Ozito MFQ-3100 User manual

WHAT’S IN THE BOX
QUICK CHANGE
MULTI FUNCTION TOOL
300W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor: 300W
Input: 230-240V ~ 50Hz
No Load Speed: 15,000-22,000/min
Orbit Angle: 2.8°
Sanding Pad Size: 90x90x90mm
Weight: 1.4kg
MFQ-3100
ozito.com.au
Multi Function Tool
Sanding Pad & Paper
Scraper x 2
Triangular Rasp
Straight Blade x 6
Semi Circualr Blade x 2
Grout Removing Disc

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. Accessory Drive Spindle
2. Accessory Locking Lever
3. On/off Switch
4. Rear Handle
5. Variable Speed Dial
MULTI FUNCTION TOOL
6. Semi Circular Blade x 2
7. Straight Blade x 6
8. Scraper x 2
9. Triangular Rasp
10.Grout Removal Disc
11.Sanding Pad
12.Sanding Paper x 35
13 Vac Adaptor
14 Dust Extraction Fixing Screw
15 Dust Extraction Base
ACCESSORIES
1. ASSEMBLY
Accessory Fitment
2. Place accessory
over the drive
spindle and
position to suit
angle needed
for application.
Note: Ensure the accessory is sitting at on spindle and locking pins.
3. Lock the accessory
locking lever to secure
the accessory.
1. Raise the
accessory locking
lever until the ange
lowers.
Dust Extraction Adaptor
1. Connect the dust extrac-
tion adaptor pipe to base.
2. Fit the dust extraction
adaptor over the accessory
drive spindle.
Note: Follow procedure in reverse to remove accessories.
3. Align the adaptor xing
screw with the mounting
hole located underneath
the tool. Tighten to secure.

OPERATION
2. CONTROLS 3. SANDING
2. To turn off, slide the
switch backwards.
The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
1. To turn on, slide the
on/ off switch forward.
On / Off Switch
Variable Speed
For various applications, you will need to select the appropriate
speed for the task.
1. Turn multi function tool on.
2. Scroll through variable
speed dial to desired speed
setting.
Note: The higher the number on the variable speed dial the
faster the oscillation frequency of the multi function tool.
1. Turn multi function tool
on and select appropriate
speed.
2. Place the multi function tool
at on the workpiece.
Note: Do not apply heavy pressure to the tool or tilt the sanding
base as this will wear out the sanding paper and may damage the
sanding pad.
Changing Sanding Paper
2. Peel paper off pad from one
of the corners.
1. Align paper to pad and
press rmly to attach.
Triangular Rasp
1. Turn multi function tool
on and select appropriate
speed.
2. Place the multi function tool
at on the workpiece.
This accessory is suitable when sanding materials which require
a large amount of material removal, for example: rough wood,
shaping timber, aking paint and rust removal.
Note: Periodicaly turn the unit off and remove any built-up
dust and debris.

MFQ-3100
4. SAWING 5. SCRAPING
Semi Circular & Straight Blade
2. Turn multi function tool on
and select speed.
1. Ensure the workpiece
is securely held down.
3. Use slight pendulum
motion when plunge
cutting.
Note: Ensure blades are not blunt or damaged in any way
before commencing application.
1. Turn multi function
tool on and select
appropriate speed.
2. Place multi function tool on the workpiece at an angle of
approx 10-15°.
3. Allow the scraper to do the work; do not apply heavy pressure
to the multi function tool. This may cause the multi function
tool to overload or cut into the surface of the workpiece.
10-15°
Grout Removal Disc
1. Turn the multi function tool
on and select speed.
2. Use slight pendulum
motion when cutting.
Note: Periodicaly turn the
unit off and remove any
built-up dust and debris.

MAINTENANCE TROUBLESHOOTING
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
Power tools that are no longer usable should not be disposed of
with household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council authority
for recycling advice.
Recycling packaging reduces the need for landll and raw materials.
Reuse of recycled material decreases pollution in the environment.
Please recycle packaging where facilities exist. Check with your
local council authority for recycling advice.
• Keep the ventilation vents of the multi function tool clean at all times, if
possible, prevent foreign matter from entering the vents.
• After each use, blow air through the multi function tool housing to ensure it is
free from all dust particles which may build up. Build up of dust particles may
cause the tool to overheat and fail.
• If the enclosure of the multi function tool requires cleaning, do not use
solvents but a moist soft cloth only. Never let any liquid get inside the multi
function tool; never immerse any part of the multi function tool into a liquid.
Carbon Brushes
When the carbon brushes wear out, the multi function tool will spark and/
or stop. Discontinue use as soon as this happens. They should be replaced
prior to recommencing use of the multi function tool.
Carbon brushes are a wearing component of the
tool and therefore are not covered under warranty.
Continuing to use the multi function tool when carbon
brushes need to be replaced may cause permanent
damage. Carbon brushes will wear out after many
uses but when the carbon brushes need to be
replaced, take the multi function tool to an electrician
or a power tool repairer for a quick and low cost replacement. Always replace
both carbon brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries
caused by the repair of the multi function tool by an unauthorised person or by
mishandling of the multi function tool.
Sparking visible through the housing air vents
A small amount of sparking may be visible through the housing vents.
This is normal and does not indicate a problem.
Excessive sparking visible through the housing air vents
and/or the multi function tool failing to operate
May indicate the carbon brushes have worn out and need to be
replaced. Carbon brushes should only be replaced by a qualied
electrician or power tool repairer.
Flange SPMFQ3100-01
On/Off Trigger SPMFQ3100-20
Accessory Lever Pin SPMFQ3100-22
Carbon brushes (pair) SPMFQ3100-40
Sanding Pad SPMFQ3100-508
Dust Extraction Assembly SPMFQ3100-510
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
VVolts Hz Hertz
~Alternating current WWatts
/min Revolutions or
reciprocation per minute
Double insulated Regulator compliance mark
no No load speed
Warning Read instruction manual

SPARE PARTS Tool: Quick Change Multi Function Tool
Model No. MFQ-3100
Item
No. Description Part No.
How To Order
01
19-23
40
44
49
508
510
Flange
Locking Lever Assembly
Carbon Brush (pair)
On/off Trigger Switch
Variable Speed Switch
Velcro Sanding Pad
Dust Extraction Assembly
SPMFQ3100-01
SPMFQ3100-20
SPMFQ3100-40
SPMFQ3100-44
SPMFQ3100-49
SPMFQ3100-508
SPMFQ3100-510
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any
further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
The following is a list of spare parts carried by Ozito.
Please contact Customer Service for any parts not
listed.
46
55
56
57
58
59
10
22
11
14
23
9
1
4
7
8
8
12
24
25
26
27
28
30 31
32
33
34
35
36
37
39
40
41
44
47
48
29
49
50
42
43 45
51
54
52
53
38
5
6
16
19
18
17
15
2
20
21
3
1
13
509
508
507
506
505
504
503
502
501
510
Item
No. Description Part No.

ELECTRICAL SAFETY
MULTI FUNCTION TOOL SAFETY INSTRUCTIONS
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New
Zealand.
This tool is double insulated in accordance with AS/NZS 60745-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician
or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The
insulation system is for added protection against injury resulting from a possible electrical insulation failure
within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not
suitable for the power input of the tool or which is damaged or defective may result in a risk of re and electric
shock.
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Donotoperatepowertoolsinexplosiveatmospheres,suchasinthepresenceofammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
notuseapowertoolwhileyouaretiredorundertheinuenceofdrugs,alcoholormedication. A
moment of inattention while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
any other condition that may affect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5. Service
a. Haveyourpowertoolservicedbyaqualiedrepairpersonusingonlyidenticalreplacement
parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Readallsafetywarnings,instructions,illustrationsandspecications
provided with this power tool. Failure to follow all instructions listed below may result in electric
shock,reand/orseriousinjury.
Hold power tool by insulated gripping surfaces only, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a “live”
wire may make exposed metal parts of the power tool “live” and shock the operator.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
The tool is recommended for use with a residual current device with a rated residual current of
30mA or less.

IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
0913
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will be replaced in
accordance with the terms of this warranty. Warranty excludes
consumable parts, for example: blades, sanding paper, etc.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
