to be cleaned for colourfastness and heat
sensitivity. OspreyDeepclean cannot take responsibility for any damage caused
through lack of attention to this point.
REMEMBER: THIS UNIT IS NOT A TOY
Special care must be taken when using it while children are in the vicinity.
The steam should never be directed at persons or animals.
The following must be observed when using the steam unit
ALWAYS Check be ore use that the power supply cable, plug and sockets are in good
condition; check or visible signs o damage (do not use i damaged)
ALWAYS Follow the correct procedure when illing the water reservoir and detergent
container
ALWAYS Wear ull PPE (personal protective equipment) when working in con ined
spaces - mask, goggles, gloves, overalls.
NEVER allow children, inexperienced, untrained or unauthorised people access to the
steam unit
NEVER allow any part o the steam unit to be immersed in water
NEVER add detergents or any other cleaning chemical to the boiler water tank. Use the
separate containers provided.
ALWAYS ensure that the electrical data on the rating plate corresponds to your local
power supply.
ALWAYS Disconnect the unit rom the power whenever it remains unattended or not
in use. Always disconnect when illing the tank or cleaning the appliance.
ONLY use your steam machine as instructed in this Manual.
ALWAYS use original replacement parts or accessories.
NEVER disconnect the plug rom the wall outlet by pulling the power cable.
ALWAYS Make sure that the power cable does not come into contact with hot sur-
aces.
NEVER Do not use the appliance i it, the accessories or power cable are in any way
damaged. All checks and repairs should only be per ormed by authorised service re-
pair locations. Dismantling or repairs done by non-quali ied persons could be danger-
ous and would void the guarantee.
ALWAYS store in a dry, ventilated room and only when it has cooled o .
• Remove water cap 1) on machine and ill with clean cold WATER ONLY—NEVER
put detergent or chemical
• Fill Detergent container 2) with appropriate detergent i required
• Find a suitable electric socket and plug in.
• Press the on/o switch 3) to the on position
• Press the boiler switch button 4) to on position
• Wait 7-8 minutes until the green light 5) stops lashing. Machine is now ready
• Connect steam hose to inlet 8)
• Select the required accessory and push irmly onto the pistol grip until it clicks in
• Connect steam by irst pressing the red switch B ) and then release steam by
pressing trigger switch C)
• Set steam volume required on machine regulator knob 9) DO NOT FORCE
• I detergent is required press the lower button A) on pistol grip. Detergent will
then be released automatically in combination with the steam and orange light (7)
will illuminate.
• Re ill with water 1) when red indicator light 6) comes on
2
1
3
4
5 6
8
9
7
10
6
SF Eco /SF3 Operating Instructions
B
C
A
A
C
B
D
Steam only hose
Steam & Vacuum hose
