Phonak CROS II-312 User manual

User Guide

3
Your CROS device
Model
FPhonak CROS II-312 Custom
FPhonak CROS II-13 Custom
Battery type
312
13
If no box is checked and you do not know the
model of your CROS device please ask your hearing
care professional.
Your hearing care professional:
Wireless models
Phonak CROS II-312 Custom
Phonak CROS II-13 Custom
CE mark applied
2015
2015
This user guide is valid for:
This user guide only applies to the CROS device.
Please see the hearing aid user guide for
instructions related to the hearing aid.

5
Contents
Your CROS device
1. Quick guide
2. Parts of the CROS device
Using the CROS device
3. Left & right CROS device markings
4. On/O
5. Batteries
6. Putting on the CROS device
7. Removing the CROS device
8. Push button
9. Volume control
Further Information
10. Care and maintenance
11. Service and warranty
12. Compliance information
13. Information and description of symbols
14. Troubleshooting
15. Important safety information
16. Important information: Cell phones
17. For the US market only, complies with the FDA
regulations
6
8
10
11
12
14
15
16
17
18
20
22
26
30
32
39
41
Your CROS device has been developed by Phonak – the
world leader in hearing solutions based in Zurich,
Switzerland.
This premium product is the result of decades of research
and expertise and is designed to keep you connected to
the beauty of sound! We thank you for making such a
great choice and wish you many years of listening
pleasure.
Please read the user guide carefully to make sure that
you understand and get the best out of your CROS device.
For more information about features and benets, simply
contact your hearing care professional.
Phonak – life is on
www.phonak-us.com

7
On/O
Push button
Volume control
The push button on your CROS
device can have various functions.
Models with this option only:
To increase the volume, turn the
volume control forwards. To decrease
the volume, turn the volume control
backwards.
OOn
6
1. Quick guide
Left & right markings
Changing batteries
Blue marking for
left device.
Red marking for
right device.
Remove the
sticker from the
new battery and
wait 2 minutes.
Left Right
Open the
battery door.
Place battery in the
battery door with the
“+” symbol facing
upwards.
1 2 3

9
CROS II-312 Custom
CROS II-13 Custom
Battery door
Push button
Custom made shell
Volume control
(optional)
Battery door
Custom
made shell
Push button
Volume control
(optional)
8
2. Parts of the CROS device
The pictures below show the models described in this user
guide. You can identify your personal model by:
• Checking “Your CROS device” on page 3.
• Or comparing your CROS device with the following
shown models. Pay attention to the shape of the CROS
device and if a volume control is present.
The Phonak CROS device is an application for single-
sided deafness, one-sided hearing loss or asymmetrical
hearing loss. It is placed on the impaired ear and
wirelessly transmits sound to the Phonak hearing aid
on the other ear.
Phonak CROS II Custom device
+ Phonak Virto V hearing aid = Phonak CROS II system
Phonak CROS II Custom only works in connection
with a Phonak Virto V hearing aid or newer as
the receiver.

11
4. On/O
The battery door is also the on/o switch.
1
2
Closed battery door =
CROS device is on
Opened battery door =
CROS device is o
10
3. Left & right CROS device markings
There is a red or blue marking to tell you if it is a left
or a right CROS device. The color mark is located on
the shell (text printed in red or blue), or shell is colored
red or blue.
Blue marking for left device.
Red marking for right device.

13
Replacement battery
This CROS device requires zinc-air batteries. Identify the
correct battery size (312 or 13) by:
• Checking “Your CROS device” on page 3.
• Checking the following table.
Please ensure you use the correct type of battery in
your CROS device (zinc-air). Please also read chapter
15.2 for further information on product safety.
Model
Phonak CROS
CROS II-312 Custom
CROS II-13 Custom
Zinc-air
battery
size
312
13
Color
marking on
package
brown
orange
IEC
code
PR41
PR48
ANSI
code
7002ZD
7000ZD
12
5. Batteries
Remove the
sticker from the
new battery.
Open the
battery door.
Place battery in the
battery door with the
“+” symbol facing
upwards.
Low power: You will hear two beeps followed by a
melody when the battery of the CROS device is
low. You will have approximately 30 minutes to
change the battery (this can vary, depending on the
battery). We recommend that you always have a new
battery on hand.
If it is dicult to close the battery door: Check that
the battery is inserted correctly and the “+” symbol
is facing upwards. If the battery is not inserted
correctly, the CROS device will not work and the
battery door can be damaged.
1 2 3

15
7. Removing the CROS device
1
2
Put your thumb behind your
lobe and gently press your ear
upward to push the CROS device
out of the canal. In order to
help it along, make chewing
movements with your jaw.
Grasp the protruding CROS
device and remove it.
14
6. Putting on the CROS device
(all models)
Take your CROS device
up to your ear and place
the ear canal part into
your ear canal.

17
9. Volume control
Models with this
option only:
To increase the volume,
turn the volume control
forwards. To decrease the
volume, turn the volume
control backwards. The
volume control can be
disabled by the hearing
care professional.
16
8. Push button
The push button on your
CROS device can have
various functions or is
not active. This depends
on the programming of
the CROS device, which
is indicated in your
individual “Hearing aid
instructions”. Please ask
your hearing care
professional for this
printout.

19
Daily
Daily cleaning and the use of a drying system is highly
recommended. C&C line from Phonak is a complete set of
cleaning products. Your hearing care professional will be
glad to advise you. Never use household cleaning
products (washing powder, soap, etc.) to clean your
CROS device.
If your CROS device fails to operate after you have
correctly inserted a new battery, contact your hearing
care professional for advice.
Weekly
For more in depth maintenance instructions or for
more than basic cleaning, please see your hearing
care professional.
18
10. Care and maintenance
Diligent and routine care of your CROS device contributes
to outstanding performance and a long service life.
Please use the following specications as a guideline.
For further information regarding product safety, see
chapter 14.2.
General information
Before using hair spray or applying cosmetics, you should
remove your CROS device from your ear, because these
products may damage it.

21
Warranty limitation
This warranty does not cover damage from improper
handling or care, exposure to chemicals or undue stress.
Damage caused by third parties or non-authorized service
centers renders the warranty null and void. This warranty
does not include any services performed by a hearing care
professional in their oce.
Serial number
(left side):
Serial number
(right side):
Date of purchase:
Authorized hearing care
professional (stamp/signature):
20
11. Service and warranty
Local warranty
Please ask the hearing care professional, where
you purchased your CROS device, about the terms
of the local warranty.
International warranty
Phonak oers a one year limited international
warranty, valid starting from the date of purchase.
This limited warranty covers manufacturing and
material defects in the CROS device itself, but not
accessories such as batteries, tubes, earmolds and
external receivers. The warranty only comes into
force if a proof of purchase is shown.
The international warranty does not aect any legal
rights that you might have under applicable national
legislation governing sale of consumer goods.

23
The wireless models listed on page 2 are certied under:
Phonak CROS II-312 Custom & Phonak CROS II-13 Custom
USA FCC ID: KWC-ITEV13
Canada IC: 2262A-ITEV13
22
Europe:
Declaration of Conformity
Hereby Phonak AG declares that this Phonak product
meets the requirements of the Medical Devices Directive
93/42/EEC as well as the Radio and Telecommunications
Terminal Equipment Directive 1999/5/EC. The full text of
the Declaration of Conformity can be obtained from the
manufacturer or the local Phonak representative whose
address can be taken from the list on www.phonak.com
(Phonak worldwide locations).
Australia:
Supplier Code Number N15398
New Zealand:
Supplier Code Number Z1285
12. Compliance information

25
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this device does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device
and receiver.
• Connect the device into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
24
Notice 1:
This device complies with Part 15 of the FCC Rules
and with RSS-210 of Industry Canada. Operation is
subject to the following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received,
including interference that may cause undesired operation.
Notice 2:
Changes or modications made to this device not
expressly approved by Phonak may void the FCC
authorization to operate this device.
Notice 3:
This device has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules and ICES-003 of Industry Canada.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This device generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful

27
EMC and Radio communications compliance
label Australia.
This symbol indicates that it is important for
the user to read and take into account the
relevant information in these user guides.
This symbol indicates that it is important for
the user to pay attention to the relevant
warning notices in these user guides.
Important information for handling and
product safety.
The product is designed such that it functions
without problems or restrictions if used as
intended, unless otherwise noted in these
user guides.
Operating
conditions
26
With the CE symbol, Phonak AG conrms
that this Phonak product – including
accessories – meets the requirements of the
Medical Devices Directive 93/42/EEC as well as
the R&TTE Directive 1999/5/EC on radio and
telecommunications equipment. The numbers
after the CE symbol correspond to the code of
certied institutions that were consulted under
the above-mentioned directives.
This symbol indicates that the products
described in these user instructions adhere to
the requirements for an applied part of Type B
of EN 60601-1. The surface of the CROS device
is specied as an applied part of Type B.
Indicates the medical device manufacturer, as
dened in EU Directive 93/42/EEC.
13. Information and description
of symbols

2928
Temperature during transportation
and storage: –20° to +60° Celsius
(–4° to +140° Fahrenheit).
Humidity during transportation: Up to 90%
(non condensing).
Humidity during storage: 0% to 70%, if not in
use. See instruction in chapter 17.2 regarding
drying the device after use.
Atmospheric pressure: 200 hPA to 1500 hPa
The symbol with the crossed-out garbage
bin is to make you aware that this device may
not be thrown away as normal household
waste. Please dispose of old or unused device,
at waste disposal sites intended for electronic
waste, or give your device to your hearing care
professional for disposal. Proper disposal
protects the environment and health.

31
What to do
Change battery (chapter 1 + 5)
Insert battery correctly (chapter 1 + 5)
Switch CROS device on by completely closing the battery door
(chapter 4)
Change battery of the hearing aid within the next 30 minutes (consult
the user guide of the hearing aid if necessary)
Change battery of the CROS device within the next 30 minutes
(chapter 1 + 5)
Wipe batteries and housing of hearing aid and CROS device with
dry cloth
30
14. Troubleshooting
If the problem persists, contact you hearing care
professional for assistance
Causes
Dead battery
Battery not inserted correctly
CROS device switched o
Indication for low hearing
aid battery
Indication for low battery of
CROS device
Moisture on battery of
hearing aid or CROS device
Problem
CROS device not functioning
Hearing aid plays two beeps
Hearing aid plays two beeps
followed by a melody
Sound switches on & o
(intermittent)

33
The intended use of a
CROS device is to transmit
sound to a hearing aid on
the better hearing ear and
hereby compensate for
impaired hearing. The
CROS system (specially
programmed for each
hearing loss) must only
be used by the intended
person. They should not
be used by any other
person as they could
damage hearing.
Changes or modications
to the CROS device that
were not explicitly approved
by Phonak are not permitted.
Such changes may damage
your ear or the CROS device.
Do not use the CROS
device in explosive areas
(mines or industrial areas
with danger of explosions,
oxygen rich environments
or areas where ammable
anesthetics are handled).
Hearing aid batteries are
toxic if they are swallowed!
Keep out of reach of children
under 3 years. If batteries
are swallowed, consult your
physician immediately!
If you feel pain in or behind
your ear, if it is inamed or if
skin irritation and accelerated
accumulations of earwax
occur, please check with
your hearing care
professional or physician.
15.1 Hazard warnings
32
Please read the information on the following pages before
using your CROS device.
A CROS device will not restore normal hearing and will not
prevent or improve a hearing impairment resulting from
organic conditions. Infrequent use of a CROS device does
not permit a user to attain full benet from it. The use of
a CROS device is only part of hearing habilitation and may
need to be supplemented by auditory training and
instruction in lipreading.
15. Important safety information

35
the manufacturer of the
active implant. Please, note
that interference can also
be caused by power lines,
electrostatic discharge,
airport metal detectors etc.
Keep magnets (i.e. battery
handling tool, EasyPhone
magnet, etc.) at least
15 cm (6 inches) away
from the active implant.
34
Hearing programs in the
directional microphone
mode reduce background
noises. Please be aware
that warning signals
or noises coming from
behind, e.g. cars, are
partially or entirely
suppressed.
The CROS device is not for
children below 36 months.
It contains small parts that
can cause choking, if
swallowed by children.
Keep out of reach of
children under 3 years.
If swallowed, consult a
physician or hospital
immediately.
External devices may only
be connected if they have
been tested in accordance
with corresponding
IECXXXXX standards. Only
use accessories approved
by Phonak AG, to avoid
any electrical shock.
The following is only
applicable for persons with
active implantable medical
devices (i.e. pacemakers,
debrillators, etc.):
Keep the wireless hearing
aid or CROS device at least
15 cm (6 inches) away
from the active implant.
If you experience any
interference, do not use the
wireless hearing aids or
CROS device and contact

37
Do not drop your CROS
device! Dropping onto a
hard surface can damage
your CROS device.
Always use new batteries
for your CROS device. In
case a battery is leaking,
replace it immediately
with a new one to avoid
any skin irritation. You
can return used batteries
to your hearing care
professional.
The batteries used in the
CROS device should not
exceed 1.5 Volts. Please do
not use silver-zinc or Li-ion
(lithium-ion) rechargeable
batteries as these may
cause severe damage to
your CROS device. The
table in chapter 5 explains
exactly which type of
battery your particular
CROS device requires.
Remove the battery if
you are not using your
CROS device for a long
period of time.
36
Never immerse your CROS
device in water! Protect it
from excessive moisture.
Always remove your CROS
device before showering,
bathing, or swimming, as
the CROS device contains
sensitive electronic parts.
15.2 Information on product safety
Protect your CROS device
from heat (never leave near
a window or in the car).
Never use a microwave
or other heating devices
to dry your CROS device.
Ask your hearing care
professional about suitable
drying methods.
When you are not using
your CROS device, leave
the battery door open so
that any moisture can
evaporate. Make sure that
you always completely dry
your CROS device after use.
Store the CROS device in a
safe, dry and clean place.

Some hearing aid users have reported a buzzing sound
in their hearing aids when they are using cell phones.
According to the ANSI 63.19 (American National
Standard Methods of Measurement of Compatibility
between Wireless Communications Devices and Hearing
Instruments) standard, the compatibility of a particular
hearing aid and cell phone can be predicted by adding
the rating for the hearing aid immunity to the rating for
the cell phone emissions. The sum of the hearing aid
rating (e.g. M2/T2=2) and the telephone rating
(e.g. M3/T3=3) is 5, and any combination that equals
5 will provide “normal use”; a sum of 6 or greater would
indicate “excellent performance”. The equipment
performance measurements, categories and system
classications are based upon the best information
available but cannot guarantee that all users will be
satised. The immunity of this hearing aid is at least
M2/T2.
16. Important information: Cell phones
3938
Special medical or dental
examination including
radiation described below,
may adversely aect the
correct functioning of your
CROS device. Remove and
keep them outside the
examination room/area
before undergoing:
Medical or dental
examination with X-ray
(also CT scan).
Medical examinations with
MRI/NMRI scans, generating
magnetic elds.
CROS devices don’t need to
be removed when passing
security gates (airports
etc.). If X-ray is used at all,
it will be in very low doses,
and will not aect the
CROS devices.
Do not use your CROS
device in areas where
electronic equipment
is prohibited.
