Palm Treo Treo 750 User manual

Getting Started Guide
Palm® Treo™ 750 smart device

Treo 750 i
Table of Contents
Welcome to AT&T 1
Overview: Your Palm®Treo™ 750 smart device 1
Take advantage of fast broadband speeds 2
Setup 3
Insert the battery 3
Complete setup 4
Navigation 5
Wake up the touchscreen and turn it off 5
Move around the touchscreen 6
Use the keyboard 8
Open, leave, and close applications 10
Your Today screen 11
Your phone 12
Turn your phone on and off 12
Make and receive calls 13
Set up voicemail 14
What can I do when I’m on a call? 15
Your web browser and email 16
Browse the web 16
Choose the best email option 17
Set up personal email 17
Set up corporate email 21
Create and send an email message 27

ii Treo 750
Synchronization 28
Why synchronize information? 28
Synchronize for the first time 28
Your Contacts, Calendar, and Messages 30
Contacts 30
Calendar 32
Messaging 33
Your music 35
Transfer music 35
Play music 36
Troubleshooting 38
Tips and Tricks 41
Keyboard 41
Phone 41
Data 42
Typing 42
Browser 43
Navigation 43
General 43
Status indicators 44

Treo 750 1
Welcome to AT&T
Overview: Your Palm®Treo™ 750 smart device
Indicator light (visible
when your Treo 750 is
being charged)
Multi-connector
5-way navigator and
Center button
Earpiece
OK
Microphone
Headset jack
Start
Phone/Send
Side button
Power/End
Volume
Left action key
Right action key
Stylus
Ringer switch
Stylus
Infrared (IR) port (side)
Car kit jack

2Treo 750
Take advantage of fast broadband speeds
You must have a 3G SIM card in your Palm®Treo™ 750 smart device to take
advantage of fast broadband speeds. To determine if you have a 3G SIM
card, look for “3G” to the left of the gold connector on the back of the
card.
If you do not have a 3G SIM card, please visit your local AT&T retail store to
swap your existing SIM card for a 3G SIM card. There is no charge for
exchanging your SIM card for a 3G SIM card.
Tip
Your phone won’t
work without a SIM
card. The SIM card is
usually preinstalled
in your Treo 750,
unless you’re
upgrading from
another AT&T
phone. Check to
see if the SIM card is
installed. It’s
located in a cutout
in the lower-right
corner of the
battery
compartment. See
"I need to insert my
SIM card" on page
38 for more
information.
If you need a SIM
card, call AT&T
customer care at
1-800-331-0500.
Camera lens
(camera version
only)
Battery door
release
Speaker
Self-portrait mirror
Infrared (IR) port
Expansion card
(miniSD) slot
Reset button (located
behind expansion
card slot door)
Press battery door
release
Notch

Treo 750 3
Setup
Insert the battery
1. Remove the battery door.
2. Insert the battery into the compartment.
3. Slide the battery door back into place.
4. Connect the charger.
The touchscreen on your Palm®Treo™ 750 smart device turns on. Wait for
the progress bar to fill and the Windows Mobile®screen to appear.
Press battery
door release
Align battery
contacts with
Treo 750
contacts

4Treo 750
Complete setup
1. When prompted, tap anywhere on the
screen to begin setup.
2. Tap the onscreen targets to align the
touchscreen, and then press Next
(right action key).
3. On the network time screen, leave the
boxes checked if you want your Treo 750 to
obtain the date, time, and time zone from
the local network. Uncheck the boxes if you
want to enter this information manually.
Press Next (right action key).
4. Read about about four important
features of your Treo 750. Press Next
(right action key) to go to each screen.
5. After you complete setup, we
recommend that you review the first two
sections of the Quick Tour. Press Start ,
select Programs, and then select Quick
Tour .
Note: If your Treo 750 doesn’t turn on after you charge it, do a soft reset by
pressing the Reset button behind the expansion card slot door with the tip of the
stylus. For more information on resetting your Treo 750, see your Treo 750 User
Guide on the Windows Mobile Getting Started CD.
Tip
You need a high-
speed data plan for
email, multimedia
messaging, and
web browsing. Find
out if you have a
plan by checking
your bill or calling
AT&T: dial 611 from
your Treo 750 or
1-800-331-0500
from any phone.
Tip
Need help setting
up your Treo 750?
Call the Palm Setup
Help desk for AT&T
customers at
1-800-331-0500.

Treo 750 5
Navigation
Wake up the touchscreen and turn it off
The phone and the touchscreen of your Palm®Treo™ 750 smart device can
be turned off and on separately. When you wake up the touchscreen and
leave the phone off you can use only the organizer features—for example,
when you’re on a plane and want to look at your calendar, play MP3 files, or
write email offline.
If you’re taking your Treo 750 out of the box and turning it on for the first
time, the phone is already on. You just need to wake up the touchscreen.
1. Press and release Power/
End to wake up the
touchscreen.
2. Press Center to turn
off Keyguard.
3. Press and release Power/
End to turn off the
touchscreen and lock the
keyboard.
Tip
How can you tell if
your phone is on?
Look in the upper-
left corner of the
Today screen, just
under the Microsoft
logo. If you see
“AT&T,” you r phone
is on.
Power/End
Center

6Treo 750
Move around the touchscreen
To move around the touchscreen on your Treo 750, you can use the 5-way
navigator, or you can tap items on the screen with the stylus. The 5-way
includes the following buttons:
Highlight and select items
The highlight identifies which item is affected by your next action. Use
Left , Right , Up , and Down on the 5-way to move the highlight
from one item to another. The highlight can take two forms: a border
around an onscreen button, a check box, an option, or a web link; or light
text on a dark background.
Did You Know?
On most screens,
one item—a button,
a list entry, or a
check box—is
highlighted by
default.
Tip
If the item you want
doesn’t appear on
the touchscreen, try
tapping the
onscreen scroll
arrows to view
more information.
Up
Down
Left Right
Center

Treo 750 7
After highlighting an item, you can select (activate) it by pressing Center
or by tapping the item with the stylus.
Select menu items
Many applications have menus that give you access to additional features.
These menus are usually hidden from view, but they appear when you press
Menu (right action key).
1. Press Menu (right action key) to
display an application’s menu.
2. Press Up or Down to highlight a menu
item.
3. If an arrow appears next to a menu item,
press Center or Right to display
additional items on a submenu, and then press
Up or Down to highlight a submenu item.
To return to the main menu without making a
selection, press Left .
4. Press Center to select the highlighted menu item, or press Left or
Menu (right action key) to close the menu and cancel your selection.
Tip
You can select most
menu items by
pressing a key on
the keyboard. To
quickly access a
menu item, press
Menu (right action
key) followed by the
underlined letter in
the menu item’s
name.

8Treo 750
Use the keyboard
Enter lowercase and uppercase letters
•To enter a lowercase letter, press the key you want.
•To enter an uppercase letter, press Shift ( or ), and then press a
letter key. You don’t need to press and hold Shift while entering the
letter.
•To turn Caps Lock on, press Shift ( or ) twice. The following
symbol appears: . To turn it off, press Shift ( or ) once.
Left
action key Right
action key
Phone/Send
Start
Power/End
Backspace
Option
Shift/Search
Return
Shift
OK

Treo 750 9
Enter numbers, punctuation, and symbols
Numbers, punctuation, and symbols appear above
the letters on the keys. To enter these characters,
do one of the following:
•Press Option , and then press the key with
the character. You don’t need to hold Option while pressing the key.
•To turn Option Lock on, press Option twice. The following symbol
appears: . To turn it off, press Option once.
Enter more symbols and accented characters
When entering text, you can press Alt to access additional symbols and
accented characters.
1. Press Alt to display the alternate character list.
2. Narrow the list by pressing the key that corresponds to the character you
want. For example, to enter an é, press E.
3. Highlight the desired character and press Center to insert the
character.
Note: To enter characters such as _ • \ % = :, press Alt by itself and select the
character from the list.
See the User Guide for a table of alternate characters.
Tip
You can also open
the onscreen
keyboard to enter
letters, numbers,
and other
characters in
applications that
support this feature.
Tap the keyboard
icon in the center at
the bottom of any
screen where it
appears. After
opening the
keyboard, you can
set various input
options by tapping
the arrow to the
right of the
keyboard icon.
Letter
Symbol

10 Treo 750
Open, leave, and close applications
Press Start to open an application
1. Press Start to open the Start
menu.
2. Use the 5-way to highlight an
application, and then press Center
to open it.
Press OK to leave an application
Press OK to leave one application
and go to another.
Note: The application you left stays open
in the background.
Press and hold OK to close an application
Applications stay open in the background (using memory and possibly
slowing you down) unless you specifically close them.
1. Press and hold OK to open Memory Settings.
2. On the Running Programs tab, do one of the following:
•Select the application to close, and then select Stop to close it.
•Select Stop All to close all open applications.
Tip
To see all your
available
applications, select
Programs from the
Start menu.
Tip
In Programs, press a
letter to jump to the
first application
that begins with
that letter. For
example, press Cto
jump to Calculator.
Press Cagain to
jump to Camera,
and so on.
Select to see all
applications

Treo 750 11
Your Today screen
From your Today screen you can quickly look up a contact, make a call, see
your latest calendar appointments, see the number of unread email
messages, and even perform a web search. To access your Today screen,
press Phone/Send .
Title bar and status info: See the User Guide to learn about the icons that
appear in this area.
Dial Lookup field: Type the number you want to call and press Center
to dial, or begin typing a name to look up the associated number in Contacts.
See "Dial by contact name" on page 31 for more information.
Speed-dial entries: Select a speed-dial button—either a picture or text—to
call the number assigned to it. See the User Guide to learn how to create
your own.
Web search field: Enter a web address or a keyword and press Center
or Return to view a list of search results based on the address or word
(data services connection required).
Tip
You can also open
the Today screen by
pressing Power/
End, unless you are
on a call. If you’re
on a call, pressing
Power/End hangs
up the call. If the
Today screen is
already displayed
and you’re not on a
call, pressing
Power/End turns
off the screen
display.
Tip
You can select a
picture for your
Today screen
background and
select which items
appear in the Today
screen. See the
User Guide for
details.
Title bar and
status info
Dial Lookup field
Speed-dial
entries
Scroll to view Web
search field

12 Treo 750
Your phone
Turn your phone on and off
When your phone is on, it is connected to the AT&T network (provided
you’re in a coverage area) so that you can make and receive phone calls
and use wireless services, such as email, messaging, and the web browser.
During initial setup, your phone is automatically turned on, so you can use
wireless services right away. If you turn off your phone, you can still use
the organizer and media features such as Calendar and Pictures & Videos.
1. Wake up the touchscreen.
2. Press Phone/Send to display the
Today screen.
3. Press and hold Power/End to turn on
your phone.
You know your phone is on and that you’re
inside a coverage area when you see the
signal-strength icon at the top of the
Today screen.
Note: If you’re prompted for a PIN code, your SIM
card is locked. If you don’t know your PIN code, ask AT&T to provide you with the
PIN code.
4. Press and hold Power/End again to turn off your phone.
You know your phone is off when the signal-strength icon displays .
Tip
To turn on the
phone from any
screen, tap the
signal-strength
icon and then
select Phone.
Tip
To find your phone
number, make sure
your phone is on
and go to the Today
screen. Press Menu
(right action key)
and select
Preferences >
Phone Settings. On
the Phone tab, look
for your phone
number below the
title bar.
Status icons

Treo 750 13
Make and receive calls
To make and receive calls, your phone must be on. When your phone is off,
your incoming calls go to voicemail.
Dial using the keyboard
1. Press Phone/Send to display your Today screen.
2. If prompted, press Center to turn
off Keyguard.
3. Use the numbers on the keyboard to
enter the number you want to call.
4. Press Phone/Send to dial.
When dialing short numbers, the number
may conflict with a contact name. If this
occurs, press Option to avoid starting a
contact lookup. For emergencies, you can always dial 911 without pressing
Option first.
5. Press Power/End to end a call.
Answer calls
To answer a call, press Phone/Send or press Answer (left action
key).
Important:
Don’t use a slash
(/) when
entering phone
numbers on your
computer. For
example, do not
enter 415/555-
5555. Your
Palm®Treo™ 750
smart device
does not
recognize the
slash in phone
numbers that
are transferred
from your
computer, and
you cannot
select numbers
written like this
to make a call.

14 Treo 750
Ignore calls
To ignore a call , do one of the following:
Send the call to voicemail: Press Power/End , or press Menu
(right action key) and select Ignore.
Send the caller a text message: Press Menu (right action key)
and select Ignore with text message. This option sends the call to
voicemail and opens a text message addressed to the caller. (Sending text
messages to land-line phones may not be supported.)
Silence the ringer
To silence the ringer while your phone is ringing, do one of the following:
•Press the Volume button or any of the letter keys.
•Slide the Ringer switch to Sound Off .
Set up voicemail
1. Go to your Today screen.
2. Press and hold 1on the keyboard or select the Voicemail speed-dial
button.
3. Follow the voice prompts to set up your voicemail.
To retrieve voicemail, go to your Today screen and then press and hold 1
on the keyboard. Enter your voicemail password if prompted, and then
follow the voice prompts to listen to your messages.
Did You Know?
If a headset is
attached, you can
press the headset
button to answer a
call and end a call.
(The headset
button may work
differently on
headsets other
than the one
provided with your
Treo 750.)
Tip
If you can’t connect
to the AT&T
voicemail system,
contact AT&T for
assistance: Dial 611
from your Treo 750
or call
1-800-331-0500
from any phone.

Treo 750 15
What can I do when I’m on a call?
During a call, you can work with information in other applications on your
Treo 750, as well as do any of the following:
Navigate around the Today screen: Use Up and Down to move
around or highlight items.
Put the call on hold: Press Hold (left action key). To take the call off
hold, press Off Hold (left action key).
Use the built-in speakerphone: Select Speakerphone . The button
turns gray when the speakerphone is on. To turn the speakerphone off, select
Speakerphone again.
Mute the microphone so you can’t be heard: Select Mute . The button
turns gray when the microphone is muted. To turn the microphone back on,
select Mute again.
Switch to another application: Press Start and select the application
so you can work with information there.
Tip
While a call is in
progress, press the
Volume button on
the side of your
Treo 750 to adjust
the call volume.
Tip
When you’re dialing
a phone number,
you don’t need to
press Option to
type numbers or
the * and # symbols.
Current duration of
call
Caller’s name and
number
Icons look like this when mute
and speakerphone are not on

16 Treo 750
Your web browser and email
Browse the web
Before You Begin: You must have a data plan on your AT&T account to
browse the web on your Palm®Treo™ 750 smart device.
1. Press Start and select Internet
Explorer.
2. Highlight the address line, enter the
address of the web page you want to view,
and then press Center . To return to a
recently viewed page, select the address line
list, and then select the web address.
3. Here are some tips on viewing web pages
and moving around in them:
•To view the previous page, press Back (left action key) or
Backspace .
•To refresh the page, press Menu (right action key) and select
Refresh.
•To scroll through the page, press Up or Down .
4. When you have finished browsing, press OK to close the browser
window.
Did You Know?
You can also start a
web search from
your Today screen
by selecting the
Web search field,
entering the item
you want to find,
and then pressing
Center on the
5-way navigator.
Tip
To adjust the size of
the text on web
pages, press Menu
(right action key),
select View >Text
Size, and then
select the size you
want.

Treo 750 17
Choose the best email option
Before You Begin: You must have a data plan with AT&T to use email on your
Treo 750.
You can use your Treo 750 to access email from both personal and corporate
email accounts.
•A personal email account is an account with an Internet service provider
(ISP) such as Yahoo!, AOL, or Comcast.
•A corporate email account is an account on a corporate mail server such
as a Microsoft Exchange or Lotus Domino server.
Set up personal email
You have the following options for setting up a personal email account on
your Treo 750:
Xpress Mail Xpress Mail allows you to access a personal email account
with a simple setup process; email for this account is then automatically sent
to your Treo 750.
We recommend using Xpress Mail for your personal email account because it
offers automated setup and includes features such as email synchronization.
Any changes made to email on your Treo 750 such as message deletions are
automatically updated in your email account.
Inbox You can use the Inbox application to enter settings for up to five
personal email accounts. For setup instructions, see "Set up Inbox to work
with a personal email account: Common email providers" on page 19.
Key Term
Email provider
The service you use
to send and receive
email. Your email
provider’s name
appears between
the @ symbol and
the dot in your
email address.
