oticon CIC P User manual

INSTRUCTIONS FOR USE CIC / MIC / ITC / ITE

Thank you
Thank you for choosing our product as your means to better hearing.
To support your efforts, we have put great care and attention into making sure that your
new hearing instruments are of the highest quality and that they are easy to use and
maintain.
We recommend that you read this manual carefully to achieve the maximum benefit of
your new hearing instruments.
Congratulations on your decision to actively improve your hearing with today’s most
advanced hearing technology in the market.
Contents
Instrument View CIC/MIC 5a
Instrument View ITC 5b
Instrument View ITC Power 5c
Instrument View ITE 5d
Changing batteries 7
Turning your instruments ON and OFF 9
Left/Right ear marking 10
Inserting your hearing instruments 11
Programs (Optional) 12
Standby (Optional) 15
Volume Control by Push Button (Optional for Ino Pro ITC* only) 16
Volume Control by Wheel (Optional for ITE and ITC Power) 18
Telecoil (Optional) 21
Auto Phone (Optional) 22
Caring for your hearing instruments 24
Using your hearing instrument 30

5a
IMPORTANT NOTICE
Please familiarise yourself with the entire contents of this booklet before using your
hearing instru ments. It contains instructions and important informa tion about the use
and handling of your hearing instru ments and batteries.
Instrument View CIC/MIC
Microphone opening Battery door
Ventilation opening
Sound outlet +
wax protection system
Ventilation opening
Battery size: 10
Pull-out string
Common problems and their solutions 36
Warranty Certificate 40
Warnings Yellow Pages

5b
Instrument View ITC
Battery size: 312
One or two microphone
openings
Battery door Ventilation opening
Ventilation opening
Sound outlet +
wax protection system
Push-button (Optional)
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, especially at night!

5c
Instrument View ITC Power
Ventilation opening
Sound outlet +
wax protection system
One or two microphone
openings
Push-button (Optional)
Volume Control Wheel
(Optional)
Battery door
Ventilation opening
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, especially at night!
Battery size: 312

5d
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, especially at night!
Battery size: 312
Instrument View ITE
Microphone openings Push-button (Optional)
Volume Control Wheel
(Optional)
Battery door
Ventilation opening
Sound outlet +
wax protection system

7
Changing batteries
The correct battery size appears in the instrument overview in the first section of
this document. Batteries perform differently. Ask your hearing care professional for help
choosing a high quality battery for your hearing instrument.
A worn out battery should be removed immediately.
When the battery power is low, you will hear a series of short beeps. This indicates
that it is time to change the battery.
To replace the battery, follow these instructions:
• Open the battery door with your fingernail and remove the
old battery.
• Remove the sticky label from the + side of the new battery.
IMPORTANT NOTICE
Open the battery compartment fully to allow air to circulate whenever you are not
using your hearing instrument, especially at night!

8 9
Turning your instruments ON and OFF
Turn ON your hearing instrument by closing the battery
door completely with the battery in place.
When the battery door is closed the instrument will start up
by playing a jingle. This indicates that the battery is working
and the instrument is operating.
Turn OFF your hearing instrument by opening the battery
door with your finger nail.
To preserve the battery, make sure your hearing instrument
is switched off when you are not wearing it.
• Insert the new battery so that its + marking faces the + sign printed on the
battery door.
• Close the battery door. If you feel any resistance, you may have inserted the battery
incorrectly. Reinsert the battery and try again.
It will take a few seconds before the battery works to full capacity.
To assist the handling of the batteries, the magnet placed
at the end of the tool can be used.
OFF
ON
MultiTool

10 11
Left/Right ear marking
Hearing instruments are fitted to the uniqueness of each ear, which means if you have
two instruments then your left hearing instrument is shaped and programmed differently
from your right. That is why it is important to distinguish between the left hearing
instrument and the right.
In order to easily identify whether it is the left ear or right ear instrument, colour markings
may be applied.
Blue text or a blue dot marks the LEFT instrument.
Red text or a red dot marks the RIGHT instrument.
Inserting your hearing instruments
Place the tip of the hearing instrument in your ear canal.
Gently pull your ear and push the hearing instrument into
the ear canal, twisting slightly if necessary, following the
natural contour of the ear canal.
DO NOT use the battery door as a handle to insert or remove
your instruments. It is not designed for this purpose.

12 13
Programs (Optional)
Your hearing instruments may have a push-button for switching between
different programs.
Push briefly on the button to switch to the next program.
A push will go forwards in the program cycle e.g from P1->P2.
When the highest numbered program is reached, the cycle
starts from program one again.
Your hearing instrument can have up to 4 different programs.
When switching between the different programs, your hearing instrument will beep.
The number of beeps will indicate which program you are using.
One beep, when you switch to program 1
 Two beeps, when you switch to program 2
 Three beeps, when you switch to program 3
 Four beeps, when you switch to program 4

14 15
Below you can see a description of the programs available in your hearing instrument.
Prg. 1:
Prg. 2:
Prg. 3:
Prg. 4:
Using 2 instruments
If you have two Ino Pro instruments the push-button on one instrument can be pro-
grammed to change the program on both hearing instruments (Binaural Coordination).
This means, when you adjust the program for one instrument, it automatically adjusts
the other.*
Binaural Coordination enabled.
*Not available for CIC, MIC and ITC Power instruments.
Standby (Optional)
If your hearing instrument has a push-button, push the button for a minimum of
3 seconds to set the instrument in standby mode.
To reactivate the instrument, push the button brieftly again.
Use the standby function if you need to silence the instrument.
PUSH
3 sec
IMPORTANT NOTICE
Do not use the stand-by function as a switch off as the hearing instrument still draws
current from the battery in this mode.

16 17
Volume Control by Push Button
(Optional for Ino Pro ITC* only)
If you have two instruments, your Hearing Care Professional may have programmed the
push-button on your instruments to one of 2 functionalities.
Left Right
Only volume control:
Press shortly to adjust the volume.
Both volume control and program shift:
Press shortly to adjust the volume and press long
(about 2 seconds) to shift program.
When you adjust the program or volume for one instrument, it automatically adjusts
the other.
If volume control has been activated in your instruments, you can adjust the volume
in specific listening situations to the level you feel
comfortable with.
To increase volume, shortly press the push-button on the RIGHT ear instrument.
To decrease volume, shortly press the push-button on the LEFT ear instrument.
When the hearing instrument is turned on, it starts up at a preferred volume level.
When adjusting the volume control to the preferred level, this is indicated by a beep.
* Does not apply to ITC Power instruments.

18 19
Volume Control by Wheel
(Optional for ITE and ITC Power)
Your ITE instrument may have a Volume Control wheel. The Volume Control wheel can be
turned with the tip of a finger and can be rotated infinitely both ways.
Volume Control Wheel
The Volume Control allows you to adjust the volume in specific listening situations to
the level you feel comfortable with.
To increase volume, turn the wheel forward.
To decrease volume, turn the wheel towards the back of your head.
When the hearing instrument is turned on, it starts up at a preferred volume level.
When adjusting the volume control to the preferred level, this is indicated by a beep.
Using 2 instruments
If you have two Ino Pro instruments the Volume Control Wheel on one instrument can be
programmed to adjust the volume on both hearing instruments (Binaural Coordination).
This means, when you adjust the volume for one instrument, it automatically adjusts
the other.*
Binaural Coordination enabled.
*Not available for CIC, MIC and standard ITC instruments.
Volume Control Wheel

21
Telecoil (Optional)
The telecoil is a receiver for audio signals transmitted from an inductive loop installation.
The telecoil is meant for telephone* conversations and for loop systems in e.g. theatres,
churches or lecture rooms.
The telecoil is activated by the push-button. When activated, you will hear a certain
number of beeps corresponding to the telecoil program.
See “Programs” for where the telecoil program is placed.
*Special phone requered.

22 23
Auto Phone (Optional)
The hearing instrument may have a built-in Auto Phone func tionality. When the hearing
instrument is close to a telephone receiver, the Auto Phone will activate a Phone Program.
When the Phone Program is activiated you will hear a number of beeps.
When you end your telephone conversation, the hearing instrument will automatically
return to the previous program.
Not all telephones can activate the Auto Phone.
The telephone receiver may need to have a special magnet
fitted. Please follow the separate instructions for mounting
the magnet, which is available from your Hearing Care
Professional.
WARNING
If you use an Autophone magnet:
• Keep magnets out of reach of children and pets. If a magnet is swallowed, see
a doctor immediately.
• Do not wear the magnet in a breast pocket and always keep it 30 cm away from
active implanatable devices.
• Preferably, use the telephone with magnet on the opposite side than a pacemaker or
other active implantants.
• Keep the magnet 30 cm away from credit cards and other magnetically sensitive
devices.

24 25
Caring for your hearing instruments
Your ear canal produces ear wax (cerumen) which may clog up the sound outlet or the
ventilation opening of your hearing instrument. Therefore your hearing instrument may
contain a filter or another device to prevent wax accumulation. Consult your Hearing Care
Professional for instructions about the specific wax protection system in your hearing
instruments.
When handling a hearing instrument, keep it over a soft surface to avoid damage
if you drop it.
Cleaning the instrument
A range of cleaning tools is prepared for the special purpose of cleaning the instruments.
These should be used to ensure the best care and performance of your hearing
instruments.
BrushCover Handle
Magnet
Screwdriver
MultiTool

26 27
Here is how . . .
• Clean away any traces of wax from around the
ventilation opening and sound outlet with the brush.
• If microphone openings are clogged by dust or dirt, this
will affect the performance of the instrument.
Carefully brush away visible signs of debris from the
openings while twisting the brush.
• Clean the ventilation openings by pressing the brush
through the hole while twisting it slightly.
• Use the cloth to wipe clean the surface of the
instrument.
The hearing instrument itself must never be washed or immersed in water or other
liquids!
Replace brush when necessary. Just pull it out of the handle and insert a new fresh brush.
Press the new one firmly into the handle.

28 29
How to change NoWax filter
1. Remove the tool from the shell. The tool has two arms, one with the new filter
and one with the removal tool.
2. Push the removal tool into the existing waxfilter and remove the used filter from
the hearing instrument.
3. Push the new filter into the hearing instrument.
4. Throw out the used tool.
Avoiding heat, humidity and chemicals
Your hearing instrument must never be exposed to extreme heat e.g. left inside a parked
car in the sun. They must never be exposed to a lot of moisture e.g. steam baths, showers
or heavy rain. Nor must they be dried in microwave ovens or other ovens.
Wipe the batteries carefully if moisture is present as it may affect their performance.
Using an anti-humidity kit can help to avoid these problems and may even extend the life
of your hearing instrument. Consult your Hearing Care Professional for further advice.
The chemicals in cosmetics, hairspray, perfume, after shave lotion, suntan lotion and
insect repellant can damage your hearing instrument. You should always remove your
hearing instrument before applying such products and allow time for the product to dry
before reinserting your hearing instrument. If you use lotion, be sure to wipe your hands
dry before putting on your hearing instrument.
1 2 3 4

30 31
Using your hearing instrument
It takes time to adjust to a new hearing instrument. How long this adjustment takes
differs from person to person. It will depend on a number of factors, such as whether you
have had a hearing instrument before and the degree of your hearing loss.
Your hearing instrument may support wireless connectivity with the Oticon ConnectLine
Streamer*. The Streamer can be used for volume and program adjustments of the
hearing instruments and to connect wirelessly with ConnectLine accessories to support
listening and conversations.
Seven easy steps to better hearing
1. In the quiet of your home
Try to accustom yourself to all the new sounds. Listen to the many background sounds
and try to identify each sound. Bear in mind that some sounds will seem different from
what you are used to. You may have to learn to identify them again. Note that in time you
will get accustomed to the sounds in your environment – if not please contact your
Hearing Care Professional.
If using the hearing instrument makes you tired, take them off for a little while and have a
rest. Gradually, you will begin to be able to listen for longer periods of time. Soon, you will
be able to wear your hearing instrument comfortably all day long.
2. Conversation with another person
Sit with someone else in a quiet room. Face each other so you can read facial expressions
easily. You may experience new speech sounds, which can seem a little disturbing in the
beginning. However, after the brain has adapted to the new speech sounds, you should
hear speech clearer.
3. Listen to radio or TV
When listening to the TV or the radio, start out by listening to news commentators since
they usually speak clearly, then try other TV programs.
If you find it difficult to listen to TV or radio, ask your Hearing Care Professional for more
information regarding the Oticon ConnectLine system* and other available accessories.

32 33
4. In group conversations
Group situations are usually accompanied by a greater degree of background noise, and
are, therefore, naturally more difficult to cope with. In such situations, therefore, focus
your attention on the person you want to hear. If you miss a word, ask the speaker to
repeat.
5. Telecoil use in church, theatre, or cinema
An increasing number of churches, theatres and public buildings often have loop systems
installed. These systems send out wireless sound to be received by the telecoil in your
hearing instrument. Typically, a sign will let you know whether the place has a telecoil.
Ask your Hearing Care Professional for details.
6. Using the telephone
When using the telephone tilt the receiver edge lightly on your
cheek-bone in order to let the sound flow directly into the hearing
instrument microphone opening. This way, the hearing instru-
ment will not whistle and you ensure the best conditions to
understand the conversation. When you have the receiver
in this position, remember to speak directly into the
microphone of the telephone in order to ensure good
understanding on the opposite “end of the line”.
If you find it difficult to use the telephone, ask your Hearing Care Professional for more
information regarding the Oticon ConnectLine system* and other available accessories.
If your hearing instrument has a telecoil (and your telephone has a built in tele-loop) you
can switch into telecoil program in order to improve the sound reception further.
Remember that the telecoil in hearing instrument may pick up disturbing signals from
electronic devices, such as a fax machines, computers, televisions or similar. Make sure
that the hearing instrument has a distance of 2–3 meters to such devices when using the
telecoil program.
