Ozito PXC PXSBK-418 User manual

SPECIFICATIONS
Input: 18V
No Load Speed: 800-1,400/min
Brush Diameter Max.: 115mm
Working Width Max.: 215mm
Max. Inlet Pressure: 87 psi (6 bar)
Max. Water Inlet Temp.: 35°C
Noise Rating: 94.6dB (A)
IP Rating: IPX0
Tool Weight: 4.1kg
STANDARD EQUIPMENT
Surface Brush
SURFACE
BRUSH
INSTRUCTION MANUAL
ozito.com.au
Additional Handle
Soft 2-Piece Nylon Brush & Cover
Hose Clip, Water Control Valve
Medium 2-Piece Nylon Brush
PXSBS-018
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO Australia/New Zealand (Head Ofce) 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
0321
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other
than that specied on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way
• Professional, industrial or high frequency use.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty Warranty excludes consumable parts, for example: and included
accessories.
CLOSED
OPEN

KNOW YOUR PRODUCT SETUP & PREPARATION
1. ASSEMBLY
1. Water Inlet Connector
2. Motor Housing
3. Hose Clip
4. Telescopic Shaft
5. Additional Handle
6. Speed Controller
7. Rear Handle
8. Battery Seating
9. On/Off Trigger
10. Forward/Reverse Switch
11. Knob
12. Nylon Brush
13. Brush Cover
14. Splash Guard
15. Shaft Collar
SURFACE BRUSH
1234567
8
BATTERY & CHARGER
This tool is compatible with all battery and chargers from the Ozito
Power X Change Range.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
10
11
9
WARNING!: ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
Fitting the Additional Handle
For transport reasons the Main Handle is at 90°to the brush housing. To
ensure that you have a comfortable working position, the main handle must
be aligned with the brush housing and the length of the Telescopic Shaft can
be adjusted.
1. Unscrew the two knobs on the
handle and separate the handle
from the bracket.
2. Place the top half in position and
secure in place with the bracket
on the underside and the two
knobs.
3. Tighten the two knobs to hold the
additional handle in position.
Note: To adjust the position, simple loosen the two knobs sufciently to
allow handle adjustment into the desired position, then tighten the two knobs
to secure in place.
1. Turn the Lock Nut anti-clockwise
to loosen and turn the Main
Handle 90°into alignment with
the brush housing.
2. To change the working height,
extended the Telescopic Shaft
to the desired height and then
retighten the Lock Nut by turning
it clockwise.
12 13 14 15
Adjusting the Working Height

2. CLEANING BRUSHES
2. The Medium Nylon Brush
(black) is supplied with a side
brush. Each of the brushes
have Rubber Caps on the
outside.
3. Slot the nylon brush with
side brush onto the brush
mount on either the left or
right side according to your
requirements and the other
nylon brush onto the other
brush mount.
1. Remove Brush Covers from each
end of the brush housing.
Fitting and Removing the Cleaning Brushes
Use only the brush which is intended to be used for the surface you want to
clean. Test the brush for suitability on an inconspicuous area rst before using
it each time. Different brushes for different surfaces are available as separate
accessories. Only use water without any additives whatsoever.
Note: Worn or frayed brushes should be replaced in good time. Replace the
brush as soon as its diameter is less than approx. 95 mm. A brush diameter of
any less can lead to damage.
•Medium Nylon Brush - Black
This brush is specically suitable for cleaning unsealed paver and stone
surfaces. It can therefore also be used for cleaning surfaces which are paved
with paving stones/concrete blocks or concreted surfaces (e.g. driveways,
decks, paths). The side brush can be used for cleaning perimeters and bases.
Diameter: 115mm. Working width: 215mm
Cleaning smooth, unsealed paver and stone surfaces
• Brush in a forward direction only, standard direction of rotation.
• In case of certain kinds of stubborn dirt, it can be helpful to clean using
both directions of rotation. Please note that when the equipment is in
reverse, it has less power.
• To clean perimeters and bases, remove the wide side cover and clean them
using the side brush.
• Afterwards, rinse the cleaned surface down with water.
•Soft Nylon Brush - Yellow/Green
This brush also be used for cleaning wood, composite materials such as
Bamboo Plastic Composite (BPC) and Wood Plastic Composite (WPC) or for
brushing (e.g. attened areas) articial turf to raise it upright, as used in the
home where it is installed, for example, on balconies or decks.
Diameter: 115mm. Working width: 195mm
Cleaning wood, composite materials(BPC/WPC)
• Always clean the boards or wooden elements in a longitudinal direction
(along the grain).
• Brush in a forward direction only, standard direction of rotation.
• It is recommended that you clean on a board-by-board basis.
• Afterwards, rinse the cleaned surface down with water.
Brushing articial turf
• Do not use water - dry-brush only.
• Brush in a forward direction only, standard direction of rotation.
• Remove all leaves, rubbish and similar before starting brushing.
WARNING!: ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
•Ultra Metal Brush (accessory)
This brush can be used for cleaning robust surfaces such as, e.g. paving
stones/ concrete blocks, concreted surfaces, granite or porphyry to remove
stubborn dirt.
Rough, unsealed paving stones, concrete blocks and
concrete surfaces
• Brush in a forward direction only, standard direction of rotation.
• In case of certain kinds of stubborn dirt, it can be helpful to clean using both
directions of rotation. Please note that when the equipment is in reverse, it
has less power. Afterwards, rinse the cleaned surface down with water.
• Not suitable for polished, ground or sealed natural/articial stone surfaces.
WARNING!: THE SURFACES MUST BE SUITABLE FOR
CLEANING USING ROTATING BRUSHES. FOR WET
CLEANING THE SURFACES MUST ALSO BE INSENSITIVE
TO WATER.
WARNING!: SENSITIVE, POLISHED, COATED AND
SCRATCH-SENSITIVE SURFACES CAN BECOME
ROUGHENED AND/OR GET DAMAGED. THIS EQUIPMENT
MUST NOT BE USED TO CLEAN SUCH SURFACES.
WARNING!: THERE IS A RISK OF INJURY FROM THE
BRISTLES - WEAR SAFETY GLOVES.
WARNING!: THERE IS A RISK OF INJURY FROM THE
BRISTLES - WEAR SAFETY GLOVES.

CLOSED
OPEN
3. PREPARATION
4. Attach the brush covers back in
place. The wider brush cover is
used with the Medium Nylon
Brush with the side brush.
1. Run water through your garden
hose to remove any foreign matter
before attaching to the water inlet.
Note: Do not use water that is
dirty, gritty or contains any chemical
products, as these could impair
operation and shorten the life of the
Surface Brush.
2. Pass a water hose (minimum Ø13mm
(½“), through the Additional Handle
and attach to the Water Inlet Connector
on the unit. Secure the hose to the
Telescopic Shaft with provided Hose
Clip.
Note: Always use a reinforced hose with
a standard hose coupling for water inlet.
To achieve top cleaning results quickly, use wet cleaning. Hose not included.
This Surface Brush requires a pressurised water source with a maximum
pressure of 87 psi (6 bar). It is recommended that a reinforced garden hose
(with minimum diameter of 12mm) is used for the inlet connection. It cannot
be used with a bucket and siphon.
Water Inlet Connector
5. The Soft Nylon Brush
(yellow/green) and the Ultra
Metal Brush is tted the
same way, but do not have a side
brush. In this case both narrow
brush covers must be used.
6. To remove brushes, rst remove
both Brush Covers on the sides.
Press the middle of the Rubber
Caps to release and pull the
brush to remove at the same
time.
Water Control Valve
The Water Control Valve can be tted
on the Water Inlet Connector before
attaching your hose. The Water
Control Valve can be opened or in the
closed position as required to control
the ow of water to the cleaning
brush.
WARNING!: ENSURE BOTH THE WATER SUPPLY
AND THE TOOL IS SWITCHED OFF AND THE
BATTERY DISCONNECTED BEFORE CONNECTING AND
DISCONNECTING THE WATER HOSE.
TAKE CARE NOT TO SPRAY WATER INTO THE MOTOR
VENTS ON THE SIDE OF THE MOTOR HOUSING. IF ANY
WATER DOES GET IT, LEAVE IN A COOL DRY PLACE TO
COMPLETELY DRY OUT BEFORE SWITCHING THE TOOL ON.

REV
FWD
REV
FWD
REV
FWD
REV
FWD
PXSBS-018
OPERATION
1. Align the ribs of the battery with
the battery mount and slide in
until it clicks into place
2. To remove, press and hold the
battery release tab and then slide
out.
Inserting & Removing the Battery
Switching On and Off
1. To switch ON, squeeze the
On/Off Trigger, the cleaning brush
will rotate.
2. To stop the cleaning brush
rotating, release the On/Off
Trigger.
Variable Speed Dial
To adjust the speed of the cleaning brush, rotate the variable speed dial. This
allows the speed to be adjusted to the particular surface being cleaned.
The dial is marked
MIN = slowest \ MAX = highest.
“1” to “5”. setting to indicate the set
speed.
4. CONTROLS
Direction Lever
Using the Direction Lever you can select the direction of rotation of the
cleaning brush and lock it so that it cannot be switched on accidentally. You
can select between forward and reverse rotation. Forward is the standard
direction of rotation, with which the unit has the most power.
Note: Hold the Surface Brush rmly by the handle and additional handle and
make sure you have a steady standing position.
Note: To avoid causing damage to the Surface Brush, the direction of
rotation must only be changed when the cleaning brush is at a standstill.
1. Forward - standard direction of
rotation: Push Direction Lever
hard left. The Surface Brush pulls
away from you.
2. Safety Lock-off: Direction Lever
in the middle position. On/Off
Trigger locked.
3. Reverse: Push Direction Lever
hard right. The Surface Brush
moves towards you.
WARNING!: KEEP YOUR HANDS AND FEET AWAY
FROM THE ROTATING CLEANING BRUSH.
WARNING!: ONLY INSERT THE BATTERY JUST
BEFORE YOU START YOUR WORK AND REMOVE IT
AGAIN WHEN YOU HAVE FINISHED.
WARNING!: TAKE CARE NOT TO EXPOSE THE
BATTERIES TO ANY WATER DURING USE. THE
BATTERY MUST NEVER BE SUBMERGED IN WATER.
WHEN NOT IN USE, THE BATTERY SHOULD BE STORED
IN A COOL AND DRY PLACE. IF THE BATTERY IS HEAVILY
SPRAYED WITH WATER OR ACCIDENTALLY SUBMERGED,
STOP USING THE BATTERY IMMEDIATELY.

OPERATION (cont.)
Overload protection
When the Surface Brush is overloaded, e.g by pressing too strongly, the
Surface Brush switches off automatically and must be switched on again by
squeezing the On/Off Trigger.
Brushing Artificial Turf
1. Place the Soft Nylon Brush evenly on the surface.
2. Set the working height to the one which is most comfortable for you (see
Adjusting the Working Height). The Splash Guard must just
clear the ground on both sides.
3. Push Direction Lever hard left. (standard direction of rotation).
4. Lift the equipment 1-2 centimetres and switch on the Surface Brush (see
Switching On and Off).
5. Set the desired speed (from slow to fast) (see Variable Speed Dial).
Wait until the full speed has been reached and then place the brush on
the articial turf. The Surface Brush will pull away from you.
6. To raise the bres upright, brush against the direction of the bres of the
articial turf once the desired speed has been reached. Do not exert any
pressure.
7. If required, draw the brush towards you and let it roll away without
pressure.
8. Repeat this movement until the desired result has been achieved.
WARNING!: THE BRUSH COVERS ON THE
SIDE MUST BE FITTED SECURELY BEFORE
USE.
WARNING! ENSURE THAT YOU HAVE FITTED
THE BRUSH WHICH IS INTENDED TO BE
USED FOR THE SURFACE YOU WANT TO CLEAN.
WARNING! THE SURFACE TO BE CLEANED
MUST BE FREE OF OBJECTS SUCH AS
STONES, TWIGS, ETC. THESE COULD BE FLUNG
UP BY THE ROTATING BRUSH OR SCRATCH THE
SURFACE.
• Inspect the brushes to check them for dirt before you start your cleaning
work and clean them if necessary.
• Carry out a test run on a small area which is not very visible to check that
brushing does not damage the surface.
• Only use by guiding it over the ground in a vertical position, it should not be
used in a horizontal position (e.g. walls) or overhead (e.g. ceiling). It must
not be used for unmade/unpaved surfaces (e.g. grass pavers).
WARNING! LIFT THE SURFACE BRUSH 1-2
CENTIMETRES OFF THE GROUND WHEN YOU
SWITCH IT ON, BUT ONLY UNTIL IT HAS REACHED
FULL SPEED. TAKE CARE WHEN DOING SO IN
ORDER TO PREVENT INJURIES.
Cleaning in General (Not artificial turf)
1. Hold the Surface Brush rmly with both hands, ensure the brush is evenly
on the surface.
2. Set the working height to the one which is most comfortable for you (see
Adjusting the Working Height). The Splash Guard must just clear
the ground on both sides.
3. Select the correct direction of rotation (see Direction Lever) for the
surface you want to clean (observe Cleaning Brushes section 2).
4. To achieve top cleaning results quickly, we recommend wet cleaning. Open
the water inlet.
5. Lift the equipment 1-2 centimetres and switch on the Surface Brush (see
Switching On and Off).
6. Set the desired speed (from slow to fast) (see Variable Speed Dial).
Wait until the full speed has been reached and then place the brush on the
surface to be cleaned.
7. Guide the brush slowly and in lines, similar to a broom, over the surface.
Only apply a small amount of pressure at rst and then increase it little by
little.
WARNING! ALWAYS WEAR ADEQUATE
PROTECTIVE CLOTHING WHEN OPERATING
THE SURFACE BRUSH TO AVOID INJURIES TO
FACE, EYES, HANDS, FEET AND HEARING.
5. USING THE SURFACE BRUSH

Wear eye & ear protection Wear Protective Gloves
Warning
Regulatory Compliance Mark
(RCM)
VVolts Hz
W
Hertz
~
n0
/min
Alternating Current Watts
No load speed
Revolutions or reciprocations
per minute
Read Instruction Manual
Caution: Hot equipment parts
Wear Protective Closed Footwear
CARING FOR THE ENVIRONMENT
Battery protection system
The tool is equipped with the battery protection system, which helps to ensure a long service
life.
The output power automatically cuts off during operation when the tool and/or battery are
placed under the following situations:
• When the tool is overloaded:
If this occurs, turn off and remove causes of overload, then turn on again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or immediately
after using the tool.
Power tools that are no longer usable should not be disposed of with household waste
but in an environmentally friendly way. Please recycle where facilities exist. Check
with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw materials. Reuse of recycled
material decreases pollution in the environment. Please recycle packaging where
facilities exist. Check with your local council authority for recycling advice.
Cleaning, maintenance and storing
Cleaning
• Keep all safety devices, air vents and the motor housing free of dirt and dust as far
as possible. Wipe the equipment with a clean cloth or blow it down with compressed
air at low pressure.
• We recommend cleaning the equipment immediately each time after use.
• Clean the equipment regularly with a damp cloth. Do not use cleaning agents or
solvents; these may be aggressive to the plastic parts in the equipment. Ensure that
no water can get into the interior of the equipment. The ingress of water into an
battery power tool increases the risk of an electric shock.
• Remove the safety guard and remove any deposits using a brush.
Maintenance
• There are no other parts inside the equipment which require maintenance
Storage
Store the equipment and its accessories in a dark and dry place at above freezing
temperature. The ideal storage temperature is between 5 and 30 °C. Store the electric
equipment in its original packaging.
Do not bend the rubber lips of the splash guard outwards. Store the equipment in such
a way that the rubber lips are not in contact with the oor/ground as far as possible.
Note: Ozito Industries will not be responsible for any damage or injuries caused
by the repair of the Surface Brush by an unauthorised person or by mishandling of
the blower vac. This tool is designed for DIY use - use in commercial or industrial
environments will void the warranty.
SPARE PARTS
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information,visit www.ozito.com.au or
contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
DESCRIPTION OF SYMBOLS
MAINTENANCE
WARNING!: ENSURE THE TOOL IS SWITCHED
OFF AND THE BATTERY DISCONNECTED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.

SURFACE BRUSH SAFETY WARNINGS
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of fire, electric shock, personal
injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
Before you connect the charger to the mains supply make sure that the data on the rating plate are identical to the mains data.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current
device reduces the risk of electric shock.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious
personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal
injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result in a hazardous situation.
5 Battery tool use and care
a. Recharge only with the charger specified by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re when used with another battery pack.
b. Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and re.
c. When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may cause burns or a
re.
d. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
e. Do not use a battery pack or tool that is damaged or modified. Damaged or modied
batteries may exhibit unpredictable behaviour resulting in re, explosion or risk of injury.
f. Do not expose a battery pack or tool to fire or excessive temperature. Exposure to re or
temperature above 130 °C may cause explosion.
g. Follow all charging instructions and do not charge the battery pack or tool outside
the temperature range specified in the instructions. Charging improperly or at temperatures
outside the specied range may damage the battery and increase the risk of re.
6 Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. Never service damaged battery packs. Service of battery packs should only be performed by the
manufacturer or authorized service provider.
WARNING! This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person responsible for their
safety.
1. Exercise extreme caution when using the product.
2. The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a case of misuse.
3. Use only the brush which is intended to be used for the surface you want to clean.
4. Use the surface brush only in daylight or good articial light.
5. Only use water without any additives whatsoever.
6. Use only the manufacturer’s recommended replacement parts and accessories.
7. Always remove the battery from the surface brush when leaving the surface brush unattended.
8. Always remove the battery from the surface brush before carrying out maintenance or cleaning work.
9. Never use damaged brushes
10. Surface brush should be stored in suitable racks, containers or boxes in such a manner that they are protected against
the effect of:
1) High humidity heat, water or other liquids which might cause damage to the brush;
2 Exposure to acids, or fumes from acids, which might induce deterioration;
3) Any temperature low enough to cause condensation on the brush when removed from storage to an area of higher
temperature;
4) Distortion of any of the brush components.
11. Never run or walk backwards when using the surface brush.
12. Keep proper footing and balance at all times. This enables better control of the surface brush in unexpected situations.
13. Use both handles at all times.

CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of with
household waste but in an environmentally friendly way. Please recycle
where facilities exist. Check with your local council authority for
recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your local
council authority for recycling advice.
DESCRIPTION OF SYMBOLS
Warning
Do not store or use battery in
temperatures exceeding 50°C
Volts Hertz
Alternating Current
Direct Current
Milliamperes
Watts
Amp Hour
Ah
W
HzV
ac/~
mA
Lithium Ion Battery
Do not put in the rubbish
Do not get battery wet
Recycle Battery
Do not incinerate
dc
Regulatory Compliance
Mark (RCM)
Do not store battery when the charge
is low; store between 40-60%.
40-60%
0%
4.0Ah BATTERY
INSTRUCTION MANUAL
PXBP-400
SPECIFICATIONS
Input: 18V
Battery Capacity: 4.0Ah Li-ion
Power Consumption: 72Wh
Weight: 0.65kg
2
1. Battery
2. Battery Release Button
3. Charge Indicator Button
ozito.com.au
31
Before using the charger or battery read all instructions and cautionary markings on the charger, battery pack and the
product using the battery pack. Do not lose these safety instructions.
Battery Warnings
1. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging
notes and procedures.
2. For optimum battery performance avoid low discharge cycles. Charge the battery pack frequently.
3. Use and store the battery pack in dry conditions with low humidity between 0-50°C, ideally at 15°C. Avoid exposing
battery pack and charger to direct sunlight.
4. Do not keep battery pack in places where temperatures are liable to reach over 50°C, such as in a car, metal shed or
similar that is in direct sunlight.
5. Do not ignite the battery pack or expose it to re. There is a risk of explosion!
6. Do not exhaustively discharge batteries. Exhaustive discharge will damage the battery cells. The most common
cause of exhaustive discharge is long-term storage and continued use of low-charge batteries. Always store the
battery with some charge. Charge the batteries every 2-3 months to restore charge. Stop working as soon as the
performance of the battery falls noticeably or the electronic protection system triggers.
7. Protect batteries and the tool from overloads. Overloads will quickly result in overheating and cell damage inside
the battery housing without this overheating being apparent externally.
8. Avoid damage and shocks. Do not use batteries which have been dropped from a height of more than one meter or
strong external impact, even if the housing of the battery pack appears to be undamaged. The battery cells inside
the battery may have suffered serious damage. 
9. If the battery pack suffers overloading and overheating, the integrated protective cut-off will switch off the equip-
ment. Do not press the ON/OFF switch on the tool if the protective cut-off has actuated. This may damage the
battery pack. Allow the battery to cool to room temperature before use.
10. Use only original battery packs. The use of other batteries may result in injuries, explosion and a re risk.
11. Protect your rechargeable battery against moisture, rain and high humidity. Moisture, rain and high humidity can
cause dangerous cell damage. Never charge or use batteries which have been exposed to moisture, rain or high
humidity.
12. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack is damaged, do not
use the battery.
13. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or
other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
14. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If accidental contact occurs, ush
with water and seek medical help immediately. Liquid ejected from the battery may cause irritation or burns.
15. Do not use a battery pack or tool that is damaged or modied. Damaged or modied batteries may exhibit unpredict-
able behaviour resulting in re, explosion or risk of injury.
16. Do not expose a battery pack or tool to re or excessive temperature. Exposure to re or temperature above 130°C
may cause explosion.
17. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer.
18. 18. Do not disassemble Battery. This may result in a risk of electric shock, electrocution or re.
Charger Warnings
19. Please check the data marked on the rating plate of the battery charger. Ensure to only connect the battery charger
to a power supply with the voltage marked on the rating plate.
20. Protect the battery charger and its cable from damage and sharp edges. Have damaged cables repaired by an
authorised service agent before use.
21. Keep the battery charger, batteries and the cordless tool out of children’s reach.
22. Do not use damaged battery chargers.
23. Do not use the supplied battery charger to charge other cordless tools. Only charge Ozito Power X Change
rechargeable batteries with an Ozito Power X Change Charger.
24. The battery pack may become warm during use. Allow the battery pack to cool to room temperature before
commencing with the charging.
25. Do not over-charge batteries. Do not exceed the maximum charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or partly charged battery pack will result in over-charging and
cell damage. Do not leave fully charged batteries in the charger.
26. Charge the battery pack in dry conditions with low humidity between 10-40°C. Avoid exposing battery pack and
charger to direct sunlight.
27. Do not use batteries which have suffered deformation during the charging process or shows any other signs of
abnormalities including, excessive curvature of the housing, gassing, hissing or cracking.
28. Never fully discharge the battery pack. A complete discharge of the battery pack will lead to premature ageing of
the battery cells.
29. Never charge the batteries unsupervised.
30. Do not cover or place any object on top of the charger, place the charger away from heat sources.
31. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the
charger.
32. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or
stress.
33. An extension cord should not be used unless necessary. Use of an improper extension cord could result in the risk of
re, electric shock or electrocution.
34. Do not disassemble charger. This may result in a risk of electric shock, electrocution or re.
35. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
36. Do not use the cordless tool or the battery charger near vapours and inammable liquids.
BATTERY & CHARGER SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the following, should
always be followed to reduce risk of re, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool. Save these instructions and other documents supplied with this tool for future reference.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in
order to avoid hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation
system is for added protection against injury resulting from a possible electrical insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for
signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the
power input of the tool or which is damaged or defective may result in a risk of re and electric shock.
To reduce the risk of electric shock, we recommend the use of a residual current device (rated 30mA or less).
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

BATTERY CHARGE INDICATOR
The purchased battery is equipped with a
battery charge indicator to show the state of
the battery charge.
Press the charge indicator button and look to
see which LED lights.
Battery requires immediate charging
Low state of charge, requires charging soon.
Mid state of charge
Full state of charge.
Note: The battery needs to be removed from the tool to check the state of charge.
BATTERY PROTECTION SYSTEM
The tool is equipped with a battery protection system, which helps to ensure longevity
of the battery.
The output power automatically cuts off during operation when the tool and/or battery
are placed under the following situations:
• When the tool is overloaded:
If this occurs, release the trigger switch and remove causes of overload, then pull
the switch trigger again to restart.
• When the remaining battery capacity becomes low:
Recharge the battery pack.
Note: The battery protection system does not in any way damage the tool.
Note: The indicated capacity may be lower than the actual level during use or
immediately after using the tool.
WARRANTY
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are
entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under
this warranty, however, where you have suffered any additional direct loss as
a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
36 MONTH REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the original date
of purchase and is intended for DIY (Do It Yourself) use only. If a product is
defective it will be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
OZITO Australia/New Zealand (Head Ofce)
25 Fox Drive, Dandenong South, Victoria, Australia 3175.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
PXBP-400
1. OPERATION
CHARGING YOUR LITHIUM ION BATTERY
This battery has been shipped in a low charge condition, and requires charging prior to
use. Allow several cycles of charging and discharging (through use with a compatible
tool) for the battery to reach its optimum performance / runtime.
This battery is compatible with chargers from the 18V Ozito Power X Change range
available through your local Bunnings Warehouse. Product availability may differ.
Only use the battery pack with Ozito Power X Change 18V cordless products.
1. Insert the power plug of the charger into the mains socket outlet. The green LED
will begin to ash when properly connected to power supply.
2. Insert the battery pack into the battery charger .
3. Remove battery from the charger once fully charged. Disconnect the charger from
the power supply.
Note: The battery pack can become a little warm during the charging. This is normal.
If the battery pack fails to charge, check:
if there is voltage at the socket outlet
that the battery and charger are properly connected.
If the battery pack still fails to charge, please contact our customer service center.
0121

CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of with household
waste but in an environmentally friendly way. Please recycle where facilities exist.
Check with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw materials. Reuse of
recycled material decreases pollution in the environment. Please recycle packaging
where facilities exist. Check with your local council authority for recycling advice.
DESCRIPTION OF SYMBOLS
2
1. Charging Unit
2. Charging Unit LED
ozito.com.au
1
COMPACT
FAST CHARGER
INSTRUCTION MANUAL
PXCG-030C
SPECIFICATIONS
Input: 200-250V ~AC 50-60Hz, 72W
Output: 20V DC, 3A
Battery Charge Time: 30Min - PXBP-150 (18V 1.5Ah)
40Min - PXBP-200 (18V 2.0Ah)
50Min - PXBP-250 (18V 2.5Ah)
60Min - PXBP-300 (18V 3.0Ah)
75Min - PXBP-400 (18V 4.0Ah)
120Min - PXBP-520 (18V 5.2Ah)
100Min - PXUBP-520 (18V 5.2Ah Ultra)
Double Insulated
Volts Hertz
Amperes Amp Hour
Read Instruction Manual
Indoor Use Only Do not dispose of in rubbish
Regulatory Compliance
Mark (RCM)
Do not charge battery in
temperatures exceeding 40°C
3.15A Slow Blow Fuse Warning
>40°C
V Hz
A Ah
T3.15A
Before using the charger or battery read all instructions and cautionary markings on the charger, battery pack and the
product using the battery pack. Do not lose these safety instructions.
Battery Warnings
1. The battery pack is not fully charged out of the carton. First read the safety instructions and then follow the charging
notes and procedures.
2. For optimum battery performance avoid low discharge cycles. Charge the battery pack frequently.
3. Use and store the battery pack in dry conditions with low humidity between 0-50°C, ideally at 15°C. Avoid exposing
battery pack and charger to direct sunlight.
4. Do not keep battery pack in places where temperatures are liable to reach over 50°C, such as in a car, metal shed or
similar that is in direct sunlight.
5. Do not ignite the battery pack or expose it to re. There is a risk of explosion!
6. Do not exhaustively discharge batteries. Exhaustive discharge will damage the battery cells. The most common cause
of exhaustive discharge is long-term storage and continued use of low-charge batteries. Always store the battery with
some charge. Charge the batteries every 2-3 months to restore charge. Stop working as soon as the performance of the
battery falls noticeably or the electronic protection system triggers.
7. Protect batteries and the tool from overloads. Overloads will quickly result in overheating and cell damage inside the
battery housing without this overheating being apparent externally.
8. Avoid damage and shocks. Do not use batteries which have been dropped from a height of more than one meter or
strong external impact, even if the housing of the battery pack appears to be undamaged. The battery cells inside the
battery may have suffered serious damage. 
9. If the battery pack suffers overloading and overheating, the integrated protective cut-off will switch off the equipment.
Do not press the ON/OFF switch on the tool if the protective cut-off has actuated. This may damage the battery pack.
Allow the battery to cool to room temperature before use.
10. Use only original battery packs. The use of other batteries may result in injuries, explosion and a re risk.
11. Protect your rechargeable battery against moisture, rain and high humidity. Moisture, rain and high humidity can cause
dangerous cell damage. Never charge or use batteries which have been exposed to moisture, rain or high humidity.
12. Never attempt to open the battery pack for any reason. If the plastic housing of the battery pack is damaged, do not
use the battery.
13. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or
other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
14. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If accidental contact occurs, ush with
water and seek medical help immediately. Liquid ejected from the battery may cause irritation or burns.
15. Do not use a battery pack or tool that is damaged or modied. Damaged or modied batteries may exhibit unpredictable
behaviour resulting in re, explosion or risk of injury.
16. Do not expose a battery pack or tool to re or excessive temperature. Exposure to re or temperature above 130°C may
cause explosion.
17. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer.
18. 18. Do not disassemble Battery. This may result in a risk of electric shock, electrocution or re.
Charger Warnings
19. Please check the data marked on the rating plate of the battery charger. Ensure to only connect the battery charger to a
power supply with the voltage marked on the rating plate.
20. Protect the battery charger and its cable from damage and sharp edges. Have damaged cables repaired by an
authorised service agent before use.
21. Keep the battery charger, batteries and the cordless tool out of children’s reach.
22. Do not use damaged battery chargers.
23. Do not use the supplied battery charger to charge other cordless tools. Only charge Ozito Power X Change rechargeable
batteries with an Ozito Power X Change Charger.
24. The battery pack may become warm during use. Allow the battery pack to cool to room temperature before commencing
with the charging.
25. Do not over-charge batteries. Do not exceed the maximum charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or partly charged battery pack will result in over-charging and cell
damage. Do not leave fully charged batteries in the charger.
26. Charge the battery pack in dry conditions with low humidity between 10-40°C. Avoid exposing battery pack and charger
to direct sunlight.
27. Do not use batteries which have suffered deformation during the charging process or shows any other signs of
abnormalities including, excessive curvature of the housing, gassing, hissing or cracking.
28. Never fully discharge the battery pack. A complete discharge of the battery pack will lead to premature ageing of the
battery cells.
29. Never charge the batteries unsupervised.
30. Do not cover or place any object on top of the charger, place the charger away from heat sources.
31. To reduce risk of damage to the electric plug and cord, pull by the plug rather than the cord when disconnecting the
charger.
32. Make sure the cord is located so that it will not be stepped on, tripped over, or otherwise subjected to damage or
stress.
33. An extension cord should not be used unless necessary. Use of an improper extension cord could result in the risk of
re, electric shock or electrocution.
34. Do not disassemble charger. This may result in a risk of electric shock, electrocution or re.
35. To reduce risk of electric shock, unplug the charger from the outlet before attempting any cleaning. Removing the
battery pack will not reduce this risk.
36. Do not use the cordless tool or the battery charger near vapours and inammable liquids.
BATTERY & CHARGER SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! When using mains-powered tools, basic safety precautions, including the following, should
always be followed to reduce risk of re, electric shock, personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before
operating the tool. Save these instructions and other documents supplied with this tool for future reference.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
This tools charger is double insulated therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in
order to avoid hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation
system is for added protection against injury resulting from a possible electrical insulation failure within the tool.
Using an extension lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the extension lead for
signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the
power input of the tool or which is damaged or defective may result in a risk of re and electric shock.
To reduce the risk of electric shock, we recommend the use of a residual current device (rated 30mA or less).
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

1. CHARGING A BATTERY 2. MAINTENANCE
• Disconnect the charger from power source before cleaning.
• Keep the charger in a dry place out of reach of children.
• If the enclosure of the charger requires cleaning, do not use solvents. Use a dry, soft
cloth only to wipe down the surface. Never let any liquid get inside the charger; never
immerse any part of the charger.
• There are no other parts inside the charger which require maintenance. Do not
take the charger apart. If the charger is damaged, contact your supplier or the
manufacturer.
Mounting The Charging Unit On A Wall
The charging unit can be mounted to a wall or workbench.
The correct dimensions for drill holes can be found on the back of the charging unit; a
template for the mounting hole locations can also be found on the Ozito website.
Note: When mounting on a wall you must use suitable screws, e.g.M3 pan-head
screws, in order to prevent damage to the housing and risk of falling.
OZITO Australia/New Zealand (Head Ofce)
25 Fox Drive, Dandenong South, Victoria, Australia 3175.
WARRANTY
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are
entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under
this warranty, however, where you have suffered any additional direct loss as
a result of a defective product you may be able to claim such expenses by
contacting our customer service helpline above.
36 MONTH REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from the original date
of purchase and is intended for DIY (Do It Yourself) use only. If a product is
defective it will be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
PXCG-030C
Charger LED Indicator Lights
LED Indicator Situation
GREEN (Flashing) Stand By (no battery pack is inserted)
RED (Flashing) Battery is charging (low charge)
RED (Illuminated) Battery is fast charging (mid charge)
GREEN (Illuminated) Battery is 85% - 100% charged and is ready for use.
BOTH(Illuminated) Battery pack is too hot or too cold (charging will begin
automatically when battery reaches correct charging
temperature).
BOTH (Flashing) The battery is deffective, charging is no longer
possible. Do not charge. Contact Ozito Customer
Service.
2. Align and then slide the ribs on
the battery into the recess in the
charger.
1. Connect the charger to the power
supply and the LED will ash
green showing power is being
supplied to the charger.
3. The red LED will illuminate while
the battery charges.
4. The green LED will illuminate
once the battery is charged.
1220
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
WARNING! DO NOT COVER OR PLACE ANY OBJECT ON
TOP OF THE CHARGER; PLACE THE CHARGER AWAY
FROM HEAT SOURCES.
WARNING! THE CHARGER SHOULD BE PROTECTED BY
A RESIDUAL CURRENT DEVICE (RATED AT 30MA OR
LESS).
