English

07
Security instructions
1 Security instructions
Please read the safety instructions, provided in a separate manual, carefully.
Make sure that the environmental, mounting, and installation prerequisites
are met. This manual should be kept at a safe place and in reach of the
installation.
1.1 Symbols
!
The exclamation mark warns about possible damage of the
device itself or connected devices.
i
The information symbol gives general hints and informs
about handling and procedures for use of the device.
1.2 General security instructions
!
Connect cables and data only when the device is powered
down.
!
The device must be supplied by a separate certied SELV
Class 2 power supply.
!
The maximum length of each connected cable is 30 m.
i
If safety instructions are missing, please contact OSRAM to
receive a new copy.

08
General device description
2 General device description
e:cue SYMPL Nodes are a system of interfaces for e:cue SYMPHOLIGHT
only. They provide various connection types like DMX512, DALI, digital
inputs and outputs etc. SYMPL Nodes always operate in online mode, as a
device interface for SYMPHOLIGHT. All interactions are initiated and
controlled by SYMPHOLIGHT. Connections between servers, Cores and
Nodes are always made with e:net via Ethernet.
The e:cue SYMPL e:bus Node is a single channel e:bus interface for use
with e:cue’s lighting control solution SYMPHOLIGHT. It provides an e:bus
interface for up to eight e:bus devices like e:cue GLASS TOUCH terminals.
The e:cue SYMPL e:bus Node is powered by an external power supply or
via Ethernet PoE. It is easily mounted on standard 35 mm DIN rails, or with
a key hole in the housing base on walls or on any stable vertical surface.
The e:cue SYMPL e:bus Node is a simple, reliable and easy to use interface
solution for e:cue lighting control solutions with SYMPHOLIGHT.
2.1 Delivery content
Delivery content for the e:cue SYMPL e:bus Node (AB444210035):
1. e:cue SYMPL e:bus Node
2. Safety instructions
3. Installation guide (English only)
i
To operate SYMPL Nodes a SYMPHOLIGHT version 2.0 or
higher is mandatory. Earlier versions do not support the
SYMPL Nodes. SYMPL Nodes are not supported by the
e:cue Lighting Application Suite.
i
e:cue SYMPL e:bus Node is not hot-pluggable.

09
General device description
2.2 Connectors and interfaces
View from top
1e:bus topology:
left: free topology
right: bus topology
2e:bus interface
(– – + +, left to right)
3e:bus status LED
4Error LED
5e:net LED (Ethernet,LAN activity)
6Status LED (Device status)
7Identify button
8Power supply
(Vcc+, Vcc– left to right)
9e:net / Ethernet
2.3 User interface: LEDs
The SYMPL e:bus Node has four LEDs. The four LEDs show the basic
states of the SYMPL Node.
LEDs
Status On: If constantly on, the device is online. Server
application is in operation.
Blinking: If blinking in one second intervals, the device is
ofine, no connection to a SYMPHOLIGHT server or
Core is available. If blinking more rapidly, the device is in
bootloader mode.

10
General device description
e:net Off: no link available.
On: link established.
Blinking: e:net trafc.
Error Off: no error detected.
On: If constantly lights in red, an error occurred. This
can be an internal error or malfunction of the device, or
an external error, e.g. a shortcut of interface
connections or alien power supply. Switch the device off
and on. If the error persists, check the wiring or contact
OSRAM Service.
Status +
Error
The Status and Error LED blink simultaneously to
identify the SYMPL Node (enabled “Identify Interface
Mode” in SYMPHOLIGHT).
e:bus status Off: no e:bus activity.
On: e:bus activity.
2.4 Identify button: Identification & Reset
The Identify button has two functions: to send an Identify message (A) and
to reset the Node (B).
(A) A short press during operation in online mode sends an Identify
message to the server. This helps to assign the Node in the Layout in
SYMPHOLIGHT.
(B) The Identify button can also be used to reset the device to factory state
or to stay in bootloader mode:
• Keep the Identify button pressed while powering up, Status and
Error light up at rst. Bootloader mode is signaled by a fast blinking
Status LED. Release the button now. The device stays in bootloader
mode to download a new rmware.
To exit the bootloader mode, short press the Identify button again.
• Press the Identify button until Status and Error LEDs blink

11
General remarks
alternating, then blink together. Releasing the button now resets the
device to its factory settings. The password and other settings are reset
to their default values. Please note that the Ofine Content cannot be
reset. To employ a reset Startup behavior, a restart of the device is
required.
• Keeping the button pressed further on, the device proceeds to
normal operation. No changes apply.
3 General remarks
3.1 Transport
Only transport the device in its original packaging. This protects the device
from damage.
3.2 Unpacking
Only unpack the e:cue SYMPL e:bus Node at its installation location. To
protect the device against condensation water, unpack it and wait until all
moisture remaining in the device has evaporated. Condensation can occur
when the device is moved from a cold to a warm location. Keep the
packaging for use in case of further transport. Inspect all parts for
completeness regarding chapter „2.1 Delivery content“ on page 08. If
there is apparent damage to the device or parts are missing from the
delivery scope, please contact the OSRAM Support service.
3.3 Warranty regulations
Depending on the product, guaranty regulations are of different duration.
The warranty time is usually noted in the quote and in the order
conrmation. See “Services”  “OSRAM Guarantee” at www.osram.com
for details. Legal warranty regulations apply in any case.

12
General remarks
3.4 Maintenance and Repair
This device requires no maintenance.
3.5 Disposal
The proper disposal of packing materials and of the device is the
responsibility of the respective user and for his account; in all other matters,
the retrieval obligation for packing materials and the device is subject to the
statutory regulations.
3.6 Support
In case of technical problems or questions regarding installation and repair
please contact:
OSRAM GmbH
Customer Service
Karl-Schurz-Str. 38
33100 Paderborn, Germany
[phone]
[email protected]
!
Before dismounting, appropriate measures must be taken to
protect the respective components against damage caused
by electrostatic discharge (ESD protection).
!
Do not try to repair the device. Return it to your OSRAM
distributor for replacement or repair.
Batteries and technical appliances must not be disposed of
with domestic waste, but should be handed in at the
appropriate collection and disposal points.

13
Installation
4 Installation
The installation of the SYMPL e:bus Node consists of mounting the device,
connections to e:bus devices, to e:net, and to power supply.
The sequence of cabling is not dened. Supply the SYMPL e:bus Node
with power after all cabling is completed; it starts booting.
4.1 Installation conditions
Installation position: Terminals on top and bottom
Horizontal spacing: No spacing necessary
Minimum vertical rail grid spacing: 115 mm (90 + 25 mm)
(excluding conduit)
Recommended vertical rail grid spacing: 160 mm (with 40 mm conduit)
Installation location Indoor
4.2 Mounting process
The e:cue SYMPL Node is designed to mount onto a 35 mm DIN rail
(EN 60715) in a vertical position.
1. Clip the device to the rail from
top.
2. Gentle pressure is then
applied to the top front to snap it
in place. The SYMPL e:bus Node
has been mounted successfully.
!
Connect cables and data only when the device is powered
down.
!
Each cable should not exceed a length of 30 m.

14
Installation
You can also mount the e:cue SYMPL Node on any at vertical surface.
Use a 3 to 3.5 mm screw for the hanger hole.
For mechanical stability, mounting on a rail is recommended.
4.3 Ethernet connection
The pin-assignment of the Ethernet port corresponds to RJ45 standards.
You can use every common Ethernet component, like cable, splitters, and
switches. Connect the SYMPL e:bus Node at the designated Ethernet
interface with a patch cable (RJ45, CAT5).
4.4 e:bus connection
The SYMPL e:bus Node can control up to eight e:bus devices with its e:bus
interface. Connect e:bus devices to the SYMPL Node using 4-pin terminal
plugs at the e:bus interface of the SYMPL Node.
The appropriate pin assignment is dened as follows:
From left to right: -, -, +, +
It is recommended to use twisted pair cabling.
Bus conguration
The e:cue SYMPL e:bus Node has a switch to select if a straight bus or a
free bus topology is used:
left: free topology
right: bus topology.
i
Never connect more than one SYMPL Node in factory state
to a network. The identical IP addresses will conict and
disturb proper communication.
i
The Ethernet port of the SYMPL Node is not designed for
inter-building connections with power and lighting transients.
Use only intra-building networks to connect the SYMPL
Nodes and Cores.

15
Network conguration
4.5 Power supply
The e:cue SYMPL e:bus Node can be powered by an external power
supply or via Power-over-Ethernet.
PoE:
For PoE, simply connect an Ethernet connection from a power sourcing
device.
External power supply:
Connect the SYMPL e:bus Node to a certied NEC Class 2 24 V DC power
supply unit. Present power supply equates to the status “On” or running of
the SYMPL Node.
To connect the device to a power supply unit, use the provided 2-pole
terminal and lay the wires as stated on the front label. The voltage
assignment is left V+ and right V-.
Turn the power on when all cables are connected to the
SYMPL e:bus Node. The device starts booting. The device has nished
booting and is in operation when the LED Status is ashing.
5 Network conguration
The conguration of the e:cue SYMPL e:bus Node is done via e:cue
SYMPHOLIGHT. See the SYMPHOLIGHT System Manual for details on
conguration, available at www.ecue.com.
The network properties of the SYMPL e:bus Node are precongured. The
successful installation of the power supply is required for changing the
!
The SYMPL e:bus Node is not suited for powering over a DC
power supply network. Use a separate certied SELV Class 2
power supply unit in the control cabinet for supplying 24 V
DC to the SYMPL e:bus Node.

16
Network conguration
network conguration. You can either adjust the network settings with
SYMPHOLIGHT or using the web interface of the SYMPL e:bus Node.
5.1 Default network properties
The SYMPL e:bus Node has as factory setting the default IP address
192.168.123.1.
DHCP is enabled by default.
To change the network conguration use either SYMPHOLIGHT or the web
interface of the SYMPL e:bus Node:
5.2 Network configuration with SYMPHOLIGHT
1. Open the context menu of the SYMPL e:bus Node in the Setup tab
of SYMPHOLIGHT by a right-click on the device.
2. Select “Congure Network”:
3. Dene the IP address, the subnet mask and the DHCP settings to
your needs:
4. Click “Apply” to submit the changes.

17
Network conguration
The network conguration of the SYMPL e:bus Node is completed.
5.3 Network configuration with the web interface
1. Open a common web browser on a connected PC. Enter the
SYMPL e:bus Node's IP address into the address bar:
e.g. http://192.168.123.1
The web interface of the SYMPL e:bus Node is displayed:
2. Click “Congure” to access the network conguration page:
3. Dene the network settings at “Device Basics” to your needs. You
can also change the password for entry to the web interfaces of the
SYMPL e:bus Node here.
4. Click “Submit” to apply the settings.
The network conguration of the SYMPL e:bus Node is completed.

18
Firmware Update
6 Firmware Update
To update the SYMPL e:bus Node, a connection of the SYMPL e:bus Node
to SYMPHOLIGHT is required.
Updating with SYMPHOLIGHT
Use the usual update options in the Device Tree of the Setup tab in
SYMPHOLIGHT: select “Update rmware” in the context menu of the
SYMPL e:bus Node or click the Update button in the head toolbar.
7 Dismounting
Disconnect all attached cables. Dismount the e:cue SYMPL e:bus Node
from the rail by pulling the black DIN rail handle and unhitching the SYMPL
Node. The dismounting is completed.
i
The employment of a discrete network is recommended.
i
Note down all employed and, if applicable, reserved IP
addresses. Keep the information for future network
congurations.
i
You can change the login password to the
SYMPL e:bus Node's conguration page and the device
name of the SYMPL e:bus Node at “Settings” page. Do not
forget the new password.
!
Before dismounting, appropriate measures must be taken to
protect the respective components against damage caused
by electrostatic discharge (ESD protection).

19
Product specications
8 Product specications
Product number AB444210035
Dimensions (W x H x D) 53.5 x 90.5 x 62 mm
0.76 x 0.30 x 0.20 in
(without fastening clip)
Weight 100 g
Power supply input 24 V DC on screw terminal
wire gauge: 0.25 ... 2.5 sqmm
(0.5 sqmm for exible wires with
ferrules)
or Power over Ethernet (PoE), IEEE
802.3af
Power consumption max. 6.5 W
Operating temperature 0 … 50 °C / 32 … 122 °F
Storage temperature -10 ... 70 °C / 14 ... 158 °F
Operating / storage humidity 0 … 80%, non-condensing
Protection class IP20
Electrical safety SELV
Housing Self extinguishing blend PC / ABS
UL document E140692
Mounting on 35 mm DIN rails
EN 60715, width: 3 units
or wall mount with 1 x 3 ... 3.5 mm screw
Interface specications
User interface 4 LED indicators (e:bus status, Error, Ethernet, Device
status)
1 push button

20
Certications
System links 1 x e:net / Ethernet, RJ45 CAT5 shielded
e:bus Interface VBUS = 19 V
max. load current = 240 mA, fused
no hot-plug support
9 Certications
e:cue SYMPL e:bus Node is certied according to
EN 55022, EN 55024, 62368-1 Ed. 2
4000805
Conforms to ANSI / UL Std. 60950-1
Certied to CSA Std. C22.2 NO. 60950-1
