Outsunny SP5009 Series User manual

1
Mounting and User Instructions for
Free Standing Double Awning
SP5009 series
Content:
Parts list ——————————————2
Packing list ——————————————3
Mounting —————————————— 4
Usage —————————————9
Safety Instructions ——————————— 10

2
Parts list：
1
Hex bolts M6*12
2
Gasket φ6
3
Square shaft cover
4
Roller and Gearbox
Connection
5
Roller
6
Round shaft
case
7
Roller connection
8
Round shaft cover
9
Gasket φ6
10
Hex bolts M6*25
11
Hex bolts M8*60
12A
Arms
12B
Standing pole
13
Screw nut M8
14
Front bar
15
Hex bolts M8*25
16
Standing pole
base
17
Plastic case
18
Short steel base
19
Long steel base
20
Crank handle

3
PACKING LIST:
NAME
PARTS NO.
QT’Y
1
Standing
Pole and
Arms
12B/12A
2
steel base
and plastic
case
19/17
2
steel base
and plastic
case
18/17
2
Standing
pole base
16
2
Crank
handle
20
1
Roller and Gearbox
Connection
4
1
Roller connectio
7
1
Square shaft cover
3
1
Round shaft cover
8
1
Round shaft case
6
1
Hex bolts M8*60
11
2
Hex bolts M8*25
15
8
Gasket φ6/Hex bolts M8*25
9/10
1
Gasket φ6/Hex bolts M6*12
2/1
1
Screw nut M8
13
4

4
Mounting：
STEP1：
STEP2：

5
STEP3：

6
STEP 4 and STEP 5:
STEP 6:

7
STEP 7:

8
STEP 8:

9
Usage：
1、Extend and retract the awning
The awning can be extended and retracted by a crank handle included in delivery.
Insert the handle in the loop that is fixed at the awning. Open the awning by turning the crank handle clockwise. By
turning it counter-clockwise you can retract the awning.

10
To insure that there is over 50kgs board press on the each steel base seat.
Important Safety Instructions:
To install this awning technical knowledge is necessary. Do not mount this awning
yourself but contact a professional workman or 3 more adult for help if
you are unsure if the awning can be mounted on the place you chose for
installation.
you do not understand the instruction manual or parts of it.
you do not have necessary tools available.
you do not have necessary technical knowledge
To insure that there is over 50kgs board press on the steel base seat.
It is not to be used during periods of strong wind , rain, hail, or snow. In case of such conditions, retract
the awning immediately.
Once the adjustment screw reaches its end position you may not turn it further. Do
not force it! Disobeying this instruction can lead to damage on the awning that can cause

11
hazard and void the warranty!
The awnings are intended as a protection against the sun only. It is not to be used
during periods of strong wind, rain, hail, or snow. In case of such conditions, retract the
awning immediately.
Never allow children to play with the awning.
Be sure the fabric is tensioned. If the fabric is not tensioned during extension, please
turn counter-clockwise until the fabric is tensioned.
Do not put any objects or parts of your body e. g. hands, in the awning while
extending and retracting. Hazard of crush!
When the front bar touches the roller as shown in following figure during retraction, don’t
try to make them closer, otherwise the product might be damaged.
Take out the crank handle from loop after adjusting the awning as you wish and put it on
a place that is not reachable for children to avoid that they play with the awning.
Maintenance
Regular maintenance will not only help to keep a long durability but is also important for your own and the safety of
other people.
Examine regularly if wall brackets are tight, fasten them if loose or lax.
Examine the gear box once in half a year. If you find any damages stop using the awning until gear box has
been repaired or renewed.
Examine the bolts and nuts once in half a year, fasten them if loose or lax.
Stop using the awning immediately if is has been damaged or it is not tighten properly.
Please contact an authorized service centre for repair and if you have any further questions.
Manufacturer information
Manufacturer: Zhejiang Lanxi Shengpeng Arts ＆CraftsCo., Ltd.
Address: №7 Caihong Roda,Light Industry Area,Lanxi,Zhejiang,China
P.C.3211103
