Panasonic CS-A9DKA User manual

1 Features 2
2 Functions 3
2.1. Remote Control 3
2.2. Indoor Unit 4
2.3. Outdoor Unit 5
3 Product Specifications 6
3.1. CS-A9DKA CU-A9DKA 6
3.2. CS-A12DKA CU-A12DKA 8
4 Dimensions 10
4.1. Indoor Unit & Remote Control 10
© 2005 Panasonic HA Air-Conditioning (M) Sdn Bhd
(11969-T). All rights reserved. Unauthorized copying
and distribution is a violation of law.
CS-A9DKA CU-A9DKA
CS-A12DKA CU-A12DKA
4.2. Outdoor Unit 11
5 Refrigeration Cycle Diagram 12
6 Block Diagram 13
7 Wiring Diagram 15
8 Operation Details 17
8.1. Heating Operation 17
8.2. Cooling Operation 18
8.3. Soft Dry Operation 19
8.4. Automatic Operation 20
Air Conditioner
CONTENTS
Page Page
Order No. MAC0501024C3

8.5. Operation Control 21
8.6. Indoor Fan Speed Control 28
8.7. Outdoor Fan Speed Control 30
8.8. Vertical Airflow Direction Control 30
8.9. Horizontal Airflow Direction Control 31
8.10. Powerful Operation 31
8.11. Quiet Operation 33
8.12. Ionizer Operation 35
8.13. Timer Control 36
8.14. Random Auto Restart Control 36
8.15. Remote Control Signal Receiving Sound 36
9 Operating Instructions 37
10 Installation Instructions 43
10.1. Safety Precautions 43
10.2. Attached accessories 45
10.3. Select the best location 45
10.4. Indoor/Outdoor Unit Installation Diagram 45
10.5. Indoor unit 46
10.6. Outdoor unit 49
11 2-way, 3-way Valve 53
11.1. Air Purging of the Piping and Indoor Unit 54
12 Servicing Information 60
12.1. Distinction Of Lead Free (PbF) Printed Circuit Board 60
12.2. Indoor Electronic Controllers Removal Procedures 60
12.3. Indoor Fan Motor And Cross Flow Fan Removal
Procedures 61
• High Efficiency
• Compact Design
• Wider range of horizontal discharge air.
• Air Filter with function to reduce dust and smoke.
• Automatic air swing and manual adjusted by Remote
Control for vertical airflow.
• Long installation piping.
− CS/CU-A9DK, long piping up to 10 meter.
− CS/CU-A12DK, long piping up to 15 meter.
• Supersonic Air Purifying Device with SUPER alleru-
buster.
− Inactive various harmful airborne elements including
allergen, viruses and bacteria.
− Generated supersonic waves enhance the ability to
collect dust and dirt in the air.
12.4. Auto OFF/ON Button 62
12.5. Remote Control Reset 63
13 Troubleshooting Guide 64
13.1. Refrigeration Cycle System 64
13.2. Relationship Between The Condition Of The Air
Conditioner And Pressure And Electric Current 65
13.3. Diagnosis Methods Of A Malfunction Of A Compressor
And 4-way Valve 65
14 Technical Data 66
14.1. Thermostat Characteristics 66
14.2. Operation Characteristics 67
15 Exploded View (Indoor Unit) 69
15.1. CS-A9DKA CS-A12DKA 69
16 Replacement Parts List (Indoor Unit) 70
17 Exploded View (Outdoor Unit) 71
17.1. CU-A9DKA 71
17.2. CU-A12DKA 72
18 Replacement Parts List (Outdoor Unit) 73
19 Electronic Circuit Diagram 75
19.1. Indoor Unit & Outdoor Unit 75
19.2. Remote Control 81
19.3. Print Pattern Indoor Unit Printed Circuit Board 82
19.4. Print Pattern Indicator & Receiver Printed Circuit Board
84
• Quality Improvement
− Random auto restart after power failure for safety restart
operation.
− Gas leakage protection.
− Prevent Compressor reverse cycle.
− Inner protector to protect Compressor.
− Noise prevention during soft dry operation.
− Blue Coated Condenser for high resistance to corrosion.
• Operation Improvement
− Quiet mode to provide quiet operation.
− Powerful mode to reach the desired room temperature
quickly.
− Ionizer control for generating negative ion in discharge
air.
− 24-hour timer setting.
• Serviceability Improvement
− Removable and washable Front Panel.
1 Features
2
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

2 Functions
2.1. Remote Control
3
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

2.2. Indoor Unit
Automatic Operation Button
• Press for < 5 second to operate Automatic
operation mode. Used when the remote control
cannot be used.
• Press for ≥5 second to operate Cooling
operation mode and compressor force to on
(“beep” sound will heard). Used when test
running or servicing.
• Within 20 second of Cooling operation, press
continuously for 5 second to enter various
setting mode. “beep, beep” sound will be heard.
(Used to toggle remote control signal receiving
sound or select remote control transmission
code).
AUTO
OFF / ON
Operation Indication Lamps (LED)
7 Minutes Time Save Control
• To reduce the built up humidity inside the room.
Anti-Dew Formation Control
• Anti-Dew Formation Control for indoor unit
discharge area.
Timer Operation
• Delay OFF/ON Timer control.
Powerful Operation
• Reaches the desired room temperature quickly.
Anti-Freezing Control
• To prevent indoor heat exchanger from freezing.
Random Auto Restart Control
• Unit will be restarted, when resume from power
failure, at previous setting.
Indoor Fan Speed Control
• Manual control fan speed (High, Medium and
Low).
• Automatic fan speed.
• Vertical airflow control can be adjusted
automatically or manually by remote control.
• Horizontal airflow can be manually adjusted by
hand.
Airflow Direction Control
Time Delay Safety Control
• Restarting is inhibited for appro. 3 minutes.
Hot-Start Control
• To prevent cold air being discharge during
Heating operation starts.
Starting Current Control
• To reduce the starting current.
Anti Cold Draft Control
• To prevent the cold draft during Heating mode
operation in thermo off condition.
Operation Mode
• Heating, Cooling, Soft Dry and Automatic
Operation.
30 Minutes Time Save Control
• Heating operation only.
Quiet Operation
• To provide quiet operation.
Ionizer Operation
• Generate and discharge negative ion.
• POWER (Green) ............. Lights up in operation,
blinks in Automatic
Operation judging and
Hot Start operation.
• TIMER (Orange) ............ Lights up in Timer
Setting.
• QUIET (Orange) ............. Lights up in Quiet
Operation.
• POWERFUL (Orange) ...... Lights up in Powerful
Operation.
• ION (Green) .................. Lights up in Ionizer
Operation.
• SUPER
ALLERU-BUSTER
(Blue) ... Lights up in operation.
4
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

2.3. Outdoor Unit
5
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

3 Product Specifications
3.1. CS-A9DKA CU-A9DKA
Unit Indoor Unit Outdoor Unit
Power Source (Phase, Voltage, Cycle) ø, V, Hz Single, 220, 50
Cooling Capacity kW (BTU/h) 2.65 (9,040)
Heating Capacity kW (BTU/h) 2.80 (9,550)
Moisture Removal l/h (Pint/h) 1.6 (3.4)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m3/min (cfm) Cooling; 5.8 (204)
Heating; 6.2 (220)
—
Me m3/min (cfm) Cooling; 7.1 (251)
Heating; 7.1 (251)
—
Hi m3/min (cfm) Cooling; 8.6 (300)
Heating; 9.4 (330)
Cooling; 26.0 (920)
SHi m3/min (cfm) Cooling; 9.4 (333)
Heating; —
—
Noise Level dB (A) Cooling; High 36, Low 26
Heating; High 38, Low 28
Cooling; High 48
Heating; High 48
Power level dB Cooling; High 49
Heating; High 51
Cooling; High 63
Heating; High 64
Electrical Data Input Power kW Cooling; 0.80
Heating; 0.70
Running Current ACooling; 3.8
Heating; 3.3
EER W/W (BTU/hW) Cooling; 3.31 (11.3)
COP - (BTU/hW) Heating; 4.00 (13.6)
Starting Current A 18.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 3/8”
L ; Half Union 1/4”
G ; 3-way valve 3/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
G ; (gas side) 3/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm2) —
Dimensions Height inch (mm) 11 - 1/32 (280) 20 - 3/32 (510)
Width inch (mm) 31 - 15/32 (799) 25 - 19/32 (650)
Depth inch (mm) 7 - 7/32 (183) 9 - 1/16 (230)
Net Weight lb (kg) 20 (9.0) 60 (27)
Compressor Description —Rotary (1 cylinder)
rolling piston type
Motor Type —Induction (2-poles)
Rated Output W — 750
6
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

Unit Indoor Unit Outdoor Unit
Fan Motor Description Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Type Induction (4-poles) Induction (6-poles)
Input W 60.5 66 - 74.8
Rated Output W 15 30
Fan Speed Low rpm Cooling; 780
Heating; 840
—
Medium rpm Cooling; 960
Heating; 960
—
High rpm Cooling; 1,160
Heating; 1,270
800
SuperHigh rpm Cooling; 1,270
Heating; —
—
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×22
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 585.7
557.1
× 484 × 36.4
Refrigerant Control Device —Capillary Tube
Refrigeration Oil (cm3) — ATMOS M60 OR SUNISO 4GDID
Refrigerant (R22) g (oz) — 860 (30.4)
Thermostat — —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 1120, Heating; 315
Flow Rate l/min — Cooling; 10, Heating; 18.2
Inner Diameter mm — Cooling; 1.6, Heating; 1.6
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 370/400VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440VAC 2.0 µF, 440VAC
Note:
• Specifications are subjected to change without prior notice for further improvement.
7
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

3.2. CS-A12DKA CU-A12DKA
Unit Indoor Unit Outdoor Unit
Power Source (Phase, Voltage, Cycle) ø, V, Hz Single, 220 , 50
Cooling Capacity kW (BTU/h) 3.52 (12,000)
Heating Capacity kW (BTU/h) 3.90 (13,300 )
Moisture Removal l/h (Pint/h) 2.0 (4.2)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m3/min (cfm) Cooling; 6.7 (236)
Heating; 7.1 (251)
—
Me m3/min (cfm) Cooling; 8.3 (294)
Heating; 8.3 (293)
—
Hi m3/min (cfm) Cooling; 9.5 (340)
Heating; 9.7 (340)
Cooling; 32.5 (1,150)
SHi m3/min (cfm) Cooling; 9.7 (343)
Heating; —
—
Noise Level dB (A) Cooling; High 39, Low 29
Heating; High 40, Low 29
Cooling; High 48
Heating; High 48
Power level dB Cooling; High 52
Heating; High 53
Cooling; High 63
Heating; High 64
Electrical Data Input Power kW Cooling; 1.08
Heating; 1.07
Running Current ACooling; 5.1
Heating; 5.1
EER W/W (BTU/hW) Cooling; 3.26 (11.1)
COP W/W (BTU/hW) Heating; 3.64 (12.4)
Starting Current A 27.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm2) —
Dimensions Height inch (mm) 11 - 1/32 (280) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 7 - 7/32 (183) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 82 (37)
Compressor Description —Rotary (1 cylinder) rolling piston
type
Motor Type —Induction (2-poles)
Rated Output W — 950
8
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

Unit Indoor Unit Outdoor Unit
Fan Motor Description Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 60.5 71.5 - 80.3
Rated Output W 15 31
Fan Speed Low rpm Cooling; 900
Heating; 960
—
Medium rpm Cooling; 1,120
Heating; 1,120
—
High rpm Cooling; 1,280
Heating;1,310
800
SuperHigh rpm Cooling; 1,310
Heating; —
—
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×24
FPI 21 17
Size (W × H × L) mm 610 × 315 × 25.4 720 × 504 × 18.9
Refrigerant Control Device —Capillary Tube
Refrigeration Oil (cm3) — ATMOS M0 OR SUNISO 4GDID
Refrigerant (R-22) g (oz) — 1,080 (38.1)
Thermostat — —
Protection Device — —
Capillary Tube Length mm — Cooling; 630, Heating; 455
Flow Rate l/min — Cooling; 6.5, Heating; 13.6
Inner Diameter mm — Cooling; 1.2 Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 35 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 440VAC 2.0 µF, 440VAC
Note:
• Specifications are subjected to change without prior notice for further improvement.
9
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

4 Dimensions
4.1. Indoor Unit & Remote Control
10
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

4.2. Outdoor Unit
4.2.1. CU-A9DKA
4.2.2. CU-A12DKA
11
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

5 Refrigeration Cycle Diagram
12
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

6 Block Diagram
13
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

14
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

7 Wiring Diagram
15
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

16
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

8 Operation Details
8.1. Heating Operation
• Heating operation can be set using remote control.
• This operation is applied to warm the room temperature reaches the setting temperature set on the remote control.
• The remote control setting temperature, which takes the reading of intake air temperature sensor, can be adjusted from 16°C
to 30°C.
• During heating operation, the compressor will stop running and restart as shown in below figure.
8.1.1. Heating Operation Time Diagram
17
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

8.2. Cooling Operation
• Cooling operation can be set using remote control.
• This operation is applied to cool down the room temperature reaches the setting temperature set on the remote control.
• The remote control setting temperature, which takes the reading of intake air temperature sensor, can be adjusted from 16°C
to 30°C.
• During cooling operation, the compressor will stop running and restart as shown in below figure.
8.2.1. Cooling Operation Time Diagram
18
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

8.3.1. Soft Dry Operation Time Diagram
8.3. Soft Dry Operation
• Soft Dry operation can be set using remote control.
• Soft Dry operation is applied to dehumidify and to perform a gentle cooling to the room.
• This operation starts when the intake air temperature sensor reaches the setting temperature on the remote control.
• When operation begins, Soft Dry will be switched “ON” for a maximum 10 minutes, then Soft Dry operation will be turned “OFF”
for a minimum 6 minutes. After that, the Soft Dry operation will be “ON” and “OFF” based on the setting temperature as shown
in below figure.
• However after 3 minutes of compressor off, during Soft Dry “OFF” (within 6 minutes Soft Dry restart control), the indoor unit will
start to operate at normal Cooling mode if the intake temperature is higher than Cooling “ON” point.
19
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /

8.4. Automatic Operation
• Automatic operation can be set using remote control.
• This operation starts to operate with indoor fan at SLo speed for 25 seconds to judge the intake air temperature.
• After judged the temperature, the operation mode is determined by referring to the below standard.
• Then, the unit start to operate at determined operation mode, until it is switched off using remote control, with the setting
temperature as shown in below table.
• Operation mode will be determine again for judgement after 1 hour of operation, if the room temperature reaches to set
temperature and compressor off time is over 7 minutes 30 seconds continuously.
The present operation mode will be continued, if the room temperature does not reach to set temperature (Compressor keeps running)
eventhough after 1 hour from automatic operation mode started.
Present Judgement Next Mode
Mode Cooling Soft Dry Heating
O O
Cooling 23°C Cooling (Judgement: Not Applicable (Judgement:
Heating 23°C & Above) Below 23°C)
O O
Soft Dry 20°C Soft Dry Not Applicable (Judgement: (Judgement:
Heating 20°C & Above) Below 20°C)
O O
Heating Cooling (Judgement: Not Applicable (Judgement:
25°C Heating Above 25°C) 25°C & below)
Automatic Set Temperature
Refer as below.
• Automatic Set Temperature
For each operation, set temperature will automatically set as shown below.
However it can be selected 2°C higher or 2°C lower from standard set temperature by pressing the “Room Temperature Setting
button”.
Operation Hi (Standard) Lo
(+2°C) (±0°C) (-2°C)
Cooling 27°C 25°C 23°C
Soft Dry 24°C 22°C 20°C
Heating 23°C 21°C 19°C
• The setting temperature for all the operations can be changed one level up or one level down from the standard temperature
as shown in below table by pressing on the temperature up or temperature down button at remote control.
20
CS-A9DKA CU-A9DKA / CS-A12DKA CU-A12DKA /
