Pact MKIV XP User manual
MKIV XP | User Manual
1
Timer Mode (TIME)
Turn the Timer ON/OFF:
With a battery installed, pressing any button will turn the MKIV XP on . Holding any button down
for 5 seconds will turn the MKIV XP off . In addition, the MKIV XP will turn itself off after about
15 minutes of inactivity.
Record Shots:
The MKIV XP will default start in “ TIMER COMMAND ” in delay mode. To use the timer in this
manner, just push the GO button, 2 to 3.5 seconds later you'll hear a beep - this is your go
signal.As you fire, the timer will automatically display and record the shot number, split time and
the time that each shot was fired. The first shot time will remain at the bottom.
EXAMPLE: “El Presidente” Drill with Timer Mode
Let's say you just fired an "El Presidente" (six-reload-six) you don't bother checking the
target (you know you shot all "A's") but you are concerned about how you did in the time
department. You check the display and it reads #012 .37 6.87 on the top line and FIRST
SHOT: 1.26 on the bottom line. With no button pushing you know quite a bit about your
string. First of all, the timer is telling you how many shots it heard (12) which is correct, the
last shot it heard was shot number 12, which came .37 seconds after shot 11. Your total
time from the start to your twelfth shot was 6.87 seconds and your first shot came at 1 .26
seconds.
1
Review Shots Sequentially:
Go ahead and press the REVIEW key. The MKIV XP will default to most recent sting in memory. If
you want to look at a previous string just enter the string number and press REVIEW , otherwise
press REVIEW again (without entering a number) to review the current string. The MKIV XP now
displays the first shot on the top of the display and “FIND SHOT” on the bottom line. Each time
you press REVIEW the timer will step to the next shot or event in memory.
Review a Specific Shot:
If you are interested in how long your reload was (from the example above), press 7 then REVIEW .
The MKIV jumps to shot number 7 and displays “ #07 1.65 4.54” . You see that your reload took
1.65 seconds (the time between shot 6 and 7). This time is a little long and you seriously
consider switching from your Six Gun to an auto-loader.
Printing from Review:
If you have one of the HP IR printers you can print the string at any time after you are done firing,
before or during review by pressing the PRNT key. (Please note that external printers are no
longer available factory-direct for this model.)
Begin New String:
To begin another string just push the GO button. This will clear your previous string and begin a
new one.
Continue a String:
If you would like the timer to add the time of your second and subsequent strings together (as
you might on an IPSC standards drill) press the CST GO button. This will NOT clear the memory
the way the GO button does.
2
NOTE : While this is a nifty training feature we caution you against using it in matches. If you
accidentally hit normal GO you'll wipe the shooters string.
Set a PAR Time:
The PAR button allows the shooter to enter a time limit (or PAR time in IPSC parlance) for a given
string.
EXAMPLE : Set PAR time of 1.2 seconds
Push the PAR button. The timer will ask you to “ ENTER PAR TIME AND PRESS SET” .
Push 1.2 (for example), SET . The timer now displays “PAR TIME 1.20” on the bottom line
of the display.
NOTE : If you are entering a number and make a mistake use the back arrow key to delete
the incorrect number.
Push the GO button. Each time the shooter fires the timer will display the shot number,
split time and total time on the top line of the display as before. When 1.2 seconds
comes around the timer will beep telling you that the time limit has been reached.
To turn the PAR time off push PAR , SET without entering a number.
Set the Delay:
The DLY button allows the shooter to control the type and length of delay (if any) between the
pressing of the GO button and the start signal. The timer defaults to a random delay of 3 to 3.5
seconds. The shooter can adjust these delay points to suit him or have the machine give him a
fixed delay.
3
EXAMPLE : Change the default random delay range to 5-10 seconds
Push DLY , YES , YES . The MKIV will briefly display “INPUT LIMITS AND PRESS SET” then
“ LOWER: 3.00 ”. Push 5 , SET . The timer asks “UPPER: 3.5”. Push 10 , SET and GO .
This time the MKIV will start its' countdown from between 5 and 10 seconds giving you
all sorts of time to psych yourself into a zombie like state of confusion.
To turn the delay off just push DLY , NO , GO . Now when you push the GO button the timer will beep
immediately.
Set Benchmark(s):
The BNCH button activates the PACT Benchmark feature. This allows the shooter to program
the timer with a series of beeps or cues at specific times after the go signal which allow him to
simulate moving and pop-up targets.
EXAMPLE : Add benchmark times at 2, 3.5, 5, and 6.25 seconds
Press BNCH , YES . The timer asks you for a time. Press 2 , SET , 3.5 , SET , 5 , SET , 6.25, SET ,
GO . The timer will beep at these times. All of the other timing features remain intact.
If you always want the same spacing between shots use the cadence feature described below.
4
Cadence Function:
The Cadence Function allows you to set periodic beeps. You may also set it to begin the
cadence at a specified time after the go signal or after the first shot.
EXAMPLE: Set cadence to 1.5 second interval beginning at 3 seconds
Start by restoring the defaults. Press MENU until you are asked if you'd like to " Restore
Defaults " and press YES . From the TIMER COMMAND prompt push the CAD , YES . Your
timer will ask you if you'd like it to start the cadence on the first shot , tell it NO this time.
Enter the initial delay. This should be the time you want to take from the go signal to your
first shot or click. For this drill enter 3 , SET . The CYCLE DELAY is the time between
cadence beeps. Push 1.5 , SET then the GO button. The MKIV XP will give you a start
signal, beep at 3 seconds then every 1.5 seconds for ever and ever.
We see this primarily a dry firing tool but you can also use it for live fire. You might have it trigger
off of the first shot to take the draw time out of some sort of long range "Bill Drill" practice.
Keyed Beeps:
The KEY button activates the Keyed Beep feature. This is a neat training tool that provides the
shooter with a beep a certain number of seconds after a specific shot. This is particularly useful
in practicing reloads.
EXAMPLE: Keyed Beep 1.5 seconds after the 6th shot
Press KEY , YES . The timer asks you for a shot number. Push 6 , SET . You must now tell it
the length of the delay, enter 1.5 SET . As with the Benchmark function you can enter
5
more than one keyed beep. When you are done entering keyed beeps you can either
press SET without entering a number to return to “ TIMER COMMAND” - or you can just
push the GO button to start the string.
Go ahead and press the GO button. When the timer hears your 6th shot it will start a
secondary timer and give you a yell 1.5 seconds later. At first you're just getting the
magazine to the gun at the beep. After some practice you find that you're almost back on
target at the beep. The feedback of the timer allows you to objectively evaluate
equipment and technique. You could also use multiple keyed beeps off of the same shot
to break the reload down some more.
Keyboard Lock Out:
In order to prevent accidental resetting of the timer during a shooters run (a problem in
movement stages where the RO runs with the shooter and leaves his finger on the GO button)
the MKIV XP has a keyboard lockout feature.
To activate it push the OPTN button until the timer asks " Lock out go keys? " Push YES and the
timer will lock its' keyboard after the next GO command. To reset the timer push the REVIEW key.
This time the timer asks " ENABLE GO KEY? " Push YES and you're back in business.
The PAR and DLY keys will remain hot. They are far enough out of the way that this does not pose
a problem. We wanted to keep those commonly used features easily accessible.
Lead Calculator:
The second option on the Timer Mode OPTN menu allows the shooter to calculate lead based on
the velocity of the bullet and target, and the distance to the target. Note that this is the lead in a
vacuum. No allowance has been made for the deceleration of the bullet. At close pistol ranges
(25 yards) this error is small. However we do not recommend this function for use at long range.
6
EXAMPLE: Set a lead based off of an object going 30 FPS at 15 yards from the shooter.
Press OPTN , OPTN , YES . The MKIV XP asks you for the velocity of your ammo. Enter 1050 ,
SET with a target range of 15 yards enter 15 , SET and a target velocity of 30 FPS enter 30 ,
SET . The timer tells you that the lead required to bust this running Jack Rabbit is 15.1
inches . If this is getting too easy try starting from the leather.
2
Rate of Fire Mode (RPM)
Rate of Fire Mode allows you to record the Rounds Per Minute (RPM) of your weapon up to 600
RPM. To begin press the RPM button. The MKIV XP now displays “ FULL AUTO CMD: ”. Press the
GO button. Instead of giving you a go beep the timer displays “ FIRE WHEN READY ”. Fire a fairly
long burst of a known number of rounds (so you have enough data to be meaningful). You'll
note that the timer is now displaying you time to the thousandth of a second.
Press REVIEW and the timer will tell you the number of rounds fired, the total time and the cycle
rate. Remember that the total number of cycles is one less than the number of shots fired.
3
Chronograph Mode (CHRN)
WARNING: Always wear eye protection when shooting! Do NOT place armor plate in front
of your sky screens! If you shoot a plate of steel a few feet in front of your face, bits of
metal will fly back at you and rip your eyes out!
7
General Setup and Tips on the Skyscreen System:
1. The closest Skyscreen sensor should be 5-10 ft. downrange from the shooter.
2. Aim so the bullet passes over the center of each screen at an altitude of between 4 and
8 inches above the sensor and centered .
3. Cables should be on the ground as much as possible.
4. Cables should be separate from each other.
5. Make sure the unit itself is NOT being hit by Muzzle Blast - Isolate the unit from the
shockwave
6. Make sure you are using a newly purchased, fully-charged battery .
7. Bright overcast days work very well
8. On VERY bright blue sky days , try canting the sensors over 60 to 90 degrees either left
or right. That will likely increase the contrast of the bullet to the diffuser improving the
ability to detect the bullet.
9. If shooting indoors , you will have to rig an incandescent light over each screen, or get
our M7 IR Skyscreen Upgrade Kit.
Connect the SkyScreens to the MKIV XP
Plug the first screen into the START plug located on the back of your timer, and the second
screen into the STOP plug. Switch the timer on, from “ TIMER COMMAND ” push the CHRN button.
The timer will switch to " CHRONO COMMAND " and display the current screen separation on the
bottom line of the display. If you need to adjust the screen separation, you can do so now. The
default is 18" which is what our new M7 Skyscreen System is set to.
NOTE : Older PACT screens will have 24" separation. To set a different screen separation, just push
the SET key and enter your separation in inches then press SET again.
Record Shots
Push the GO button, the timer will display " Chronograph mode running ". Fire a round over your
Skyscreens. The display should say something like this:
8
#001
856.2 FPS
AV
856.2 FPS
Each time you fire, the shot number and velocity of your last shot will appear on the top line of
the display and your current average velocity will appear on the bottom.
Now let's say that an odd-ball velocity appears, like " 6952.3 FPS ". This is an obvious error. You
can remove it from memory by pushing the NO key. The MKIV XP will "back up" to the previous
shot.
NOTE : The MKIV XP needs one second between shots. This is to allow the smoke to clear. If you
fire too soon, the Chronograph will not record the shot.
When you are done with your string, the MKIV XP will provide you with a statistical summary of
your string. If you have a printer just push the PRNT key and you will receive a hard copy of you
string number, statistical summary and each shot. In addition, all chrono data is held in memory
for download to your PC.
Push REVIEW to review the desired string. If you want to look at the most recent string push
REVIEW again. The highest and lowest shot velocities and their corresponding shot numbers are
displayed.
HI #003
868.2 FPS
LO #007
823.5 FPS
Press REVIEW again. The Standard Deviation of your string is displayed in addition the SD is
displayed as a percent of your average velocity (coefficient of variation).
SD
45.8 FPS
CV
5.99%
9
Push REVIEW again. The MKIV XP calculates the Mean Absolute Deviation (average variation) of
your string and once again displays it as a percent of your average velocity. This number is the
key to measuring and comparing the velocity variations in your loads. The load illustrated varies
an average of 5.02%. This is the number that should be used to compare one load to another.
The smaller the better.
MAD
38.4
CV
5.02%
One more time, press REVIEW . " ES " stands for Extreme Spread which is the difference between
the high and low shot velocities. " AVRG " is obviously the average velocity of you string. At this
point you can continue to press the review key and review each shot. The “ FIND SHOT " function
is identical to counterpart in timer mode.
ES
105.9 FPS
AVRG
763.8 FPS
You can EDIT out individual bad shots with the NO button during review. The MKIV XP will
recalculate your statistical summary less the edited shots.
When you are done reviewing your data, you can push the GO button and the timer will clear its
memory an you can start another string. Also, you can push CST GO (Comstock Go) and add
more shots to the existing database.
NOTE : If you don't want to mess around with all the review functions, you can start a fresh string
by pushing GO at any time.
10
Automatic Power Factoring (APF):
With CHRONO COMMAND displayed on the screen push the PAR button. The timer will ask you
to “ ENTER BULLET WEIGHT AND PUSH SET ”. Push 2, 0, 0 , SET . Now press the GO button and
chronograph a shot.
ES
105.9 FPS
AVRG
763.8 FPS
Remember that the power factor for the individual shot is displayed, not the average.
4
Ballistic Computer (TRAJ)
The Ballistic Calculator is so easy to use that you really don't need much explanation. It does
however, have some trick features that may not be apparent on the first pass.
Use Chrono Data:
From “ TIMER COMMAND ” press TRAJ . The first thing the Ballistic Computer needs to know is
the velocity to base the calculation on. If you're shooting at the range it will pick up the current
average velocity (which you can override) from the chronograph. If none is present in memory it
will default to 2500.0 FPS .
Enter a Velocity Manually:
If you want to change the default , stay away from the SET key and first tell the machine what it
needs to know. For example, if you want the machine to use “2650 FPS” for its calculation just
type “ 2650 ”. If you make a mistake entering a number just use the back arrow key then GO to
erase it. When the number entered is ok with you hit SET and the Ballistic Calculator will accept it
and move to the next screen.
11
NOTE: Yes/No questions are answered with the YES and NO keys. No SET is required. Also, Any
time you are messing around with the Ballistic Calculator and you realize you've painted yourself
into a corner hit (gently now) the NO button until you exit the mode. This will take you out of the
Ballistic Calculator. Then hit TRAJ again and it will let you start from the beginning with the last
things you entered as the defaults.
EXAMPLE: Make a trajectory printout
If you haven't already pressed the TRAJ do so now so that the screen shows:
ENTER VELOCITY: 2500.0
Let's change the velocity to 2650 and press SET . The Ballistic Calculator will now ask you
for the Ballistic Coefficient (BC) . This is always a decimal number but the Ballistic
Calculator is smart enough to add the decimal if you forget it. Enter a BC of .475 and
press SET .
NOTE : The Ballistic Calculator will only produce correct results with “C1” ballistic
coefficients. This is the industry standard and is what you will find in every bullet
manufactures current specifications even if they don't label it as “C1”
Enter Conditions:
Next the Ballistic Calculator asks you if you want it to use Standard (sea level, 59
degrees) or Nonstandard conditions. Tell it YES to accept the standard conditions. If you
answer NO it will ask you for altitude and temperature information. Based on the data the
Ballistic Calculator will correct the BC to your nonstandard conditions.
12
Enter Sight Height:
Sight height if the distance from the center of the bore to the center of you sight. If you're
just playing around, use the default of 1.5" . However if your making a "for real" field drop
card do it right and measure the thing (a pain in the back side). If you're using an iron
sight gun (particularly handguns) don't use the 1.5" number at all. It's so far from your
gun that the resultant trajectory data will be pretty bad.
Maximum Point Blank Range:
The Ballistic Calculator now has all the data it needs for the trajectory calculation. You'll
now need to tell the Ballistic Calculator what sort of zero you want. If you select the MAX
PB RANGE the Ballistic Calculator will find the maximum range at which you can fire the
gun without the bullet traveling more than so many inches above or below the line of
sight.
This option is strongly recommended for field marksman (hunters and warriors). The
default value is a six inch "vital zone." This means that you'll end up with a zero that
keeps the bullet within an imaginary six inch tube (three inches above to three inches
below the line of sight) from the muzzle to the maximum "point blank" range. The
Ballistic Calculator will tell you where to zero at 100 yards for this and print a drop table
according to that zero.
Specific Range:
The second option of SPECIFIC RANGE is of use to target shooters. If your local range
only goes to 100 yards but your competition is at 500 yards you can have the Ballistic
Calculator figure out where to set your gun at 100 to be dead on at 500. Again it will print
you a drop table based on that zero. One neat trick we added to this zero option is the
ability to offset the zero. Normally when the Ballistic Calculator asks you if you want an
13
offset you'd just hit SET to accept the zero default. However, if you've got a gun in the
safe that you have already zeroed two inches high at 100 you can use this feature to
back into a drop table that puts the bullet two inches high at 100. The offset option will
add about 20 seconds to the drop calculation. It is, however, quite a bit faster than
rezeroing your gun.
The next three questions (starting range ending range and increment) are self
explanatory. You'll probably find yourself hitting the SET key three times to accept each
default. The final question is whether or not you want the Ballistic Calculator to print to
the screen or paper. If you opt for a paper print out the MKIV XP will go on automatic
from here giving you a print out based on your parameters. If you want to print to the
screen you'll use the SET button to advance from screen to screen. To make another print
out just push TRAJ again. All of the parameters you used on the last print out will appear
as defaults (assuming you did not turn the machine off) speeding data entry.
5
Additional Functions
Send Shot Data to PC:
“Send To PC” is the first question asked under the OPTN button. It will activate the USB port on
the back of the unit. In order to utilize this feature you must do the following:
1. Download and install the MKIV XP Shot Browser Software - http://bit.ly/2qNV30D
2. Plugin the MKIV XP to your computer’s Serial Port (Don’t have a serial port? You can
purchase a serial to USB cord on Amazon - https://amzn.to/2HDECOQ )
3. Open the program (If you are using anything newer than Windows XP you’ll need to open
the program in Windows Compatibility Mode - http://bit.ly/2HgDtxl )
4. Send data to the PC using the instructions on the program.
5. You’ll then see options to retrieve stored Timer , Chrono and Rate OF Fire data to your PC
and save it for review with a spreadsheet or word processor.
14
Clear the Memory:
In short, to clear your MKIV XP memory, you’ll turn on the unit and cycle through the options the
SET / MENU button provides until you get to “ Delete ALL Strings? (N) ”. At that point you’ll press
PRNT / YES to clear it and then finish cycling through the options. You’ll need to do this for the
Timer and Chronograph mode to clear the full memory.
6
Chronograph Troubleshooting (RPM)
Accuracy and Tolerance Recommendation:
Having worked with dozens of chronographs, we strongly recommend to give yourself some
leeway on the velocity of your match ammo. In other words, if you need 850 FPS to make Major,
don't load 851 and think you are safe. The problem is not inaccuracies of the chronograph, but
rather the variation in the performance of ammo due to weather conditions. We recommend
that you give yourself at least a 25 fps cushion, 50 fps would be better.
The skyscreens just eat batteries, such are the laws of physics. Whenever the screens are
plugged in the Chronograph detection circuit is on. When you are done chronographing, unplug
the screens.
Troubleshooting:
Many light sensitive chronographs have a reputation for being flaky under certain light
conditions. We have gone to great lengths to minimize this problem on the new XP series, but
you will still occasionally run into a combination of conditions that may make it hard for your
chrono to read. It will help if you develop an understanding of how your chronograph works.
Your MKIV XP is looking for a decrease in light level when the bullet passes over the screen.
Assuming that enough light was entering the screen to begin with, your MKIV XP will always get
15
an accurate reading. If, on the other hand, the light level increases as the bullet crosses the
skyscreen, you will probably get no reading at all.
If you find that your MKIV XP is having trouble getting readings on a sunny day with a dark blue
sky you should try shooting lower over the skyscreens. You may eliminate the problem by
changing the light conditions just a bit by tilting your Skyscreens or changing the direction of the
sun. You will find the MKIV XP will operate in very low light conditions, but a some point there
will not be enough light to see the bullet.
Muzzle Blast:
When you fire a supersonic round the bullet gets to the skyscreen before the blast does. Keep
the muzzle a 5-10 ft. back from the first skyscreen to keep from beating it up. Remember that
the farther your screens are from the muzzle the lower the velocity your chronograph will read
(the bullet starts slowing down as soon as it leaves the barrel).
If you ever have a problem with your MKIV XP that you can't resolve please don't suffer in
silence! Go to our support section of our website at https://pact.com or shoot us an email to
WARNING : Shooting is dangerous. It is up to you to conduct yourself in a safe manner at
all times following established procedures as outlined by Firearms and Ammunition
manufacturers. Failing to do so may result in the death or severe injury of yourself and
others, as well as earning you a place in the Darwin Awards.
DON'T BE A DUMB ASS!
ALWAYS WEAR EYE PROTECTION!
GOOD LUCK AND GOOD SHOOTING!
16
Table of contents
Other Pact Timer manuals
