QUICK START GUIDE
RE-1/RE-2 Router
Enterprise-Class, Audio/Video Router
Version 1.0

pakedgedevice&software inc
Contents
Overview.............................................................................................................................................................3
Package Contents ...........................................................................................................................................4
Installing the Router.......................................................................................................................................5
Changing the Router Password.................................................................................................................5
Accessing the Router GUI............................................................................................................................5
Connecting to the Internet..........................................................................................................................5
Changin the LAN IP........................................................................................................................................9
Troubleshooting and Support................................................................................................................. 10

pakedgedevice&software inc
Overview
The RE-1 and RE-2 are enterprise grade audio/video routers that are designed to minimize
installation times through an intuitive GUI. See the Table 1 below for more information. Table
1’s description of the LED’s applies to both the RE-1 and RE-2.
Table 1: LED Explanation (From Left to Right)
*Note: Port number 2 can be congured as a second wan port and Port number 5 can be congured as
a Guest network. Please see the user’s manual for additional information.
LED Status Operaon
Power
Blue The router is powered on
O The router is turned o
LAN (Ports 2-5) LINK/ACT
Blue Port is online (link established)
Flashing Blue Acvity
O No device connected
WAN2 (Port 2) LINK/ACT
Blue Port is online (link established)
Flashing Blue Acvity
O No device connected
WAN1 LINK/ACT
Blue Port is online (link established)
Flashing Blue Acvity
O No device connected

pakedgedevice&software inc
Below you will nd a description of the interfaces on the back of the RE-1 and RE-2 in Table 2.
Table 2: Interface Explanation (From Left to Right)
*The USB 1 interface can also be used for le sharing, but will be limited to the slower USB 2.0 speeds
Table 3 illustrates some of the similarities and dierences between the RE-1 and RE-2.
Table 3: RE-1 vs RE-2
Package Contents
RE-Router
Mounting Brackets
Power Cable
6ft CAT5E Cable
Quick Start Guide
Interface Type Speed Protocol Descripon
AC Power input AC N/A N/A Power Input
Power Switch N/A N/A N/A On/O Power Switch
WAN RJ-45 10/100/1000
Mbps Ethernet WAN port used for the internet connecon from the ISP
LAN (Ports 2-5) RJ-45 10/100/1000
Mbps Ethernet 4-port switch connecons on the internal network
USB 1 USB-A 480Mbps USB 2.0 Management USB port
USB 2 USB-A 5Gbps USB 3.0 USB port used for le sharing
Feature RE-1 RE-2
UPnP Yes Yes
VLAN Capable No Yes
VPN Support Yes Yes
File Browser No Yes

pakedgedevice&software inc
Installing the Router
1. If mounting the router in a standard 19” AV rack, attach the rack-mounting
brackets that come with the router to the sides. If not rack-mounting, ensure that
the router is physically mounted near power and network connections.
2. Connect power to the device.
3. Connect an ethernet cable from your computer to any of the LAN ports on the
router.
Changing the Router Password
It is strongly recommended that you change the default password for the router. Please refer
to the user manual for step by step instructions.
Accessing the Router GUI
1. Make sure your network card is set to obtain an IP address automatically. Then open
any internet browser and go to the address http://192.168.1.99 or you can simply type
pakedgerouter.com Note: For best results we recommend using Mozilla Firefox as your
web browser.
2. Enter the default username pakedge and the password pakedger. Click login.
Connecting to the Internet
The router supports the three main types of internet connections:
• DHCP (Typically used by cable companies and DSL basic service)
• Static IP (Fixed public IP address mostly used by Business Class Broadband services)
• PPPoE (Used by DSL companies such as AT&T)
Determine what type of internet connection you have from your Internet Service Provider
(ISP), and then follow one of the three instruction sets below to connect the router to the
internet.

pakedgedevice&software inc
DHCP:
By default, the router will connect to the internet using DHCP. If your ISP uses DHCP, you may
need to reset the modem to get internet access. If you are using a modem that has a router
built into it, you may have to congure DMZ settings to allow complete functionality of the
RE-1/RE-2.
Static IP:
To congure the router to a static IP, complete the following steps:
1. Hover your mouse towards the top of page to see the menu. Click on Network Zones.
2. Click on Edit under WAN zone.

pakedgedevice&software inc
3. Select Static Address for the Protocol.
4. Click on Switch Protocol.
5. Enter the IP address from your ISP. Select the appropriate Subnet Mask from your
ISP. You can select custom to enter a custom subnet mask. Then enter your Default
Gateway and DNS Server. Leave the override MAC address at default. Click Apply.
The router now has the Static IP congured on it.

pakedgedevice&software inc
PPPoE:
To congure the router using a PPPoE connection, you will need to complete the following
steps:
1. Hover your mouse towards the top of page to see the menu. Click on Network Zones.
2. Click on Edit under WAN zone.
3. Select PPPoE from the Protocol drop down menu. Then click on Switch Protocol.

pakedgedevice&software inc
4. Enter the username that the ISP assigned under the PAP/CHAP username eld. Enter
the password in the PAP/CHAP password eld. Click Apply when nished. The router
is now setup for PPPoE.
Changing the LAN IP
The default IP address of the router is 192.168.1.99. If you need to change the IP address of
the router or change the entire network address take the following steps.
1. Click on Network Zones.
2. Click Edit under LAN zone.

pakedgedevice&software inc
3. Enter the new IP address you wish to use in the IP Address eld. In the following
example we change the IP address of the router to 192.168.1.1.
4. Click Apply towards the bottom to nalize the settings.
Troubleshooting and Support
If you are unable to get the router functional using these steps, you can refer to the full
manual on our website or contact the Technical Support Team for assistance.
Contact information
Website: www.pakedge.com
Email: [e-mail]
Phone: [phone]
