Panasonic CW-C182KF-W User manual

1 Product Specifications 2
2 Dimensions 3
3 Wiring Diagram 4
4 Refrigeration Cycle Diagram 6
5 Air Conditioner Performance Evaluation 6
6 Troubleshooting Guide 6
7 Operating Instructions 8
CW-C182KF-W
CW-C242KF
CW-C182KF-M
10
9 Care and Maintenance 14
10 Service Information 15
11 Technical Data 16
12 Exploded View 17
13 Replacement Part List 18
Room Air Conditioner
CONTENTS
Page Page
OrderNo. RAC0312002C3
8 How to Install
CW-C183KF-W
CW-C243KF
CW-C183KF-M
PRECAUTION OF LOW TEMPERATURE
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigeration circuit.
©2004 Matsushita Electric Industrial Co. Ltd.
All rights reserved. Unauthorizedcopying and distrib-
ution is aviolation of law.

1 Product Specifications
Model CW-C182KF-W/M
CW-C183KF-W/MCW-C242KF
Phase Single Single
Voltage 220 - 240 V 220 - 240 V
Frequency 50 Hz 50 Hz
Capacity 5.33 -5.40 kW
18,200 -18,400 Btu/h 6.95 - 7.10 kW 23,700 - 24,200 Btu/h
Running Current 9.7 A-9.7A 13.7 - 13.9 A
Input Power 2.02 - 2.12 kW 2.81 - 2.98 kW
EER 2.64 - 2.55 W/W 2.47 - 2.38 W/W
Starting Current 55 A 67 A
Noise Level Indoor (High / Low): 51 - 52 / 47 - 48 dB(A)
Outdoor (High / Low): 58 - 59 / 54 - 55 dB(A) Indoor (High / Low): 57 - 58 / 54 - 55 dB(A) Outdoor (High / Low): 63 - 64 / 60 - 61 dB(A)
Fan Motor Output 110 W 190 W
Compressor Output 1.5 kW 2.0 kW
Moisture Removal 2.9 Ltr/h
6.1 Pint/h 4.0 Ltr/h 8.5 Pint/h
Air Circulation 14.0 -14.5 m
3
/min.
490 - 510 Ft3/min. 17.4 -18.0 m
3
/min.
610 -630 Ft3/min.
Dimensions Height: 16-7/8 inches (428 mm)
Width: 26 inches (660 mm)
Depth: 30-11/32 inches (770 mm)
Height: 16-7/8 inches (428 mm)
Width: 26 inches (660 mm)
Depth: 30-11/32 inches (770 mm)
Net Weight 71.5 kg
158 Ib
Refrigerant (R-22) 880 g
31 oz 1100 g 38.8 oz
Note: Specifications are subject to change without notice for further improvement.
2
70 kg
155 Ib
CW-C243KF
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

2 Dimensions
Unit: Inch (mm)
2.1. Top View, Front View & Side View.
2.2. Unit.
CW-C183KF-W,CW-C183KF-M,CW-C243KF
A - Width 26” (660)
B-Height 16-7/8” (428)
C - Depth 30-11/32” (770)
D1-31/32” (50)
E8-25/32” (223)
F 10-1/4” (260)
G9-11/32” (237)
H12-25/32” (325)
I7-15/32” (190)
J10-1/32” (255)
K3-5/32” (80)
L 12-15/32” (317)
M 10-11/32” (263)
N1-21/32” (42)
O 12-7/16” (316)
P2-25/32” (70)
Q 12-7/32” (310)
R7-15/32” (190)
2.2. Unit.
3
Item
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M
CW-C182KF-W,CW-C182KF-M,CW-C242KF

3 Wiring Diagram
3.1.1. Resistance of Fan Motor windings
and the rated Capacitor.
CW-C182KF-W/M
CW-C183KF-W/M
Connection CJ110A
Main Resistance 30.8-46.2 Ω
Aux Resistance 28.1-42.1 Ω
Capacitor CWR33010009
(7µF, 450VAC)
3.1.2. Resistance of Compressor
windings and the rated Capacitor.
CW-C182KF-W/M
CW-C183KF-W/M
Connection 2JS318D4AA02
Main Resistance 1.247 Ω
Aux Resistance 2.358 Ω
Capacitor CWR33010744
(45µF, 450VAC)
Note: Resistance at 20°C of Ambient Temperature.
3.1. CW-C182KF-W/M, CW-C183KF-W/M.
4
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

3.2.1. Resistance of Fan Motor windings
and the rated Capacitor.
CW-C242 (243) KF
Connection CJ190A
Main Resistance 15.7-23.5 Ω
Aux Resistance 27.4-41.0 Ω
Capacitor CWR33010024
(6µF, 450VAC)
3.2.2. Resistance of Compressor
windings and the rated Capacitor.
CW-C242 (243) KF
Connection 2JS438D4DA02
Main Resistance 0.844 Ω
Aux Resistance 3.082 Ω
Capacitor CWR33000001
(50µF, 440VAC)
Note: Resistance at 20°C of Ambient Temperature.
3.2. CW-C242KF,CW-C243KF.
5
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

A
B
C
D
Note: Indoor temperature at 27°C (DB), 19°C (WB) and Outdoor at
35°C (DB), 24°C (WB) for Cooling.
4 Refrigeration Cycle Diagram
5 Air Conditioner Performance Evaluation
Intake & Discharge Air
Temperature Difference Current Drain Determination Remedy
• 8°C and over (14.4°F) • As specified. • Nothing wrong. • None.
• 8°C and over (14.4°F) • Higher than specified. • Nothing wrong, outdoor
temperature is too high, heat
radiation is not efficient.
• Improve heat radiation.
• Under 8°C (14.4°F) • Higher than specified. • Something is preventing heat
radiation. • Excessive amount of refrigerant.
• Improve heat radiation.
• Under 8°C (14.4°F) • Lower than specified. • Leakage of refrigerant or
refrigerant system is blocked. • Locate and repair leak.
• Flush refrigeration cycle.
• Under 8°C (14.4°F) • Higher than specified by
50%. • Compressor defect or compressor capacitor defect. • Replace the compressor or compressor capacitor.
Note: Room air humidity is relatively higher, the temperature difference will be smaller.
6 Troubleshooting Guide
Warning: Disconnect unit from electrical power supply before making any electrical checks.
Trouble Check Result Cause Remedy
Fan Motor and
Compressor won’t run. • Supply Voltage
• Fuse Box or Circuit
Breaker.
• Power cord or
Wiring Harness.
• Thermostat Setting.
• Less than 10% by
Rated.
• Open Contacts.
• Pulled loose or
Shorted.
• Higher than room
temp.
• Temporary or Permanent?
• Customer Restarted unit
immediately without waiting
3 minutes.
• Consult ELECTRICIAN, If
permanent.
• Repair Open Circuit.
• WAIT FOR 3 MINUTES.
• Repair or Replace it.
• Set it LOWER.
Fan Motor won’t run
(Compressor run). • Objects around
Fan.
• RESISTANCE
between Wires.
• Capacitor Fan
Motor.
• Main Control
Switch.
• Locked Fan.
• Shorted / Open
circuit.
• OHM Meter doesn’t
Deflect.
• No contacts at
Position Shown.
• Fan Hitting Cowling or
• Foreign Materials.
• Frozen Bearings.
• Shorted or Burned out.
• Capacitor Defect.
• Main Control Switch defect.
• Adjust Fan position setting
screw.
• Remove Foreign Materials.
• Replace Fan Motor.
• Replace Fan Motor.
• Replace Capacitor Fan.
• Replace Main Control
Switch.
Compressor won’t run
(Fan run). • Thermostat setting.
• RESISTANCE
between Terminal
and the
Compressor Body.
• RESISTANCE
between Terminals.
• Overload Protector.
• Capacitor
Compressor.
• Thermostat.
• Main Control
Switch.
• Higher than room
temp.
• Shorted.
• Shorted.
• Infinity between
Terminals.
• OHM Meter doesn’t
deflect.
• No click heard.
• No contacts at
Position Shown.
• Winding Coil touched to the
compressor shell.
• Rear Shorted or Burnt out.
• Overload Protector defect.
• Capacitor defect.
• Thermostat defect.
• Main Control Switch defect.
• Set it lower.
• Replace Compressor.
• Replace Compressor.
• Replace Overload
Protector.
• Replace Capacitor
Compressor.
• Replace Thermostat.
• Replace Main Control
Switch.
6
CW-C182 (183) KF-W/M
CW-C242 (243) KF
Pressure
(MPa) Temperature (°C) Pressure (MPa) Temperature (°C)
2.09 ~ 2.19 64 ~ 83 2.23 ~ 2.30 72 ~ 88
1.94 ~ 2.04 38 ~ 48 2.01 ~ 2.16 35 ~ 45
0.54 ~ 0.63 8 ~ 12.5 0.52 ~ 0.56 6.5 ~ 10.5
0.48 ~ 0.54 5.5 ~ 13.5 0.50 ~ 0.54 4~12
Item
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

Trouble Check Result Cause Remedy
Air Swing won’t run. • Air Swing Switch.
• Resistance between
wires.
• OFF position.
• No contact at
position.
• OHM Meter doesn’t
deflect.
• Open circuit.
• Shorted or open circuit.
• Set it ON.
• Replace Air Swing Switch.
• Replace Air Swing Motor.
Insufficient cooling. • Thermostat Setting.
• Ventilation door
open.
• Air filter dirty.
• Location of
installation.
• Evaporator /
Condenser Coil
obstructed.
• Unit capacity for the
room too small.
• Temp difference
and running current.
• Higher than room
temp.
• Open.
• Clogged or dirty.
• Sunlight hitting
outdoor side.
• Obstacles.
• Clogged or dirty.
• Not satisfied.
• REFER TO
PERFORMANCE
EVALUATION.
• Reduces capacity.
• Restricted air circulation.
• Restricted Heat Exchanger.
• Restricted Heat Exchanger.
• Restricted air circulation.
• Leakage of refrigerant or
refrigeration system is
blocked.
• Set it lower.
• Close Vent. door.
• Clean or replace Air Filter.
• Consider building an
AWNING.
• Remove obstacles or
reinstall unit.
• Clean the coils.
• Replace the unit with
bigger one.
• Locate repair leak.
• Flush refrigeration cycle.
Noise. • Source of Noise • Vibration.
• Intermittent Noise.
• Faulty installation.
• Fan hitting objects.
• Refrigerant tubing touching
each other.
• Reinstall unit or Reinforce
the installation.
• Adjust Fan position or
remove foreign materials.
• About 1/2” Clearance
needed.
Water dripping inside
room. • Unit installation.
• Drain Tray-
Styrofoam pieces
blocking drain
channel.
• Tilted to inside room.
• Clogged.
• Restricted run off.
• Clogged or blocked.
• Tilt unit to outside slightly.
• Remove the foreign
materials.
Frozen Evaporator • Thermostat setting.
• Air filter /
Evaporator.
• Temp. difference
and running current.
• Set too low for
ambient conditions.
• Clogged or Dirty.
• REFER TO
PERFORMANCE
EVALUATION.
• Outdoor temp. low (Night
time).
• Restricted air circulation.
• Leakage of refrigerant or
refrigeration system is
blocked.
• Set the Main Control Knob
to Fan to melt ice and set
the Temp. Control to higher
temperature.
• Clean Air filter /
Evaporator.
• Locate and repair leak.
• Flush refrigeration cycle.
7
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

7.1.1. Vertical Airflow Direction Vane.
7.1.2. Ventilation Lever.
When the slide lever is in the:
• “OPEN” position, the ventilation door
opens to allow air, smoke or odours to be
expelled from the room.
• “CLOSE” position, the ventilation door is
closed and the air will be circulated inside
the room and conditioned.
7.1.3. Recommended.
Use the air conditioner under the following conditions:
• When humidity does not exceed 90% and room
temperature is above 21°C.
− Continuous operation at humidities of over 90% may
cause condensation to form on the intake and outlet
vanes.
7 Operating Instructions
7.1. Parts Identification.
8
$LUIORZ GLUHFWLRQ DGMXVWPHQW 8SDQG'RZQ
• ••
• 7KH YHUWLFDO DLUIORZ GLUHFWLRQ YDQH LV
FRQWUROOHG E\ SRVLWLRQLQJ WKH YDQH WR
GLVFKDUJH WKH DLU XSZDUGV GRZQZDUGV
RU VWUDLJKW RXW
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

7.2. How to Operate.
(1) Open the Control Panel Cover.
Fig. 1
(2) Power Supply
Switch off the breaker and set the Main Control Knob to the
OFF position before connecting the power plug cord to an
independent power supply.
Fig. 2
(3) Main Control Knob
Set the Main Control Knob to either Super Quiet, High Cool
or Super Cool as desired, FAN setting operates the fan
only.
Caution: If the Main Control Knob is turned off or
changed to a fan setting from a cooling operation
setting, WAIT at least 3 minutes before resetting to
cooling operation.
Fig. 3
(4) Thermostat Control Knob
Turn the Thermostat Control Knob as shown in Fig. 4.
Usually “6” ~ “7” is the recommended setting position.
Note: When the Thermostat Control Knob is set to “10”,
moisture may freeze onto the evaporator fins and prevent
effective cooling. If this happens, turn the Main Control
Knob to FAN, and the Thermostat Control Knob
counterclockwise. This will quickly defrost the evaporator
fins so that normal cooling can be resumed. Fig.4
(5) Air Swing Switch
(Airflow direction adjustment side-to-side)
To obtain a fixed airflow direction, set the Air Swing Switch
to “ON” for the vanes to swing from side to side until the
desired flow direction is reached, then switch it to “OFF”.
For continuous side-to-side air circulation, set the Air Swing
Switch to “ON”.
Fig. 5
9
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

8 How to Install
8.1. Before installing the air conditioner, please read the following:
8.1.1. Electrical Work.
• Always use at the rated voltage and with a specific air conditioning circuit.
• Power supply point shall be the place where there is ease for the power disconnection in case of emergency.
• Some installation locations may require installation of a short-circuit breaker.
• Time delay fuse or circuit breakerrating is 16 Amp. forCW-C182 (183) KF-W/Mand 25 Amp. for CW-C242 (243) KF.
• Nominal cross sectional area of power supply wire must be 3core x2.0 mm2or above (CW-C182KF-W/M,CW-C183KF-W/M )
and 3core x3.5 mm2or above (CW-C242KF,CW-C243KF).
• The power supply must be from an independent circuit.
• All electrical installations must be made in accordance with local wiring and safety regulations wherever applicable.
• There must be a double pole switch with minimum of 3 mm contact gap in the fixed installation circuit (Applicable for models
without power supply plug only).
8.1.2. Select the Best Location.
• Install the unit at the nearest power outlet.
• The air conditioner should be installed in a dry place where there are no draughts.
• Condensation from the air conditioner must be drained into an appropriate location.
• Do not install in a location where flammable gas leaks is a possibility.
• Usage in locations where the air is salty such as coastal areas or near hot spas, or where sulphurous gas is generated, may
lead to a malfunction.
• Do not install this appliance in a laundry room or other locations where water may drip from the ceiling, etc.
• Select an installation location which is rigid and strong enough to support or hold the unit and select a location for easy
maintenance.
8.2. Preparation for Installation.
• There should not be any obstacles surrounding the unit.
• Prepare an installation hole that is only slightly bigger than the cabinet size.
10
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M




86OLGHWKH&KDVVLVRXWIURPWKH
&DELQHW
83ODFH&DELQHWLQWRWKHLQVWDOODWLRQ
KROH WKHQ VHFXUH LW ZLWK ZRRG
VFUHZV RU QDLOV
• ••
• 1RWH 7LOW GRZQ IRU EHWWHU GUDLQDJH PD[  PP
8/RFNWKH&KDVVLVWRWKH&DELQHW
UHXVLQJ WKH &KDVVLV /RFNLQJ
%UDFNHW DQG VFUHZ
8$WWDFKWKH)URQW*ULOOHWRWKH
&DELQHW DQG IDVWHQ LW ZLWK VFUHZV
• ••
• 1RWH 'HSHQGLQJ XSRQ WKH ORFDWLRQ RI WKH $& RXWOHW URXWH
WKH $& FRUG WR HLWKHU WKH OHIW RU ULJKW VLGH ZKLOH LQVWDOOLQJ WKH
)URQW *ULOOH
8,QVWDOODWLRQ3URFHGXUHV
1
8.3.1. Remove the Chassis Locking
Bracket and screws.
• Unscrew and remove the Chassis Locking Bracket from the
front of the Cabinet. Remove the two screws from the rear
of the Cabinet (For transportation purpose only).
8.3.4. Slide the Chassis back into the
Cabinet.
CW-C183KF-W /CW-C243KF/CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

8,QVHUWWKH$LU)LOWHU



85HPRYHWKH)URQW,QWDNH*ULOOH
• ••
• 5DLVH WKH )URQW ,QWDNH *ULOOH E\ DSSUR[LPDWHO\  6OLGH LW
WR WKH OHIW WR XQKLQJH WKHQ SXOO RXWZDUGV
85HPRYDORIWKH)URQW*ULOOH
2
85HPRYHWKH)URQW*ULOOH
a2SHQWKH&RQWURO3DQHOFRYHU
:KHQ SHUIRUPLQJ WKH IROORZLQJ VWHSV GR QRW SXOO WKH ERWWRP
HGJH RI WKH )URQW *ULOOH WRZDUGV \RX PRUH WKDQ  LQFKHV RU
\RX PD\ GDPDJH WKH WRS WDEV
b3UHVVLQZDUGRQWKH&DELQHWQHDUWKHERWWRPULJKWVLGHRI
WKH )URQW *ULOOH ZKLOH SXOOLQJ WKH )URQW *ULOOH WR WKH ULJKW WKHQ
VOLJKWO\ WRZDUGV \RX WR UHOHDVH WKH ULJKW WDE
c3UHVVLQZDUGRQWKH&DELQHWQHDUWKHERWWRPOHIWVLGHRIWKH
)URQW *ULOOH ZKLOH SXOOLQJ WKH )URQW *ULOOH WR WKH OHIW WKHQ
VOLJKWO\ WRZDUGV \RX WR UHOHDVH WKH OHIW WDE
d6OLGHWKH)URQW*ULOOHXSZDUGVWRUHOHDVHWKHWZRWRSWDEV
85HPRYHWKH$LU)LOWHU
• ••
• /LIW WKH DLU ILOWHU E\ WKH KROGHU DQG SXOO RXWZDUGV
8$WWDFKWKH)URQW,QWDNH*ULOOH
• ••
• 6OLGH WKH )URQW ,QWDNH *ULOOH VOLJKWO\ WR WKH ULJKW WR DWWDFK LW
WKHQ SXVK GRZQ WR VHFXUH LW
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

13
5 Slide the chassis back into the cabinet
3 Install the drain pan
ÒÒÒÒÒ
EXTERNALVIEW
Screws
Drain pan Drain hose
Bottom side view
with drain pan.
Install the drain pan
at the right corner
of the cabinet.
Ò
4 Connect the drain hose
INTERNALVIEW
2 Remove the rubber plug from the base pan
Transferring
• Repositioning or transfer of the air conditioner due to renovation or moving requires an additional service charge.Please
consult your dealer before moving.
Note: Drain hose or tubing can be purchased locally to satisfy your particular needs.
• Ò
Rubber plug
1 Slide the chassis out from the cabinet
13
8.5.CondensedWater Drainage
This air conditioner employs a “Slinger-Up System” which is designed to splash the condensed water on the condenser coil for
maximum cooling efficiency,thus producing a splashing sound. If the splashing sound annoys you, you can provide an outside
drainage by using the following procedure which may, however, cause a small loss of performance.
Note:
If the unit is installed at coastal area,drainage of condensed water is recommended to prevent the condenser being corroded easily.
±±±±≤≤
≤≤
≤
¥¥¥¥
µµµµ
12

 9DFXXP WKH IURQW RI WKH ILOWHU DQG WKHQ ZDVK WKH EDFN RI LW
ZLWK ZDWHU ,I LW LV EDGO\ VRLOHG ZDVK ZLWK D PLOG KRXVHKROG
GHWHUJHQW
9&OHDQLQJWKH)URQW,QWDNH
*ULOOH
*HQWO\ ZDVK ZLWK ZDWHU DQG D VSRQJH 'R QRW XVH D VFUXEELQJ
EUXVK RU RWKHU KDUG FOHDQLQJ DLGV
9&OHDQLQJWKH8QLW
&OHDQ WKH &DELQHW )URQW *ULOOH ZLWK D PLOG VRDS RU GHWHUJHQW
DQG OXNHZDUP ZDWHU
9&OHDQLQJWKH$LU)LOWHU
 5HPRYH WKH )URQW ,QWDNH *ULOOH
 7LOW XS DQG SXOO RXW WKH $LU )LOWHU E\ WKH KROGHU
1RWH 'R QRW FOHDQ ZLWK EHQ]HQH WKLQQHU VFRXULQJ SRZGHU RU FRUURVLYH FKHPLFDOV 'R QRW GU\ WKH )URQW ,QWDNH *ULOOH RU
WKH $LU )LOWHU LQ GLUHFW VXQOLJKW ([SRVXUH WR GLUHFW VXQOLJKW PD\ GLVFRORU RU GHIRUP WKH SDQHO
9&DUHDQG0DLQWHQDQFH
&DXWLRQ$OZD\VWXUQRIIWKHDLUFRQGLWLRQHUDQGWKHPDLQSRZHUVXSSO\EHIRUHXQSOXJJLQJWKHSRZHUFRUGWRFOHDQWKH
XQLW
14
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

1.Remove the Front Intake Grille (refer to page 12).
2.Remove the Air Filter (refer to page 12).
3.Remove the Front Grille (refer to page 12).
4.Remove the 2 knobs.
5.Take off the Control Panel.
6.Release the thermostat sensor from the sensor holder.
7.Loosen the 3 screws of the Control Board.
8.Slide the Control Board out from the chassis.
Control Board Part Location
10 Service Information
10.1. Removal of the Control Board
15
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

11.2.1. CW-C182KF-W, CW-C182KF-M.
11.2.1.1. Cooling Characteristics Vs.
Outdoor Temperature.
11.2.2. CW-C242KF,CW-C243KF.
11.2.2.1. Cooling Characteristics Vs.
Outdoor Temperature.
11 Technical Data
11.1. Thermostat Characteristics.
11.1.1. CW-C182KF-W/M, CW-C183KF-W/M,CW-C242KF, CW-C243KF.
11.1.1.1. Mechanical Thermostat.
11.2. Operation Characteristics.
16
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M
CW-C183KF-W, CW-C183KF-M.

12 Exploded View
(Note)
• The above exploded view is for the purpose of parts disassembly and replacement.
• The non-numbered parts are not kept as standard service parts.
17
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M

Part Name &Description Qty. CW-C182KF-W CW-C183KF-W CW-C242KFCW-C243KF
100 Base Pan Complete 1CWR012116021
101 Bulkhead Complete 1CWR01231606 <---- <----
102 Air Guide - Propeller Fan 1CWR01231603 <---- <----
103 Bracket - Fan Motor 1CWR01701605 <---- <----
106 Top Plate 1CWR01251601 <----
109 Drain Tray - Evaporator 1CWR12411007 <---- <---- <----
112 Discharge Grille Complete 1CWR01441601 <---- <---- <----
116 Connecting Bar - Air Swing Vanes 1CWR10581602 <---- <---- <----
117 Vane - Air Swing 2CWR10511601 <---- <---- <----
120 Blower Wheel Complete 1CWR10311602 <---- <---- <----
121 Propeller Fan 1CWR10331601 <---- <---- <----
122 Nut - Propeller Fan 1CWR70310126 <---- <---- <----
123 Control Board (Aux.1) 1CWR01221601 <---- <---- <----
124 Holder - Capacitor (Compressor) 1CWR01241601 <---- <---- <----
125 Control Board (Main) 1CWR01411601
128 Holder - Sensor 1CWR26271276
129 Drain Plug - Base Pan 1CWR76711012
130 Chassis Locking Bracket 1CWR01211601 <---- <---- <----
131 Ventilation Lever 1CWR10581605 <---- <---- <----
135 Air Guide - Blower Wheel 1CWR12101602 <---- <---- <----
144 Air Guide - Blower Wheel (Front) 1CWR01231604 <---- <---- <----
145 Rectification Plate 1CWR12311601 <---- <---- <----
146 Inflectional Aixs 1CWR10561601 <---- <----
202 Nut - Compressor Mount 3CWR70310014<---- <---- <----
210 Condenser 1CWR01101605 CWR01101604
211 Strainer 1CWR07211106
212 Capillary Tube 1CWR03001809 CWR03001807
300Fan Motor 1CWR15011502 CWR15011603
302Capacitor - Fan Motor 1CWR33010009 CWR33010024
303Capacitor - Compressor 1CWR33010744 CWR33000001 <----
3041CWR45010312
306
Main Control Switch
1CWR45020104
308Thermostat 1CWR45040014 <---- <---- <----
310 Terminal Board 1CWR42011147
311Power Supply Cord 1CWR40020486 CWR400204861
312Air Swing Motor 1CWR15211006 <---- <---- <----
500 Front Grille Complete 1CWR20001603 <---- <---- <----
502Grille Door 1CWR20161601 <---- <---- <----
503Intake Grille 1CWR20001602 <---- <---- <----
505Vane 14CWR10511602 <---- <---- <----
507Link - Vanes 1CWR10581604 <---- <---- <----
508 Control Panel 1CWR20161603 <---- <---- <----
509Knob Complete - Turning 2CWR45031125 <---- <---- <----
600 Cabinet Complete 1CWR01431603
610 Drain Pan 1CWR20181801 <---- <---- <----
702 Screw - Bracket Fan Motor 4CWR70140032 <---- <----
703 Screw - Blower Wheel 1CWR70110028 <---- <---- <----
707Screw - Front Grille Mount (3 Screws) 1CWR70140362 <---- <----
710 Screw - Drain Pan (2 Screws) 1CWR70140561 <---- <---- <----
711 Screw - Chassis Locking Bracket 1CWR70140561 <---- <---- <----
712Screw - Unit Installation (4 Screws) 1CWR70140234 <----
715Operating Instructions 1CWR66121277 <---- <---- <----
200 Compressor 12JS318D4AA02 <----
<----
<----
<----
<----
<----
<---- <----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<---- <----
2JS438D4DA02
Ref. No.
Evaporator
220 1
<----<----
<----
1<----
<----
<----
<----
Switch -Air Swing
501 Air Filter
CWR01001603
1CWR111200021
18
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M
<----
<----<----
<----
<----
<---- <----<----
<----<----
<----
<----
<----
<---- <----<----
<----
<----
<----
<----
<----
<----
<----
<----
13 Replacement Part List
13.1. CW-C182(183)KF-W, CW-C242(243)KF.

Ref. No. Part Name & Description Qty.
100 Base Pan Complete 1
101 Bulkhead Complete 1
102 Air Guide - Propeller Fan 1
103 Bracket - Fan Motor 1
106 Top Plate 1
109 Drain Tray - Evaporator 1
112 Discharge Grille Complete 1
116 Connecting Bar - Air Swing Vanes 1
117 Vane - Air Swing 2
120 Blower Wheel Complete 1
121 Propeller Fan 1
122 Nut - Propeller Fan 1
123 Control Board (Aux.1) 1
124 Holder -Capacitor (Compressor) 1
125 Control Board (Main) 1
128 Holder - Sensor 1CWR26271276
129 Drain Plug - Base Pan 1CWR76711012
130 Chassis Locking Bracket 1CWR01211601
131 Ventilation Lever 1CWR10581605
135 Air Guide - Blower Wheel 1CWR12101602
144 Air Guide -Blower Wheel (Front) 1CWR01231604
145 Rectification Plate 1CWR12311601
200 Compressor (fittings) 12JS318D4AA02
<----
202 Nut -Compressor Mount 3
210 Condenser 1
CWR01001603
211 Strainer 1
CWR15011502
212 Capillary Tube 1
220 Evaporator
1
300 Fan Motor
1
302 Capacitor -Fan Motor 1CWR33010009
303 Capacitor - Compressor
304 Main Control Switch 1CWR45010312
306 Switch - Air Swing 1CWR45020104
308 Thermostat 1CWR45040014
310 Terminal Board 1CWR42011147
311 Power Supply Cord 1CWR40020486
312 Air Swing Motor 1CWR15211006
500 Front Grille Complete 1CWR20001802
501 Air Filter 1CWR111200021 <----
502 Grille Door 1CWR20161601 <----
503 Intake Grille 1CWR20001602 <----
505 Vane 14 CWR10511602 <----
507 Link -Vanes 1CWR10581604 <----
508 Control Panel 1CWR20161603 <----
509 Knob Complete - Turning 2CWR45031125 <----
600 Cabinet Complete 1CWR01431603
610 Drain Pan 1CWR20181801 <----
Screw -Bracket Fan Motor 4CWR70110028 <----
Screw -Blower Wheel 1
CWR70140362 <----
Screw -Front Grille Mount (3Screws) 1
CWR70140561 <----
Screw -Drain Pan (2 Screws) 1
CWR70140561 <----
Screw -Chassis Locking Bracket 1
CWR70140234 <----
Screw -Unit Installation (4 Screws) 1
Operating Instructions
CWR70140032








<----
CW-C182KF-M CW-C183KF-M
CWR012116021
CWR01231606
CWR01231603
CWR01701605
CWR01251601
CWR12411007
CWR01441601
CWR10581602
CWR10511601
CWR10311602
CWR10331601
CWR70310126
CWR01221601
CWR01241601
146 Inflectional axis
<----
1CWR10561601
CWR01101605
CWR07211106
CWR03001809
CWR33010744
<----
<----
<----
<----
CWR70310014
<----
<----
<----
CWR01411601
<----
<----
<----
<----
<----
1CWR66121277
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
1
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
<----
711
702
703
707
712
710
715
1
<----
19
<----
<----
<----
13.2. CW-C182KF-M, CW-C183KF-M.
CW-C183KF-W /CW-C243KF /CW-C183KF-M
CW-C182KF-W /CW-C242KF /CW-C182KF-M
• The above parts are kept for seven years in accordance with MEI service policy.
• However, longer lead time will be taken in supplying the non-numbered parts.
• Allparts are suppliedfrom China (VendorCode: 20614027).

20 Printed in China
