Panasonic CS-RZ25TKR User manual

English
Operating Instructions
Air Conditioner
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
The included Installation Instructions should be kept and read
by the installer before installation.
Remote control is packaged in the indoor unit and removed
by the installer before installation.
Model No.
Indoor Unit Outdoor Unit
CS-RZ25TKR
CS-RZ35TKR
CU-RZ25TKR
CU-RZ35TKR
ECONOMY
iAUTO-X
ACXF55-11360
ACXF55-11360_SM0717-0_EN.indd 1ACXF55-11360_SM0717-0_EN.indd 1 13/6/2017 11:54:28 AM13/6/2017 11:54:28 AM

2
Provides maximum comfort and clean air
with optimal energy saving methods.
Use remote
control within 8 m
from the remote
control receiver of
the indoor unit.
Quick Guide
Inserting the batteries
12
3
1Pull out the back cover
of remote control.
2
Insert AAA or R03
batteries.
3Close the cover.
AClock setting
1Press and
set the
time .
• Press and hold
for approximately
5 seconds to show
time in 12-hour
(am/pm) or 24 hour
indication.
2Confirm .
FAN SPEED
AIR SWING
ECONOMY
ON
OFF
SET
CANCEL
TIMER
TEMP
OFF/ON
MODE
FAN SPEED
AIR SWING
ECONOMY
ON
OFF
CANCEL
TIMER
A
B
ACXF55-11360_SM0717-0_EN.indd 2ACXF55-11360_SM0717-0_EN.indd 2 13/6/2017 11:54:29 AM13/6/2017 11:54:29 AM

3
Table of contents
Safety precautions ………… 4-7
How to use
……………………… 8-9
To learn more
………………… 10
Cleaning instructions
……… 11
Troubleshooting
………… 12-14
Information………………… 15
Accessories
• Remote control
• AAA or R03 batteries × 2
• Remote control holder
• Screws for remote control
holder × 2
The illustrations in this manual are for
explanation purposes only and may differ
from the actual unit. They are subject
to change without notice for future
improvement.
BBasic operation
2Press
OFF/ON
to
start/stop the
operation.
POWER
• Please note that
the indication
is on display to
start the unit.
3Select the desired
temperature.
TEMP
Up
Down
Selection range:
16.0 °C ~ 30.0 °C /
60 °F ~ 86 °F.
• Press and hold for
approximately 10 seconds
to switch the temperature
indication in °C or °F.
Thank you for purchasing
Panasonic Air Conditioner.
WARNING
This symbol shows
that this equipment
uses a flammable
refrigerant. If the
refrigerant is leaked,
together with an
external ignition
source, there is
a possibility of
ignition.
CAUTION
This symbol shows
type of flammable
refrigerant
contained in the
system.
CAUTION
This symbol shows
that the Operation
Instructions should
be read carefully.
CAUTION
This symbol shows
that a service
personnel should be
handling this
equipment with
reference to the
Installation
Instructions.
CAUTION
This symbol
shows that there is
information included
in the Operation
Instructions and/
or Installation
Instructions.
1Press
MODE
to select
the desired mode.
AUTO HEAT COOL
FANi AUTO-X DRY
English
ACXF55-11360_SM0717-0_EN.indd 3ACXF55-11360_SM0717-0_EN.indd 3 13/6/2017 11:54:30 AM13/6/2017 11:54:30 AM

4
Safety precautions
To prevent personal injury, injury to
others or property damage, please
comply with the following:
Incorrect operation due to failure to
follow instructions below may cause
harm or damage, the seriousness of
which is classified as below:
This appliance is not intended for
accessibility by the general public.
For appliance filled with R32
(mild flammable refrigerant).
If the refrigerant is leaked and
exposed to an external ignition
source, there is a risk of fire.
WARNING
This sign
warns of
death or
serious
injury.
CAUTION
This sign
warns of
injury or
damage to
property.
The instructions to be followed are
classified by the following symbols:
This symbol denotes an
action that is PROHIBITED.
These symbols denote
actions COMPULSORY.
WARNING
Indoor unit and outdoor unit
This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use of the
appliance by a person
responsible for their safety.
Children should be supervised to
ensure that they do not play with
the appliance.
The appliance shall be installed
and operated in a room with
floor area larger than 2.06m² and
keep away from ignition sources
(such as heat/sparks/open-
flame) or, hazardous areas (such
as gas appliances, gas cooking,
reticulated gas supply systems,
or electric cooling appliance, etc.
Be aware that refrigerant may
not contain an odour, highly
recommended to ensure suitable
flammable refrigerant gas
detectors are present, operating
and able to warn of a leak.
Please consult authorised dealer
or specialist to clean the internal
parts, repair, install, remove
and reinstall the unit. Improper
installation and handling will
cause leakage, electric shock or
fire.
Confirm with authorised dealer
or specialist on usage of any
specified refrigerant type.
Using refrigerant type other than
the specified may cause product
damage, burst and injury etc.
Indoor unit
Outdoor unit
Power supply
Remote control
Air inlet
Air inlet
Air inlet
Air inlet
Air outlet
Air outlet
Air outlet
Air outlet
ACXF55-11360_SM0717-0_EN.indd 4ACXF55-11360_SM0717-0_EN.indd 4 13/6/2017 11:54:30 AM13/6/2017 11:54:30 AM

5
English Safety precautions
Do not use means to accelerate
the defrosting process or
to clean, other than those
recommended by manufacturer.
Any unfit method or using
incompatible material may cause
product damage, burst and
serious injury.
Do not pierce or burn as the
appliance is pressurized. Do not
expose the appliance to heat,
flame, sparks, or other sources
of ignition. Else it may explode
and cause injury or death.
Do not install the unit in
a potentially explosive or
flammable atmosphere.
Failure to do so could result in
fire.
Do not insert your fingers
or other objects into the
air conditioner indoor or
outdoor unit, rotating parts
may cause injury.
Do not touch the outdoor unit
during lightning, it may cause
electric shock.
Do not expose yourself directly
to cold air for a long period to
avoid excess cooling.
Do not sit or step on the
unit, you may fall down
accidentally.
Remote control
Do not allow infants and small
children to play with the remote
control to prevent them from
accidentally swallowing the
batteries.
Power supply
Do not use a
modified cord, joint
cord, extension cord
or unspecified cord to
prevent overheating
and fire.
To prevent overheating, fire or
electric shock:
•Do not share the same power
outlet with other equipment.
•Do not operate with wet hands.
•Do not over bend the power
supply cord.
•Do not operate or stop the unit
by inserting or pulling out the
power plug.
If the supply cord is damaged,
it must be replaced by the
manufacturer, service agent or
similarly qualified persons in
order to avoid a hazard.
It is strongly recommended to
be installed with Earth Leakage
Circuit Breaker (ELCB) or
Residual Current Device (RCD)
to prevent electric shock or fire.
To prevent overheating, fire or
electric shock:
•Insert the power plug properly.
•Dust on the power plug should
be periodically wiped with a dry
cloth.
Stop using the product if any
abnormality/failure occurs and
disconnect the power plug or
turn off the power switch and
breaker.
(Risk of smoke/fire/electric
shock)
Examples of abnormality/failure
•The ELCB trips frequently.
•Burning smell is observed.
•Abnormal noise or vibration of
the unit is observed.
•
Water leaks from the indoor unit.
•Power cord or plug becomes
abnormally hot.
•Fan speed cannot be controlled.
•The unit stops running
immediately even if it is
switched on for operation.
•The fan does not stop even if
the operation is stopped.
Contact your local dealer
immediately for maintenance/
repair.
ACXF55-11360_SM0717-0_EN.indd 5ACXF55-11360_SM0717-0_EN.indd 5 13/6/2017 11:54:30 AM13/6/2017 11:54:30 AM

6
Safety precautions
WARNING
Precaution for appliance filled
with R32
Pay careful attention to the following
points when operating the appliances
and dealing with different refrigerants.
The appliance shall be installed,
and/or operated in a room with
floor area larger than Amin (m²)
and keep away from ignition
sources, such as heat/sparks/
open flame or hazardous areas
such as gas appliances, gas
cooking, reticulated gas supply
systems or electric cooking
appliances, etc. (Refer to Table
A of Installation instructions table
for Amin (m²))
Be aware that refrigerant may
not contain an odour, highly
recommended to ensure suitable
flammable refrigerant gas
detectors are present, operating
and able to warn of a leak.
Since the working pressure is
higher than that of refrigerant
R22 models, some of the piping
and installation and service tools
are special.
Especially, when replacing a
refrigerant R22 model with a new
refrigerant R32 model, always
replace the conventional piping
and flare nuts with the R32 and
R410A piping and flare nuts on
the outdoor unit side.
The R32 flare nut and pipe on
the outdoor unit side can also be
used for a R410A model.
Models that use refrigerant R32
and R410A have a different
charging port thread diameter to
prevent erroneous charging with
refrigerant R22 and for safety.
Therefore, check beforehand.
[The charging port thread
diameter for R32 and R410A is
12.7 mm (1/2 inch).]
Be extra careful so that foreign
matter (oil, water, etc.) does not
enter the piping.
Also, when storing the piping,
securely seal the opening by
pinching, taping, etc. (Handling
of R32 is similar to R410A.)
This appliance shall be stored in
a well ventilated area.
This appliance shall be stored
in a room without continuously
operating open flames and
ignition sources.
This appliance shall be stored
so as to prevent mechanical
damage from occurring.
Do not use means to accelerate
the defrosting process or
to clean, other than those
recommended by manufacturer.
Any unfit method or using
incompatible material may cause
product damage, burst and
serious injury.
This equipment must be earthed
to prevent electrical shock or fire.
Prevent electric shock by
switching off the power supply
and unplug:
-Before cleaning or servicing,
-When extended non-use, or
-During abnormally strong
lightning activity.
ACXF55-11360_SM0717-0_EN.indd 6ACXF55-11360_SM0717-0_EN.indd 6 13/6/2017 11:54:30 AM13/6/2017 11:54:30 AM

7
English
CAUTION
Indoor unit and outdoor unit
Do not wash the indoor unit
with water, benzine, thinner
or scouring powder to avoid
damage or corrosion at the unit.
Do not use for preservation
of precise equipment, food,
animals, plants, artwork or other
objects. This may cause quality
deterioration, etc.
Do not use any combustible
equipment in front of the airflow
outlet to avoid fire propagation.
Do not expose plants or pet
directly to airflow to avoid injury,
etc.
Do not touch the sharp
aluminium fin, sharp parts
may cause injury.
Do not switch ON the indoor
unit when waxing the floor. After
waxing, aerate the room properly
before operating the unit.
Do not install the unit in oily and
smoky areas to prevent damage
to the unit.
Do not dismantle the unit for
cleaning purpose to avoid injury.
Do not step onto an unstable
bench when cleaning the unit to
avoid injury.
Safety precautions
Do not place a vase or water
container on the unit. Water may
enter the unit and degrade the
insulation. This may cause an
electric shock.
Do not open window or door
for long time during operation,
it may lead to inefficient power
usage and uncomfortable
temperature changes.
Prevent water leakage by
ensuring drainage pipe is:
-Connected properly,
-Kept clear of gutters and
containers, or
-Not immersed in water
After a long period of use or use
with any combustible equipment,
aerate the room regularly.
After a long period of use, make
sure the installation rack does
not deteriorate to prevent the unit
from falling down.
Remote control
Do not use rechargeable (Ni-Cd)
batteries. It may damage the
remote control.
To prevent malfunction or
damage of the remote control:
•Remove the batteries if the unit
is not going to be used for a
long period of time.
•New batteries of the same type
must be inserted following the
polarity stated.
Power supply
Do not disconnect the plug
by pulling the cord to prevent
electric shock.
Do not pierce or burn as the
appliance is pressurized. Do not
expose the appliance to heat,
flame, sparks, or other sources
of ignition. Else it may explode
and cause injury or death.
ACXF55-11360_SM0717-0_EN.indd 7ACXF55-11360_SM0717-0_EN.indd 7 13/6/2017 11:54:31 AM13/6/2017 11:54:31 AM

8
How to use
ECONOMY
iAUTO-X
To adjust fan speed
• For AUTO, the indoor fan speed is automatically
adjusted according to the operation mode.
• If i AUTO-X mode is set, fan speed is fixed to AUTO.
To adjust fan speed, cancel i AUTO-X mode.
AUTO
FAN
FAN SPEED
To adjust airflow direction
• Do not adjust the flap by hand.
To adjust airflow direction
• For lateral direction, it is manually
adjustable as shown.
AIR SWING
Upper direction
To save electrical power consumption
• Save power consumption at unoccupied room by
adjust set temperature up to 3°C automatically.
• Brightness of all indicators will be dimmed.
ECONOMY
• The unit controls set temperature according to room
temperature to accelerate room cooling.
• After max 4 hours, the set temperature follows the
last set temperature setting.
• Fan speed is fixed at AUTO, fan speed selection is
prohibited.
• During unit is off, press will turn on the unit
with i AUTO-X mode.
• i AUTO-X mode can be cancelled by pressing the
respective button again.
To reach temperature quickly
Set
temperature
i AUTO-X
Max = 4 hours
-1°C /
-2°F
Indicator
POWER
TIMER
i AUTO-X
ECONOMY
FAN SPEED
AIR SWING
ECONOMY
ON
OFF
SET
CANCEL
TIMER
TEMP
OFF/ON
MODE
Not used
in normal
operations.
Press to restore
the remote
control to default
setting.
ACXF55-11360_SM0717-0_EN.indd 8ACXF55-11360_SM0717-0_EN.indd 8 13/6/2017 11:54:31 AM13/6/2017 11:54:31 AM

9
English
See "To learn more..." for details.
How to use
Note
,
ECONOMY
, ,
ECONOMY
• Can be activated in all modes and can be
cancelled by pressing the respective button
again.
• Cannot be selected at the same time.
To set the timer
ON
OFF
TIMER
CANCEL
SET
C
AN
C
E
L
21 3
1Select ON or OFF
timer
Example:
OFF at 22:00
• Each time pressed:
Cancel
2Set the time
3Confirm
• To cancel ON or OFF timer, press
or to select respective or then
press .
• If timer is cancelled manually or due to
power failure, you can restore the timer
again by pressing or to select
respective or then press .
• The nearest timer setting will be displayed
and will activate in sequence.
• Timer operation is based on the clock set
in the remote control and repeats daily
once set. For clock setting, please refer to
Quick Guide.
2 sets of ON and OFF timers are available to turn ON or OFF the unit at different preset
times.
To switch between powerful/quiet
POWERFUL:
To reach the preset temperature quickly
• This operation stops automatically after 20 minutes.
QUIET:
To enjoy quiet operation
• This operation reduces airflow noise.
ACXF55-11360_SM0717-0_EN.indd 9ACXF55-11360_SM0717-0_EN.indd 9 13/6/2017 11:54:31 AM13/6/2017 11:54:31 AM

10
To learn more...
Operation mode
AUTO : During operation mode selection the POWER indicator blinks.
• Unit selects operation mode every 10 minutes according to setting temperature
and room temperature.
HEAT : Unit takes a while to warm up. The POWER indicator blinks during this
operation.
COOL : Provides efficient comfort cooling to suit your needs.
DRY : Unit operates at low fan speed to give a gentle cooling operation.
FAN : To circulate air in the room.
i AUTO-X : The fast cooling is ideal when you come home on a hot day.
Energy saving temperature setting
Operating the unit within the recommended temperature range may save energy.
HEAT :
20.0 °C ~ 24.0 °C / 68 °F ~ 75 °F.
COOL : 26.0 °C ~ 28.0 °C / 79 °F ~ 82 °F.
Air flow direction
In COOL/DRY mode:
If AUTO is set, the flaps swings up/down automatically.
In i AUTO-X mode:
If AUTO is set, the horizontal flap is fixed at the lower position and shift to the upper
position after reaches set temperature. If manual is set, the horizontal flap are fixed at the
predetermined position.
In HEAT mode:
If AUTO is set, the horizontal flap is fixed at the predetermined position.
Auto restart control
If power is resumed after a power failure, the operation will restart automatically after a
period of time with previous operation mode and airflow direction.
• This control is not applicable when TIMER is set.
Operating conditions
Use this air conditioner in the temperature range indicated in the table.
Temperature °C (°F)
Indoor Outdoor
DBT WBT DBT WBT
COOL
Max. 32 (89.6) 23 (73.4) 46 (114.8) 26 (78.8)
Min. 16 (60.8) 11 (51.8) 5 (41.0) -
HEAT
Max. 30 (86.0) - 24 (75.2) 18 (64.4)
Min. 16 (60.8) - -15 (5.0) -
DBT: Dry bulb temperature, WBT: Wet bulb temperature
ACXF55-11360_SM0717-0_EN.indd 10ACXF55-11360_SM0717-0_EN.indd 10 13/6/2017 11:54:32 AM13/6/2017 11:54:32 AM

ECONOMY
11
English To learn more... / Cleaning instructions
Cleaning instructions
To ensure optimal performance of the
unit, cleaning has to be carried out at
regular intervals. Dirty unit may cause
malfunction and you may see error code
“H99”. Please consult authorised dealer.
• Switch off the power supply and unplug
before cleaning.
• Do not touch the aluminium fin, sharp parts
may cause injury.
• Do not use benzine, thinner or scouring
powder.
• Use only soap ( pH 7) or neutral
household detergent.
• Do not use water hotter than 40 °C / 104 °F.
Indoor unit
Air filters
Once every 2 weeks
• Wash/rinse the filters gently
with water to avoid damage
to the filter surface.
• Dry the filters thoroughly under shade,
away from fire or direct sunlight.
• Replace any damaged filters.
Remove air filter Attach air filter
Insert into the unit
Anti-bacterial filter
Anti-bacterial filter.
• Clean the filter whenever necessary.
• Wash/rinse the filter gently with water to
avoid damage to the filter.
• Dry the filter thoroughly under the shade,
away from fire or direct sunlight.
• Replace the filter every 10 years or replace
any damaged filter. Part no.: CZ-SA22P
Indoor unit
Wipe the unit gently with a
soft, dry cloth.
Coils and fans should be clean
for at least every 6 months by
an authorised dealer.
Outdoor unit
Clear debris that surround the
unit.
Clear any blockage from drain
pipe.
Front panel
Wash gently and dry.
Remove the front panel
1Release the
hooks at
both ends
2Pull out and lift up
ECONOMY
Close it securely
1Insert
at both
sides
ECONOMY
2Push in
3Close down
4Press both ends and center of the front
panel
Aluminium fin
Anti-bacterial filter
Front panel
Air filters
ACXF55-11360_SM0717-0_EN.indd 11ACXF55-11360_SM0717-0_EN.indd 11 13/6/2017 11:54:32 AM13/6/2017 11:54:32 AM

12
The following symptoms do not indicate malfunction.
Symptom Cause
POWER indicator blinks before the unit is
switched on.
• This is a preliminary step in preparation for the
operation when the ON timer has been set.
• When ON Timer is set, the unit may start earlier (up
to 35 minutes) before the actual set time in order to
achieve the desired temperature on time.
POWER indicator blinks during HEAT
mode with no warm air supply (and flap is
closed).
• The unit is in defrost mode (and AIR SWING is set
to AUTO).
TIMER indicator is always on.
• The timer setting repeats daily once set.
Operation is delayed a few minutes after
restarting.
• The delay is a protection to the unit’s compressor.
Indoor fan stops occasionally during
heating operation.
• To avoid unintended cooling effect.
Indoor fan stops occasionally during
automatic fan speed setting.
• This helps to remove the surrounding odour.
Airflow continues even after operation has
stopped.
• Extraction of remaining heat from the indoor unit
(maximum 30 seconds).
The room has a peculiar odour.
• This may be due to damp smell emitted by the wall,
carpet, furniture or clothing.
Cracking sound during operation.
• Changes of temperature caused the expansion/
contraction of the unit.
Water flowing sound during operation.
• Refrigerant flow inside the unit.
Mist emerges from indoor unit.
• Condensation effect due to cooling process.
Outdoor unit emits water/steam.
• Condensation or evaporation occurs on pipes.
Louder noise at outdoor unit during early
operation of i AUTO-X.
• The compressor and fan rotate at higher speed to
boost cooling performance during initial operation.
Discoloration of some plastic parts.
• Discoloration is subject to material types used in
plastic parts, accelerated when exposed to heat,
sun light, UV light or environmental factor.
Check the following before calling for servicing.
Symptom Check
Operation in HEAT/COOL mode is not
working efficiently.
• Set the temperature correctly.
• Close all doors and windows.
• Clean or replace the filters.
• Clear any obstruction at the air inlet and air outlet
vents.
Noisy during operation.
• Check if the unit has been installed at an incline.
• Close the front panel properly.
Remote control does not work.
(Display is dim or transmission signal is
weak.)
• Insert the batteries correctly.
• Replace weak batteries.
The unit does not work. • Check if the circuit breaker is tripped.
• Check if timers have been set.
The unit does not receive the signal from
the remote control.
• Make sure the receiver is not obstructed.
• Certain fluorescent lights may interfere with signal
transmitter. Please consult authorised dealer.
Troubleshooting
ACXF55-11360_SM0717-0_EN.indd 12ACXF55-11360_SM0717-0_EN.indd 12 13/6/2017 11:54:33 AM13/6/2017 11:54:33 AM

13
English Troubleshooting
When...
■The remote control is missing or a malfunction has occurred
AUTO
OFF/ON
1.Raise the front panel.
2.Press the button once to use in i AUTO-X mode.
3.Press and hold the button until you hear 1 beep, then release to use in
forced COOL mode.
4.Repeat step 3. Press and hold the button until you hear 2 beeps, then
release to use in forced HEAT mode.
5.Press the button again to turn off.
■The indicators are too bright
• To dim or restore the unit’s indicator brightness, press and hold for 5 seconds.
■Conducting a seasonal inspection after extended non-use
• Check the remote control batteries.
• Check that there is no obstruction around the air inlet and outlet vents.
• Use Auto OFF/ON button to select COOL/HEAT operation. After 15 minutes of operation, it
is normal to have the following temperature difference between the air inlet and outlet vents:
COOL: ≥8 °C / 14.4 °F HEAT: ≥14 °C / 25.2 °F
■The units are not going to be used for a long period of time
• Activate HEAT mode for 2~3 hours to remove moisture left in the internal parts thoroughly to
prevent mould growth.
• Turn off the power supply and unplug.
• Remove the remote control batteries.
NON SERVICEABLE CRITERIAS
TURN OFF THE POWER SUPPLY AND UNPLUG then please consult an authorised
dealer when in following conditions:
• Abnormal noise during operation.
• Water/foreign particles have entered the remote control.
• Water leaks from Indoor unit.
• Circuit breaker switches off frequently.
• Power cord becomes unnaturally warm.
• Switches or buttons are not functioning properly.
ACXF55-11360_SM0717-0_EN.indd 13ACXF55-11360_SM0717-0_EN.indd 13 13/6/2017 11:54:33 AM13/6/2017 11:54:33 AM

14
Troubleshooting
How to retrieve error codes
If the unit stops and the TIMER indicator blinks, use the remote control to retrieve the error code.
TIMER
SET
CANCEL
ON
OFF
SET CHECK CLOCK RESET
AC RC
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
S
ET CL
O
C
K
R
E
S
ET
A
C
RC
Press for
5 seconds
Press until you hear beep
sound, then write down the
error code
21
Press for 5
seconds to
quit checking
3Turn the unit off and
reveal the error code to
authorised dealer
4
• For certain errors, you may restart the unit for limited operation if there are 4 beeps when operation starts.
* Some error code may not be applicable to your model. Consult authorised dealer for clarification.
Diagnostic
display
Abnormality/Protection
control
H 00 No memory of failure
H 11 Indoor/outdoor abnormal
communication
H 12 Indoor unit capacity unmatched
H 14 Indoor intake air temperature sensor
abnormality
H 15 Outdoor compressor temperature
sensor abnormality
H 16 Outdoor current transformer (CT)
abnormality
H 17 Outdoor suction temperature sensor
abnormality
H 19 Indoor fan motor mechanism lock
H 21 Indoor float switch operation
abnormality
H 23 Indoor heat exchanger temperature
sensor 1 abnormality
H 24 Indoor heat exchanger temperature
sensor 2 abnormality
H 25 Indoor ion device abnormality
H 26 Minus ION abnormality
H 27 Outdoor air temperature sensor
abnormality
H 28 Outdoor heat exchanger temperature
sensor abnormality
H 30 Outdoor discharge pipe temperature
sensor abnormality
H 31 Abnormal swimming pool sensor
H 32 Outdoor heat exchanger
temperature sensor 2 abnormality
H 33 Indoor/outdoor misconnection
abnormality
H 34 Outdoor heat sink temperature sensor
abnormality
H 35 Indoor/outdoor water adverse current
abnormality
H 36 Outdoor gas pipe temperature
sensor abnormality
H 37 Outdoor liquid pipe temperature
sensor abnormality
H 38 Indoor/outdoor mismatch (brand code)
Diagnostic
display
Abnormality/Protection
control
H 39 Abnormal indoor operating unit or
standby units
H 41 Abnormal wiring or piping connection
H 50 Ventilation fan motor locked
H 51 Ventilation fan motor locked
H 52 Left-right limit switch fixing
abnormality
H 58 Indoor gas sensor abnormality
H 59 Eco sensor abnormality
H 64 Outdoor high pressure sensor
abnormality
H 67 nanoe abnormality
H 70 Light sensor abnormality
H 71 DC cooling fan inside control board
abnormality
H 72 Abnormality tank temperature sensor
H 97 Outdoor fan motor mechanism lock
H 98 Indoor high pressure protection
H 99 Indoor operating unit freeze protection
F 11 4-way valve switching abnormality
F 16 Total running current protection
F 17 Indoor standby units freezing
abnormality
F 18 Dry circuit blocked abnormality
F 87 Control box overheat protection
F 90 Power factor correction (PFC)
circuit protection
F 91 Refrigeration cycle abnormality
F 93 Outdoor compressor abnormal
revolution
F 94 Compressor discharge pressure
overshoot protection
F 95 Outdoor cooling high pressure
protection
F 96 Power transistor module overheating
protection
F 97 Compressor overheating protection
F 98 Total running current protection
F 99 Outdoor direct current (DC) peak
detection
ACXF55-11360_SM0717-0_EN.indd 14ACXF55-11360_SM0717-0_EN.indd 14 13/6/2017 11:54:33 AM13/6/2017 11:54:33 AM

15
English Troubleshooting / Information
Information for Users on Collection and Disposal of Old Equipment and used Batteries
[Information on Disposal in other Countries outside the European Union]
These symbols are only valid in the European Union. If you wish to discard
these items, please contact your local authorities or dealer and ask for the
correct method of disposal.
Pb
Note for the battery symbol (bottom two symbol examples):
This symbol might be used in combination with a chemical symbol. In this case
it complies with the requirement set by the Directive for the chemical involved.
Information
ACXF55-11360_SM0717-0_EN.indd 15ACXF55-11360_SM0717-0_EN.indd 15 13/6/2017 11:54:33 AM13/6/2017 11:54:33 AM

Printed in Malaysia ACXF55-11360
SM0717-0
Panasonic Corporation
1006 Kadoma, Kadoma City,
Osaka, Japan
Website: http://www.panasonic.com
© Panasonic Corporation 2017
ACXF55-11360_SM0717-0_EN.indd 16ACXF55-11360_SM0717-0_EN.indd 16 13/6/2017 11:54:33 AM13/6/2017 11:54:33 AM
