Osram ARCHISHAPE 2.0 Linear User manual

• Please read instruction carefully before
assembling and installation
• Please keep instruction as reference in the future
ARCHISHAPE®2.0 Linear Power

W
HH1
H2
L
2
ARCHISHAPE®2.0 Linear Power
Weight
(g)
Rated
power
(W)
Input
current
(A)
Rated voltage
(V) IP
Maximum
projected area
(m2)
300mm 1800 20 0.09
220-240 66
0.039
500mm 3000 34 0.18 0.065
1000mm 5000 70 0.36 0.13
Max. connected qty.
(1.5mm2master cable)
Rated power 220-240V
300mm 20W 30 pcs
500mm 34W 30 pcs
1000mm 70W 16 pcs
Above calculation is based on 1.5mm2cable. Please consult local sales for other calculations.
Signal amplifier is required when the distance between adjacent luminaires is more than 80 meters,
or more than 32 luminaires are connected.
L W H H1 H2
300mm
75mm 149mm 79mm 70mm500mm
1000mm

D
6x35mm
90° 90°
1
2
“click”
1
2
3
ARCHISHAPE®2.0 Linear Power
D
Max
300mm 100mm
500mm 300mm
1000mm 800mm
1
2
4
3

18
26
11
8
ASL 2&3-pin Connector Socket End Cap CE
AM259050055
ASL 3-pin AC Power Starter Cable 600 CE
AM251620055
16.8
56 600
50
10.2 Label
Strip wire 10mm
with copper
terminals
10.2
ASL 3-pin AC Interconnection CAB 1000 CE
AM251630055
ASL 4-pin DATA Starter Cable 2m
AM296170055
9.5
2000
50
ASL 4-pin Interconnection Cable 1m
AM296150055
9.5
19.1
59 1000
ASL 4-pin Connector Socket End Cap
AM296160055
59
19.1
4
ARCHISHAPE®2.0 Linear Power

Brown
L (AC)
Blue
N (AC)
Green/Yellow
Female connector
Female connector
Male connector
AC 220-240V
IP66 conjunction box 3-pin starter cable 3-pin interconnection
1000mm (optional) Use end cap for
final fixture in chain
Female
connector
AC 220-240V
DMX in
IP66 conjunction box
3-pin starter cable
4-pin starter cable
3-pin interconnection
cable(optional)
4-pin interconnection
cable(optional)
Green/Yellow
Brown
DMX+
GRAND
Blue
DMX–
Black
ADDRESS
Brown
L (AC)
Blue
N (AC)
Green/Yellow
Use end cap for
final fixture in chain
Use 4-pin end cap
1. Do not connect the ADDRESS wire for
the first fixture.
2. Do not connect GRAND to earth, but
connect GRAND with DMX controller.
Female
connector
5
ARCHISHAPE®2.0 Linear Power
5B - DMX version
5A - On O version

6
ARCHISHAPE®2.0 Linear Power
After connecting the cables, tangle up with
water-proof tapes for extra protection.
૶থࡻ၍મথཀྵࢫLjႴ๑ᆩᆫዊݞ຤ঌټܔথཀྵ
૶থت৊ႜ׀ජᅜ༵ࠃܮྔԍࢺă
ాତрቢ៞ତᐝޢĂᅮֹϡᐹኳ֨ቱ૲၆ତᐝ
ాତ఍ซҖᜇᖒͽ೩ֻᗝγ᜕ܲĄ
Handle the fixture with care. Do not pull or handle
the lead cables and connectors.
Ҿጎڨ้ᆌൟధൟݣăൎက༵ઙڨڦ၍મࢅথཀྵă
щ྅፶׍ᑕᅅᅅٸĄ೩ٛ፶׍۞ቢ៞׶ତᐝĄ

1. The luminaire should be installed and maintained by qualified electrician and wired in
accordance with the latest IEE electrical regulations or the national regulations. Terminal block
not included. Installation may require advice from a qualified person.
2. Make sure the products are grounded.
3. The power must be OFF during installation and maintenance.
4. The external flexible cable or cord of this luminaire cannot be replaced. If the cord is damaged,
the luminaire shall be destroyed.
5. The light source of this luminaire can not be exchanged; if the user needs to exchange the light
source (e.g. the light source is at the end of its life cycle), then the completed luminaire has to
be exchanged.
6. Installation: Surfac e mounted. Outdoor use. No mounting height limited.
7. Make sure the products are securely installed.
8. The housing might become hot during or after operation.
9. No modification on the product is allowed.
10. Suitable for indoor and outdoor use. Do not immerse in water.
11. Not suitable for ordinary lighting in household room illumination.
12. Power supply system should be equipped with SPD (Surge protection Device) accordance
with electrical regulations.
13. For DMX version, reinforced insulation has been complied between LV supply and control
conductors.
WARNING:
C10449057
G15066404
2019-07-04
1. Order all power supplies / cables / connectors / controllers / signal amplifers / IP66 junction boxes separately.
2. Connect luminaires to main power supply & DMX cable by IP66 junction box (purchased by customer).
Make sure the wiring is correct and reliable. Suggest to wrap the connectors by waterproofed tape for security.
3. Regular check and cleaning are required.
4. Do not stare at the operating light source. The luminaire should be positioned so that prolonged staring into the
luminaire at a distance closer than 2m is not expected
5. Suggest to use shielded twisted-pair as signal cable. Terminate each DMX line with a 120 ohm resistor to get
stable DMX signal.
6. DMX version requires addressing tool to address the luminaires.
7. Signal amplifer is recommended when the distance between controller and the first luminaire is over 100 meters.
INSTRUCTION:
