Ozito Power X Change PXPLS-082 User manual

STANDARD EQUIPMENT
0.5
0
0.5
0
PXPLS-082
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
No Load Speed: 15,000/min
Planing Width: 82mm
Planing Depth: 0-2mm
Rebate Depth: 0-8mm
Blade Type: Reversible 65Mn
Blade Dimensions: 82 x 5.5 x 1.2mm
Weight: 2.41kg
ozito.com.au
0520
Cordless Planer
Parallel Guide, Angle Bracket
& Rebate Guide
2 x Thumb Screws, Carriage
Bolt & Wingnut
Spanner & Hex Key
CORDLESS
PLANER
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
0.5
0
1.5
2
Attaching The Rebate Guide
The rebate guide allows you to create a stepped cut of a specic height in a
piece of material
1. Place the rebate guide in the slot on the
same side as the dust extraction chute.
2. Place one of the supplied
thumbscrews into the slot and
tighten by rotating it clockwise.
Attaching The Parallel Guide
1. Fasten the angle bracket to the parallel
guide using the supplied carriage bolt and
wingnut.
2. Align the angle bracket with the
hole on the side of the planer.
3. Place one of the supplied thumbscrews
into the hole and tighten by rotating it
clockwise.
1. Depth Adjustor
2. Safety Lock-Off Button
3. On/Off Trigger
4. Battery Seating
5. Base Park Shoe
6. Rear Base Plate
7. Motor Housing
8. Parallel Guide
9. Angle Bracket
10.Front Base Plate
11.Cutting Depth Guide
12.Dust Extraction Port
13.Rebate Thumbscrew
14.Rebate Guide
This tool is compatible with all batteries & chargers from the Ozito Power X Change
range.
For optimal performance, we recommend the use of a 3.0Ah battery or
larger battery to operate this tool..
CORDLESS PLANER
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. ASSEMBLING THE GUIDES
SETUP & PREPARATION
1.5
2
0.5
0
1.5
2
0.5
0
1 42 3
10
14
13
11
12
56789
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

Cutting Depth Adjustment
The planing depth can be adjusted between 0 and 2mm. The numbers on
the depth adjustment knob correspond to the planing depth (mm). Always
test the setting on a scrap workpiece rst.
1. Increase the cutting depth by
rotating the knob clockwise.
2. Decrease the cutting depth by rotating the
knob counter-clockwise.
Note: Set the depth adjustment knob back to ‘0’ once nished with the
tool to protect the blades from damage.
Rebate Guide Adjustment
1. Loosen the rebate thumbscrew.
2. Slide the rebate guide to the
required depth.
3. Tighten the rebate thumbscrew to secure
it.
Dust Extraction
A vacuum can be tted to the dust
extraction chute during planing jobs
to collect dust and wood chips,
keeping the work area cleaner.
Installing The Battery Pack
1. Slide the battery into the tool
base until it clicks into place.
2. To remove the battery, hold down
the battery release button and
then slide the battery out.
3. CONTROLS
OPERATION
1.5
2
0.5
0
1.5
2
1.5
2
1.5
2
1.5
2
0.5
0
1.5
2
WARNING! ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

Parallel Guide Adjustment
1. Loosen the parallel guide wingnut.
2. Slide the guide to the required
position and tighten the wingnut.
3. After adjusting the parallel guide, make
sure the guide is clear of the blade
by adjusting the position of the angle
bracket.
Turning The Tool On/Off
1. Press and hold the lock-off
button.
2. Pull the on/off trigger to start the tool.
You can then release the lock-off button.
3. Release the on/off trigger to stop
the planer.
Note: Wait until the blade comes
to a complete stop before setting
the tool down.
Automatic Base Park Shoe
The Base Park Shoe allows you to
rest the planer on the workpiece
without the blades causing dents or
damage.
The park shoe will rotate out of the
way when the tool is pushed along
the work surface.
WARNING! THE PARK SHOES DOES NOT PROTECT
THE BLADE FROM DAMAGE. ALWAYS WAIT UNTIL
THE BLADE STOPS COMPLETELY BEFORE SETTING
THE PLANER DOWN.
0.5
0
0.5
0
0.5
0
0.5
0
0.5
0
0.5
0
0.5
0

Planing Flat Surfaces
1. Set the required depth on the planer.
2. Adjust the parallel guide as
necessary.
Note: For nishing surfaces, use
a low chip depth and make multiple
passes over the material.
3. Rest the front base plate
completely at on the material
surface, ensuring the blades
are not in contact with the
material. Hold the depth adjustor
with one hand and the trigger
handle with your dominant hand.
4. Switch on the planer and allow
the planer to reach maximum
speed.
5. Steadily push the planer over the
surface with both hands. Allow
the blades to do the work.
Note: Ensure that both base
plates lie at along the material
during planing.
Note: Place more pressure on the rear base plate when lifting the planer
off the material. This will reduce the possibility of creating gouges as you
lift the planer off.
Chamfering Edges
The planer has a precision machined ‘V’ groove in the front base plate for
making 45° chamfers along the edges of your workpiece.
1. Set the required depth on the planer.
Note: A layer of material will be removed
from the workpiece even if the cutting depth
is set to 0; always test the setting on a scrap
workpiece rst.
2. Place the groove precisely on the
corner of the workpiece.
3. Plane along the edge of your
workpiece.
0.5
0
0.5
0
0.5
0
0.5
0
0.5
0
4. USING THE PLANER
PXPLS-082

MAINTENANCE
WARNING! BEFORE CLEANING OR CARRYING OUT
ANY MAINTENANCE PROCEDURE, ENSURE THAT
THE BATTERIES HAVE BEEN REMOVED.
Cleaning
• Keep the ventilation slots of the tool clean at all times to ensure efcient
operation.
• After each use, blow air through the tool housing to ensure it is free from
all dust, dirt, etc. Build up of dust or dirt particles may cause the tool to
overheat and shorten the life of the tool.
• If the housing of the tool requires cleaning, do not use solvents. Use of a
cloth only is recommended.
• Never allow any liquid to get inside the tool, never immerse any part of
the tool into liquid.
Changing The Blades
Before you make any adjustments, make sure the battery has been removed
from the tool.
The blades that come tted to the tool are 82mm blades. The drum is tted
with two separate blades; both must be reversed or replaced at the same
time. Never replace only one blade.
WARNING! ALWAYS WEAR PROTECTIVE GLOVES
WHEN CHANGING THE BLADE.
1. Loosen the 3 hex head screws
using the spanner provided.
2. Push the used blade out through the slot
in the motor housing using a screwdriver.
Keep ngers away from blade.
3. Install new blades in the same orientation
as the worn blades.
Note: Blades are reversible. If changing
blades for the rst time, turn over the blades to expose a fresh cutting edge.
4. Tighten the 3 hex head screws.
5. Repeat the process for the second blade.
5. REBATE CUTS
Making a Rebate Cut
Rebates are recesses or grooves cut into the
edge of a piece of material.
1. Mark out the area for rebate and
clamp the workpiece down.
2. Adjust the parallel guide to the appropriate width.
3. Adjust the rebate guide to the height of
the desired rebate.
4. Adjust the chip depth by turning the depth
adjustment knob.
Note: It is recommended that rebates are
formed over several passes. A 6mm rebate
can be formed by making 3 passes over the
material at a depth setting of 2mm.
5. Switch on the planer.
6. Plane along workpiece, using the
parallel guide to keep the planer
square to the material.
7. The rebate guide indicates when
the required rebate height is
achieved. Keep planing along
the workpiece until the rebate
guide touches the surface of the
rebate.
1.5
2
0.5
0
0.5
0

DESCRIPTION OF SYMBOLS
Wear eye, ear & breathing
protection
Warning
Regulatory Compliance Mark
(RCM)
VVolts n0No load speed
/min Revolutions or reciprocations
per minute
Read Instruction Manual
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly
way. Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
Adjusting The Blade Height
The blade holders contain 2 grub screws each that control the height of
the planer blades. This is preset during factory assembly and should not be
adjusted when changing the blades.
If the height of the blades need to
be adjusted, the grub screws can be
turned with the provided Hex key.
1. Rotate clockwise to raise the
blades or anti-clockwise to lower
it. The blade should always be
parallel with housing drum.
2. To check that the blade is in the correct height, place a ruler or similar
against the surface of the rear base plate and rotate the roller. The blade
should just touch the ruler without scratching it. The height should be
checked on both ends of the blade.
3. If the blade hits the ruler, then the blade needs to be lowered.
If there is a gap between the blade and ruler then the blade needs to be
raised.
4. Repeat the process for the second blade.
Note: Always check the height of the blade with the ruler after changing
blades or altering the blade holder screws.
Storage
When not in use, the tool should be stored in a dry, frost free location, keep
out of children’s reach.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by repair of the tool by an unauthorised person or by mishandling.
1.5
2
FRONT BASE PLATE REAR BASE PLATE
STRAIGHT EDGE

ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of fire, electric shock, personal
injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New
Zealand.
This tools charger is double insulated; therefore no earth wire is required.
Note: Double insulation does not take the place of normal safety precautions when
operating this tool. The insulation system is for added protection against injury
resulting from a possible electrical insulation failure within the tool.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in
order to avoid a hazard.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or which is damaged or defective may result in a
risk of fire and electric shock.
The power supply for this products charger should be protected by a residual current device (rated
at 30mA or less). A residual current device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in
the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless)
power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a
second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected
situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from
one terminal to another. Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service provider.
PLANER SAFETY WARNINGS
WARNING! This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Wait for the cutter to stop before setting the tool down. An exposed cutter may engage the
surface leading to possible loss of control and serious injury.
• Use clamps or another practical way to secure and support the workpiece to a stable
platform. Holding the work by hand or against the body leaves it unstable and may lead to loss
of control.
• Use of this tool can generate dust containing chemicals known to cause cancer, birth
defects or other reproductive harm. Use appropriate respiratory protection.
• Be sure to read the instruction manual thoroughly before using this tool.
• Be sure to switch OFF immediately if the tool is jammed in work.
• Be sure the tool is disconnected from power source when cleaning or making adjustments
to the tool.
• Be sure the tool is properly held and set for correct use before turning switch to ON.
• Be sure to use specified replacement parts only.
• Be sure to maintain tool with care. Follow instructions for lubricating and changing
accessories.
• Be sure to store tool in a clean dry place after disconnecting from power source.
• Keep air vents unobstructed for proper motor cooling.
• DO NOT lay tool down on shoe when the blades are exposed. This can chip the blades.
• Keep side dust extraction port unobstructed at all times.
• Never reach under the tool for any reason unless it is turned off and the battery is
disconnected.
• BLADES ARE EXPOSED AND EXTREMELY SHARP.
• Use this tool for working with wood and wood products only.
• Never operate without securely holding the front handle.
• Always operate planer with two hands.
• Planer blades are extremely sharp – Handle with great care.
• Some wood contains preservatives such as copper chromium arsenate (CCA) which can be
toxic. When sanding, drilling, or cutting these materials extra care should be taken to avoid
inhalation and minimise skin contact.
