Osram M51 User manual

M51 New Strobe Light
768 * 0.5W RGB 3in1；96*10W White LED Strobe
Light
User manual
P le ase rea d t he ins t r u ction s ca refu ll y before use

2
TABLE OF CONTENTS
1. Safety Instructions ...........................................................................3-4
2. Technical Specification ....................................................................5-6
3. Display and Menu...............................................................................6-8
4. DMX List ...........................................................................................9-21
5. Product Size .......................................................................................22
6. Attention ..........................................................................................22
7. Fixture Cleaning ...............................................................................23
statement
Fixtures should be fastened on the hooks with screws. Make sure the
installation is secure to prevent chattering and slipping during operation. Also
make sure that the structure of the connected luminaire can support the
luminaire 10 times the weight. At the same time, when installing the lamps,
they also use a safety rope to support the weight of the lamps by 12 times.
The installation of the equipment should be carried out by professionals, and it
should also be installed in places where people can't reach them casually or
where no one is free to pass by.

3
1. S af ety I nst r uctions
Please keep this User Guide for future consultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using
the unit.
Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order
to avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at
least 50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while operating
as it is fire hazard.
Use safety cable when fixes this unit. DO NOT handle the unit by taking its head
only, but always by taking its base.
Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the
temperature is higher than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hand during its operation. Turn off the power
and allow about 15 minutes for the unit to cool down before replacing or serving.
In the event of serious operating problem, stop using the unit
immediately.Never try to repair the unit by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the

4
nearest authorized technical assistance center. Always use the same type
spare parts.
DO NOT touch any wire during operation as high voltage might be causing
electric shock.
Warning:
To prevent or reduce the risk of electrical shock or fire, do not expose the unit
to rain or moisture.
DO NOT open the unit within five minutes after switching off.
The housing, the lenses, or the ultraviolet filter must be replaced
if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing
or attempt any repairs yourself. In the unlikely event your unit may require
service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket. Always ensure
that the unit is firmly fixed to avoid vibration and slipping while
operating. And make sure that the structure to which you are attaching the
unit is secure and is able to support a weight of 10 times of the unit’s weight.
Also always use a safety cable that can hold 12 times of the weight of the unit
when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people.

5
2. Technical Specifications
Light source: 768*0.5w RGB 3-in1 LED ,96*10w white led (6000K)
● Lamp life: ≥50000 hours
● Input voltage: AC100-250V ,50-60Hz
● Full power :1200W,Power factor PF≥0.98
● Beam angle: 130°
● Color system: RGB 3-in-1 + White LED
Control
DMX Channel:10/15/25/29 CH
Control Modes: DMX512/mater-Slave/Auto Run/Music/RDM
Pan/Tilt
Pan/:540°, accuracy 2.11°/step, fine-tuning accuracy: 0.008°;
Tilt:270°, accuracy 0.86°/step, fine-tuning accuracy: 0.0034°;
Using magnetic coded reset system
Construction
Menu display: 1.8-inch LCD color display; Chinese and English can be
switched at will, and the font can be reversed 180° display;
Data In/Out socket: 3-pin & 5-pin XLR sockets
Protection Rating: IP20
Working temperature: -10℃～45℃
Electronic control technology:
Menu or console control lamp reset;
0-100% dimming;
Constant current drive mode;
Temperature sensor detection, intelligent adjustment of light source power;

6
Lamp information query;
Intelligent fan speed control
Effect configuration:
full optical domain dimming, 65536-level dimming accuracy;
Fast strobe 1~25Hz;
White light is divided into 4 areas to control, and color is divided into 12 areas
to control;
Preset 56 kinds of effect macro function
Specification:
Dimension : 376×490×388mm; NW: 17kg;
3.Display and Menu:
Display:

7
MENU To select the programming functions
DOWN To go backward in the selected functions
uP To go forward in the selected functions
ENTER To confirm the selected functions
Set DMX Address Code
1 Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter
into
2 Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"
keys to amended
3 Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not
save and Exit
Menu
1.Mic Sense
001 - 100
Sound sensitivity adjustment
2.Language
English
Chinese
3.No Signal
1.（Black Out) 2.(Hold)
4.Fan Set
1.Auto 2.Low 3.High
Fan settings
5.Reset
Yes
No
6.Default
1.Yes 2.NO
Reset
7.Adjust
Pass Word：****
Pan
Change the value of Pan/Tilt to
correct the angle
Tilt
Address
Setting from 001 - 512
Rever
Pan Invert
1.YES 2.NO
X forward and reverse settings
Tilt Invert
1.YES 2.NO
Y forward and reverse settings
Display
1.YES 2.NO
Display font forward and

8
reverse settings
Information
1.CH Value
Each channel show CH value
2.Temp ____℃
Show the temperature of led
board
3.Soft V1.0
Show the version number
Channel
10 channels
15 channels
25 channels
29 channels
Mode
DMX 512
AUTO
Master/Alone
SOUND
Master/Alone
Manual
Master
Pan:0--255
Manual Control
Tilt:0--255
Red：0--255
Alone
Greed：0--255
Blue：0--255
White：0--255
Strobe：0-255

9
4. DMX Channel List:
Model 1 - CH 10
Channel
Display
Function
Value
CH-1
Pan
0-540° Pan control
0 --- 255
CH-2
Tilt
0-205° Tilt control
0 --- 255
CH-3
Dimmer
Linear dimming dark to bright
0--255
CH-4
Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
Random strobe
204--255
CH-5
Middle
White dimming
0--255
CH-6
Both sides
Red dimming dark to bright
0--255
CH-7
Both sides
Green dimming dark to bright
0--255
CH-8
Both sides
Blue dimming dark to bright
0--255
CH-9
Dimming mode
Model 1
0--49

10
CH-9
Dimming mode
Model 2
50--99
Model 3
100--149
Model 4
150--255
CH-10
Reset
NO
0-250
Reset within 5s
251--255
Model 2 - CH 15
Channel
Display
Function
Value
CH-1
Middle
White dimming
0--255
CH-2
Middle
White fine-tuning
0--255
CH-3
Middle
Total dimming is linear dimming
from dark to bright
0--255
CH-4
Middle
Total dimming, fine-tuning control
0--255
CH-5
Middle - Strobe
On
0--3
Synchro strobe speed
4--203

11
From slow to fast (1HZ-25HZ)
Random strobe
204--255
CH-6
Both sides
Red dimming dark to bright
0--255
CH-7
Green dimming dark to bright
0--255
CH-8
Blue dimming dark to bright
0--255
CH-9
Total dimming is linear dimming
from dark to bright
0--255
CH-10
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
Random strobe
204--255
CH-11
Pan
0-540° Pan control
0 --- 255
CH-12
Tilt
0-205° Tilt control
0 --- 255
Model 1
0--49

12
CH-13
CH-13
Dimming mode
Dimming mode
Model 2
50--99
Model 3
100--149
Model 4
150--255
CH-14
Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
Random strobe
204--255
CH-15
Reset
NO
0-250
Reset within 5s
251--255
Model 3 - CH 25
Channe
l
Display
Function
Value
CH-1
Pan
0-540° Pan control
0 --- 255
CH-2
Tilt
0-205° Tilt control
0 --- 255

13
CH-3
Pan/Tilt speed
Speed from fast to slow
0--255
CH-4
Middle-dimming
linear dimming from dark to
bright
0--255
CH-5
CH-5
Middle-Strobe
Middle-Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
CH-6
Random strobe
204--255
Middle-White
White dimming dark to bright
0--255
CH-7
Middle-Static
pattern
No effect
0--16
Monochrome pattern 1
17--33
Monochrome pattern 2
34--50
......(One of 17)
......
Monochrome pattern 13
221--237
Monochrome pattern 14
238--255
No effect
0--9

14
CH-8
CH-8
Middle-Dynamic
pattern
Middle-Dynamic
pattern
Dynamic pattern 1
10--19
Dynamic pattern 2
20--29
......(One of 10)
.......
Dynamic pattern 10
100--109
Dynamic pattern 11
110--255
CH-9
Middle-dynamic
pattern speed
(with 8 CH)
No effect
0--9
Forward, from fast to slow
10--132
Go backward, from slow to fast
133--255
CH-10
Pattern effect
Pattern effect fade
0--255
CH-11
Both side-Dimmer
Linear dimming dark to bright
0--255
CH-12
Both side-Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
Random strobe
204--255

15
CH-13
Both sides
Red dimming dark to bright
0--255
CH-14
Both sides
Green dimming dark to bright
0--255
CH-15
Both sides
Blue dimming dark to bright
0--255
CH-16
Both
sides-dynamic
pattern
No effect
0--9
Dynamic pattern 1
10--17
Dynamic pattern 2
18--25
......(One of 8)
.......
Dynamic pattern 30
242--249
Dynamic pattern 31
250--255
CH-17
Both sides-Pattern
translation (with
16 CH)
Select pattern scene
0--255
CH-18
Both sides-Pattern
self-propelled
speed (with16 CH)
no effect
0--9
Forward, from fast to slow
10--132
Go backward, from slow to fast
133--255

16
CH-19
Both
sides-background
total dimming
Linear dimming dark to bright
0--255
CH-20
Red dimming
Linear dimming dark to bright
0--255
CH-21
Green dimming
Linear dimming dark to bright
0--255
CH-22
Blue dimming
Linear dimming dark to bright
0--255
CH-23
Dimming mode
Model 1
0--49
Model 2
50--99
Model 3
100--149
Model 4
150--255
CH-24
Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203
Random strobe
204--255
CH-25
Reset
NO
0-250

17
Reset within 5s
251--255
Model 4- CH 29
Channel
Display
Function
Value
CH-1
Pan
0-540° Pan control
0 --- 255
CH-2
Pan fine-tuning
Pan fine-tuning control
0 --- 255
CH-3
Tilt
0-205° Tilt control
0 --- 255
CH-4
Tilt fine-tuning
Tilt fine-tuning control
0 --- 255
CH-5
Pan/Tilt speed
Speed from fast to slow
0--255
CH-6
Middle-dimming
linear dimming from dark to
bright
0--255
CH-7
Middle-fine-tuning
Dimming fine-tuning control
0--255
CH-8
Middle-Strobe
On
0--3
Synchro strobe speed
4--203

18
From slow to fast (1HZ-25HZ)
CH-9
Random strobe
204--255
Middle-White
White dimming dark to bright
0--255
CH-10
Middle-White
fine-tuning
White fine-tuning
0--255
CH-11
Middle-Dimming
mode
Model 1
0--49
Model 2
50--99
Model 3
100--149
Model 4
150--255
CH-12
Middle-Static
pattern
No effect
0--16
Monochrome pattern 1
17--33
Monochrome pattern 2
34--50
......(One of 17)
......
Monochrome pattern 13
221--237
Monochrome pattern 14
238--255

19
CH-13
CH-13
Middle-Dynamic
pattern
Middle-Dynamic
pattern
No effect
0--9
Dynamic pattern 1
10--19
Dynamic pattern 2
20--29
......(One of 10)
.......
Dynamic pattern 10
100--109
Dynamic pattern 11
110--255
CH-14
Middle-dynamic
pattern speed
(with 13 CH)
No effect
0--9
Forward, from fast to slow
10--132
Go backward, from slow to fast
133--255
CH-15
Middle-Pattern
effect
Pattern effect fade
0--255
CH-16
Both side-Dimmer
Linear dimming dark to bright
0--255
CH-17
Both side-Strobe
On
0--3
Synchro strobe speed
From slow to fast (1HZ-25HZ)
4--203

20
Random strobe
204--255
CH-18
Both sides
Red dimming dark to bright
0--255
CH-19
Both sides
Green dimming dark to bright
0--255
CH-20
Both sides
Blue dimming dark to bright
0--255
CH-21
Both
sides-dynamic
pattern
No effect
0--9
Dynamic pattern 1
10--17
Dynamic pattern 2
18--25
......(One of 8)
.......
Dynamic pattern 30
242--249
Dynamic pattern 31
250--255
CH-22
Both sides-Pattern
translation (with
21 CH)
Select pattern scene
0--255
CH-23
Both sides-Pattern
self-propelled
no effect
0--9
Forward, from fast to slow
10--132
