Pacific energy Trenton User manual

INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Trenton
MODEL: TRENTON
SERIES: A
FREESTANDING GAS STOVE
INSTALLATION AND
OPERATING INSTRUCTIONS
180118-40 100000457
TRNT.BODYA
Visit www.pacificenergy.net for the most recent version of this manual
SERIAL#
WARNING : If the informa tion in the se instruc tio ns is
not followed exactly, a fi re or explosion may result
causing property damage, personal injury or death.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certifi ed kit is used.
This appliance is suitable for installation in a bedroom
or bed sitting room.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a
neighbour’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier call the fi re
department.
- Installation and service must be performed by a
qualifi ed installer, service agency or the gas supplier.
WARNING:
FIRE OR EXPLOSION HAZARD
Fa ilure to fo llo w sa fe ty wa rning s e xa c tly c o uld re sult
in serious injury, death, or property damage.

2100000457 180118-40
TRNT.BODYA
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
DANGER
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with the appliance and
shall be installed for the protection of children and
other at-risk individuals.
We re c o mme nd tha t o ur g a s he a rth
p ro d uc ts b e insta lle d a nd se rvic e d b y
professionals who are certied in the
Unite d Sta te s b y the Na tio na lFire p la c e
Institute ®(NFI) a s NFI G a s Sp e c ia lists
Table of Contents
Important Note for the Commonwealth of Massachusetts ....... 3
Caution ....................................................................................... 4
Safety ........................................................................................ 5
First Fire ..................................................................................... 5
Manufactured (Mobile) Homes .................................................. 6
Installation Requirements .......................................................... 6
Special Operator Note ............................................................... 6
Remote Control System ............................................................ 7
System Description ............................................................ 7
Transmitter (Remote Control with LCD Display)................. 7
Temperature indication Display.......................................... 8
Turn on the Gas Stove........................................................ 8
Turn off the Gas Stove ....................................................... 8
Manual Bypass of the Remote System.............................. 8
Key Lock ............................................................................ 8
Remote Flame Control ....................................................... 9
ROOM THERMOSTAT (Remote Transmitter Operation)..... 9
Smart Thermostat (Remote Transmitter Operation) ........... 9
Comfort Fan Speed Control............................................. 10
Continuous Pilot/Intermittent Pilot (CPI/IPI) selection...... 10
Remote dimmer control (Light) ........................................ 10
Low Battery Power Detection .......................................... 11
Remote Transmitter.......................................................... 11
IFC Module (Receiver)...................................................... 11
Warnings and Cautions ........................................................... 11
Maintenance ............................................................................ 12
Glass Door ....................................................................... 12
Annual Inspection............................................................. 12
Periodically....................................................................... 12
Lighting Instructions ................................................................ 13
Trenton Gas Stove Dimensions ............................................... 14
Clearances to combustibles .................................................... 15
Minimum Clearance to Combustible Materials................ 15
Locating the Gas stove ........................................................... 15
Vent Terminal Clearances ........................................................ 16
Vent Terminal Minimum Clearances ........................................ 16
Trenton Co-Axial Venting Chart ............................................... 17
Co-Linear Venting .................................................................... 18
Optional Direct Vent Termination “Snorkel” ............................. 19
Installation ............................................................................... 20
Venting Components ............................................................... 21
Trenton Gas Stove Rear Component ...................................... 22
Gas and Electrical Connections .............................................. 23
Gas connection ................................................................ 23
Electrical connection........................................................ 23
Packaging ........................................................................ 24
Safety screen removal.............................................................. 24
Glass door removal ................................................................. 24
Log set pieces ................................................................ 25
Log Set Installation .................................................................. 26
Installation of log set ........................................................ 26
Glass Door Installation ............................................................ 28
Safety Screen Installation ........................................................ 29
Accent Lighting Glass Plates .................................................. 31
Changing the glass plate.................................................. 31
IFC Module .............................................................................. 32
Operating Procedure ............................................................... 32
Initializing the System for the first time ............................ 32
Damper Adjustment ................................................................ 33
Venturi Adjustment .................................................................. 33
Gas Supply .............................................................................. 34
Gas Pressure Check ................................................................ 34
Gas Pressure Testing Procedure ............................................. 35
Pilot Flame Adjustment ........................................................... 35
Propane Conversion ................................................................ 36
Replacement Parts .................................................................. 37
Wiring Diagram ........................................................................ 38
Rating Label ............................................................................ 39

3TRNT.BODYA
100000457 180118-40
From Massachusetts Rules and Regulations 248 CMR 5.08:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part
for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent
termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and
porches, the following requirements shall be satisfied.
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gas fitter shall observe that a hard wired carbon monoxide detector with an alarm and battery
back-up is installed on the floor level where the gas equipment is to be installed, in addition, the installing plumber or gas fitter
shall observe that a battery operated or hard-wired carbon monoxide detector with an alarm is installed on each additional level
of the dwelling, building or structure served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility
of the property owner to secure the services of qualified licensed professionals for the installation of hard-wired carbon monoxide
detectors.
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard-wired
carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision cannot be met at the time of completion of installation, the owner shall have
a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a
battery operated carbon monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above
provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed as IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height
of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance
or equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP
CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the
installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with
the provisions of 248 CMR 5.089(2)(a) 1 through 4.
(b) EXEMPTIONS. The following equipment is exempt from 248 CMR 5.089(2)(a) 1 through 4.
1. The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54 as
adopted by the Board; and:
2. Product Approved side wall horizontal vented gas fueled equipment installed in a room or structure separate from the dwelling,
building or structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS – GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the
equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS – GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the fuel gases, but
identifies “special venting systems”, the following requirements shall be satisfied by the manufacturer.
1. The referenced “special venting system” instructions shall be included with the appliance or equipment installation instructions;
and
2. The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a parts
list and detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting
instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
Important Note for the Commonwealth of Massachusetts

4100000457 180118-40
TRNT.BODYA
Owner information
Your Trenton direct vent, Free-standing gas stove has been professionally installed by:
Dealer name: ___________________________________
Phone Number: _________________________________
If you discover any problems with your gas stove contact your dealer immediately to have the unit repaired.
Caution: Do not attempt to repair the gas stove because you may cause injury to yourself or others, and risk
causing damage to the unit.
Before operating your gas stove carefully read this manual and pay close attention to all Safety Warnings. The
manual contains important information on the unit’s safe operation and maintenance.
FOR YOUR SAFETY - Do not install or operate your Trenton gas stove without first reading and
understanding this manual. Any installation or operational deviation from the following instructions voids the
Pacific Energy Fireplaces Warranty and may prove hazardous.
This gas stove and its individual shut off valve must be disconnected from gas supply piping system during
any pressure testing of that system at test pressures in excess of ½ psig (3.5 kPa).
This gas stove must be isolated from the gas supply piping system by closing its individual manual shut off
valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½
psig (3.5 kPa).
Do not use the gas stove if any part has been under water. Immediately call a qualified service technician to
inspect the gas stove and to replace any part of the control system and any gas control which has been under
water.
Caution
Congratulations on your purchase of a
Pacific Energy Gas Stove.

5TRNT.BODYA
100000457 180118-40
Owner information
When lit for the first time, the gas stove will emit a slight odor for a couple of hours. This is due to the curing
of paints, sealants, gaskets, and lubricants used in the manufacturing process. This condition is temporary.
Open doors and windows to ventilate the area. Odor caused by the curing process may cause discomfort to
some individuals.
It is normal for gas stoves fabricated from steel to give off some expansion and/or contraction noises during
the start up or cool down cycle. Similar noises are found with your furnace heat exchanger or cook stove
oven.
First Fire
Due to high temperatures, this gas stove should be located out of traffic and away from furniture and
draperies.
Children and adults should be alerted to the hazards of high surface temperatures and should stay away to
avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the same room as the gas stove.
Toddlers, young children, and others may be susceptible to accidental contact burns. A physical barrier
is recommended if there are at-risk individuals in the house. To restrict access to the gas stove, install an
adjustable safety gate to keep toddlers, young children, and other at-risk individuals out of the room and
away from hot surfaces.
Clothing or other flammable material should not be placed on or near the gas stove.
Any grill, panel or door removed for servicing the unit must be replaced prior to operating. Failure to do so
may create a hazardous condition.
Installation and repair should be done by a qualified service person. The gas stove should be inspected
before use and at least annually by a professional service person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding material, etc. It is imperative that control compartments,
burners and circulating air passageways of the gas stove be kept clean.
It is our policy that no responsibility is assumed by the Company or by any of its employees or
representatives for any damages caused by an inoperable, inadequate, or unsafe condition which is the
result, either directly or indirectly, of any improper operation or installation procedures.
This gas stove must not be connected to a chimney flue serving a separate solid fuel burning gas stove.
Safety

6100000457 180118-40
TRNT.BODYA
Owner information
Manufactured (Mobile) Homes
In some jurisdictions, the Trenton gas stove may be installed in Manufactured Homes after the “first sale”.
Consult local codes for approval. The gas stove must be fastened in place.
Install in accordance with the current standard Mobile Homes, CAN/CSA Z240 MH (in CANADA), and the
Manufacturer’s Home Construction and Safety Standard, Title 24 CFR, Part 3280 or the current Standard
for Fire Safety Criteria for Manufactured Home Installations, Sites and Communities ANSI/NFPA 501A (in the
USA).
Installation Requirements
The Trenton gas stove installation and venting must conform to the current CAN/CGA-B149 installation code
(in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes.
Only qualified (licensed or trained) personnel should install this product.
In the state of Massachusetts, only a licensed Plumber and Gas Fitter may install this product.
NOTE: pilot may take up
to 30 seconds to ignite
each time the “ON” button
has been selected
Special Operator Note

7TRNT.BODYA
100000457 180118-40
Owner information
The Proflame Remote Control System consists of three elements:
1. Proflame Remote Transmitter.
2. Proflame Integrated Fireplace Control (IFC) module.
3. A wiring harness to connect the IFC to the gas valve and stepper motor.
Remote Control System
Transmitter (Remote Control with LCD Display)
System Description
The Proflame Remote Transmitter uses a streamline design with a simple button layout and informative LCD
display (Figure 1). The remote transmitter is powered by 3 AAA type batteries. A mode key is provided to
index between the features and a thermostat key is used to turn on/off or index through thermostat functions
(Figure 1 and Figure 2).
Blue back lit LCD display
ON/OFF Key
THERMOSTAT Key
UP/DOWN Arrow Key
MODE Key
Figure 1: Proflame 2 handset.
OFF
ON
SMART
MAX
KEY LOCK
LOW BATTERY ALARM
ROOM
TEMPERATURE
CPI MODE
ACCENT LIGHTING
OFF/ON
FLAME OFF/ON
SET POINT:
TEMPERATURE/LEVEL/STATE
THERMOSTAT OFF/
ON/SMART
TRANSMISSION
COMFORT FAN
Figure 2: Proflame 2 LCD screen details.

8100000457 180118-40
TRNT.BODYA
Owner information
Temperature indication Display
With the remote transmitter in the “OFF” position, press the thermostat
key and the mode key at the same time. Look at the LCD screen on the
remote transmitter to verify that a C or F is visible to the right of the room
temperature display (Figure 3 and Figure 4).
Turn on the Gas Stove
With the system OFF, press the ON/OFF Key on the remote transmitter. The
remote transmitter display will show some other active Icons on the screen.
At the same time the Receiver will activate the gas stove. A single “beep”
from the Receiver (module) will confirm reception of the command.
Turn off the Gas Stove
With the system ON, press the ON/OFF Key on the Remote transmitter.
The Remote transmitter LCD display will only show the room temperature
(Figure 3 and Figure 4). At the same time the Receiver (module) will turn off
the gas stove. A single “beep” from the Receiver confirms reception of the
command.
Manual Bypass of the Remote System
If the batteries of the receiver or remote transmitter are low or depleted,
the gas stove can be turned off manually using ON/OFF switch located on
battery holder at the rear of the Trenton (Figure 66 on page 32). This will
bypass the remote transmitter.
Key Lock
This function will lock the keys to avoid unsupervised operation.
To activate this function, press the MODE and UP keys at the same time.
The lock icon will appear (Figure 5). To de-activate this function, press the
MODE and UP keys at the same time.
Figure 3: Display in Fahrenheit.
Figure 4: Display in Celcius.
Figure 5: Key lock.

9TRNT.BODYA
100000457 180118-40
Owner information
Remote Flame Control
The Proflame has six (6) flame levels. With the system turned on, and the flame level at maximum in the gas
stove, press the down arrow key once to reduce the flame height by one step until the flame is turned off.
The up arrow key will increase the flame height each time it is pressed. If the up arrow key is pressed while
the system is on but the flame is off, the flame will come on in the high position (Figure 9).
A single “beep” will confirm reception of the command.
ROOM THERMOSTAT (Remote Transmitter Operation)
The remote transmitter can operate as a room thermostat. The thermostat can
be set to a desired temperature to control the comfort level in a room.
To activate this function, press the thermostat key (Figure 1). The LCD display on
the remote transmitter will change to show that the room thermostat is “ON” and
the set temperature is now displayed (Figure 10). To adjust the set point, press
the up or down arrow keys until the desired set point temperature is displayed on
the LCD screen of the remote transmitter.
The Smart Thermostat function adjusts the flame
height in accordance to the difference between the
set point and the room temperatures. As the room
temperature gets closer to the set point, the Smart
Function will modulate the flame down. If the room
temperature is cool, the Smart Function will modulate
the flame up. To activate this function, press the
THERMOSTAT key (Figure 1) until the word “SMART”
appears to the right of the temperature icon (Figure
11). To adjust the set point, press the up or down
arrow keys until the desired set point temperature
is displayed on the LCD screen of the remote
transmitter (Figure 11).
Smart Thermostat (Remote Transmitter Operation)
Figure 6: Flame off. Figure 7: Flame level 1. Figure 8: Flame level 5. Figure 9: Flame level
maximum.
SET TEMPERATURE
ROOM TEMPERATURE
Figure 10: Room temperature.
Figure 11: Smart flame
function. Figure 12: Smart flame adjusting
temperature.

10 100000457 180118-40
TRNT.BODYA
Owner information
Comfort Fan Speed Control
If the gas stove is equipped with a hot air circulating fan, the speed of the fan can be controlled by the
Proflame System. The fan speed can be adjusted through six (6) speeds. To activate this function use the
Mode Key (Figure 1) to index to the fan control icon (Figure 13). Use the Up/Down Arrow Keys (Figure 1) to
turn on, off or adjust the fan speed (Figure 13 and Figure 14). A single “beep” will confirm reception of the
command.
Continuous Pilot/Intermittent Pilot (CPI/IPI) selection
With the system in the “OFF” position, press the Mode Key (Figure 1) to index to the CPI mode icon
(Figure 15). Pressing the Up Arrow Key will activate the Continuous Pilot Ignition mode (CPI). Pressing the
Down Arrow Key will return to IPI (Figure 16). A single “beep” will confirm the reception of the command.
Remote dimmer control (Light)
The light bulb function controls the exterior accent lighting. To activate this function use the Mode Key
(Figure 1) to index to the light bulb icon (Figure 17). The intensity of the output can be adjusted through six
(6) levels. Use the Up/Down Arrow Keys (Figure 1) to adjust the output level (Figure 18).
A single “beep” will confirm reception of the command.
Figure 13: Fan off. Figure 14: Fan level HI.
Figure 15: CPI - IPI
selection.
Figure 16: IPI.
Figure 17: Accent
lighting off.
Figure 18: Accent lighting
high.

11 TRNT.BODYA
100000457 180118-40
Owner information
Low Battery Power Detection
Remote Transmitter
The life span of the remote control batteries depends on various
factors: quality of the batteries used, the number of ignitions of the
gas stove, the number of changes to the room thermostat set point,
etc.
When the remote batteries are low, an icon will appear on the LCD
display of the remote (Figure 19) before all battery power is lost.
When the batteries are replaced this icon will disappear.
IFC Module (Receiver)
The life span of the IFC module batteries depends on various factors: quality of the batteries used,
the number of ignitions, the number of changes to the room thermostat set point, etc.
When the IFC batteries are low, a “double-beep” will be emitted from the IFC module when it receives
a command from the remote. This is an alert for a low battery condition for the IFC board. When the
batteries are replaced, a single “beep” will be emitted from the IFC module when a key is pressed.
See "Initializing the System for the first time" on page 32.
WARNING
Fire Hazard. Can cause severe injury or death
The IFC Modules (receiver) causes ignition of the gas
stove. The gas stove can turn on suddenly. Keep away
from the gas stove burner when operating the remote
system or activating manual bypass of the remote
system.
WARNING
Shock Hazard. Can cause severe injury or death
This gas stove is powered by line voltage. Do not try
to repair this device. In no way is the enclosure to
be tampered with or opened. Disconnect from line
voltage before performing any maintenance.
Figure 19: Low battery power.
Warnings and Cautions

12 100000457 180118-40
TRNT.BODYA
Owner information
Turn off gas and electrical power supply (if applicable) and allow ample time for the gas stove to cool before
servicing gas stove. It is recommended that the gas stove and its venting should be inspected at least once a
year by a qualified service person.
Glass Door:
Warning: Do not operate gas stove with glass door removed, cracked or broken. Replacement of the glass
door should be done by a licensed or qualified service person.
Do not strike or otherwise impact the glass in any way that may cause it to break. If the glass becomes
cracked or broken it must be replaced before using the gas stove. A replacement glass door can be obtained
from your nearest Pacific Energy dealer. Do not substitute with any other type.
To replace broken glass door, refer to, See "Glass door removal" on page 24 and "Glass Door Installation"
on page 28.
Annual Inspection:
a) Remove glass door and decorative media (such as logs and embers). Inspect decorative
media and burner assemblies for soot buildup. If excessive buildup of soot is present, have a
qualified service person inspect and adjust unit for proper combustion. Clean burners with a
brush or vacuum cleaner, paying close attention to burner ports.
b) Check the pilot system for proper flame size and operation. Clean pilot of soot, dust or
any other deposits.
c) Check that the vent pipe and vent terminal are open and free from blockage or debris. If the
venting is disassembled for cleaning, it must be properly re-assembled and re-sealed.
d) Check glass panel gasket, replace if necessary. It is important that the glass seal be
maintained in good condition.
e) Check and replace batteries as needed.
Note: The gas stove area must be kept clear and free from combustible materials, gasoline and
other flammable vapors and liquids.
Periodically:
a) Viewing glass may be cleaned as necessary with fireplace glass cleaner.
b) Exterior finish may be cleaned with mild soap and water.
CAUTION:
Do not use abrasive cleaners on glass or any other part of the gas stove.
Do not clean glass when hot.
Maintenance

13 TRNT.BODYA
100000457 180118-40
Owner information
FOR YOUR SAFETY READ BEFORE LIGHTING
LIGHTING INSTRUCTIONS
TO TURN OFF GAS APPLIANCE
WARNING:
If you do not follow these instructions exactly, a
fire or explosion may result causing property damage,
personal injury or loss of life.
A.This appliance is equipped with an ignition device which
automatically lights the pilot. Do not try to light the pilot by hand.
B.BEFORE LIGHTING smell all around the appliance area for gas. Be
sure to smell next to the floor because some gas is heavier than
air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS:
- Do not try to light any appliance.
- Do not touch any electric switch; do not use any phone in your
building.
- Immediately call your gas supplier from a neighbour's phone. Follow
the gas supplier's instructions.
- If you cannot reach your gas supplier, call the fire department.
C. Use only your hand to push in or turn the gas control knob. Never use
tools. If the knob will not push in or turn by hand, don't try to repair it,
call a qualified service technician. Force or attempted repair may
result in a fire or explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance & to replace any part of the control system & any gas
control which has been under water.
1. STOP! Read the safety information above on this label.
2. This appliance is equipped with an ignition device which
automatically lights the pilot. Do not try to light the pilot by hand.
3. Push the "On/ Off" switch to turn the fireplace ON.
- If the burner does light go to step 6.
- If the burner does not light, complete steps 4 through 5.
- If the burner will not light or stay lit after several tries, push the
"On/ Off" switch for the fireplace to OFF, turn off all electric power
to the fireplace and call your service technician or gas supplier.
Note: Sufficient time must be allowed for air to escape from lines if
the unit is being lit for the first time.
4. Push the "On/ Off" switch to the fireplace Off.
5. Allow sufficient length of time (minimum 5 minutes) for any gas in the
combustion chamber to escape. If you still smell gas, STOP! Follow
"B" in the safety information above on this label. If you don't smell
gas, go to step 3.
6. Set fireplace to desired setting by using hand held remote.
Push the "on/ off" switch to the "Off" position.
2. Turn off all electric power to the appliance and remove backup
batteries if service is to be performed or for extended shutdown.
Due to high surface temperatures, keep children, clothing and furniture away. Keep burner and control compartment clean. See installation and
operating instructions accompanying the appliance.
A cause de la temperature elevee des parios, tenir eloignes les enfants, les vetements et les meubles. Maintenir propres le bruleur et le
compartiment de commande. Voir les instructions relatives a l'installation et au fonctionnement qui accompagnent l'appareil.
CAUTION:
Hot while in operation. Do not touch. Severe burns may result. Keep children,
clothing, furniture, gasoline and other liquids having flammable vapours away. Keep burner and control
compartment clean. See installation and operating instructions accompanying the appliance.
ATTENTION:L'appareil est chaud lorsqu'il fonctionne. Ne pas toucher l'appareil. Risque de
brûlures graves. Serveiller les enfants. Garder les vêtements, le meubles, l'essence ou autres liquides
produisant des vapeurs infl ammables loin de l'appareil. S'assurer que le brûleur et le compartiment des
commandes sont propres. Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil.
Lighting Instructions

14 100000457 180118-40
TRNT.BODYA
Installer information
Trenton Gas Stove Dimensions
Dimensions
Height 30 5/ 8 inches
Width 26 3/4 inches
Depth 21 15/16 inches
Height to center
of Flue Outlet 24 inches
26 3/4”
30 5/8”
21 15/16”
24”
Figure 20: Trenton dimensions.

15 TRNT.BODYA
100000457 180118-40
Installer information
Clearances to combustibles
Minimum Clearance to Combustible Materials
INTERIOR SIDE WALL 4”
INTERIOR BACK WALL 4 “
INTERIOR CEILING 18”
VENTING PIPE CLEARANCE 1”
Locating the Gas stove
Location Note:
The Trenton can be
installed directly onto
any flooring material
without an additional
floor protector. Only
requirement is that
the floor be stable
and strong enough to
support the stove
Note on corner placement:
Refer to minimum clearances as shown
in Figure 21 & Figure 22. Refer to
Figure 25 on page 17 for venting
allowances.
4”
4”
18”
MIN.
Figure 21: Trenton clearance to combustibles.
4”
4”
1”
4”
4”
4” 1”
4”
Vertical venting
Horizontal venting
Vertical venting
Vertical venting
Horizontal venting
4”
4”
1”
1”
“
LOCATION EXAMPLES INCLUDE MINIMUN
CLEARANCES TO COMBUSTIBLE MATERIAL
Figure 22: Trenton common locations & minimum allowances.

16 100000457 180118-40
TRNT.BODYA
Installer information
A *12 inches (30 cm) min. Clearances above grade, veranda, porch, deck, or balcony
B *12 inches (30 cm) min. Clearance to window or door that may be opened
C 12 inches (30 cm) min. Clearance to permanently closed window recommended to prevent condensation on window
D 16 inches (40 cm) min. Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (60 cm)
E 16 inches (40 cm) min. Clearance to unventilated soffit
F 6 inches (15 cm) min. Clearance to outside corner
G 6 inches (15 cm) min. Clearance to inside corner
H 3 feet (90 cm) min. *Not to be installed above a meter/regulator assembly within 3 feet (90 cm) horizontally from the center-line of the
regulator
I *3 feet (90 cm) min. Clearance to service regulator vent outlet
J *12 inches (30 cm) min. Clearance to non mechanical air supply inlet to building or the combustion air inlet to any other appliance
K *6 feet (1.8 m) min. Clearance to a mechanical air supply inlet
L *7 feet (2.1 m) min. ^ Clearance above paved side-walk or a paved driveway located on public property
M **16 inches (76 cm) min Clearance under veranda, porch, deck, or balcony
Minimum clearances to the vent terminal must be maintained
as shown in Figure 23 and the Roof Pitch Table. Measure
clearances to the nearest edge of termination hood.
NOTE: Vent terminal must not be recessed
NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE
DIFFERENT CLEARANCES.
Vent Terminal Clearances
Vent Terminal Minimum Clearances
36"
See Roof Pitch Table
48"
ADJACENT
24"
(91.5 cm) (61 cm)
(122 cm)
STRUCTURES
OR FENCE
VENT TERMINAL MINIMUM CLEARANCES
TO ADJACENT STRUCTURES
Figure 23: Clearances to adjacent structures.
Roof Pitch Table (minimum)
ft m
Flat to 6/12 1.00 0.30
Over 6/12 to 7/12 1.25 0.38
Over 7/12 to 8/12 1.50 0.46
Over 8/12 to 9/12 2.00 0.61
Over 9/12 to 10/12 2.50 0.76
Over 10/12 to 11/12 3.25 0.99
Over 11/12 to 12/12 4.00 1.22
M
K
I
A
V
G
G
H
A
J
V
G
A
B
C
A
V
V
A
V
B
F
B
L
V
E
V
V
V
D
FIXED
CLOSED
FIXED
CLOSED OPEN-
ABLE
OPEN-
ABLE
AIR SUPPLY INLET
VENT TERMINAL GAS METER
AREA WHERE TERMINAL
IS NOT PERMITTED
B
B
Figure 24: Minimum clearances to vents.
^ a vent shall not terminate directly above a side-walk or paved driveway which is located between two single family dwellings and serves both dwellings*
** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the floor*
* as specified in CGA B149 Installation Codes, Note: local Codes or Regulation may require different clearances
* for U.S.A. Installations follow the current National Fuel Gas Code, ANSI Z223.1

17 TRNT.BODYA
100000457 180118-40
Installer information
Trenton Co-Axial Venting Chart
Note: The vent must not exceed
a total length of 30 feet. Any
combination of rise and run may
be used but must be constrained
to the boundaries of this chart. A
Maximum of three (3) 90° elbows
may be used. Only one (1) 90°
elbow or combination of other
elbows equaling 90° can be used
without reducing horizontal run.
For each additional 90° elbow, or
an equal combination of elbows,
reduce horizontal vent run by 2
feet. Ensure vent pipe is properly
supported.
Damper Note:
The damper position is factory
set to the closed position. Every
venting configuration is different,
and the damper setting may need
slight adjustment.
(See page 33 for damper
adjustment).
No venting options
No venting options
Venting envelope
Venting envelope
1’
2’
3’
4’
5’
6’
7’
8’
9’
10’
11’
12’
13’
14’
15’
16’
17’
18’
19’
20’
21’
22’
23’
24’
25’
26’
27’
28’
29’
30’
31’
1’ 2’ 3’ 4’ 5’ 6’ 7’ 8’ 9’ 10’ 11’ 12’ 13’ 14’ 15’
Note: For horizontal termination at the
end of venting which is no higher than 2
feet vertically, the Snorkel terminal must
be used. Otherwise, the regular terminal
can be used.
16’
Figure 25: Trenton venting chart examples.

18 100000457 180118-40
TRNT.BODYA
Installer information
Co-Linear Venting
Intake
Air
Exhaust
Air
Co-Linear Venting Notes:
•TN24 requires a 3 inch
diameter exhaust vent
and a 3 inch intake vent.
•Max. Vent Height 35’
(15.25M) to termination
•Min. Vent Height 10’
(3m) to termination.
High wind cap
Prairie cap
1. Measure chimney height, cut flex liner (min.10’
to termination) as required. Mark one pipe at
both ends to identify combustion air intake
pipe from flue outlet pipe.
2. Attach marked flex liner pipe to the intake side
of vent terminal. Seal and secure with sealant
and screws provided. Attach the other pipe
to the outlet side of vent terminal. Seal and
secure with sealant and screws provided.
3. Insert both flex liners from top of the chimney,
down through the damper opening.
4. Before attaching vent terminal to top of
chimney, apply a bead of caulking to top of
clay liner. Slip vent terminal over liner and
secure in place with lateral retaining bolts.
5. For larger chimneys, flashing will need to be
constructed according to local building codes.
Simpson Duravent High-Wind (cap style) Co-Linear
Kit w/Flex (46DVA-CL33) or Simpson Duravent Prairie
(cap style) Co-Linear Kit w/Flex (46DVA-CL33P) are
recommended for use with this appliance.
Visit http://www.duravent.com for kit details.
NOTE:
If venting the TN24 through an existing
fireplace opening using a co-axial to
co-linear adapter, the customer will have a
couple of aesthetic options which include:
1. Sealing up the existing fireplace opening
with a cover or other material, leaving
room in the cover or other material to
accommodate the adapter so that it is
positioned flush Figure 26 with the cover
or other material.
2. Positioning the TN24 so that it and
the adapter are located outside of the
existing fireplace opening.
Figure 26: Trenton co-linear venting configuration.

19 TRNT.BODYA
100000457 180118-40
Installer information
33 1/4”
13” 7” 1”
4 1/4”
8 3/4”
24 1/2”
6 1/2”
4” 6 5/8”
Front view Side view
Rear view
Optional Direct Vent Termination “Snorkel”
Note:
For proper operation, the Snorkel
must be oriented so that the vent
inlet and outlet are located at the
bottom end of the unit as shown in
the side view of this diagram. Failure
to position the unit as such will
restrict the exhaust and compromise
overall air circulation.
Figure 27: Snorkel dimensions.

20 100000457 180118-40
TRNT.BODYA
Installer information
Installation
Attachment
points
Attachment points and
drain ports
SE
ALANT
Installation:
The Snorkel can be attached to an exterior wall using 4 supplied screws. Be sure to position
the Snorkel correctly so that the drain ports are located at the bottom of the unit.
Exterior facing or siding can butt right up to the sides of the unit and can extend up to 1” from
the wall to which the unit is attached.
Exterior caulking should be applied to the unit both at the wall where the unit attaches and
where the exterior facing or siding meets the unit.
Figure 28: Fastening the snorkel.
Figure 29: Caulking the snorkel.
