Panasonic CS-CE12GKEW User manual

© 2007 Panasonic HA Air-Conditioning (M) Sdn. Bhd.
(11969-T). All rights reserved. Unauthorized copying
and distribution is a violation of law.
Order No. MAC0706002A2
Air Conditioner
CS-CE7GKEW CU-CE7GKE
CS-CE9GKEW CU-CE9GKE
CS-CE12GKEW CU-CE12GKE
TABLE OF CONTENTS PAGE PAGE
1 Specifications ----------------------------------------------------- 2
1.1. CS-CE7GKEW CU-CE7GKE-------------------------- 2
1.2. CS-CE9GKEW CU-CE9GKE-------------------------- 4
1.3. CS-CE12GKEW CU-CE12GKE----------------------- 6
2 Technical Data----------------------------------------------------- 8
2.1. Operation Characteristics--------------------------------8
2.2. Sensible Capacity Chart--------------------------------20
3 Exploded View and Replacement Parts List-----------21
3.1. Indoor Unit------------------------------------------------- 21
3.2. Outdoor Unit----------------------------------------------- 23
Please file and use this manual together with the service manual for Model No. CS-E9GKEW-5 / CU-
E9GKE-5, CS-E12GKEW-5 / CU-E12GKE-5, Order No. MAC0612063C2.

2
1 Specifications
1.1. CS-CE7GKEW CU-CE7GKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity kW 2.05 (0.70 ~ 2.40)
kCal/h 1760 (600 ~ 2060)
EER W/W 4.27 (4.12 ~ 4.07)
kCal/hW 3.67 (3.53 ~ 3.49)
Noise Level dB (A) High 37, Low 24, Q-Lo 21 High 45
Power level dB High 48, Low 35, Q-Lo 32 58
H
E
A
T
I
N
G
Capacity kW 2.80 (0.70 ~ 4.00)
kCal/h 2410 (600 ~ 3440)
COP W/W 4.31 (4.38 ~ 3.92)
kCal/hW 3.71 (3.75 ~ 3.37)
Noise Level dB (A) High 38, Low 25, Q-Lo 22 High 46
Power level dB High 49, Low 36, Q-Lo 33 59
Moisture Removal l/h 1.3
pt/h 2.7
Air Volume
Q-Lo m3/min (ft3/min) Cooling; 4.6 (160) —
Heating; 5.1 (180)
Lo m3/min (ft3/min) Cooling; 6.3 (220) —
Heating; 6.5 (230)
Me m3/min (ft3/min) Cooling; 7.2 (250) —
Heating; 7.7 (270)
Hi m3/min (ft3/min) Cooling; 9.8 (350) Cooling; 28.8 (1020)
Heating; 10.3 (360)
SHi m3/min (ft3/min) Cooling; 10.1 (360) —
Heating; 10.7 (380)
Refrigeration Control Device — Check Valve & Capillary Tube
Refrigeration Oil cm3— RB68A or Freol Alpha68M (320)
Refrigerant (R410A) g (oz) — 790 (27.9)
Dimension Height mm (inch) 280 (11-1/32) 540 (21-1/4) Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-3/8)
Net Weight kg (lbs) 9 (20) 33 (73)
Pipe Diameter Gas mm (inch) 9.52 (3/8)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner Diameter mm 16 —
Length mm 650 —
Compressor Type — Hermetic Motor Motor Type — Brushless (6-pole)
Rated Output W — 650

3
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Note
• Specifications are subject to change without notice for further improvement.
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (6-pole)
Input Power W — 62
Output Power W 30 25
Fan Speed
Q-Lo (Cool/Heat) rpm 740 / 790 —
Lo (Cool/Heat) rpm 790 / 840 —
Me (Cool/Heat) rpm 1010 / 1070 —
Hi (Cool/Heat) rpm 1230 / 1300 750 / -
SHi (Cool/Heat) rpm 1270 /1340 —
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 19 2 x 24 x 17
Size (W x H x L) mm 610 x 315 x 25.4 36.4 x 504 x 713
684
Air Filter Material Polypropelene —
Type One-Touch —
Item Unit
Power Source (Phase, Voltage, Cycle) ø Single V 230
Hz 50
Input Power W Cooling; 480 (170 ~ 590)
Heating; 650 (160 ~ 1020)
Starting Current A 3.1
Running Current A Cooling; 2.3
Heating; 3.1
Power Factor % Cooling; 91
Heating; 91
Power factor means total figure of compressor, indoor fan motor and outdoor fan motor.
*Maximum over current protection A 4.8
Power Cord Number of core —
Length m —
Thermostat Electronic Control
Protection Device Electronic Control

4
1.2. CS-CE9GKEW CU-CE9GKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity kW 2.60 (0.80 ~ 3.00)
kCal/h 2240 (690 ~ 2580)
EER W/W 4.41 (4.57 ~ 4.00)
kCal/hW 3.80 (3.94 ~ 3.44)
Noise Level dB (A) High 39, Low 25, Q-Lo 21 High 46
Power level dB High 50, Low 36, Q-Lo 32 59
H
E
A
T
I
N
G
Capacity kW 3.60 (0.80 ~ 5.00)
kCal/h 3100 (690 ~ 4300)
COP W/W 4.31 (4.85 ~ 3.73)
kCal/hW 3.71 (4.18 ~ 3.21)
Noise Level dB (A) High 40, Low 27, Q-Lo 24 High 47
Power level dB High 51, Low 38, Q-Lo 35 60
Moisture Removal l/h 1.6
pt/h 3.4
Air Volume
Q-Lo m3/min (ft3/min) Cooling; 4.9 (170) —
Heating; 6.1 (220)
Lo m3/min (ft3/min) Cooling; 6.6 (230) —
Heating; 7.1 (250)
Me m3/min (ft3/min) Cooling; 7.8 (280) —
Heating; 8.6 (300)
Hi m3/min (ft3/min) Cooling; 10.4 (370) Cooling; 29.8 (1050)
Heating; 11.0 (390)
SHi m3/min (ft3/min) Cooling; 10.7 (380) —
Heating; 11.4 (400)
Refrigeration Control Device — Check Valve & Capillary Tube
Refrigeration Oil cm3— RB68A or Freol Alpha68M (320)
Refrigerant (R410A) g (oz) — 965 (34.1)
Dimension Height mm (inch) 280 (11-1/32) 540 (21-1/4) Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-3/8)
Net Weight kg (lbs) 9 (20) 34 (75)
Pipe Diameter Gas mm (inch) 9.52 (3/8)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner Diameter mm 16 —
Length mm 650 —
Compressor Type — Hermetic Motor Motor Type — Brushless (6-pole)
Rated Output W — 700

5
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Note
• Specifications are subject to change without notice for further improvement.
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (6-pole)
Input Power W — 65
Output Power W 30 25
Fan Speed
Q-Lo (Cool/Heat) rpm 770 / 890 —
Lo (Cool/Heat) rpm 830 / 940 —
Me (Cool/Heat) rpm 1070 / 1170 —
Hi (Cool/Heat) rpm 1310 / 1420 770 / —
SHi (Cool/Heat) rpm 1350 / 1460 —
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 19 2 x 24 x 17
Size (W x H x L) mm 610 x 315 x 25.4 36.4 x 504 x 713
684
Air Filter Material Polypropelene —
Type One-Touch —
Item Unit
Power Source (Phase, Voltage, Cycle) ø Single V 230
Hz 50
Input Power W Cooling; 590 (175 ~ 750)
Heating; 835 (165 ~ 1340)
Starting Current A 3.9
Running Current A Cooling; 2.8
Heating; 3.9
Power Factor % Cooling; 92
Heating; 93
Power factor means total figure of compressor, indoor fan motor and outdoor fan motor.
*Maximum over current protection A 5.9
Power Cord Number of core —
Length m —
Thermostat Electronic Control
Protection Device Electronic Control
ITEM UNIT INDOOR UNIT OUTDOOR UNIT

6
1.3. CS-CE12GKEW CU-CE12GKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity kW 3.50 (0.80 ~ 4.00)
kCal/h 3010 (690 ~ 3440)
EER W/W 3.83 (4.32 ~ 3.39)
kCal/hW 3.29 (3.73 ~ 2.92)
Noise Level dB (A) High 42, Low 28, Q-Lo 21 High 48
Power level dB High 53, Low 39, Q-Lo 32 61
H
E
A
T
I
N
G
Capacity kW 4.80 (0.80 ~ 6.50)
kCal/h 4130 (690 ~ 5590)
COP W/W 3.81 (4.57 ~ 3.44)
kCal/hW 3.28 (3.94 ~ 2.96)
Noise Level dB (A) High 42, Low 33, Q-Lo 30 High 50
Power level dB High 53, Low 44, Q-Lo 41 63
Moisture Removal l/h 2.0
pt/h 4.2
Air Volume
Q-Lo m3/min (ft3/min) Cooling; 5.0 (180) —
Heating; 8.0 (280)
Lo m3/min (ft3/min) Cooling; 7.0 (250) —
Heating; 8.5 (300)
Me m3/min (ft3/min) Cooling; 8.7 (310) —
Heating; 9.9 (350)
Hi m3/min (ft3/min) Cooling; 11.2 (400) Cooling; 31.0 (1090)
Heating; 11.7 (410)
SHi m3/min (ft3/min) Cooling; 11.5 (410) —
Heating; 12.1 (430)
Refrigeration Control Device — Check Valve & Capillary Tube
Refrigeration Oil cm3— RB68A or Freol Alpha68M (320)
Refrigerant (R410A) g (oz) — 980 (34.6)
Dimension Height mm (inch) 280 (11-1/32) 540 (21-1/4) Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-3/8)
Net Weight kg (lbs) 9 (20) 35 (77)
Pipe Diameter Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose Inner Diameter mm 16 —
Length mm 650 —
Compressor Type — Hermetic Motor Motor Type — Brushless (6-pole)
Rated Output W — 700

7
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
Note
• Specifications are subject to change without notice for further improvement.
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (6-pole)
Input Power W — 70
Output Power W 30 30
Fan Speed
Q-Lo (Cool/Heat) rpm 780 / 1090 —
Lo (Cool/Heat) rpm 920 / 1150 —
Me (Cool/Heat) rpm 1175 / 1325 —
Hi (Cool/Heat) rpm 1430 / 1500 830 / —
SHi (Cool/Heat) rpm 1470 / 1540 —
Heat Exchanger
Fin Material Aluminium (Pre Coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 21 2 x 24 x 17
Size (W x H x L) mm 610 x 315 x 25.4 36.4 x 504 x 713
684
Air Filter Material Polypropelene —
Type One-Touch —
Item Unit
Power Source (Phase, Voltage, Cycle)
ø Single
V 230
Hz 50
Input Power W Cooling; 915 (185 ~ 1180)
Heating; 1260 (175 ~ 1890)
Starting Current A 5.8
Running Current A Cooling; 4.2
Heating; 5.8
Power Factor % Cooling; 95
Heating; 95
Power factor means total figure of compressor, indoor fan motor and outdoor fan motor.
*Maximum over current protection A 8.7
Power Cord Number of core —
Length m —
Thermostat Electronic Control
Protection Device Electronic Control
ITEM UNIT INDOOR UNIT OUTDOOR UNIT

8
2 Technical Data
2.1. Operation Characteristics
2.1.1. CS-CE7GKEW CU-CE7GKE

9

10

11

12
2.1.2. CS-CE9GKEW CU-CE9GKE

13

14

15

16
2.1.3. CS-CE12GKEW CU-CE12GKE

17

18

19

20
2.2. Sensible Capacity Chart
OCS-CE7GKEW CU-CE7GKE
OCS-CE9GKEW CU-CE9GKE
OCS-CE12GKEW CU-CE12GKE
230V Outdoor Temp. (°C)
Indoor wet
bulb temp. 30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 2.03 1.54 0.44 1.90 1.48 0.47 1.77 1.42 0.51 1.61 1.35 0.55
19.0°C 2.05 0.48
19.5°C 2.23 1.61 0.45 2.09 1.55 0.48 1.94 1.49 0.52 1.77 1.42 0.56
22.0°C 2.43 1.67 0.46 2.27 1.61 0.49 2.12 1.55 0.52 1.92 1.48 0.57
230V Outdoor Temp. (°C)
Indoor wet
bulb temp. 30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 2.58 1.96 0.54 2.41 1.88 0.58 2.24 1.80 0.62 2.04 1.71 0.67
19.0°C 2.60 0.59
19.5°C 2.83 2.05 0.55 2.65 1.97 0.59 2.46 1.89 0.63 2.24 1.80 0.68
22.0°C 3.09 2.12 0.56 2.88 2.04 0.60 2.68 1.97 0.64 2.44 1.88 0.70
230V Outdoor Temp. (°C)
Indoor wet
bulb temp. 30 35 40 46
TCSHCIPTCSHCIPTCSHCIPTCSHCIP
17.0°C 3.47 2.63 0.84 3.24 2.52 0.91 3.02 2.43 0.97 2.74 2.30 1.05
19.0°C 3.50 0.92
19.5°C 3.81 2.76 0.86 3.56 2.65 0.92 3.31 2.55 0.99 3.01 2.43 1.07
22.0°C 4.15 2.86 0.87 3.88 2.75 0.94 3.61 2.65 1.01 3.28 2.53 1.08
TC
SHC
IP
-
-
-
Total Cooling Capacity (kW)
Sensible Heat Capacity (kW)
Input Power (kW)
Indoor 27°C/19°C
Outdoor 35°C/24°C
