OttLite Hampton User manual

L
ENGLISH
CONGRATULATIONS!
You’ve purchased the finest in natu-
ral lighting technology with your new
OttLite®product.
PRODUCT REGISTRATION FORM
Please complete the enclosed Product
Registration Form and return it today
by mail, or register online by going to:
www.OttLite.com/warranty.
WARNING: To prevent electric shock,
make sure the lamp is not plugged in
until all assembly steps are complete.
LAMP ASSEMBLY
1. Make sure the lamp is not plugged
into an electrical outlet.
2. Remove the screw (H) from the upper
pole (F). Insert the upper pole (F) into the
back of the shade (G), re-insert screw (H)
and tighten using enclosed tool (I).
3. Thread the lower pole (D) into hole (C)
in the base (B) until secure.
4. Screw the upper lamp stem (A) into the
lower lamp stem (D).
5. To adjust lamp height, turn ring (E)
counter-clockwise to loosen. Adjust
upper pole to desired height, and tighten
ring by turning clockwise.
BULB INSERTION/REPLACEMENT
1. Make sure the lamp is not plugged into
an electrical socket.
2. If the lamp has been in use, allow it
to cool for approximately five minutes
before proceeding.
3. To install a bulb in the socket, hold the
bulb (L) firmly near the base, align bulb
pins with matching pin-holes then push
it straight into the socket until it “snaps”
into place.
4. To remove a bulb (L) already installed
in the lamp, grasp it firmly at the base
and, using a slight rocking motion, pull it
straight out of the socket. Do not twist or
turn the bulb.
5. Plug the lamp into a standard 120V
socket. Your lamp is ready for use.
6. Turn lamp on or off by using rocker
switch (K).
Please note that in operation, OttLite®
tubes are not dimmable.
Enjoy your OttLite®Hampton Floor lamp!
This lighting system is designed for
use with OttLite®type (style number
SB20-M). Use of other products voids
the warranty and may result in dam-
age to the lighting system.
CAUTION! IMPORTANT SAFETY INSTRUCTIONS:
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER) AS A FEATURE TO
REDUCE THE RISK OF ELECTRIC SHOCK. THIS PLUG WILL FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE
PLUG DOES NOT FIT FULLY IN THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A
QUALIFIED ELECTRICIAN. NEVER USE WITH AN EXTENSION CORD UNLESS PLUG CAN BE FULLY INSERTED.
DO NOT ALTER THE PLUG.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
AVERTISSEMENT! IMPORTANTES DIRECTIVES DE
SÉCURITÉ:
CETTE LAMPE PORTATIVE EST MUNIE D’UNE FICHE POLARISÉE (UNE LAME PLUS LARGE QUE L’AUTRE). CE
DISPOSITIF DE SÉCURITÉ DIMINUE LE RISQUE DE CHOCS ÉLECTRIQUES PUISQUE LA FICHE NE S’INSÈRE DANS
LA PRISE QUE D’UN SEUL CÔTÉ. SI ELLE N’ENTRE PAS DANS LA PRISE, INVERSEZ-LA. SI ELLE N’ENTRE
TOUJOURS PAS, CONTACTEZ UN ÉLECTRICIEN QUALIFIÉ. N’UTILISEZ JAMAIS AVEC UNE RALLONGE SAUF SI
LA FICHE S’INSÈRE ENTIÈREMENT. NE MODIFIEZ PAS CE DISPOSITIF DE SÉCURITÉ.
AVERTISSEMENT: POUR ÉVITER LES CHOCS ÉLECTRIQUE, INSÉREZ LE BOUT LARGE DE LA FICHE
DANS LA GRANDE FENTE ET POUSSEZ JUSQU’AU BOUT.
¡PRECAUCIÓN! INSTRUCCIONES DE SEGURIDAD
IMPORTANTES:
ESTA LÁMPARA PORTÁTIL TIENE UN ENCHUFE POLARIZADO (UNA DE SUS PATAS ES MÁS ANCHA QUE LA OTRA)
COMO CARACTERISTICA PARA REDUCIR EL RIESGO DE UNA DESCARGA ELÉCTRICA. ESTE ENCHUFE ENCAJARÁ EN
CUALQUIER TOMACORRIENTE POLARIZADO SOLO DE UNA MANERA. SI EL ENCHUFE NO CALZA COMPLETAMENTE
EN EL TOMACORRIENTE DÉLE LA VUELTA. SI AÚN NO ENCAJA, PÓNGASE EN CONTACTO CON UN ELECTRICISTA
CALIFICADO. NUNCA UTILICE UNA EXTENSIÓN A NO SER QUE EL ENCHUFE PUEDA SER TOTALMENTE
INSERTADO. NO ALTERE EL ENCHUFE.
PRECAUCIÓN: PARA PREVENIR UNA DESCARGA ELÉCTRICA, HAGA COINCIDIR LA PATA ANCHA DEL
ENCHUFE CON LA RANURA ANCHA, INSERTE TOTALMENTE.
Hampton Floor Lamp
CAUTION! If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer
or its service agent or a similar qualified person in order to avoid a hazard. Indoor use only.
INS120013 REV010912
20w Hampton Floor Lamp
20H418VH-CA SL-786
FÉLICITATIONS! Vous avez fait l’achat
de la plus innovatrice technologie
naturelle et de renom en éclairage
avec votre produit OttLite.®
FORMULAIRE
D’ENREGISTREMENT DE PRODUIT
Compléter le formulaire d’enregistrement
qui est inclus pour votre produit et nous le
retourner dès aujourd’hui par le retour du
courrier, ou enregistrez-vous en ligne en
allant à :www.OttLite.com/warranty.
AVERTISSEMENT: Pour éviter les chocs
électriques, assurez-vous que la lampe
ne soit pas branchée avant d’avoir
effectué toutes les étapes de montage.
ASSEMBLAGE DE LA LAMPE
1. Assurez-vous que la lampe n’est pas
branchée dans une prise de courant
électrique.
2. Retirez la vis (H) de la tige supérieure
(F). Insérez la tige supérieure (F) au dos de
l’abat-jour (G), insérez à nouveau la vis (H)
et resserrez en utilisant l’outil (I) fourni.
3. Faites passer la tige inférieure (D) dans le
trou (C) du socle (B) jusqu’à ce qu’elle soit
solidement attachée.
4. Vissez la tige supérieure de la lampe (A)
dans la tige inférieure de la lampe (D).
5. Pour régler la hauteur de la lampe,
tournez la vis écrou (E) dans le sens inverse
des aiguilles d’une montre pour la desserrer.
Ajustez la tige supérieure à la hauteur dési-
rée puis resserrez la vis écrou en tournant
dans le sens des aiguilles d’une montre.
INSERTION/REMPLACEMENT DE
L’AMPOULE
1. Assurez-vous que la lampe n’est pas
branchée dans une prise de courant
électrique.
2. Si la lampe a été utilisée, laissez-la
refroidir pendant environ cinq minutes
avant de continuer.
3. Pour installer une ampoule (L) dans
la douille, attrapez-la fermement et
poussez-la directement dans la douille
en appliquant une pression sur la
base de l’ampoule jusqu’à ce qu’elle
« s’enclenche » en position.
4. Pour retirer une ampoule (L) déjà
installée dans la lampe, attrapez-la
fermement et retirez-la vers l’extérieur
de la douille. Ne faites pas pivoter ou ne
tournez pas l’ampoule en la retirant de la
douille.
5. Branchez la lampe dans une prise
standard de 120V. Votre lampe est prête
à l’emploi.
6. Pour allumer ou éteindre la lampe,
appuyez sur le commutateur à bascule (K).
Veuillez noter qu’une fois en marche,
l’intensité des ampoules OttLite®ne peut
pas être réglée.
Profitez de votre lampadaire Hampton
d’OttLite®!
Ce système d’éclairage est conçu pour
être utilisé avec les tubes OttLite®type
(numéro de style SB20-M). L’utilisation
d’autres produits annule la garantie
et pourrait endommager le système
d’éclairage.
FRANÇAIS Lampadaire Hampton
ATTENTION! Si le câble ou le cordon souple externe de ce lampadaire est endommagé, celui-ci doit être remplacé exclusive-
ment par le fabricant, son agent de service ou toute personne compétente afin d’éviter tout danger. Pour usage à l’intérieur seulement.
20w Hampton Floor Lamp
20H418VH-CA SL-786
¡FELICITACIONES! Usted acaba de
adquirir la mejor tecnología de iluminación
natural con su nuevo producto OttLite.®
FORMULARIO DE REGISTRO
Por favor, llene el Formulario de Registro
de Producto anexo y envíelo por correo
hoy mismo, o regístrese en línea visitando:
www.OttLite.com/warranty.
ADVERTENCIA: Para prevenir un choque
eléctrico, cerciórese de que la lámpara
no se conecte hasta que se complete el
ensamblaje y todos los pasos.
ENSAMBLAJE DE LÁMPARA
1. Cerciórese de que la lámpara no esté
conectada a un tomacorriente.
2. Retire el tornillo (H) del poste superior
(F). Inserte el poste superior (F) en la parte
trasera de la pantalla (G), vuelva a insertar
el tornillo (H) y apriete con la herramienta
anexa (I).
3. Enrosque el poste inferior (D) en el
agujero (C) de la base (B) hasta que
quede seguro.
4. Enrosque la varilla superior de la
lámpara (A) a la varilla inferior de la
lámpara (D).
5. Para ajustar la altura de la lámpara, gire
el anillo (E) en dirección opuesta a las
manecillas del reloj para aflojarlo. Ajuste
el poste superior hasta la altura deseada y
apriete el anillo girándolo en dirección de
las manecillas del reloj.
INSTALACIÓN/REEMPLAZO
DE BOMBILLO
1. Cerciórese de que la lámpara no esté
conectada en algún tomacorriente.
2. Si la lámpara ha estado en uso,
permita que se enfríe por aproximadamente
cinco minutos antes de proseguir.
3. Para instalar un bombillo (L) en el
soquete, sujételo firmemente en su mano
y empújelo bien derecho hacia adentro del
soquete aplicando presión a la base del
bombillo, hasta que “encaje” en su lugar.
4. Para retirar un bombillo (L) ya
instalado en la lámpara, sujételo
firmemente en su mano y hálelo bien
derecho hacia afuera del soquete. No gire
o dé vueltas al bombillo mientras lo retira
del soquete.
5. Conecte la lámpara a un tomacorriente
estándar de 120V y estará lista para su uso.
6. Para encender y apaguar la lámpara,
accione el interruptor oscilante (K).
Por favor tenga en cuenta que durante
la operación, los bombillo OttLite®no son
graduables.
¡Disfrute su lámpara de piso Hampton
de OttLite®!
Este sistema de iluminación está dis-
eñado para ser utilizado únicamente con
bombillos OttLite®typo (numéro de
style SB20-M). El uso de otros productos
anula la garantía y pudiera resultar en
daños al sistema de iluminación.
ESPAÑOL
¡PRECAUCIÓN! Si el cable o cordón flexible externo de esta luminaria está dañado, debe ser exclusivamente reemplazado por
el fabricante o su agente de servicio o una persona calificada similar a fin de evitar un riesgo. Sólo para uso en interiores.
Lámpara de Piso Hampton
L
INS120013 REV010912
