Panasonic CS-F50DTE5 User manual

1 Service Information 3
1.1. Example of trouble at test operation 3
1.2. Caution of test operation 3
1.3. Caution during automatic address setting 3
1.4. Operation range 4
2 Features 5
2.1. New design 5
2.2. Such quietness! 5
2.3. Easy installation 6
© 2005 Panasonic HA Air-Conditioning (M) Sdn Bhd
(11969-T). All rights reserved. Unauthorized copying
and distribution is a violation of law.
CS-F50DTE5 CU-L50DBE8
2.4. Piping 6
2.5. Easy maintenance 6
2.6. Auto fan mode (indoor unit) 6
2.7. Low-noise outdoor units 7
2.8. Improved workability 8
2.9. A brand-new control method 9
2.10. Wired Remote Control 10
2.11. Wireless Remote Control 10
Air Conditioner
CONTENTS
Page Page
Order No. MAC0502038C2

2.12. Group Control Equipment 11
3 Specification 12
3.1. Product Specification 12
4 Dimensions 13
4.1. CS-F50DTE5 13
4.2. CU-L50DBE8 14
5 Refrigeration Cycle 15
6 Block Diagram 16
6.1. CS-F50DTE5 16
6.2. CU-L50DBE8 17
7 Wiring Diagram 18
7.1. CS-F50DTE5 18
7.2. CU-L50DBE8 19
8 Operation Details 20
8.1. Wired Remote Control (Optional part) 20
8.2. Wireless Remote Control (Optional part) 21
9 Operation Control 22
9.1. Operation Mode 22
9.2. Compressor Start Control 22
9.3. Cooling Operation 22
9.4. Heating Mode Operation 25
9.5. Louver Control 28
9.6. Odour Removing Operation 30
9.7. Energy Save Operation 31
9.8. Outdoor Fan Remaining Heat Removal Control 31
9.9. Crank Case Heater Control 31
9.10. Valve Error 31
9.11. Pump Down Operation 32
9.12. Indoor Air Volume Up Control (DC Fan Motor Type Only)
32
10 Installation Instruction 33
10.1. Pipe length 33
10.2. Refrigerant additional charge 34
10.3. Position of the centre gravity 34
10.4. Indoor unit installation 35
10.5. Outdoor unit installation 44
10.6. Wired remote control installation 55
10.7. Wireless remote control installation manual 62
10.8. Twin 69
11 Installation and Servicing Air Conditioner Using R410A 70
11.1. Outline 70
11.2. Tools for installing/servicing refrigerant piping 71
11.3. Refrigerant piping work 75
11.4. Installation, transferring, servicing 77
12 Troubleshooting Guide 81
12.1. Self-diagnosis error code table 81
13 Replacement Parts 83
13.1. Indoor unit 83
13.2. Outdoor unit 88
14 Electronic Circuit Diagram 92
14.1. Indoor unit 92
14.2. Outdoor unit 96
14.3. Wired remote control 101
14.4. Wireless remote control 102
14.5. Print pattern 103
2
CS-F50DTE5 CU-L50DBE8

1 Service Information
Notice of Address setting for NEW Ceiling / NEW Outdoor Unit.
The new Ceiling / New Outdoor models are possible to have address setting for twin control by automatic when main
power supply is switched on.
(Manual address setting is also possible by using Dip switch on Indoor unit P.C. board.) However, this address setting is only
possible when made proper wiring connection and also Indoor unit should be original virgin unit.
1.1. Example of trouble at test operation
If found out as following phenomenon at test operation on site, it may have possibility of wrong address setting.
Therefore, please ensure of the address setting.
1. LCD display of wired remote control had not illuminate although the main power supply switch is ‘on’.
2. LCD display had indicated as normal illumination when power supply switch is ‘on’, however outdoor unit cannot be operated.
(But, it is necessary to take 3 to 5 minutes for outdoor unit to start from the timing of remote control ON/OFF switch is ‘on’.)
3. P.C. board had memorized wrong setting information.
a. If main power supply is switched ‘on’ with the wrong connection.
b. When changing the connection or combination of units due to re-installation etc.
• • •
• When changing the system from twin control to normal one to one system.
• • •
• When making the replacement of units as master and slave etc.
1.2. Caution of test operation
Do not touch the remote control switch and do not change any wirings for one minute when the main power supply switch is ‘on’.
(Because the unit is having automatic address setting during the first one minute.)
1.3. Caution during automatic address setting
When main power supply switch is ‘on’, the P.C. board will automatically memorized the connecting system.
Consequently, when initial power supply is ‘on’, there will not be interchangeability of units even of the same type and same
capacity unit. Therefore unable to connect the unit to another system.
3
CS-F50DTE5 CU-L50DBE8

1.4. Operation range
1.4.1. Power Supply
The applicable voltage range for each unit is given in the following table. The working voltage among the three phases must be
balanced within a 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of
the rated voltage.
MODEL Unit Main Power Applicable Voltage
CU- Phase, Volts Hz Max Min
L34DBE5 1~240 50 264 216
L43DBE5 1~220 50 242 198
1~230 50 253 207
L50DBE8 3N~380 50 418 342
3N~400 50 440 360
3N~415 50 457 374
1.4.2. Indoor and Outdoor Temperature
• • •
• Model 50Hz CU-L34DBE5, CU-L43DBE5, CU-L50DBE8
Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)
Max Min Max Min
Cooling 50 32/23 21/15 43/- -15/-
Heating 50 27/- 16/- 24/18 -20/-
4
CS-F50DTE5 CU-L50DBE8

2.1. New design
2.1.1. Gentle curved styling
• • •
• The base has gentle curves which express a functional
beauty. It spreads the air quietly over a wide area.
2.2. Such quietness!
2.2.1. Several new mechanism add up to
low 46 dB noise (L50BT - High Fan
Speed)
1. Delta throat fan
A delta throat (projection) has been attached to the fan
outlet to suppress the generation of vortexes. This helps
maintain air flow speed even at lower fan speeds and is
effective in reducing noise.
2. Reflux orifice
The orifice at the intake port is equipped with an air flow
guide which minimizes the flow disturbances which occur at
the orifice and inside the impeller.
This reduces pressure losses inside the casing and also
helps reduce noise.
3. Adoption of wing-shaped vanes
• • •
• The vanes of the fan have been changed to
“aerodynamic” shaped vanes, so that the air flow more
smoothly over the vane surfaces and noise is thus
suppressed.
• • •
• Side filters have been adopted in the pipe partitions.
These allow the air intake space to be increased and
also further reduce noise.
2.2.2. Automatic swinging louvre
• • •
• The horizontal air flow angle is a wide 100 degrees
(manual). The louvre can swing automatically (through 70
degrees vertically) using the remote control. This increases
the area of comfortable air flow and warms the air even to
floor level.
2.2.3. Newly-shaped louvre
• • •
• The newly-shaped louvre and air outlet effectively distribute
the air flow. During cooling, this stops warm air from
collecting near the louvre, and prevents freezing.
2 Features
5
CS-F50DTE5 CU-L50DBE8

2.3. Easy installation
2.3.1. Easy suspension
• • •
• A suspension bolt fixing bracket with 4-point support is
attached to the main unit, which increases the space
available for installation.
2.3.2. Two installation methods :
standard and wall
• • •
• In addition to the standard (1) ceiling installation, a wall (2)
installation method (using a wall-hanging bracket) is
available for cases where the ceiling is too high for the main
unit to be suspended.
2.4. Piping
2.4.1. 3-direction pipe lead-out
• • •
• The refrigerant piping can lead out in one of three directions
(right, rear-right and top-right), and the drain pipe direction
can be selected from four directions (right, rear-right, left
and rear-left).
2.5. Easy maintenance
2.5.1. Long life filter (standard
equipment)
• • •
• In general office environments, cleaning (maintenance) is
not required until after approximately 2,500 hours of
operation, thus reducing maintenance work.
• • •
• For optimum comfort, it is recommended to clean the air
filter every 1-1/2 months.
2.5.2. Maintenance is possible from
underneath the unit.
• • •
• If the bottom panel is detached, the drain pan can then be
removed and installed from underneath the unit, and
inspection and servicing of component such as the control
panel also becomes easier.
2.6. Auto fan mode (indoor unit)
• • •
• Auto fan mode is added besides high, medium and low. It
automatically adjusts the fan speed according to the indoor
unit’s temperature.
6
CS-F50DTE5 CU-L50DBE8

[Product features]
2.7. Low-noise outdoor units
2.7.1. Low-noise design improves in surrounding areas
1. The noise-suppressing winglet fan is a result of new research into vane design theory. The unique curved shape suppresses
the generation of vortexes, thus reduces air flow noise.
2. The adoption of double-orifice rings reduces air passage resistance.
3. Strengthening of the noise insulation materials in the compressor and the sealing-in of mechanical noise allows vibration noise
to be greatly enclosed and suppressed.
4. The heat exchanger has an L-shaped design to allow air to flow more smoothly.
5. Noise is automatically reduced further during night time operation with lower outdoor air temperatures.
7
CS-F50DTE5 CU-L50DBE8

2.8.1. Pipes that are one size larger can
also be connected for renewal
• • •
• If renewing the system, existing refrigerant pipes can be
utilized so that only the indoor units need to be replaced.
• • •
• For example, liquid and gas pipes from 10 years ago can be
connected to current pipes with the same size for one size
larger. Effective utilization of materials reduces working
time and trouble. (Adaptor sockets are not supplied.)
2.8.3. Drain water dripping-prevention
structure
• • •
• The base of the outdoor unit is provided with a single drain
hole in order to prevent drain water from leaking out of the
unit. Body connecting a drain elbow and a discharge pipe,
water leakages can be prevented even when the unit is
installed against a wall.
2.8. Improved workability
2.8.2. Additional refrigerant charging
• • •
• All models do not require any additional charging of refrigerant for 30m of pipe length. This makes installation much easier.
2.8.4. Space saving design allows units to be installed side by side continuously
• • •
• Servicing after installation can be carried-out by removing the front covers.
2.8.5. Easy test operation
• • •
• Test operation can be carried out for both indoor and outdoor units.
2.8.6. Long pipe design
• • •
• Maximum piping length of 50m.
2.8.7. Internal pipe connection
• • •
• Pipes are connected inside the units (inside the side covers), making the final appearance more attractive.
• • •
• Pipes can be diverted outward in any of four directions (forward, right, down, rear).
• • •
• Small liquid pipe diameters of 9.53mm, making installation work much easier.
8
CS-F50DTE5 CU-L50DBE8

2.8.8. Centralized draining method
• • •
• Even when multiple outdoor units are installed to a wall, the
drain outlets can be concentrated into a single drain pipe.
This makes installation easier and also improve
appearance.
2.9. A brand-new control method
1.
Easier power supply wiring connection
Power supply wiring and other wiring tasks can be carried out more easily.
• • •
• Twin non-polar wires used to connect indoor and outdoor units.
• • •
• Adoption of connection error prevention circuits for drive wires and signal wires. If a connection error is made, the relay does
not operate and current does not flow to the circuit boards.
2.
Twin operation
• • •
• Simultaneous air conditioning of wide spaces and corners is possible. Indoor units of same horsepowers can even be used
in combination.
• • •
• Master unit and slave-units can be set automatically in twin systems. No address setting is necessary.
• • •
• Multiple indoor units can be operated simultaneously with a single remote control. Note that individual operation is not
possible.
3.
Separate indoor/outdoor unit power supplies
The power supply can be connected to (1) just the outdoor units, or (2) to both the indoor and outdoor units.
4.
Easy test operation
Test operation can be carried out for both indoor and outdoor units.
5.
Automatic setting initialization function (Remote control and Indoor unit)
In accordance with the indoor and outdoor units connected and the connection methods, conditions such as the connection
configuration (twin format) and remote-control functions such as automatic louvre operation and cooling or heating mode are
automatically detected and set instantly.
9
CS-F50DTE5 CU-L50DBE8

2.10. Wired Remote Control
1. The new design includes an easily-visible red pilot lamp. The power can be turned on and off at a single touch, without opening
the cover.
2. Has a build-in thermistor, allowing indoor temperature detection in accordance with indoor conditions by switching with main unit
thermistor.
3. Twin non-polar wires make installation work easy. (10 m cable supplied as accessory.)
2.11. Wireless Remote Control
1. New design with compact size. (Operation range within approximately 8 m.)
2. Built-in timer with OFF/ON timer setting (within 24 hours)
Wired Wireless
CZ-RD513C CZ-RL513T
NOTE: Both of the above remote control is packed separately from the indoor unit.
10
CS-F50DTE5 CU-L50DBE8

2.12. Group Control Equipment
Wired
remote
control
Group control by one remote
control
• • •
• All air conditioner units are
controlled as a whole by remote
control.
• • •
• All indoor units operate in the
same mode.
• • •
• A maximum of 16 units can be
connected together (sequental
starting)
[Remote side]
• • •
• Optional wired remote
control CZ-RD513C
[Local side]
Not needed
Twin remote control separate
control
• • •
• Each indoor unit can be operated
by either one of the two remote
control.
• • •
• Apart from timer setting time,
displays for two remote control are
identical.
• • •
• Last button pressed has priority
(main or slave is set at remote
control unit).
[Remote side]
• • •
• Optional wired remote
control
[Local side]
• • •
• Optional wired remote
control CZ-RD513C
Common
control
Common control / group
• • •
• Operation is possible using either
wired or wireless remote control
unit.
• • •
• Last button pressed has priority.
• • •
• Optional wired remote
control and wireless
remote control
Wired CZ-RD513C
Wireless CZ-RL513T
11
CS-F50DTE5 CU-L50DBE8

3.1. Product Specification
3 Specification
3.1.1. CS-F50DTE5 CU-L50DBE8
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F50DTE5 CU-L50DBE8
Remote CZ-RD513C (Wired)
Control CZ-RL513T (Wireless)
Cooling Capacity kW 14.0
BTU/h 47,700
Heating Capacity kW 16.0
BTU/h 54,600
Refrigerant Charge-less m 30
Standard Air Volume for High, m3/min Hi 32 Me 28 Lo 26 Hi 98
Medium and Low Speed cfm 1130 1040 960 3460
Outside Dimension (H x W x D) mm 250 x 1600 x 700 1340 x 900 x 320
inch 9-27/32 x 62-31/32 x 27-9/16 52-7/8 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 47 (104) 105 (231)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.DØ20 I.DØ20x1
Compressor Type, Number of Set -Hermetic - 2P (Rotary), 2
Starting Method - DC-INV control
Motor Type -4-pole single phase brushless motor
Rated Output kW - 3.8
Fan Type, Number of Set Sirocco fan-4 Propeller fan-1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.14 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (3 x 14 x 18) Corrugate-fin type (2 x 51 x 18)
Refrigerant Control -Exp. Value
Refrigerant Oil (Charged) cm3-FV50S (1200)
Refrigerant (Charged) R410A kg (oz) - 3.50 (123)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High pressure switch, Current transformer
Noise Level dB (A) Hi 50 Lo 46 Cooling 54, Heating 56
Power level dB Cooling : Hi 67 Lo 63
Heating : Hi 67 Lo 63
Cooling 68, Heating 70
Moisture Removal L/h 9.0
EER W/W 2.91
COP W/W 3.41
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by JIS-B8615
Volts V 380 400 415
Phase 3N 3N 3N
Power Consumption kW Cool 4.81 4.81 4.81
Heat 4.69 4.69 4.69
Running Current ACool 7.6 7.4 7.2
Heat 7.4 7.2 7.0
Starting Current A 7.6 7.4 7.2
Power Factor % Cool 96 94 93
Heat 96 94 93
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V 50Hz
12
CS-F50DTE5 CU-L50DBE8

4 Dimensions
4.1. CS-F50DTE5
13
CS-F50DTE5 CU-L50DBE8

4.2. CU-L50DBE8
14
CS-F50DTE5 CU-L50DBE8

5 Refrigeration Cycle
15
CS-F50DTE5 CU-L50DBE8

6 Block Diagram
6.1. CS-F50DTE5
16
CS-F50DTE5 CU-L50DBE8

6.2. CU-L50DBE8
17
CS-F50DTE5 CU-L50DBE8

7 Wiring Diagram
7.1. CS-F50DTE5
18
CS-F50DTE5 CU-L50DBE8

7.2. CU-L50DBE8
19
CS-F50DTE5 CU-L50DBE8

REMOTE
The OFF/ON button cannot be used.
LOCAL
All wired remote control buttons can be used.
Time/time setting display
Check display
Fan speed display
Operation mode selection display
FILTER RESET display
(Appears after the cumulative running time reaches
approximately 2,500 hours of operation.)
Temperature setting display (16°C - 31°C)
Airflow direction setting display
OFF/ON button
Used to start and stop the operation.
FAN SPEED button
Used to select the fan speed of high (HI), medium (MED), low
(LO) or auto (AUTO).
MODE button
Used to select the operation of AUTO, HEAT, FAN, COOL, or
DRY.
TEMP (UP/DOWN) buttons
Used to select the desired temperature.
AIR SWING (AUTO/MANUAL) buttons
Used to determined the air swing condition, either auto or
manual.
FILTER RESET button
Press to reset the “FILTER RESET” display after washing the
filter.
TEST RUN button*
VENTILATION button*
ECONOMY operation button
Provides Energy saving function
ODOUR WASH button
Provides deodorizing function.
CHECK button
Press this button if the check display is flashing.
TIMER/CLOCK SET buttons
Used to set the timer operation and the current time.
Operation indicator
Lights up when the unit in operation.
8 Operation Details
8.1. Wired Remote Control (Optional part)
Name and function of each part
NOTES
• • •
• Ensure that the correct button is pressed as simultaneous pressing of the multiple buttons will not make the setting correct.
• • •
• The illustration above is for explanatory purposes only. The appearance will be different during actual operation.
• • •
• Do not operate the remote control with wet hands. Otherwise, electric shock or malfunction may occur.
• • •
• Do not press the remote control buttons with sharp object as this may damage the remote control.
• • •
• Buttons marked with * are not needed for normal operation. If one of these buttons is pressed by mistake, press the same
button once more to cancel the operation.
• • •
• When the power resumed after power failure, the unit will restart automatically with all the previous settings preserved by
the memory function. (Auto restart function)
20
CS-F50DTE5 CU-L50DBE8
