Pacific SANISWEEP Installation and operation manual

READ THIS BOOK
This operator’s book has important information for the use
and safe operation of this machine. Read this book care-
fully before starting the machine. Keep this book and tell
all operators to read the book. If you do not follow the
instructions, you can cause an injury or damage equipment,
furniture or buildings.
For new books write to:
Pacific Steamex, Inc.
2259 S. Sheridan
Muskegon, MI 49442-6252
Carefully inspect all components to ensure that there is no
concealed freight damage. If such damage is discovered,
file a “CONCEALED DAMAGE REPORT” immediately
with the delivering carrier.
The contents of this manual are based on the latest product
information available at the time of publication. Pacific
Steamex reserves the right to make changes or improve-
ments to its machines without notice.
FOR YOUR CONVENIENCE, RECORD THE
MACHINE MODEL AND SERIAL NUMBER:
MODEL_______________________________
SERIAL NUMBER______________________
OPERATING & MAINTENANCE
INTRODUCTION INSTRUCTIONS
Manual Powered
Sweepers
SANISWEEP
and
SUPERSWEEP

NOTES

Introduction
The SaniSweep and SuperSweep manually operated sweep-
ers are designed with three brushes: two counter rotating cir-
cular brushes and one centrally located cylindrical brush. The
two circular brushes pick up small and large debris and the
cylindrical brush removes the remaining fine debris. The
sweepers are for use on hard, flat surfaces. The sweepers will
pick up paper, leaves and general litter – both inside and out.
However they are not designed for dust. The debris is swept
into the hopper and the hopper is easily removed by lifting
the handle; then the hopper can be carried separately for dis-
posal of the debris.
Assembly
Your sweeper requires little assembly before operation. Fol-
low these simple steps:
Assemble the operator’s handle. The machine handle is
shipped in three parts: the “U” shaped tube and two black
lower sections (or holders).
1. First connect each black holder to the U tube. De-
press the spring button on the U tube, then slide the black
holder on until the spring button clicks into the hole.
2. Connect the handle assembly to the machine. Simply
slide the handle assembly over the recessed holes on each
side of the front cover. Then snap into the holes to lock in
place.
Operation
This sweeper can be used for both indoor and outdoor sweep-
ing.
DO NOT PICK UP ANYTHING THAT IS BURNING
OR SMOKING, SUCH AS CIGARETTES, MATCHES
OR HOT ASHES.
1. Make sure the hopper and front cover are securely
fastened. Slots in the hopper slide over locators on the front
cover. After the hopper and front cover are fitted together,
push the hopper’s handle down. This will latch the hopper
to the front cover.
2. Adjust the brush pressure to accommodate your pick
up needs. The height adjustment dial is located on the front
of the sweeper. For larger debris use a high setting, number
1 is the highest position. Move to a higher number (lower
position) for picking up finer debris. Do not press the brushes
too firmly to the ground because this will eventually wear out
the drive mechanism.
3. Start sweeping. The overlapping brushes ensure good
coverage. Dirt and debris will be pushed into the hopper as
soon as you begin pushing the sweeper. The carrying capac-
ity of the hopper can be increased by raising the front of the
sweeper, this will move debris to the back of the hopper.
4. Empty the hopper when you’re done sweeping. Sim-
ply pull up on the hopper’s handle and lift the hopper off the
front cover. Dispose of the debris in an approved waste re-
ceptacle. Clean the hopper if necessary. Reattach the hop-
per to the front cover.
5. Store the sweeper indoors.
Maintenance
1. Clean the hopper and machine by wiping with a dry
cloth as needed.
2. Brushes: After each use, remove any strings or debris.
3. Replacement or Cleaning of the Angled Wheels (24):
Set the height adjustment dial to position 8. Pull the angled
wheel strongly, to remove it and its axle from the tooth sleeve.
Clean or replace the wheel, then push it firmly back into the
tooth sleeve. Make sure you place the wheels back in their
correct positions, they are marked L and R for the left and
right positions.
4. Cleaning or Replacement of the Circular Brushes (28)
and Clutch Assembly (26 & 27): Remove the angled wheel
(24) as explained in Step 3. Pull the brush towards you - the
brush and clutch assembly will come away from the pivot
housing. The clutch assembly can now be pulled away from
the brush. The brushes and clutch assembly may be cleaned
with water. The gears should only be lubricated with silicone
spray.
Ensure that the brushes and clutch assemblies are fitted on
the correct side of the sweeper when reassembling. To guide
you, the inside of the front cover is marked L and R, as are
the wheels and each brush is marked L/// and R\\\ which in-
dicates the direction of the bristle point. To reassemble, place
the brush over the pivot housing then push the clutch assem-
bly over the pivot housing. Refit the angled wheel.
OPERATION AND MAINTENANCE

1
2
3
4
5
6
7
8
9
10
9
11
12
13
14
15
16
17
18
19
1
20
25
26
27
28
29
30
10
1
31
32
33
34
35
36
37
24
SANISWEEP & SUPERSWEEP

ITEM PART NUMBER DESCRIPTION QTY
1 964151 Screw
2 712315 Cover, Hopper 1
3 703901 Handle, Hopper 1
4 712015 Clamp 1
5 717701 Axle for Hopper 2
6 711115 Bushing 4
7 719704 Tread Wheel 2
8 712316 Bottom, Hopper 1
9 902037 Ball Bearing 6805zz 4
10 712415 Clutch Element Ring 2
11 712016 Wheel Clamp 2
12 719215 Tread Wheel 2
13 719716 Wheel 2
14 713516 Pinion (Gear) 2
15 710916 Cylindrical Brush 1
16 712716 Driver, Brush 2
17 902036 Ball Bearing 6903zz 4
18 713515 Pinion (Gear) 2
19 716615 Sweeping Plate 1
20 715101 Sweeping Lip 1
24 719715L Wheel w/Axle Left - SaniSweep 1
719715R Wheel w/Axle Right - SaniSweep 1
719720L Wheel w/Axle Left - SuperSweep 1
719720R Wheel w/Axle Right - SuperSweep 1
25 980634 Washer, 6mm 2
26 713502 Tooth Sleeve 2
27 712410 Clutch Complete Left 1
712411 Clutch Complete Right 1
28 710915L Circular Brush Left - SaniSweep 1
710915R Circular Brush Right - SaniSweep 1
710920L Circular Brush Left - SuperSweep 1
710920R Circular Brush Right - SuperSweep 1
29 714215 Pivot Housing 2
30 980638 Washer Pivot Housing 2
31 718515 Adjustment Slide -SaniSweep 2
718520 Adjustment Slide -SuperSweep 2
32 713215 Frame - SaniSweep 1
713220 Frame - SuperSweep 1
33 712715 Dial: Height Adjustment 1
34 715117 Holder for Sliding Lever 2
35 712115 Spring Clip 2
36 715116 "U" Handle Tube (Sliding Lever) 1
37 713903 Grip, Handle 2
PARTS LIST
71
1

WARRANTY POLICY
SANISWEEP & SUPERSWEEP
The Pacific Steamex Inc. Sweeper has been manufactured, tested and inspected in accordance with specific engineering
requirements and is WARRANTED to be free from defects in workmanship and materials as follows:
One (1) year – All components unless excluded below.
This warranty extends to the original user/purchaser and only when used, operated and maintained in accordance with Pacific
Steamex Inc. Operating and Maintenance instructions.
This warranty does not apply to the following wear parts of the machine including:
Part Number Part Name
710915L Circular Brush, Left - SaniSweep
710915R Circular Brush, Right - SaniSweep
710920L Circular Brush, Left - SuperSweep
710920R Circular Brush, Right - SuperSweep
710916 Cylindrical Brush
Nor does it apply to damage or failure caused by improper use, abuse or neglect. Warranty credit or replacement of return parts
is subject to incoming inspection of those items.
To secure repair under this warranty, the following procedure should be taken:
•The inoperative machine or warranted parts must be delivered to the authorized dealer with shipping and delivery charges
prepaid. If unable to locate the Dealer, you may contact Pacific Steamex Inc. at the address listed herein for the location
of the nearest Pacific Steamex Inc. repair center or agent or for other instructions pertaining to your warranty difficulty.
•Upon compliance with the above warranty procedure, all warranted repairs would be completed at no additional charge or
cost to the user.
•Only Pacific Steamex Inc. or its authorized dealers and agents may make no charge warranty repairs on this product. All
others do so at their own risk.
This warranty limits Pacific Steamex Inc. liability to the repair of the product and/or warranted parts replacement and does
not include incidental or consequential damages arising from the use of a Pacific Steamex Inc. machine whether defective or
not.
This warranty is in lieu of all other expressed or implied warranties and is extended to the original purchaser/user.
PACIFIC STEAMEX, INC.
2259 S. SHERIDAN
MUSKEGON, MICHIGAN 49442-6252
1-800-968-1332
FAX [phone]
10/99 715603
