Panasonic CS-V9PKA-2 User manual

English 中文
Operating Instructions
Air Conditioner
F569395
操作說明書
空調器
感謝您購買 Panasonic 空調器。
附帶安裝說明。
在操作空調器前,請細讀此操作說明,並保存此書
以備日後參考。
Operating Instructions
Air Conditioner
Thank you for purchasing Panasonic Air Conditioner.
Installation instructions attached.
Before operating the unit, read these operating
instructions thoroughly and keep them for future
reference.
Model No.
Indoor Unit Outdoor Unit
CS-V9PKA-2
CS-V12PKA-2
CS-V18PKA-2
CS-V24PKA-2
CU-V9PKA
CU-V12PKA
CU-V18PKA
CU-V24PKA

2
中文
簡易指南
1
2
3
裝入電池
1拉出遙控器的背蓋
2
裝入 AAA 或 R03 電池
(可用大約一年)
3把蓋關上
TIMER
SET
CANCEL
ON
OFF
123
SET CLOCK RESET
TIMER
C
AN
C
E
L
ON
O
FF
1
3
S
ET
R
E
S
ET
2 3
1
時間設定
1按下 CLOCK(時間)
2
設定時間
3確認
8m
MODE
POWERFUL/
QUIET
TEMP
OFF/ON
NANOE-G
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
SET CLOCK
FAN SPEED
RESET
P
O
WERFUL/
Q
UIET
N
AN
O
E-
G
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
AIR
S
WIN
G
S
ET CL
O
C
K
F
AN
S
PEE
D
R
E
S
ET
3
2
1
V9PKA-2, V12PKA-2
MODE
POWERFUL/
QUIET
TEMP
OFF/ON
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
FAN SPEED
SET CLOCK
FAN
SPEED
AIR
SWING
AUTO
COOL
DRY
NANOE-G
RESET
P
O
WERFUL/
Q
UIET
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
A
IR
S
WIN
G
FAN
S
PEE
D
S
ET CL
O
C
K
FAN
S
PEE
D
AIR
S
WIN
G
AUT
O
C
OOL
DRY
NAN
O
E-
G
R
E
S
ET
V18PKA-2,
V24PKA-2
3
2
1
基本操作
1選擇所需要的模式
DRYAUTO COOL
2
開始/停止操作
POWER
• 請注意 OFF(關機)指示燈如下:
啟動:
停止:
(V9PKA-2, V12PKA-2)
•
請注意 OFF(關機)指示燈開啟 以啟動。
(V18PKA-2, V24PKA-2)
3選擇所需要的溫度
• 選擇範圍:16 °C ~ 30 °C
。
• 在所建議的溫度內操作本機可為您節省能源。
COOL(製冷): 26 °C ~ 28 °C 。
DRY(除濕): 比室温低 1 °C ~ 2 °C 。
• 持續按下 5 秒以調暗或恢復主機的指示燈
亮度。
• 在室内機遙控接收器的 8 米範圍内使用遙控器。
本操作說明書裡的圖解僅作為說明用途,並且可能
與實際產品有所區别。若因為產品改進而發生變
更,恕不另行通知。

3
中文
English
Quick guide
Inserting the batteries
1Pull out the back cover of remote control
2
Insert AAA or R03 batteries
(can be used ~ 1 year)
3Close the cover
Clock setting
1Press CLOCK
2
Set the time
3Confirm
Basic operation
1Select the desired mode
DRYAUTO COOL
2
Start/stop the operation
POWER
• Please note that the OFF indication is as
follows:
To start:
To stop:
(V9PKA-2, V12PKA-2)
• Please note that the OFF indication is
on to start.
(V18PKA-2, V24PKA-2)
3Select the desired temperature
• Selection range: 16 °C ~ 30 °C.
•
Operating the unit within the recommended
temperature may save energy.
COOL: 26 °C ~ 28 °C.
DRY : 1 °C ~ 2 °C lower than room
temperature.
• To dim or restore the unit’s indicator brightness,
press and hold for 5 seconds.
• Use remote control within 8 m from the remote
control receiver of the indoor unit.
The illustrations in this manual are for explanation
purposes only and may differ from the actual unit.
They are subject to change without notice for future
improvement.
中文
目錄
安全措施 .................................................... 4-5
如何使用 .................................................... 6-9
清洗說明 ..................................................... 10
故障檢修 ......................................................11
信息 ......................................................... 封底
附件
• 遙控器
• AAA 或 R03 電池 × 2
• 遙控器托架
• 用於遙控器托架的螺釘 × 2
English
Table of contents
Safety precautions................................. 12-13
How to use............................................. 14-17
Cleaning instructions .................................. 18
Troubleshooting ......................................... 19
Information................................... Back cover
Accessories
• Remote control
• AAA or R03 batteries × 2
• Remote control holder
• Screws for remote control holder × 2

4
安全措施
為了防止個人傷害，危害其他人或財物的損失，請遵
守以下指示:
因不遵守以下指示導致的錯誤操作將引起傷害或損
壞，其嚴重程度分類如下:
警告
此標識所示的行為有
可能導致嚴重傷害或
死亡。
注意
此標識所示的行為有
可能導致傷害或財產
損失。
要遵守的指示按下列符號分類:
此符號表示被禁止的行為。
此符號表示務必執行的行為。
警告
室内機及室外機
此裝置不適合殘疾、感應欠佳或智障，經驗與知
識不足的人士（包括兒童）使用。除非負責其安
全的監督人從旁監督或指示如何正確使用此裝
置。務必監督兒童以確保他們不會玩弄本機。
請諮詢授權經銷商或專業人員清潔内部零件，
修理、安裝、拆卸和重新安裝本機。安裝及處
理不當將導致漏電，觸電或火災。
請向授權經銷商或專業人員確認有關任何指定
製冷劑類型之運用。使用所指定以外的製冷劑
類型會導致產品損壞，爆裂並導致傷害等。
切勿將本機安裝在爆炸或可燃性的環境中。
否則會導致火災。
切勿把手指或其他物件插入空調器的室
内或室外機以免受到旋轉部件傷害。
閃電時切勿觸摸室外機，否則會導致觸電。
切勿長時間受冷氣流直接吹拂以免過冷。
切勿坐或踩踏在主機上以免意外摔跤。
遙控器
切勿讓嬰兒和小孩玩遙控器以免不小心吞下電
池。
電源
切勿採用改裝電線，接合電線，
延長電線或非指定的電線,以免
過熱及火災。
為免過熱，火災或觸電:
• 切勿與其他設備共用一個電源插座。
• 切勿用潮濕的手操作。
• 切勿過度扭曲電線。
• 切勿以插入或拉出插頭的方式來操作或停止
本機。
室內機
室外機
電源
遙控器
空氣吸入口
空氣吸入口
空氣吸入口
空氣吸入口
空氣吹出口
空氣吹出口
空氣吹出口
空氣吹出口

5
中文
如果電線損壞，必須由製造商、其服務代理
商或具有同等資格的合格人員進行更換以免
遭受危害。
強烈建議您安裝接地漏電電源斷路器 (ELCB)
或殘餘電流裝置 (RCD) 以免觸電或火災。
為免過熱，火災或觸電:
• 妥當插入插頭。
• 務必定時用乾布擦掉插頭上的灰塵。
當出現任何異常/故障時，請停止使用本機，
拔出電插頭或關掉電源開關及斷路器。
(煙霧/火災/觸電危險)異常/故障舉例
• 接地漏電電源斷路器 (ELCB) 頻繁跳閘。
• 出現燒焦味。
• 本機出現異常噪音或振動。
• 室内機漏水。
• 電線或插頭變得異常熱。
• 無法控制風量。
•
本機立即停止運轉，雖然已經打開準備操作。
• 雖然已經停止操作, 風扇仍然不停止轉動。
立即諮詢經銷商以進行保養/修理。
更換或安裝電源插頭必須由授權/合格人員進
行。主導電體裏的電線由下列不同的顏色分
類：
接頭
紅色
電線
負載線
中線
接地線
顏色 (GB 標準)
藍色
綠色-黃色
褐色
黑色
綠色/黃色
電線顏色會隨國家電線代碼的標準而有所區
别。
本設備必須接地以免觸電或火災。
為免觸電，請在下列情況時關閉電源並拔出
插頭:
- 清洗或維修之前，
- 長期不使用時，或
- 異常強烈閃電時。
安全措施
注意
室内機及室外機
切勿用水、苯、稀釋劑或潔亮粉末清洗室内
機以免損壞或腐蝕本機。
切勿充作其他用途，如貯藏食物、動物、
植物、藝術品或其他物件。否則會破壞品
質等。
切勿在氣流出口使用任何易燃器具以免引起
火災。
切勿讓植物或寵物受冷氣流直接吹拂以免損
傷等。
切勿觸摸尖銳的鋁散熱片以免受到
尖銳部件傷害。
當在地面打蠟時切勿 ON(開機)室内機。打
蠟完畢之後，請先讓房間良好通風再操作
本機。
切勿將本機安裝在油煙重的場所以免損壞
本機。
切勿拆卸本機來進行清洗工作以免受傷。
當清洗本機時切勿踩踏在不穩固的架子上以
免受傷。
切勿將花瓶或水容器放置在本機上。水會
進入本機而導致絕緣受到破壞。這會引起
觸電。
切勿在 COOL/DRY(製冷/除濕)模式下長時
間打開門窗。
為免漏水，請確保排水軟管:
- 連接正確，
- 不受通水道及容器阻擋，或
- 不浸在水裏
長時間使用或與其他易燃設備一起使用後請
定時讓房間通風換氣。
長期使用後，請注意安裝支架是否有損壞以
免主機墜落。
遙控器
切勿使用可充電電池 (Ni-Cd)。它會損壞遙
控器。
為免遙控器失靈或損壞:
• 如果準備長期不使用本機，務必將電池取
出。
• 務必採用同類型的新電池並對準電極插
入。
電源
切勿以抽拉電線的方式來拔除插頭以免觸電。

MODE
POWERFUL/
QUIET
TEMP
OFF/ON
NANOE-G
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
SET CLOCK
FAN SPEED
RESET
TEMP
O
FF/
ON
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
CL
O
C
K
F
遙控器顯示屏
V9PKA-2, V12PKA-2
持續按下大約 10 秒以
在°C 或°F 格式中顯
示溫度。
按下以恢復遙控器的出
廠設定。
在正常操作下不使用。
6
MODE 選擇運轉模式
AUTO(自動) - 給您方便
• 本機將按照室溫自動選擇運轉模式。
• 一旦選取 AUTO(自動)模式，本機將以標準設
定溫度來運轉。
房間溫度 運轉模式 標準設定溫度
23˚C 及以上 COOL (製冷) 25˚C
23˚C 以下 DRY (除濕) 22˚C
• 按下 至 “HI” +2˚C 或 至 “LO” -2˚C
以獲取標準設定溫度。
COOL(製冷) - 享受清涼
• 為了在 COOL(製冷)模式下降低耗電量，請拉
上窗簾以避免陽光直接照射和室外暖氣進入。
DRY(除濕) - 為您創造乾爽的環境
• 空調以低速運轉，進行極為柔和的製冷運轉。
POWERFUL/
QUIET
轉換於強勁和安靜之間
QUIETPOWERFUL NORMAL
POWERFUL: 迅速達到設定温度
POWERFUL
• 此功能將在 15 分鐘後自動停止。
QUIET: 享受安靜運轉
QUIET
• 此功能將減低氣流噪音。
FAN SPEED
選擇風量
(遙控器顯示屏)
• 至於 AUTO(自動)運轉，室内風扇風量將依據運
轉模式自動調節。
如何使用
指示燈
POWER
TIMER
NANOE-G
POWERFUL/QUIET
(綠色)
(橙色)
(藍色)
(橙色/
綠色)
調節水平風向
• 可手動調節。
自動 OFF/ON(關/開)按鈕
當遙控器遺失或失靈時使用。
向上提起正面板:
•
在AUTO(自動)模式使用時，
按一次按鈕。
• 在COOL(製冷)模式使用時，
持續按下按鈕直到聽見一聲
“嗶”，然後鬆開。
• 再按一次按鈕以關閉。

7
中文
設定預約時間
要在預設時間内 ON (開機)或 OFF (關機)主機
時。
TIMER
SET
CANCEL
ON
OFF
123
C
AN
C
E
L
3
21 3
1選擇 ON(開機)或
OFF(關機)模式
舉例:
在22:00
OFF(關機)
OFF
OFF
TIMER
2設定時間
2
OFF
TIMER
3確認 SET
OFF
TIMER
TIMER
• 按
ON
或 OFF 然後按下 CANCEL 以取消 ON (開
機)或 OFF (關機)定時預約時間。
• 如果自行取消定時預約或因爲發生停電而被取
消，您可按下 SET 以恢復之前的設定(在電流
恢復後)。
• 當設定了定時 ON(開機)時，為了在您設定的
時間內達到您所設定的溫度，空調器會在設定
的時間提前運轉(高達 15 分鐘)。
• 定時預約機能將依據遙控器所設定的時間操
作，並且一旦被設定後會每天重覆操作。至於
時鐘設定，請參閱簡易指南。
NANOE-G
以淨化空氣
NANOE-G
• 用
OFF/ON
啟動本機時 nanoe-G 功能會自動開始
操作。
•
此功能在本機關閉時依然可以啟動。在此情況下，
本機將 AUTO(自動)調節風量及風向並送風。
在濾塵網中消滅病毒/細菌
NANOE-G
POWER
• 視本機的累積操作時間而定，在關閉主機後
nanoe-G 濾塵網抗菌功能可能會每天只啟動一
次。
• 為排除留在内部機件的濕氣，導風板將在稍微打
開的情況下操作風扇送風 30 分鐘。此流程只會
在主機關閉之前操作 COOL/DRY(製冷/除濕)模
式方為有效。之後，nanoe-G 將於停止風扇送風
和關閉導風板的狀態下在濾塵網中消滅病毒/細菌
達2 小時。
• 切勿在此功能操作中關閉電源。電源中斷後此功
能操作將不恢復。
• 要在此後禁用本功能，持續按下
NANOE-G
直到聽見
一聲短“嗶”。這不會禁用 nanoe-G 淨化空氣。
• 要恢復 nanoe-G 濾塵網抗菌功能時，持續按下
NANOE-G
直到聽見一聲長“嗶”。
AIR SWING
調節垂直風向
(遙控器顯示屏)
• 保持室內空氣循環。
• 在 COOL/DRY (製冷/除濕)模式下，如果設定
為AUTO (自動)風向時，導風板將自動向上/下
擺動。
• 切勿用手調節導風板。
注意
POWERFUL
/
QUIET
,
NANOE-G
• 可以在任何模式中操作。再分別按下相關的按鈕
即可取消操作。
POWERFUL
/
QUIET
• 無法被同時選取。
操作條件
在以下溫度範圍內使用空調器。
DBT : 乾球溫度
WBT : 濕球溫度
溫度(°C) 室内 室外
DBT WBT DBT WBT
COOL
(製冷)
最高 32 23 43 26
最低 16 11 16 11
如何使用

8
MODE 選擇運轉模式
AUTO(自動) - 給您方便
• 本機將按照室溫自動選擇運轉模式。
• 一旦選取 AUTO(自動)模式，本機將以標準設
定溫度來運轉。
房間溫度 運轉模式 標準設定溫度
23˚C 及以上 COOL (製冷) 25˚C
23˚C 以下 DRY (除濕) 22˚C
• 按下 至 “HI” +2˚C 或 至 “LO” -2˚C
以獲取標準設定溫度。
COOL(製冷) - 享受清涼
• 為了在 COOL(製冷)模式下降低耗電量，請拉
上窗簾以避免陽光直接照射和室外暖氣進入。
DRY(除濕) - 為您創造乾爽的環境
• 空調以低速運轉，進行極為柔和的製冷運轉。
POWERFUL/
QUIET
轉換於強勁和安靜之間
QUIETPOWERFUL NORMAL
POWERFUL: 迅速達到設定温度
POWERFUL
• 此功能將在 15 分鐘後自動停止。
QUIET: 享受安靜運轉
QUIET
• 此功能將減低氣流噪音。
FAN SPEED
選擇風量
(遙控器顯示屏)
• 至於 AUTO(自動)運轉，室内風扇風量將依據運
轉模式自動調節。
如何使用
自動 OFF/ON(關/開)按鈕
當遙控器遺失或失靈時使用。向上提起正面板:
•
在AUTO(自動)模式使用時，按一次按鈕。
• 在COOL(製冷)模式使用時，持續按下按鈕直到聽見一聲“嗶”，然後鬆開。
• 再按一次按鈕以關閉。
MODE
POWERFUL/
QUIET
TEMP
OFF/ON
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
FAN SPEED
SET CLOCK
FAN
SPEED
AIR
SWING
AUTO
COOL
DRY
NANOE-G
RESET
TEMP
O
FF/
ON
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
CL
O
C
K
F
V18PKA-2, V24PKA-2
遙控器顯示屏
持續按下大約 10 秒以
在°C 或°F 格式中顯
示溫度。
按下以恢復遙控器的出
廠設定。
在正常操作下不使用。
指示燈
POWER
TIMER
NANOE-G
POWERFUL/QUIET
(綠色)
(橙色)
(藍色)
(橙色/
綠色)

9
中文
設定預約時間
要在預設時間内 ON (開機)或 OFF (關機)主機
時。
TIMER
SET
CANCEL
ON
OFF
123
C
AN
C
E
L
3
21 3
1選擇 ON(開機)或
OFF(關機)模式
舉例:
在22:00
OFF(關機)
OFF
2設定時間
2
3確認 SET
TIMER
• 按
ON
或 OFF 然後按下 CANCEL 以取消 ON (開
機)或 OFF (關機)定時預約時間。
• 如果自行取消定時預約或因爲發生停電而被取
消，您可按下 SET 以恢復之前的設定(在電流
恢復後)。
• 當設定了定時 ON(開機)時，為了在您設定的
時間內達到您所設定的溫度，空調器會在設定
的時間提前運轉(高達 15 分鐘)。
• 定時預約機能將依據遙控器所設定的時間操
作，並且一旦被設定後會每天重覆操作。至於
時鐘設定，請參閱簡易指南。
NANOE-G
以淨化空氣
NANOE-G
• 用
OFF/ON
啟動本機時 nanoe-G 功能會自動開始
操作。
•
此功能在本機關閉時依然可以啟動。在此情況下，
本機將 AUTO(自動)調節風量及風向並送風。
在濾塵網中消滅病毒/細菌
NANOE-G
POWER
• 視本機的累積操作時間而定，在關閉主機後
nanoe-G 濾塵網抗菌功能可能會每天只啟動一
次。
• 為排除留在内部機件的濕氣，導風板將在稍微打
開的情況下操作風扇送風 30 分鐘。此流程只會
在主機關閉之前操作 COOL/DRY(製冷/除濕)模
式方為有效。之後，nanoe-G 將於停止風扇送風
和關閉導風板的狀態下在濾塵網中消滅病毒/細菌
達2 小時。
• 切勿在此功能操作中關閉電源。電源中斷後此功
能操作將不恢復。
• 要在此後禁用本功能，持續按下
NANOE-G
直到聽見
一聲短“嗶”。這不會禁用 nanoe-G 淨化空氣。
• 要恢復 nanoe-G 濾塵網抗菌功能時，持續按下
NANOE-G
直到聽見一聲長“嗶”。
A
IR SWING
調節風向
(遙控器顯示屏)
• 保持室內空氣循環。
• 在 COOL/DRY(製冷/除濕)模式下，如果設定
為AUTO(自動)風向時，導風板將自動向上/下
擺動。
• 切勿用手調節導風板。
注意
POWERFUL
/
QUIET
,
NANOE-G
• 可以在任何模式中操作。再分別按下相關的按鈕
即可取消操作。
POWERFUL
/
QUIET
• 無法被同時選取。
操作條件
在以下溫度範圍內使用空調器。
DBT : 乾球溫度
WBT : 濕球溫度
溫度(°C) 室内 室外
DBT WBT DBT WBT
COOL
(製冷)
最高 32 23 43 26
最低 16 11 16 11
如何使用

10
清洗說明
為了確保本機發揮最佳性能，您必須進行定期清
洗。請諮詢授權經銷商。
• 進行清洗前，關掉電源並拔出插頭。
• 切勿觸摸鋁片，尖銳部分會造成傷害。
• 切勿使用苯、稀釋劑或潔亮粉末。
• 僅使用肥皂 ( pH 7) 或中性家用清潔劑。
• 切勿使用溫度高過 40 °C 的水。
室內機
使用乾、軟的布輕抹。
正面板
輕洗並弄乾。
取出正面板
POWER
TIMER
NANOE-G
POWERFUL/QUIET
提起
拉出
1
2
確實關上
至於 CS-V18PKA-2, CS-V24PKA-2 型號:
按正面板的中央。
4
POWER
TIMER
NANOE-G
POWERFUL/QUIET
裝入於兩側
1
按正面板的兩端
3
關閉
2
nanoe-G 產生器
每6 個月
• 使用乾棉花棒清洗。
• 運轉時切勿觸摸。
空氣濾塵網
每2 星期
• 用水輕輕清洗/冲洗濾塵網以免損
壞濾塵網的表層。
• 在陰凉處徹底弄乾濾塵網，遠離
火源或直射陽光。
• 請更換損壞的濾塵網。
取出空氣濾塵網 安裝空氣濾塵網
裝入主機
至於長期不使用時的換季檢查
• 檢查遙控器的電池。
• 確保室內機或室外機的空氣吸入或吹出口順
暢無阻。
• 運轉 15 分鐘後，在正常情況下，室內機空氣
吸入及吹出口的溫差為:
COOL(製冷): ≥8 °C
長期不使用時
• 啟動 nanoe-G 運轉 2 至3 小時是徹底排除留在
内部機件的濕氣，以防止微菌滋生。
• 關閉電源並拔出插頭。
• 取出遙控器的電池。
室內機
POWER
TIMER
NANOE-G
POWERFUL/QUIET
鋁片正面板
空氣濾塵網
nanoe-G 產生器

11
中文
故障檢修
以下現象並非表示故障。
現象 原因
室內機散發出霧氣。 • 製冷導致冷凝現象。
運轉時，聽見類似流水聲。 • 機內製冷劑流動的聲音。
室內有異味。 • 這可能是牆壁、地毯、家具或衣物散發出來的氣味。
在自動風量設定中，室內風扇時開時停。 • 這是為了排除周圍所發出的異味。
重新啟動後，運轉延遲幾分鐘。 • 此延遲用於保護本機壓縮機。
室外機滴水/蒸氣。 • 這是配管表面水蒸氣冷凝或蒸發的現象。
TIMER(定時器)的指示燈一直亮。 • 一旦設定後，定時預約設定會每天重覆操作。
運轉時發出吱嗄噪聲。 • 温度變化造成主機膨脹或收縮。
在進行维修之前請先檢查以下各項。
現象 檢查
在COOL(製冷)模式運轉時無法有效地操作。 •
設定正確溫度。
• 關上所有房門及窗戶。
• 清洗或更換濾塵網。
• 移除阻擋空氣吸入或吹出口的任何阻礙物。
運轉時產生噪音。 • 檢查是否装斜了主機。
• 妥善關閉正面板。
遙控器不操作。
(顯示屏變暗或傳輸信號微弱。)
• 正確地安装電池。
• 更換微弱的電池。
本機不能啟動。 • 檢查是否是電流斷路器跳開了。
• 檢查是否已設定預約時間。
本機沒有從遙控器收到信號。 • 確認接收器不受阻礙。
• 某種類型的螢光燈可能會影響訊號接收。請諮詢授權經
銷商。
不可維修的情況
若出現以下情況，請關閉電源並拔出插頭，然後諮詢授權經銷商:
• 運轉時發出異常噪音。
• 有水/異物進入遙控器。
• 室內機漏水。
• 電源斷路器經常跳閘。
• 電線異常發熱。
• 開關鈕或按鈕不能正常操作。
清洗說明 / 故障檢修

12
Safety precautions
To prevent personal injury, injury to others
or property damage, please comply with the
following:
Incorrect operation due to failure to follow
instructions below may cause harm or damage,
the seriousness of which is classified as below:
WARNING
This sign warns of
death or serious
injury.
CAUTION
This sign warns of
injury or damage to
property.
The instructions to be followed are classified by
the following symbols:
This symbol denotes an
action that is PROHIBITED.
These symbols denote
actions COMPULSORY.
WARNING
Indoor unit and outdoor unit
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
Please consult authorised dealer or specialist to
clean the internal parts, repair, install, remove
and reinstall the unit. Improper installation and
handling will cause leakage, electric shock or fire.
Confirm with authorised dealer or specialist on
usage of any specified refrigerant type.
Using refrigerant type other than the specified
may cause product damage, burst and injury etc.
Do not install the unit in a potentially explosive
or flammable atmosphere. Failure to do so could
result in fire.
Do not insert your fingers or other
objects into the air conditioner indoor or
outdoor unit, rotating parts may cause
injury.
Do not touch the outdoor unit during lightning, it
may cause electric shock.
Do not expose yourself directly to cold air for a
long period to avoid excess cooling.
Do not sit or step on the unit, you may
fall down accidentally.
Remote control
Do not allow infants and small children to play
with the remote control to prevent them from
accidentally swallowing the batteries.
Power supply
Do not use a modified cord,
joint cord, extension cord or
unspecified cord to prevent
overheating and fire.
To prevent overheating, fire or electric shock:
• Do not share the same power outlet with other
equipment.
• Do not operate with wet hands.
• Do not over bend the power supply cord.
• Do not operate or stop the unit by inserting or
pulling out the power plug.
Indoor unit
Outdoor unit
Power supply
Remote control
Air inlet
Air inlet
Air inlet
Air inlet
Air outlet
Air outlet
Air outlet
Air outlet

13
English
If the supply cord is damaged, it must be
replaced by the manufacturer, service agent
or similarly qualified persons in order to avoid
a hazard.
It is strongly recommended to be installed
with Earth Leakage Circuit Breaker (ELCB)
or Residual Current Device (RCD) to prevent
electric shock or fire.
To prevent overheating, fire or electric shock:
• Insert the power plug properly.
• Dust on the power plug should be
periodically wiped with a dry cloth.
Stop using the product if any abnormality/
failure occurs and disconnect the power plug
or turn off the power switch and breaker.
(Risk of smoke/fire/electric shock) Examples
of abnormality/failure
• The ELCB trips frequently.
• Burning smell is observed.
• Abnormal noise or vibration of the unit is
observed.
• Water leaks from the indoor unit.
• Power cord or plug becomes abnormally hot.
• Fan speed cannot be controlled.
• The unit stops running immediately even if it
is switched on for operation.
• The fan does not stop even if the operation
is stopped.
Contact your local dealer immediately for
maintenance/repair.
Replacement or installation of power plugs
shall be performed by authorized/qualified
personnel only. The wires in this mains lead
are coloured in accordance with the following
code:
Terminals
Red
wires
live
neutral
earth
colours (GB Standard)
blue
green-yellow
brown
Black
Green/Yellow
Wiring colour may vary depending on a
country wiring code’s standard.
This equipment must be earthed to prevent
electrical shock or fire.
Prevent electric shock by switching off the
power supply and unplug:
- Before cleaning or servicing,
- When extended non-use, or
- During abnormally strong lightning activity.
CAUTION
Indoor unit and outdoor unit
Do not wash the indoor unit with water,
benzine, thinner or scouring powder to avoid
damage or corrosion at the unit.
Do not use for preservation of precise
equipment, food, animals, plants, artwork
or other objects. This may cause quality
deterioration, etc.
Do not use any combustible equipment in front
of the airflow outlet to avoid fire propagation.
Do not expose plants or pet directly to airflow
to avoid injury, etc.
Do not touch the sharp aluminium
fin, sharp parts may cause injury.
Do not switch ON the indoor unit when waxing
the floor. After waxing, aerate the room
properly before operating the unit.
Do not install the unit in oily and smoky areas
to prevent damage to the unit.
Do not dismantle the unit for cleaning purpose
to avoid injury.
Do not step onto an unstable bench when
cleaning the unit to avoid injury.
Do not place a vase or water container on the
unit. Water may enter the unit and degrade the
insulation. This may cause an electric shock.
Do not open window or door for long time
during COOL/DRY mode operation.
Prevent water leakage by ensuring drainage
pipe is:
- Connected properly,
- Kept clear of gutters and containers, or
- Not immersed in water
After a long period of use or use with any
combustible equipment, aerate the room
regularly.
After a long period of use, make sure the
installation rack does not deteriorate to
prevent the unit from falling down.
Remote control
Do not use rechargeable (Ni-Cd) batteries. It
may damage the remote control.
To prevent malfunction or damage of the
remote control:
• Remove the batteries if the unit is not going
to be used for a long period of time.
• New batteries of the same type must be
inserted following the polarity stated.
Power supply
Do not disconnect the plug by pulling the cord
to prevent electric shock.
Safety precautions

MODE
POWERFUL/
QUIET
TEMP
OFF/ON
NANOE-G
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
SET CLOCK
FAN SPEED
RESET
TEMP
O
FF/
ON
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
CL
O
C
K
F
Remote control display
V9PKA-2, V12PKA-2
Press and hold for
approximately
10 seconds to show
temperature setting in
°C or °F.
Press to restore the
remote control to
default setting.
Not used in normal
operations.
14
MODE
To select operation mode
AUTO - For your convenience
• Unit selects the operation mode according to
the room temperature.
• Once AUTO mode is selected, the unit will
operate at the standard setting temperature.
Room
temperature
Operation
mode
Standard setting
temperature
23˚C & above COOL 25˚C
Below 23˚CDRY 22˚C
• Press for “HI” to +2˚C or for “LO” to
-2˚C to the standard setting temperature.
COOL - To enjoy cool air
• To reduce power consumption during COOL
mode, use curtains to screen off sunlight and
outdoor heat.
DRY - To dehumidify the environment
• Unit operates at low fan speed to give a gentle
cooling operation.
POWERFUL/
QUIET
To switch between
powerful & quiet
QUIETPOWERFUL NORMAL
POWERFUL: To reach temperature quickly
POWERFUL
• This operation will stop automatically after 15
minutes.
QUIET: To enjoy quiet operation
QUIET
• This operation reduces airflow noise.
FAN SPEED
To select fan speed
(Remote control display)
• For AUTO, the indoor fan speed is automatically
adjusted according to the operation mode.
How to use
Indicator
POWER
TIMER
NANOE-G
POWERFUL/QUIET
(Green)
(Orange)
(Blue)
(Orange/
Green)
To adjust horizontal airflow direction
• Manually adjustable.
Auto OFF/ON button
Use when remote control is
misplaced or a malfunction
occurs. Raise the front panel:
• To use in AUTO mode, press
the button once.
• To use in COOL mode, press
and hold the button until 1 beep
is heard, then release.
•
Press the button again to turn
off.

15
English
To set the timer
To turn ON or OFF the unit at a preset time.
TIMER
SET
CANCEL
ON
OFF
123
C
AN
C
E
L
3
21 3
1Select ON or OFF
timer
Example:
OFF at 22:00
OFF
OFF
TIMER
2Set the time
2
OFF
TIMER
3Confirm SET
OFF
TIMER
TIMER
• To cancel ON or OFF timer, press ON or OFF
then press CANCEL.
• If timer is cancelled manually or due to power
failure, you can restore the previous setting
(once power is resumed) by pressing SET .
• When ON Timer is set, the unit may start
earlier (up to 15 minutes) before the actual
set time in order to achieve the desired
temperature on time.
• Timer operation is based on the clock set in
the remote control and repeats daily once set.
For clock setting, please refer to Quick guide.
NANOE-G
To purify the air
NANOE-G
• nanoe-G starts automatically when the unit is
turned on with
OFF/ON
.
• Can be activated even when the unit is turned
off. In this condition, the unit will operate as a fan
with AUTO fan speed and louver swing.
To deactivate viruses/bacteria on the filter
NANOE-G
POWER
• Depending on the unit’s accumulated operation
time, nanoe-G in-filter deactivation may activate
only once a day after the unit turned off.
• To remove the moisture left in the internal parts,
the fan will operate for 30 minutes with louver
opened slightly. This process only applicable
when the unit is operated in COOL/DRY mode
before turned off. Then, nanoe-G deactivates
viruses/bacteria on the filter for 2 hours with fan
stopped and louver closed.
• Do not turn off the power supply during this
operation. After power failure, this operation will
not resume.
• To disable this operation in the future, press and
hold
NANOE-G
until a short beep sound is heard. This
will not disable the nanoe-G to purify the air.
• To restore the nanoe-G in-filter deactivation, press
and hold
NANOE-G
until a long beep sound is heard.
AIR SWING
To adjust vertical airflow
direction
(Remote control display)
• Keeps the room ventilated.
• In COOL/DRY mode, if AUTO is set, the louver
swings up/down automatically.
• Do not adjust the louver by hand.
Note
POWERFUL
/
QUIET
,
NANOE-G
• Can be activated in all modes and can be
cancelled by pressing the respective button again.
POWERFUL
/
QUIET
• Cannot be selected at the same time.
Operation conditions
Use this air conditioner under the following
temperature range.
DBT : Dry bulb temperature
WBT : Wet bulb temperature
Temperature (°C) Indoor Outdoor
DBT WBT DBT WBT
COOL Max. 32 23 43 26
Min. 16 11 16 11
How to use

16
MODE
To select operation mode
AUTO - For your convenience
• Unit selects the operation mode according to
the room temperature.
• Once AUTO mode is selected, the unit will
operate at the standard setting temperature.
Room
temperature
Operation
mode
Standard setting
temperature
23˚C & above COOL 25˚C
Below 23˚CDRY 22˚C
• Press for “HI” to +2˚C or for “LO” to
-2˚C to the standard setting temperature.
COOL - To enjoy cool air
• To reduce power consumption during COOL
mode, use curtains to screen off sunlight and
outdoor heat.
DRY - To dehumidify the environment
• Unit operates at low fan speed to give a gentle
cooling operation.
POWERFUL/
QUIET
To switch between
powerful & quiet
QUIETPOWERFUL NORMAL
POWERFUL: To reach temperature quickly
POWERFUL
• This operation will stop automatically after 15
minutes.
QUIET: To enjoy quiet operation
QUIET
• This operation reduces airflow noise.
FAN SPEED
To select fan speed
(Remote control display)
• For AUTO, the indoor fan speed is automatically
adjusted according to the operation mode.
How to use
Indicator
POWER
TIMER
NANOE-G
POWERFUL/QUIET
(Green)
(Orange)
(Blue)
(Orange/
Green)
Auto OFF/ON button
Use when remote control is misplaced or a malfunction occurs. Raise the front panel:
• To use in AUTO mode, press the button once.
• To use in COOL mode, press and hold the button until 1 beep is heard, then release.
• Press the button again to turn off.
MODE
POWERFUL/
QUIET
TEMP
OFF/ON
TIMER
SET
CANCEL
ON
OFF
123
AIR SWING
FAN SPEED
SET CLOCK
FAN
SPEED
AIR
SWING
AUTO
COOL
DRY
NANOE-G
RESET
TEMP
O
FF/
ON
TIMER
S
ET
C
AN
C
E
L
ON
O
FF
1
2
3
CL
O
C
K
F
V18PKA-2, V24PKA-2
Remote control display
Press and hold for
approximately
10 seconds to show
temperature setting in
°C or °F.
Press to restore the
remote control to
default setting.
Not used in normal
operations.

17
English
NANOE-G
To purify the air
NANOE-G
• nanoe-G starts automatically when the unit is
turned on with
OFF/ON
.
• Can be activated even when the unit is turned
off. In this condition, the unit will operate as a fan
with AUTO fan speed and louver swing.
To deactivate viruses/bacteria on the filter
NANOE-G
POWER
• Depending on the unit’s accumulated operation
time, nanoe-G in-filter deactivation may activate
only once a day after the unit turned off.
• To remove the moisture left in the internal parts,
the fan will operate for 30 minutes with louver
opened slightly. This process only applicable
when the unit is operated in COOL/DRY mode
before turned off. Then, nanoe-G deactivates
viruses/bacteria on the filter for 2 hours with fan
stopped and louver closed.
• Do not turn off the power supply during this
operation. After power failure, this operation will
not resume.
• To disable this operation in the future, press and
hold
NANOE-G
until a short beep sound is heard. This
will not disable the nanoe-G to purify the air.
• To restore the nanoe-G in-filter deactivation, press
and hold
NANOE-G
until a long beep sound is heard.
A
IR SWING
To adjust airflow direction
(Remote control display)
• Keeps the room ventilated.
• In COOL/DRY mode, if AUTO is set, the louver
swings left/right and up/down automatically.
• Do not adjust the louver by hand.
Note
POWERFUL
/
QUIET
,
NANOE-G
• Can be activated in all modes and can be
cancelled by pressing the respective button again.
POWERFUL
/
QUIET
• Cannot be selected at the same time.
Operation conditions
Use this air conditioner under the following
temperature range.
DBT : Dry bulb temperature
WBT : Wet bulb temperature
Temperature (°C) Indoor Outdoor
DBT WBT DBT WBT
COOL Max. 32 23 43 26
Min. 16 11 16 11
To set the timer
To turn ON or OFF the unit at a preset time.
TIMER
SET
CANCEL
ON
OFF
123
C
AN
C
E
L
3
21 3
1Select ON or OFF
timer
Example:
OFF at 22:00
OFF
2Set the time
2
3Confirm SET
TIMER
• To cancel ON or OFF timer, press ON or OFF
then press CANCEL.
• If timer is cancelled manually or due to power
failure, you can restore the previous setting
(once power is resumed) by pressing SET .
• When ON Timer is set, the unit may start
earlier (up to 15 minutes) before the actual
set time in order to achieve the desired
temperature on time.
• Timer operation is based on the clock set in
the remote control and repeats daily once set.
For clock setting, please refer to Quick guide.
How to use

18
Cleaning instructions
To ensure optimal performance of the unit,
cleaning has to be carried out at regular
intervals. Please consult authorised dealer.
• Switch off the power supply and unplug before
cleaning.
• Do not touch the aluminium fin, sharp parts may
cause injury.
• Do not use benzine, thinner or scouring powder.
• Use only soap ( pH 7) or neutral household
detergent.
• Do not use water hotter than 40 °C.
Indoor unit
Wipe the unit gently with a soft,
dry cloth.
Front panel
Wash gently and dry.
Remove the front panel
POWER
TIMER
NANOE-G
POWERFUL/QUIET
Raise
Pull out
1
2
Close it securely
For CS-V18PKA-2, CS-V24PKA-2:
Press at center of the front panel.
4
POWER
TIMER
NANOE-G
POWERFUL/QUIET
Insert at
both sides
1
Press both ends of
the front panel
3
Close down
2
nanoe-G Generator
Every 6 months
• Clean with dry cotton bud.
• Do not touch during operation.
Air filters
Every 2 weeks
• Wash/rinse the filters gently
with water to avoid damage to
the filter surface.
• Dry the filters thoroughly under shade, away
from fire or direct sunlight.
• Replace any damaged filters.
Remove air filter Attach air filter
Insert into the unit
For seasonal inspection after extended
non-use
• Checking of remote control batteries.
• No obstruction at air inlet and air outlet vents.
• After 15 minutes of operation, it is normal to
have the following temperature difference
between air inlet and air outlet vents:
COOL: ≥8 °C
For extended non-use
• Activate nanoe-G operation for 2~3 hours as an
alternative to remove moisture left in the internal
parts thoroughly to prevent mould growth.
• Turn off the power supply and unplug.
• Remove the remote control batteries.
POWER
TIMER
NANOE-G
POWERFUL/QUIET
Aluminium finFront panel
Air filters
Indoor unit
nanoe-G
Generator

19
English
The following symptoms do not indicate malfunction.
Symptom Cause
Mist emerges from indoor unit. • Condensation effect due to cooling process.
Water flowing sound during operation. • Refrigerant flow inside the unit.
The room has a peculiar odour. • This may be due to damp smell emitted by the wall,
carpet, furniture or clothing.
Indoor fan stops occasionally during automatic
fan speed setting.
• This helps to remove the surrounding odour.
Operation is delayed a few minutes after
restarting.
• The delay is a protection to the unit’s compressor.
Outdoor unit emits water/steam. • Condensation or evaporation occurs on pipes.
TIMER indicator is always on. • The timer setting repeats daily once set.
Cracking sound during operation. • Changes of temperature caused the expansion/
contraction of the unit.
Check the following before calling for servicing.
Symptom Check
Operation in COOL mode is not working
efficiently.
• Set the temperature correctly.
• Close all doors and windows.
• Clean or replace the filters.
• Clear any obstruction at the air inlet and air outlet vents.
Noisy during operation. • Check if the unit has been installed at an incline.
• Close the front panel properly.
Remote control does not work.
(Display is dim or transmission signal is weak.)
• Insert the batteries correctly.
• Replace weak batteries.
The unit does not work. • Check if the circuit breaker is tripped.
• Check if timers have been set.
The unit does not receive the signal from the
remote control.
• Make sure the receiver is not obstructed.
• Certain fluorescent lights may interfere with signal
transmitter. Please consult authorised dealer.
NON SERVICEABLE CRITERIAS
TURN OFF POWER SUPPLY AND UNPLUG then please consult authorised dealer under the following
conditions:
• Abnormal noise during operation.
• Water/foreign particles have entered the remote
control.
• Water leaks from Indoor unit.
• Circuit breaker switches off frequently.
• Power cord becomes unnaturally warm.
• Switches or buttons are not functioning properly.
Troubleshooting
Cleaning instructions / Troubleshooting

F569395
FT0513-0
Printed in Malaysia
Panasonic Corporation
Website: http://panasonic.net/
© Panasonic Corporation 2013
信息/Information
中文
關於用戶回收與丟棄舊設備及電池的信息
[非歐共體國家的處理信息]
這些符號僅有效於歐洲共同體。如果您
要丟棄這些物件，請諮詢您的當地政府
或經銷商並詢問正確的丟棄方式。
Pb
電池符號的注意事項（底部兩個符號舉
例）:
此符號可與化學符號綜合使用。
在此情況下，它須符合制定給該化學的
使用條件。
English
Information for Users on Collection and Disposal of Old Equipment and used Batteries
[Information on Disposal in other
Countries outside the European
Union]
These symbols are only valid in the
European Union. If you wish to discard
these items, please contact your local
authorities or dealer and ask for the
correct method of disposal.
Pb
Note for the battery symbol (bottom
two symbol examples):
This symbol might be used in
combination with a chemical symbol.
In this case it complies with the
requirement set by the Directive for the
chemical involved.
