ASSEMBLY INSTRUCTIONS MODEL W771A, 86.5” x 39.5” 1 Person Bivy Tent
DANGER
DANGER
WARNING
SAFETY WARNING -
DOs AND DO NOTs
EVERYONE WHO USES THIS TENT SHOULD READ THIS MANUAL AND BECOME FAMILIAR WITH ALL
SAFETY WARNINGS AND PRECAUTIONS FOR SAFE USE, ASSEMBLY, CARE, MAINTENANCE,
AND STORAGE. KEEP THIS MANUAL SO YOU CAN REFER TO IT LATER.
CARBON MONOXIDE GAS WILL KILL YOU
Stoves, heaters, grills, lantern, candles, and other fuel-burning devices that burn propane, natural gas, charcoal, kerosene, coal, or other fuels
produce a toxic gas called carbon monoxide. Because carbon monoxide gas is invisible, odorless, and colorless, a dangerous level of carbon
monoxide gas can accumulate in a tent which cannot be detected by sight, smell, or taste. For these reasons:
• DO NOT use matches, lighters, stoves, heaters, grills, lanterns, candles, cooking equipment, or other fuel-burning devices inside or near a tent.
• DO NOT build fires inside or near a tent.
• DO NOT leave campfires unattended.
Your failure to follow this warning will cause death, serious injury, or permanent disability to you or others.
• DO NOT leave children unattended inside a tent or in camp.
• DO NOT allow children to assemble a tent.
• DO NOT allow children to enter or exit a tent except through the door.
• DO NOT allow children to remain in a closed-up tent on hot days.
Your failure to follow this warning will cause death, serious injury, or permanent disability to your children.
PROTECT YOUR CHILDREN
This tent is made with flame resistant fabric which meets CPAI-84 specification. IT IS NOT FIREPROOF. The fabric will burn if left in continuous
contact with any flame source. The application of any foreign substance to the tent fabric may render the flame-resistant properties ineffective.
Your failure to follow this warning could cause death, serious injury, or permanent disability to you or others.
FLAMMABILITY WARNING KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC
1. Do not pitch tent near open fire.
2. Do not leave campfire unattended.
3. Do not leave children unattended inside a tent.
4. Do not use heating, lighting or cooking equipment with open flames in or near tents.
5. Do not use other than recommended water repellent compounds on your tent.
6. Do not spray the tent with insecticide.
7. Do not store tent on concrete floor.
CAMPING DO’S AND DON’TS
DO NOT...
1. Always extinguish campfire before leaving area.
2. Exercise care when using electricity and lighting in and near tents.
3. Make certain your tent is properly ventilated in all weather conditions. In extreme weather conditions, snow could obstruct airflow and
cause asphyxiation unless cleared frequently.
4. Anchor your tent securely to provide additional security from changing climatic conditions. Snow pegs, skis and/or heavy rocks may
be necessary to supplement tent stakes and guy cords.
5. Take your tent down and store properly after camping.
DO...
DO NOT LEAVE YOUR TENT SET UP IN DIRECT SUNLIGHT LONGER THAN NECESSARY. THE SUN’S ULTRAVIOLET
(UV) LIGHT DEGRADES ALMOST EVERY FABRIC AND MATERIAL. IF LEFT IN SUNLIGHT FOR PROLONGED PERIODS
OF TIME, FABRIC WILL FADE AND WEAKEN. DO NOT STORE TENT ON CONCRETE FLOOR. DO NOT SPRAY THE
TENT WITH INSECTICIDE.
Your tent is water repellent, however, it is not waterproof. During heavy rain, some leakage may occur. Keep
objects from touching the inside of the tent. Such objects may cause leakage at point of contact. If seam leakage
occurs, it can be controlled by applying a seam sealer compound.
EXERCISE CARE WHEN USING ELECTRIC DEVICES IN AND NEAR TENTS.
Although our tents and screen houses are constructed to rigid specifications, periods of wind or rain
soaking the ground may loosen the stakes and cause the uprights to sink into the ground. This will
weaken the rigidity of the overall structure. Water pockets may also form in the roof if the unit is not
assembled taut, possibly causing broken frames and torn fabric.
If you have questions or need to order a part, call 1-800-325-4121 or send an e-mail to [email protected].
Have your model number or part number ready when you call. DO NOT ORDER BY REFERENCE KEY NUMBER.
Send your request for parts to:
Exxel Outdoors, LLC.
6235 Lookout Road
Boulder, CO 80301
CARE
REPLACEMENT PARTS
MODEL NO W771A, 86.5” x 39.5” 1 Person Bivy Tent
W771U
4
4
8
A
DESCRIPTION PART NO.
QTY
REQ
KEY
NO.
Upright Pole
Guy Rope
Steel Stake
A1001
PIN STAKE

ASSEMBLY INSTRUCTIONS MODEL W771A, 86.5” x 39.5” 1 Person Bivy Tent
IMPORTANT: WE ADVISE YOU TO ASSEMBLE THE TENT ONCE BEFORE
GOING CAMPING TO BECOME FAMILIAR WITH THE ASSEMBLY OF THE TENT.
NOTE: PLEASE LOOK AT THE REPLACEMENT PARTS DIAGRAM TO SEE HOW
YOUR FRAME IS ASSEMBLED.
TO PROLONG THE LIFE OF THE TENT FLOOR, SELECT A LEVEL, CLEAN AREA
FOR THE CAMPSITE. TO PREVENT DAMAGE TO THE ZIPPER, UNZIP THE
DOORS TO ALLOW AIR TO ENTER THE TENT.
STEP 1: Spread tent out flat, floor side down. Unzip bottom of door to allow
air to enter the tent.
Top View NOTE: To take down tent, follow steps above in the reverse order. Be sure to
leave doors unzipped. MAKE SURE TENT IS CLEAN AND DRY BEFORE
STORING. Place stakes into stake bag and poles into pole bag, which are
provided. The tent should be folded into equal parts toward the center to
distribute the bulk. Fold fly and lay on top. Start a small tight roll, the width
of your carry bag, with the pole bag placed at the end opposite the doors.
Roll tent toward doors to allow air to escape. Once rolled, secure with strings
or rope, and place into carry bag.
STEP 3: Extend the four aluminum poles (A) by pulling out each section and
placing the jointed ends into the connected pole sections.
STEP 2: Stake tent to the ground by inserting metal stakes
through the stake loops at the four corners. Hammer stakes
into ground at a 45° angle and pull tent floor out even and
snug.
STEP 4: On one side of the tent, insert the tip of the pole
into the grommet on the webbing just above the grey vent.
Insert the other pole end into the grommet at the base of
the tent. Repeat this step at the other side of the tent.
STEP 5: Guy ropes are needed to stand up the tent ends.
Locate the guy rope at the end of the webbing above the
vents. Make a loop at the end by using slider (as shown)
and place loop over tent stake. Pull directly to the side of
the tent and hammer stake into ground at a 45° angle.
Adjust slider to make guy rope snug. Repeat with the
corresponding guy rope on opposite side of tent.
Tent should appear as shown
STEP 6: The front door can be zipped open and guyed out as a porch awning.
To set up the awning, locate the 2 remaining aluminum poles. Place the end of
one pole into the grommet at the corner of the unzipped door and place the
opposite end on the ground.
STEP 7: With the awning pole aligned vertically extend the guy rope at the
corner of the awning and make a loop at the end by using the slider and place
loop over tent stake. Hammer stake into ground at a 45° angle. Adjust slider
to make guy rope snug.
STEP 8: Repeat steps 6 at 7 at the second corner of the awning.
Tent should appear as shown.
A
A
