oticon miniRITE T User manual

Instructions for use miniRITE T
Oticon CROS

239875CA-US / 2021.07.19 / v1 / Oticon CROS Firmware 1.0

Model overview
This booklet is valid for Oticon CROS and covers both CROS and BiCROS.
CROS
BiCROS
Oticon CROS is to be used with a compatible Oticon hearing aid that has
either a single push button or a double push button for volume control.
Single push button
Double push button
For an overview of which hearing aids Oticon CROS is compatible with,
please go to www.oticon.global/cros-compatibility
239875CA-US / 2021.07.19 / v1 / Oticon CROS Firmware 1.0

Introduction to this booklet
This booklet gives you guidance on how to use and maintain your new
transmitter. Please read the booklet carefully, including the Warnings
section. This will help you get the full benefit of your new transmitter.
Your hearing care professional has adjusted the transmitter to meet
your needs. If you have further questions, please contact your hearing
care professional.
About Start-up Handling Warnings More info
For your convenience, this booklet contains a navigation bar to help
you easily navigate through the different sections.

Intended use
The transmitter is intended to transmit sound from the poorer ear to
a hearing aid placed on the better ear.
The transmitter is intended to be used by adults and children older
than 36 months together with a hearing aid.
IMPORTANT NOTICE
For details on the functionality of the hearing aid, please refer to the hearing
aid’s Instruction for use.

Table of contents
About
CROS solution 8
Your transmitter 10
Left/right identification 12
MultiTool for handling batteries and cleaning 13
Start-up
Turn the transmitter ON and OFF 14
When to replace the battery 15
How to replace the battery (size 312) 16
Put on the transmitter 18
Handling
Caring for the transmitter 19
Replace the earpiece 20
ProWax miniFit filter 22
Change volume on the transmitter 23
Mute 26
Sound indicators 27

Warnings
General warnings 28
More info
Troubleshooting 36
Water & dust resistant (IP68) 38
Conditions of use 39
Warranty 40
Technical information 42

8About Start-up Handling Warnings More info
CROS solution
A CROS or BiCROS solution consists of a transmitter and a hearing aid.
The transmitter is placed on the poorer ear. It wirelessly sends sound
from the poorer ear surroundings to the hearing aid placed on the better
ear. The transmitter only works with certain Oticon hearing aids.
CROS (Contralateral Routing of Signals) is a solution for people with
limited or no hearing in one ear combined with normal hearing in the
opposite ear.
BiCROS (Bilateral Contralateral Routing of Signals) is a solution for
people with limited or no hearing in one ear and hearing loss in the
opposite ear.
About

9
Hearing aidTransmitter
Sound transmission

10 About Start-up Handling Warnings More info
Your transmitter
What it is and what it does
Battery drawer
Contains the battery
and functions as an
on/off switch
Wax filter
Wax protection
Dummy speaker
No sound
Ear grip
Holds the dummy
speaker in place
(optional)
Microphones
Sound in
Nail grip
Open the
battery drawer
Push button
Change volume
and mute

11
Open dome
60 85
Please see details for replacing the dome in
section: Replace the earpiece.
* Only for dummy speaker 60
6 mm5 mm* 8 mm 10 mm
The dummy speaker has no
acoustic purpose. The choice of
size depends on what fits best in
your ear.
Dummy speakers
The dummy speaker uses an open
dome as shown below. This helps
the transmitter stay in your ear.
Earpiece
Dome sizes

12 About Start-up Handling Warnings More info
Left/right identication
It is important to distinguish between the transmitter and the hearing
aid. The left/right colour indicator helps you distinguish between left
and right.
On the transmitter, you can find left/right colour indicators in the
battery drawer. On the dummy speaker it is located as shown.
RED indicates RIGHT
BLUE indicates LEFT

13
MultiTool for handling batteries and cleaning
The MultiTool contains a magnet that makes it easier to replace the
battery in the transmitter. It also contains a brush and wire loop for
cleaning and removing earwax. If you need a new MultiTool, please
contact your hearing care professional.
Brush
Wire loopMagnet
IMPORTANT NOTICE
The MultiTool has a built-in magnet. Keep the MultiTool at least 30 cm away
from credit cards and other magnetically sensitive devices.

14 About Start-up Handling Warnings More info
Turn the transmitter ON and OFF
The battery drawer is used to switch your transmitter on and off. To save
battery life, make sure the transmitter is switched off when you are not
wearing it. If you wish to return to the standard settings, simply open
and close the battery drawer.
Turn ON
Close the
battery
drawer with
the battery
in place.
Turn OFF
Open the
battery
drawer.
Start-up

15
When to replace the battery
When it is time to replace the battery in the transmitter, you will hear
three alternate high pitch tones in the hearing aid. They will be repeated
in moderate intervals until the battery runs out.
Three alternate tones
= The battery is running low
Four descending tones
= The battery has run out
Battery tip
Keep a spare battery on you at all times to ensure your transmitter
always works.

16 About Start-up Handling Warnings More info
How to replace the battery (size 312)
2. Uncover 3. Insert
Fully open the battery
drawer. Remove the
battery.
Remove the sticky
label from the +side
of the new battery.
Tip:
Wait 2 minutes for the
battery to draw air to en-
sure optimal functioning.
Insert the new battery
into the battery drawer.
Make sure the + side is
facing up.
Insert it from above,
NOT from the side.
1. Remove

17
MultiTool
Close the battery drawer. The MultiTool can be used to change
the battery. Use the magnetic end to
remove and insert batteries.
The MultiTool is provided by your
hearing care professional.
4. Close Tip

18 About Start-up Handling Warnings More info
Put on the transmitter
Ear grip
(optional)
Place the transmitter
behind your ear.
Hold the bend of the
dummy speaker wire
between your thumb
and index finger. The
earpiece should point
towards opening of
the ear canal.
Gently push the
earpiece into your ear
canal until the dummy
speaker wire sits close
to your head. If the
dummy speaker has an
ear grip, place it in the
ear so it follows the
contour of the ear.
Step 1 Step 2 Step 3

19
Handling
Caring for the transmitter
When handling your transmitter, hold it over
a soft surface to avoid damage if you drop it.
Clean the microphone openings
Use the brush of the MultiTool to
carefully brush debris away from the
openings. Carefully brush the surface
around the openings.
Make sure that no parts of the
MultiTool are squeezed into the
microphone openings by force.
This may damage the transmitter.
IMPORTANT NOTICE
Use a soft, dry cloth to clean the transmitter. The transmitter must never be
washed or immersed in water or other liquids.
Microphone
openings

20 About Start-up Handling Warnings More info
Replace the earpiece
The earpiece should not be cleaned. If it is filled with wax, replace it with
a new one.
Hold on to the dummy
speaker and then pull
off the earpiece.
Insert the dummy
speaker into the
exact centre of the
earpiece for a secure
attachment.
Push firmly to ensure
that the earpiece is
securely fastened.
Step 1 Step 2 Step 3
