Osstell IDx Installation and user guide

Osstell IDx | How to Create a Backup
1
2
First make sure you have a WiFi
connection, then click the settings
symbol in the lower le corner and select
”More”.
Select Net Service and click Ok next
to ”Manage Backups”.
1
Backups of your Osstell IDx data can be saved on Osstell Connect or on a USB stick.
Backup to Osstell Connect

4
3
Once the backup is complete, you can nd it under the ”Import” tab, where you will be
able to restore it if needed.
2
Select the ”Export” tab, then click ”All”
and then click the ”Export” button.
It is possible to save three dierent backup versions. Since the Osstell IDx backs up
your data automatically on a regular basis, the oldest backup will be deleted when a
new one is created.
You are also able to create a backup to a USB stick.

3
1
The IDx will automatically open the USB
folder. Select the Export tab, then click
”All” and then ”Export”.
Backup to a USB stick
Turn over your IDx and insert a USB
memory stick.
USB Files
4
Once the backup is complete, you can nd it under the ”Import” tab, where you will be
able to restore it if needed. Remove the USB stick when nished.

4
1
2
First make sure you have a WiFi
connection, then click the settings
symbol in the lower le corner and select
”More”.
If you are restoring a backup from a
USB stick, simply insert the USB and
the import folder (step 3) will open
automatically.
Select Net Service and click Ok next
to ”Manage Backups”.
Restore a Backup
3
Select the ”Import” tab, then click the
backup you want to restore and then
click the blue download / import button.

4
Press Ok to restore the backup.
5
5
Enter the system backup code
(created during the registration
process).
The IDx will restore the data, restart and ask for your PIN to complete the installation. If you are
restoring a backup from a USB, it is now safe to remove it.
