OYPLA Home 3115 User manual

2KW Free Standing Patio Heater
User Manual
USER MANUAL Model No: 3115
User Manual

USER MANUAL Model No: 3115
•Make sure all bolts are secured before using. The user takes all responsibility for the
construction and placement of the product.
•Make sure the quartz tube heater is out of the reach of children to avoid potential hazards
and injuries.
•Never leave the heater unattended.
•Once you are finished with the patio heater be sure to turn it off, leaving it on can be
dangerous. Allow to cool before moving/storing.
•To protect against electrical shock, do not immerse cord, plug or any part of this appliance
in water or any other liquid.
•Ensure the power supply to the socket into which the appliance is plugged, is in accordance
with the rating label on the appliance and that the socket is earthed.
•Leaving the product outside exposed to weather, especially direct sun, rain and salt air, will
speed the weathering process. This can be slowed by removing the product from these
conditions, or covering it with a suitable cover.
•This product is not a toy, and is only to be used for its designated purpose.
•Do not carry out alterations or modifications to this product.
•This product is intended for outdoor use only.
•Clean only with a damp cloth. Do not use strong industrial cleaning substances. Never clean
while hot or in use.
•If the product is damaged or has any defects, please contact cser[email protected]
Safety Instructions
Notice: Ensure you read and fully understand instructions before use
While every attempt is made to ensure the highest degree of protection in all equipment, we cannot
guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold on
this condition, which no representative of the company can waive or change.

Operating Instructions
Parts List:
If you are missing any of the below parts please contact [e-mail]
Please be aware that you will be referring to this parts list throughout the assembly process.
USER MANUAL Model No: 3115USER MANUAL Model No: 3115

USER MANUAL Model No: 3115
1. Begin by unscrewing the base screws (part 1) and the base pole screws (part 2, M6X30). Attach the lower
support pole (part 3) to the base (part 4) using the base pole screws (part 2, M6X30) and tightening them
until secure. After this, slide the screw cover (part 5) over the lower support pole (part 3) and push it down
until it connects with the base (part 4).
2. Unscrew the support screws (part 6, M5X6) found at the top of
the lower support pole (part 3). Slide a power cord fixture (part 7)
onto the lower support pole (part 3), securing this in place with
the fixture screw (part 8, M5X15) and the nut that is pre-installed
in the power cord fixture (part 7).
3. Once done, slide the middle support pole (part 9)
on to the lower support pole (part 3), ensuring that
they are tightly connected. After this, secure both
poles together using the support screws (part 6,
M5X6) taken from the lower support pole (part 3).
Do not overtighten.
Part 1
Part 2
Part 3
Part 3
Part 5
Part 4
Part 7
Part 8
Part 9
Part 3
Part 6

4. Unscrew the support screws (part 6, M5X6) found at the top of middle support pole (part 9). After this,
slide a power cord fixture (part 7) on to the middle support pole (part 9), securing it in place with the fixture
screw (part 8, M5X15). Once done, push the upper support pole (part 10-A) in to the middle support pole
(part 9), ensuring that they are tightly connected. After this, secure both poles together using the support
screws (part 6, M5X6) taken from the middle support pole (part 9). Do not overtighten. Please see the images
below.
5. Loosen the height adjustment knob (part 10-C) found at the top of the upper support pole (part 10-A).
After this, slide a power cord fixture (part 7) on to the height adjustment pole (part 10-B) securing it in place
with the fixture screw (part 8, M5X15). Pull the height adjustment pole (part 10-b) out from the upper
support pole (part 10-A). Slide the power cord fixture (part 7) onto the height adjustment pole (part 10-B).
Please see the images below.
Part 9
Part 7
Part 8
Part 10-A
Part 9
Part 6
Part 10-C
Part 10-B
Part 10-A
Part 10-A
Part 7
Part 8
Part 10-B
USER MANUAL Model No: 3115

Imported into the EU by Oypla.com LLP, Uxbridge, UB8 2FX
Environmental Protection
Products bearing the symbol shown above means that used electrical and electronic equipment (WEEE) should not be mixed
with general household waste. For proper treatment, recovery and recycling, please take this product(s) to designated collection
points where it will be accepted free of charge. Disposing of this product correctly will help save valuable resources and prevent
any potential negative effects on human health and the environment, which could otherwise arise from inappropriate waste
handling. Please contact your local authority for further details of your nearest designated collection point. Penalties may be
applicable for incorrect disposal of this waste, in accordance with your national legislation.
Please retain a copy of all instructions for future
consultation.
6. Attach the heater enclosure (part 11-A) to
the height adjustment pole (part 10-B) by
using the attachment screw (part 11-B) that’s
found on the back of the heater enclosure
(part 11-A). Please see the image to the right.
7. After completing all previous steps, push the power cord into the power cord fixtures that are on the
support poles of the 2KW Quartz Free Standing Patio Heater. One done, turn the 2KW Quartz Free Standing
Patio Heater on by pulling on the cord found on the back of the heater enclosure. It has four heat settings;
0 (off), 1 (650W, low), 2 (1350W, medium) and 3 (2000W, high).
Part 10-B
Part 11-A
Part 11-B
