The contents of this manual are based on the latest
product information available at the time of publica-
tion. Pacific Steamex reserves the right to make
changes or improvements to its machines without
notice.
FOR YOUR CONVENIENCE, RECORD THE
FOLLOWING IMPORTANT INFORMATION:
MODEL
SERIAL NUMBER
PART NUMBER
DATE PURCHASED
FLOORMASTER 18B
OPERATING & MAINTENANCE
INTRODUCTION INSTRUCTIONS
READ THIS BOOK
This operator’s book has important information for
the use and safe operation of this machine. Read
this book carefully before starting the machine.
Keepthisbookandtellalloperatorstoreadthebook.
If you do not follow the instructions, you can cause
an injury or damage equipment, furniture or build-
ings.
For new books write to:
Pacific
2259 S. Sheridan
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there
is no concealed freight damage. If such damage is
discovered, file a “CONCEALED DAMAGE RE-
PORT” immediately with the delivering carrier.

TABLE OF CONTENTS
2
IMPORTANT SAFETY INSTRUCTIONS
SYMBOLS USED ON THE MACHINE
MACHINE PREPARATION
1. UNPACKING THE MACHINE
2. BATTERY INSTALLATION
3. CONNECTING THE BATTERY CHARGER
4. CHARGING THE BATTERIES
5. CONNECTING THE BATTERY CONNECTOR
6. BATTERY INDICATOR
7. SQUEEGEE ASSEMBLY
8. ADJUSTING THE SQUEEGEE HEIGHT
9. ADJUSTING THE SQUEEGEE INCLINATION
10. HEIGHT HANDLE BAR
11. RECOVERY TANK
12. SOLUTION TANK
13. SOLUTION WATER
14. ADJUSTING THE BRUSHES
OPERATION
OPERATING
DEVICE TOO FULL
MOVEMENT
BRAKE
UPON COMPLETION OF THE WORK
DAILY MAINTENANCE
CLEANING THE RECOVERY TANK
CLEANING THE SOLUTION TANK FILTER
CLEANING THE VACUUM FILTER
CLEANING THE SQUEEGEE
REPLACING THE SQUEEGEE BLADES
DISASSEMBLY OF THE BRUSH
WEEKLY MAINTENANCE
CLEANING THE SQUEEGEE HOSE
CHECK BRAKE
TROUBLE SHOOTING GUIDE
INSUFFICIENT WATER ONTO THE BRUSH
THE MACHINE DOES NOT CLEAN SATISFACTORILY
THE SQUEEGEE DOES NOT DRY THE FLOOR WELL
EXCESSIVE FOAM PRODUCTION
WARRANTY POLICY
3
4
6
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
7
8
9
10
11
12
13
14
15
16
17
18
20
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

READ AND UNDERSTAND ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING
THIS MACHINE!
WARNING: To reduce the risk of fire, electric shock or injury:
1. You must have training in the operation of the machine before using it. READ THE
INSTRUCTION BOOK. If you do not understand any instruction, ask your supervisor.
2. Make sure all labels, decals, warnings, cautions and instructions are fastened to the machine.
3. Read the labels carefully on the machine. Do not cover them for any reason and replace them
if damaged.
4. Do not operate this machine unless it is completely assembled, inspect the machine carefully
before operation.
5. Pay close attention to other people and especially children while operating this machine.
6. Be a careful driver, do not strike shelving or scaffolding, especially where there is a danger of
falling objects.
7. Machines can cause an explosion when operated near flammable materials and vapors. Do
not use this machine with or near fuels, grain dust, solvents, thinners, or other flammable
materials.
8. In case of fire, use a powder extinguisher. Do not use water.
9. Do not use this machine as a means of transport.
10. Do not use acid solutions that could damage the machine.
11. Adjust your speed to the conditions of the floor.
12. Do not turn the machine on a ramp. Do not stop and leave the machine on a ramp or incline.
13. When the machine is parked, take out the key and set the parking brake.
14. During any maintenance operation disconnect the power supply from the machine.
15. Lead acid batteries generate gases that can cause an explosion. Read the instruction manual
supplied with the battery charger. Keep sparks and flames away from batteries.
NO SMOKING. Charge the batteries only in an area with good ventilation.
16. Do not use a charger if the power cord is damaged.
17. Always wear eye protection and protective clothing when working near batteries. Remove all
jewelry. Do not put tools or other metal across the battery terminals, or the tops of the batter-
ies.
18. Check the level of the electrolyte every time you charge the batteries. If the level is low, add
distilled water only.
19. Maintenance and repairs must be performed by authorized Service Centers only. Make ad-
justments according to the specifications given in the service manual for this machine.
20. Keep the electrical parts of the machine dry. Do not wash the machine with direct water jets or
high pressure, nor with corrosive material. For storage, keep the machine in a dry building.
21. Water solutions or cleaning materials used with this type of machine can leave wet areas on
the floor surface. These areas can cause a dangerous condition for the operator or other per-
sons. Always put CAUTION signs near the area you are cleaning.
22. Do not reach under shrouds with fingers, hands, or toes when machine is running.
IMPORTANT SAFETY INSTRUCTIONS
3

4
SYMBOLS USED ON THE MACHINE
Symbol for the water valve:
Indicates the solenoid valve switch.
Symbol indicating the raised or lowered position of the brush base:
Indicates the lever for lifting the brush base.
Symbol for the brush:
Indicates the brush motor switch.
Symbol for the vacuum motor:
Indicates the vacuum motor switch.
Symbol indicating the raised or lowered position of the squeegee:
Indicates the squeegee lever position.
Symbol indicating the charge levels of the batteries:
It is necessary to recharge the batteries when the green light begins to blink
Symbol for the brakes:
It is used on top of the emergency and parking brake lever.
Indicates the drain pipe of the recovery tank.

5
SYMBOLS USED ON THE MACHINE
Indication of the maximum recommended temperature for the solution water (50°C or
122°F): It is located near the fill hole of the solution tank.
Symbol indicating the adjustment lever for the handle bar height.
Symbol for the key switch.
Symbol for the coupling:
Indicates the anchor points and the load direction.
This symbol serves as a reminder for the operaor to read the manual.
The WARNING symbol:
Carefully read the sections preceded by this symbol, this is for the safety of the
operator and of the machine.

6
MACHINE PREPARATION
1. UNPACKING THE MACHINE
1. Use a fork truck to move the machine when packaged.
2. Take off the outer package
3. The machine is fixed on the pallet with wooden wedges that block the wheels.
4. Take the wedges off.
5. Using a ramp, pull the machine down from the pallet, pushing it in reverse
motion. Avoid violent blows to the base.
2. BATTERY INSTALLATION
The two 12 volt 145 A/H batteries fit in the compartment under the recovery tank.
Recommended Batteries: Crown Battery Manufacturing Company Part #711
Trojan Battery Company Part #30XHS
East Penn Manufacturing Company Part #8KFS
For battery maintenance and charging, follow the instructions
provided by the battery supplier.
Installation Instructions:
1. Lift the recovery tank forward.
2. Detach the squeegee hose (1) from the recovery tank.
3. Take off the vacuum plug (2) by rotating it counterclockwise.
4. Take the recovery tank off.
5. Place the batteries in their compartment.

7
MACHINE PREPARATION
6. Connect the batteries’ connector (2) to the machine’s connector (1).
7. Reassemble the recovery tank, vacuum plug and squeegee hose.
3. CONNECTING THE BATTERY CHARGER
The battery chargers’ connector fits into the battery connector (2) located under the
recovery tank.
4. CHARGING THE BATTERIES
NEVERALLOWTHEBATTERIESTO RUN COMPLETELYDOWN, recharge
them within a few minutes after the battery indicator starts blinking. Never leave the
batteries completely discharged, even if the machine is not being used.
Check the electrolyte level at least every 20 times the batteries are charged. Add only
distilled water if the level is low.
WARNING! When charging the batteries, follow all the instructions
provided with this manual and the battery charger. Trained staff must carry
out the installation and maintenance operations.
WARNING!Fire Danger:Lead acid batteries generate gases that can cause
anexplosion. Keep sparksand flamesaway frombatteries. NOSMOKING!
WARNING! To prevent an explosion, charge the batteries only in an area
with good ventilation.
WARNING! Always wear eye protection and protective clothing when
working near batteries.
When charging the batteries, keep the recovery tank lifted with the prop as shown in
the figure.
Turn the key to the OFF position. Connect the DC connector on the charger to the
DC battery connector. Connect the AC charger plug to a receptacle that has the
correct voltage and frequency for your charger. Make sure the receptacle is
connected to the electrical ground.

8
MACHINE PREPARATION
5. CONNECTING THE BATTERY CONNECTOR
After charging the batteries, reconnect the battery connector (2) to the connector of
the machine (1).
6. BATTERY INDICATOR
The battery indicator is a green signal light; it is constantly on when the batteries are
sufficiently charged. The signal light will blink when it is necessary to recharge the
batteries.
7. SQUEEGEE ASSEMBLY
The squeegee is assembled as shown in the figure. The squeegee lever should be in
its up position. Insert the holding pin into the squeegee stud bolt to secure the
squeegee in place. Then fit the squeegee hose into its coupling; the hose should be
located to the right of the lifting cable.

9
MACHINE PREPARATION
2
1
8. ADJUSTING THE SQUEEGEE HEIGHT
The height from the floor to the squeegee should be adjusted based on the blade’s
wear. Rotate the knob (2) counter-clockwise to lift the squeegee and clockwise to
lower it.
Note: Adjust the right and left knobs the same amount; the squeegee should be
positioned parallel to the floor.
9. ADJUSTING THE SQUEEGEE INCLINATION
During operation, the rear squeegee blade is most efficient when tilted back about
3/16 inch (5mm) along its whole length. To increase the blade bending in the central
part, tilt the squeegee body backward by turning the adjuster (1) counter-clockwise.
Subsequently, turn the adjuster clockwise to increase the bending at the sides of the
squeegee blade.
10. HANDLE BAR HEIGHT
The handle bar is adjustable in three different positions:
1. Release the lever.
2. Put the handle bar at the desired height.
3. Release the lever and the handle bar will lock in place.
11. RECOVERY TANK
1. Open the cover and confirm the vacuum plug (2) is properly closed: line up the
notches and rotate the plug clockwise to close. The vacuum motor hose must also
be attached.
2. Confirm the squeegee hose (1) is properly connected.
3. Make sure the drain plug, which is located in the front of the machine is also
closed.

10
MACHINE PREPARATION
12. SOLUTION TANK
Unscrew the water inlet plug and confirm the solution filter, located on the bottom
left side, is properly assembled.
13. SOLUTION WATER
Fill the solution tank with clean water at a temperature not more than 50°C/122°F.
Add the proper concentration of liquid detergent by following the manufacturer in-
structions. Excess foam in the recovery tank can damage the vacuum motor, so use
only the minimum amount of detergent necessary. Reassemble the cover.
14. ADJUSTING THE BRUSHES
Both brushes should have the same amount of contact with the floor, along their
whole length.
1. Lower the brushes, set the emergency brake and turn the brushes on.
2. Turn the knob (1) to adjust the brush pressure.
3. Turn the screw (2) to obtain equal contact of the brushes with the floor (tightening
the screw will increase pressure on the rear brush).
WARNING!: Always use low foaming detergent. Adding antifoam
liquid into the recovery tank before cleaning will also help prevent
foaming. NEVER USE PURE ACID.

11
OPERATION
OPERATING
1. Connect the machine connector (1) to the battery connector.
2. Turn thekey (2)clockwise toON. The greensignal lightwill comeon (3) indicating
the batteries are charged (if blinking, the batteries need to be charged).
3. Press the solenoid valve switch (4).
4. Press the vacuum motor switch (5).
5. Press the brush motor switch (6).
6. Adjust the amount of cleaning solution through the lever (1). There should be
enough solution to wet the floor uniformly, but not so much that it gets past the
splash guard. Remember that the correct solution quantity depends on the type of
floor, the dirt and the speed.
7. Release the lever (2) and lower the brush base.
8. Lower the squeegee using lever (3).
9. Check that the parking brake (4) is released.
10. The machine will move by pushing the lever (1) on the handle bar forward. During
the first few yards of operation, check that the quantity of the cleaning solution is
sufficient and that the squeegee dries the floor surface.

12
OPERATION
Attention: If problems occur during operation, release the lever on the handle bar and
immediately lower the brake lever located on the left side. This action will stop the
machine’s movement.
To restart the machine after the problem has been solved, release the parking brake
lever and push the lever on the handle bar forward.
DEVICE TOO FULL
The machine is equipped with a float that stops the vacuum when the recovery tank is
full. When this occurs, empty the recovery tank by removing the plug on the drain
hose.
Use gloves for protection from contact with dangerous solutions.
MOVEMENT
The movement of this machine is obtained through front brush assistance. Its’ harder
bristles create a pulling effect.
There is no separate traction drive motor in this unit.
WARNING! Lift the squeegee when moving backward.
BRAKE
The machine is equipped with a braking system controlled through the left lever (1)
located on the left side, which is used as a both a parking and an emergency brake.

13
UPON COMPLETION OF THE WORK
After finishing your work and before any type of maintenance is done, it is necessary
to do the following:
1. Close the water valve through lever (1).
2. Lift the brush base with lever (2).
3. Lift the squeegee with lever (3). Note: The squeegee blades can be damaged if the
squeegee is not raised during storage or transport.
4. Switch off the solenoid valve switch (1).
5. Switch off the brush switch (2).
6. Switch off the vacuum motor switch (3).
7. Transport the machine to the location where the recovery tank should be emptied.
8. Turn the key (4) OFF.
9. Set the parking brake.
10. Pull out the hose on the front part of the recovery tank.
11. Unscrew the drain plug and empty the recovery tank.
Use gloves to protect yourself from contact with dangerous solutions.
12. Take the brush off and clean it with water (for brush disassembly please read the
section “DISASSEMBLY OF THE BRUSH”).
13. Slide the hopper out and clean thoroughly using gloves.

14
DAILY MAINTENANCE
CLEANING THE RECOVERY TANK
1. Pull out the hose on the front of the recovery tank.
2. Unscrew the drain plug and empty the tank.
Use gloves to protect yourself from contact with dangerous solutions
3. Lift the cover of the recovery tank.
4. Take off the vacuum plug (2) by rotating it counter-clockwise.
5. Remove the filter and its housing.
6. Rinse with water.
If a more thorough cleaning is necessary, separate the filter from its housing. Loosen
the screws that lock the filter in place, then unscrew the filter from its’ housing.
If removing the recovery tank, remember to detach the squeegee hose (1) and the
vacuum plug (2) first. Then proceed with steps 5 and 6 above. Reassemble everything
by repeating these operations in reverse.

15
DAILY MAINTENANCE
CLEANING THE SOLUTION TANK FILTER
1. Unscrew the plug on the solution tank.
2. Take out the filter by pulling up on the filter cap, then clean the filter thoroughly
with water.
3. Reassemble by pushing the cap until it snaps into the filter body.
CLEANING THE VACUUM FILTER
1. Lift the cover.
2. Take off the vacuum plug by rotating it counter-clockwise.
3. Remove the filter and its housing.
4. Use water to clean the walls and the bottom of the filter.
5. If necessary, loosen the screws which lock the filter to the housing.
6. Rotate the filter counterclockwise until it is released.
7. Wash all components thoroughly.
8. Reassemble repeating the above operations inversely.
CLEANING THE SQUEEGEE
To obtain the best drying results, keep the squeegee clean.
To clean the squeegee it is necessary to:
1. Remove the hose from the squeegee.
2. Loosen the knobs (1).
3. Clean the inside of the squeegee thoroughly.
4. Clean the squeegee blades thoroughly.
5. Reassemble.
REPLACING THE SQUEEGEE BLADES
Check the squeegee blades for wear and if necessary, change them.
To replace the squeegee blades:
1. Remove the squeegee hose from its coupling.
2. Take off the pin from the stud bolt.
3. Remove the squeegee from its support.
4. Loosen the nuts that lock the rubber blades and take them off.
5. Replace the blades.
6. To reassemble the squeegee, repeat the above operations inversely

16
DAILY MAINTENANCE
DISASSEMBLY OF THE BRUSH
To remove the brushes:
1. Lift the brush base (lever 1).
2. Set the brake (lever 2).
3. Clean the hopper as described on page 13.
4. Remove any strings or debris that may be preventing free brush rotation.
5. Unscrew the wing nut (1).
6. Take off the plate (2).
7. Take off the plugs (3).
8. Remove the brushes and clean.
WARNING: Make sure the key is turned to the OFF position.

17
WEEKLY MAINTENANCE
CLEANING THE SQUEEGEE HOSE
Weekly or whenever the suction is insufficient, make sure the squeegee hose is not
obstructed. To clean:
1. Take off the hose from its coupling on the squeegee.
2. Take off the other end from the recovery tank.
3. Wash the inner part of the hose with a water jet from the tank side.
4. Reassemble.
WARNING!Do not wash the hose that goes from the vacuum motor
to the vacuum plug.
CHECK BRAKE
Check the distance between the brake pads and the wheels weekly. Adjust this
distance to about 1/8 inch (3mm) by adjusting the nuts shown in the diagram.

18
TROUBLE SHOOTING GUIDE
INSUFFICIENT WATER ONTO THE BRUSH
1. Make sure the water valve is open (lever 1).
2. Confirm there is water in the solution tank.
3. Make sure that the solenoid valve switch is on (button furthest on right).
THE MACHINE DOES NOT CLEAN SATISFACTORILY
Check the condition of the brush and replace it if necessary. The brush should be
replaced when the bristles reach about 5/8 inch (15mm).
THE SQUEEGEE DOES NOT DRY THE FLOOR WELL
1. Check that the squeegee blades are clean.
2. Adjust the inclination of the squeegee (see “MACHINE PREPARATION” #9).
3. Confirm the vacuum hose is correctly fitted in its housing on the recovery tank.
4. Take off the entire vacuum assembly and clean it.
5. Replace the blades if worn.
6. Check that the vacuum motor switch is on.
7. Check the squeegee height adjustment (see “MACHINE PREPARATION #8).
EXCESSIVE FOAM PRODUCTION
Check that a low foam detergent has been used. If required, add a small quantity of
antifoam liquid into the recovery tank.
Remember that more foam is generated when the floor is not very dirty. Use less
detergent if this is the case.
REFER TO THE PARTS & SERVICE MANUAL FOR ELECTRICAL
SCHEMATICS AND ADJUSTMENTS & INSPECTIONS

19
NOTES
