Ozito OZPPL280WA User manual

PALM PLANER
280W MODEL NO. OZPPL280WA
www.ozito.com.au
To view our full range visit
OPERATING INSTRUCTIONS

1. Depth of cut adjustment knob
2. Lock off button
3. On/Off Switch
4. Rubber Palm Grip
5. Rear Shoe (Not shown)
6. Drive belt cover
7. Planer drum (Not shown)
8. Adjustable front shoe
9. Material extractor port
10. Spanner
11. Chip Collection Bag
Motor size: 280W
Input: 230 – 240V ~ 50Hz
No load speed: 18000 /min
Planing width: 50 mm
Planing depth: 0 – 0.6 mm
Blade type: 50 mm TCT reversible slither blades
Weight: 1.4kg
Features: Ergonomic design
Material collection bag
Variable depth of cut
Soft grip handle
Palm grip design
This Palm Planer has been designed to comply with the following Australian/New Zealand
Standards and any other applicable standards referenced therein:
AS/NZS 60745-1 Hand held motor operated electric tools - Safety
general requirements.
AS/NZS 60745-2.14 Hand held motor operated electric tools.
Particular requirements for planers
8
1
3
5
7
4
6
9
2
11
10
2
SPECIFICATIONS – MODEL NO. OZPPL280WA

3
TABLE OF CONTENTS
SPECIFICATIONS…………………………………………
TABLE OF CONTENTS…………………………………..
INTRODUCTION………………………………………...
SAFETY INSTRUCTIONS………………………………..
OPERATION ……………………………………………..
MAINTENANCE …………….…………………………..
CONTENTS ……………………………………………...
WARRANTY………………………………………………
Page 2
Page 3
Page 4
Page 4
Page 8
Page 10
Page 11
Page 12

INTRODUCTION
SAFETY INSTRUCTIONS
ELECTRICAL SAFETY
4
Congratulations on purchasing an Ozito Palm Planer.
We aim to provide quality tools at an affordable price.
We hope you will enjoy using this tool for many years.
Your Ozito Palm Planer OZPPL280WA has been designed
for planing timber and is intended for DIY use only.
Warning! When using mains-powered equipment, basic safety
precautions, including the following, should always be
followed to reduce risk of fire, electric shock, personal injury
and material damage.
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for
future reference.
The electric motor has been designed for 230V and 240V only. Always
check that the power supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable
for Australia and New Zealand.
If the supply cord is damaged, it must be replaced by an electrician or a
power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety
precautions when operating this tool. The insulation system is for added
protection against injury resulting from a possible electrical insulation
failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of
this tool. Before use, inspect the extension lead for signs of damage, wear
and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead
completely. Use of an extension lead not suitable for the power input of
the tool or which is damaged or defective may result in a risk of fire
and/or electric shock.
It is recommended that the extension lead is a maximum of 25m in
length. Do Not use multiple extension leads.
!
!

5
GENERAL SAFETY INSTRUCTIONS
Warning! Read all instructions, Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury. The
term “Power Tool” in all of the warnings listed below refers to your
mains operated (corded) power tool or battery operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
1) WORK AREA
a) Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use safety equipment. Always wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Avoid accidental starting. Ensure the switch is in the off position
before plugging in. Carrying power tools with your finger on the switch or
plugging in power tools that have the switch on invites accidents.
!
!

6
GENERAL SAFETY INSTRUCTIONS (cont.)
d) Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of these devices can reduce dust related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that can not be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools, unplugged & out of the reach of children
and do not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may
affect the power tools operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance
with these instructions and in the manner intended for the
particular type of power tool, taking into account the working
conditions and the work to be performed. Use of the power tool for
operations different from intended could result in a hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of
the power tool is maintained.

ADDITIONAL SAFETY INSTRUCTIONS FOR PLANERS
7
Warning! Use of this tool can generate dust containing chemicals
known to cause cancer, birth defects or other reproductive harm.
Use appropriate respiratory protection.
•Recommendation for the use of a residual current device with a rated
residual current device of 30mA or less for extra protection against
electric shock.
• Read the instruction manual thoroughly before using this tool.
• Ensure the voltage agrees with specific data on the nameplate.
• Be sure to switch OFF immediately if the tool is jammed in work.
• Ensure the tool is disconnected from power source when cleaning or
making adjustments to the tool.
• Ensure the tool is properly held and set for correct use before turning
switch to ON.
•Be sure to use specified replacement parts only.
• Be sure to maintain tool with care. Follow instructions for lubricating
and changing accessories.
• Be sure to store tool in a clean dry place after disconnecting from
power source.
• Keep air vents unobstructed for proper motor cooling.
• Wait for the cutter to stop before setting the tool down. An exposed
cutter may engage the surface leading to possible loss of control and
serious injury.
•DO NOT lay tool down on shoe when the blades are exposed.
This can chip the blades.
•Never reach under the tool for any reason unless it is turned off and
unplugged. BLADES ARE EXPOSED AND EXTREMELY SHARP.
•Use this tool for working with wood and wood products only.
•It is recommended that you operate your palm planer with two hands.
• Planer blades are extremely sharp – Handle with great care.
CAUTION: Some wood contains preservatives such as copper
chromium arsenate (CCA) which can be toxic. When sanding,
drilling, or cutting these materials extra care should be taken
to avoid inhalation and minimise skin contact.
!
!
!
!

8
Switch
ALWAYS PICK UP YOUR PALM PLANER BEFORE DEPRESSING THE SWITCH.
The palm planer is started by first depressing the lock-off button (2) on
the top of the handle and then depress the On/Off switch (3). The palm
planer will not start unless the lock off button (2) is depressed. To turn the
palm planer OFF, release On/Off switch (3).
This tool is not designed for the On/Off switch to be locked in the ‘ON’
position. Never jam the On/Off switch in the ‘ON’ position.
Adjusting Planing Depth
WARNING: TURN OFF AND UNPLUG PALM PLANER.
Planing depth is infinitely variable from 0 to 0.6 mm. This is adjustable by
rotating the depth of cut adjustment knob (1). As the knob is rotated
clockwise from the “0” position the cutting depth will increase from 0 to a
maximum of 0.6 mm.
It is recommended that test cuts be made in scrap wood after each
re-adjustment to make sure that the desired amount of wood is being
removed by the palm planer. Several shallow passes will produce a
smoother finish than one deep pass.
Planing
Ensure that the work piece is firmly secured.
Adjust the palm planer to the desired depth of cut.
Hold the rubber palm grip (4) firmly in one hand while holding the depth
of cut adjusting knob (1) with your other hand. Place the front shoe (8) on
the surface to be planed, making certain that the cutting blades are not
touching the surface.
Push down firmly on the rubber palm grip (4) of the palm planer so that
the front shoe (8) is ABSOLUTELY FLAT on the work surface. Depress the
lock off button (2) and then depress the On/Off switch (3). Allow the
motor to reach full speed before beginning to plane.
Move the tool slowly into the work and maintain downward pressure to
keep the palm planer flat. Be particularly careful to keep the tool flat at
the beginning and the end of the work surface.
Planing Tip
For a smoother appearance, fasten a piece of scrap wood to the end of
the piece you are planing. Don’t stop planing until the cutting blades of
the planer are past your work piece and into the scrap material.
Edge Chamfering
Your palm planer has a precision machined groove in the front shoe for
planing along a corner of the wood. It is a good idea to try a scrap piece
of wood before doing final pieces.
TOOL OPERATION
!
!

9
Dust Bag
Regularly check and empty the dust bag for best results.
Changing And Adjusting Blades
For best results, keep the blades clean and replace when necessary.
To Change Blades
Before you make any adjustments, make sure the power cord has been
disconnected from the electricity supply.
The blades that come standard with the tool are 50mm TCT reversible, slither
blades (D).
The planer drum (7) is fitted with two separate blades; both must be reversed
or replaced at the same time. Never replace only one blade.
• Loosen (do not remove) the hex head bolts (B) with the 8 mm spanner (10)
provided.
• With the two hex head bolts (B) loose, push the old blade out of the
blade block (F) with a screwdriver. The blades have two cutting edges on
them. If this is the first time you are changing blades, you need only to
turn the blades around to expose the fresh cutting edge, otherwise you
will have to replace the blades.
•Install the new or reversed, blades by sliding the blades all the way back
into the blade block (F) until the end of them is flush with the edge of the
rear shoe.
• Securely tighten the two hex head bolts (B) (repeat for both blades).
Fitting The Material Collection Bag
•Secure the plastic sleeve on the end of the material collection bag (11) on
to the material extractor port (9) on the side of the palm planer.
Changing The Drive Belt
• Remove the two screws on the drive belt cover (6) and remove the cover.
Remove the broken or damaged belt.
• Place the new drive belt onto the smallest drive pulley first and while
turning the planer drum (7) anti-clockwise slip the new belt onto the larger
planer drum (7) drive pulley until the belt is fully located over all of the
pulley drive grooves.
TOOL OPERATION (cont.)
Fig. 1
7. Planer drum
F. Blade blockE. Blade Plate
D. TCT reversible slither blades
C. Allen key blade height adjuster screws
B. Hex head bolts

10
MAINTENANCE
• After each use, blow air through the tool housing to ensure it is free
from all dust particles that may build up. Build up of dust particles
may cause the tool to overheat and fail.
• If the housing of the tool requires cleaning do not use solvents but a
moist soft cloth only. Never let any liquid get inside the tool; never
immerse any part of the tool into a liquid.
• When the carbon brushes wear out the tool will spark and/or stop. The
brushes are a consumable component of the tool and should be
replaced prior to the carbon wearing out fully. Brushes will wear out
after many uses but before they do take the tool to a power tool
repairer for quick and low cost replacement. Always replace both
brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the tool by an unauthorised person or by
mishandling of the tool.
VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute
Double insulated Regulator compliance mark
n o No load speed
DESCRIPTION OF SYMBOLS
Power tools that are no longer usable should not be
disposed of with household waste but in an
environmentally friendly way. Please recycle where
facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landfill and
raw materials. Reuse of recycled material decreases
pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council
authority for recycling advice.
CARING FOR THE ENVIRONMENT

1 x Palm Planer OZPPL280WA
1 x Material collection bag
2 x TCT Blades (fitted)
1 x 8mm Spanner
1 x Operation manual
AUSTRALIA (Head Office)
1-23 Letcon Drive, Bangholme Victoria, Australia, 3175
Telephone: [phone]
Website: www.ozito.com.au
Email: [email protected]
CONTENTS
OZITO INDUSTRIES PTY LTD
11

WARRANTY
THIS WARRANTY FORM AND CONFIRMED BUNNINGS REGISTER RECEIPT SHOULD
BE RETAINED BY THE CUSTOMER AT ALL TIMES
The warranty is only made available by returning the product to your nearest
Bunnings Warehouse with a confirmed Bunnings register receipt.
PURCHASED FROM:________________________________________________
DATE PURCHASED: ________________________________________________
3 YEAR REPLACEMENT WARRANTY
Your Ozito tool is guaranteed for a period of 36 months from the original date of
purchase and is intended for DIY (Do it yourself) use only.
WARNING
The following actions will result in the warranty being void.
•Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage other than that specified on
the tool.
•If the tool shows signs of damage or defects caused by or resulting from abuse,
accidents or alterations.
• If the tool is disassembled or tampered with in any way.
Note: Warranty excludes consumable parts such as brushes, batteries, sanding
pads, blades, discs, drill bits, collets, drive belts and other accessories.
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES.
SHOULD YOU HAVE ANY QUESTIONS PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY OR
REPAIR PLEASE TELEPHONE OUR CUSTOMER
SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER
AND DATE OF PURCHASE AVAILABLE. AN OZITO CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND ANSWER ANY QUESTIONS
YOU MAY HAVE RELATING TO THE WARRANTY POLICY OR PROCEDURE.
