Panasonic R410A User manual

– VRF System Air Conditioner –
■ R410A Models
Model No.
Indoor Units
Type Indoor
Unit Type
Rated Capacity
36 45 56 73 106 140
T2 Ceiling S-36MT2E5A S-45MT2E5A S-56MT2E5A S-73MT2E5A S-106MT2E5A S-140MT2E5A
ENGLISH
Read through the Installation Instructions before you proceed with the installation.
In particular, you will need to read under the “IMPORTANT!” section at the top of the page.
FRANÇAIS
Lisez les instructions d’installation avant de commencer l’installation.
En particulier, vous devez lire la section “IMPORTANT!” en haut de la plage.
ESPAÑOL
Lea las Instrucciones de instalación antes de proceder con la instalación del equipo.
En concreto, deberá leer detenidamente la sección “¡IMPORTANTE!” situada al principio de la página.
DEUTSCH
Lesen Sie die Einbauanleitung, bevor Sie mit der Installation beginnen.
Insbesondere die Hinweise im Abschnitt “WICHTIG!” oben auf der Seite müssen unbedingt gelesen werden.
ITALIANO
Leggere le Istruzioni di installazione prima di procedere con l’installazione.
Prestare particolare attenzione alla sezione “IMPORTANTE!” all’inizio della pagina.
NEDERLANDS
Lees de installatie-instructies zorgvuldig door voor u begint met de installatie.
U moet vooral het gedeelte waar “BELANGRIJK!” boven staat heel goed lezen.
PORTUGUÊS
Leia cuidadosamente as instruções de instalação antes de prosseguir com a instalação.
Em particular, é necessário ler as informações na secção “IMPORTANTE!” na parte superior da página.















for Refrigerant R410A
INSTALLATION INSTRUCTIONS
F616392
II_F616392_EU_L.indb 1 2013-12-16 15:24:36

2
IMPORTANT!
Please Read Before Starting
This air conditioner must be installed by the sales dealer
or installer.
This information is provided for use only by authorized
persons.
For safe installation and trouble-free operation, you must:
● Carefully read this instruction booklet before beginning.
● Follow each installation or repair step exactly as shown.
● This air conditioner shall be installed in accordance with
National Wiring Regulations.
● Pay close attention to all warning and caution notices
given in this manual.
WARNING
This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.
CAUTION
This symbol refers to a hazard or unsafe
practice which can result in personal injury
or product or property damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help for a
special problem, contact our sales/service outlet or your
certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
SPECIAL PRECAUTIONS
WARNING
WARNING When Wiring
Risk of Electric Shock
WARNING
ELECTRICAL SHOCK CAN
CAUSE SEVERE PERSONAL
INJURY OR DEATH. ONLY A
QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD
ATTEMPT TO WIRE THIS
SYSTEM.
• Do not supply power to the unit until
all wiring and tubing are completed or
reconnected and checked.
• Highly dangerous electrical voltages are
used in this system.
Carefully refer to the wiring diagram and
these instructions when wiring. Improper
connections and inadequate grounding
can cause accidental injury or death.
• Connect all wiring tightly. Loose wiring
may cause overheating at connection
points and a possible fire hazard.
• Provide a power outlet to be used
exclusively for each unit.
• Provide a power outlet exclusively for
each unit, and full disconnection means
contact separation in all poles must
be incorporated in the fixed wiring in
accordance with the wiring rules.
• To prevent possible hazards from
insulation failure, the unit must be
grounded.
When Transporting
Be careful when picking up and moving
the indoor and outdoor units. Get a partner
to help, and bend your knees when lifting
to reduce strain on your back. Sharp
edges or thin aluminum fins on the air
conditioner can cut your fingers.
When Installing…
Select an installation location which is
rigid and strong enough to support or hold
the unit, and select a location for easy
maintenance.
…In a Room
Properly insulate any tubing run inside a
room to prevent “sweating” that can cause
dripping and water damage to walls and
floors.
WARNING
CAUTION Keep the fire alarm and
the air outlet at least
1.5 m away from the unit.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete
blocks to provide a solid, level foundation
for the outdoor unit. This prevents water
damage and abnormal vibration.
…In an Area with High Winds
Securely anchor the outdoor unit down
with bolts and a metal frame. Provide a
suitable air baffle.
…In a Snowy Area (for Heat Pump-type
Systems)
Install the outdoor unit on a raised platform
that is higher than drifting snow. Provide
snow vents.
…In laundry rooms
Do not install in laundry rooms. Indoor unit
is not drip proof.
II_F616392_EU_L.indb 2 2013-12-16 15:24:37

3
ENGLISH
When Connecting Refrigerant Tubing
WARNING
WARNING
• When performing piping
work do not mix air except
for specified refrigerant
(R410A) in refrigeration
cycle. It causes capacity
down, and risk of
explosion and injury due
to high tension inside the
refrigerant cycle.
• Refrigerant gas leakage
may cause fire.
• Do not add or replace
refrigerant other than
specified type. It may
cause product damage,
burst and injury, etc.
• Ventilate the room well, in the event
that is refrigerant gas leaks during
the installation. Be careful not to allow
contact of the refrigerant gas with a
flame as this will cause the generation
of poisonous gas.
• Keep all tubing runs as short as
possible.
• Use the flare method for connecting
tubing.
• Apply refrigerant lubricant to the
matching surfaces of the flare and union
tubes before connecting them, then
tighten the nut with a torque wrench for
a leak-free connection.
• Check carefully for leaks before starting
the test run.
• Do not leak refrigerant while piping work
for an installation or re-installation, and
while repairing refrigeration parts.
Handle liquid refrigerant carefully as it
may cause frostbite.
When Servicing
• Turn the power OFF at the main
power box (mains) before opening
the unit to check or repair electrical
parts and wiring.
• Keep your fingers and clothing away
from any moving parts.
• Clean up the site after you finish,
remembering to check that no metal
scraps or bits of wiring have been left
inside the unit being serviced.
WARNING
WARNING
• This product must not be
modified or disassembled
under any circumstances.
Modified or disassembled
unit may cause fire,
electric shock or injury.
• Do not clean inside
the indoor and outdoor
units by users. Engage
authorized dealer or
specialist for cleaning.
• In case of malfunction
of this appliance, do not
repair by yourself. Contact
the sales dealer or service
dealer for repair.
WARNING
CAUTION
• Do not touch the air
inlet or the sharp
aluminum fins of the
outdoor unit. You may get
injured.
•
Ventilate any enclosed
areas when installing or
testing the refrigeration
system. Escaped refrigerant
gas, on contact with fire
or heat, can produce
dangerously toxic gas.
• Confirm after installation
that no refrigerant gas is
leaking. If the gas comes
in contact with a burning
stove, gas water heater,
electric room heater or
other heat source, it can
cause the generation of
poisonous gas.
Others
WARNING
CAUTION
• Do not sit or step on
the unit, you may fall
down accidentally.
• Do not touch the air
inlet or the sharp
aluminum fins of the outdoor
unit. You may get injured.
• Do not stick any
object into the FAN
CASE.
You may be injured
and the unit may be
damaged.
NOTICE
The English text is the original instructions. Other
languages are translations of the original instructions.
II_F616392_EU_L.indb 3 2013-12-16 15:24:38

4
IMPORTANT! ...................................... 2
Please Read Before Starting
1. GENERAL ...................................... 5
1-1. Tools Required for Installation (not supplied)
1-2. Accessories Supplied with Unit
1-3. Type of Copper Tube and Insulation Material
1-4. Additional Materials Required for Installation
2. SELECTING THE INSTALLATION SITE . . . . . . . . . . . . . . 6
2-1. Indoor Unit
3. HOW TO INSTALL THE INDOOR UNIT . . . . . . . . . . . . . . . 7
■ Ceiling Type (T2 Type) ............................. 7
3-1. Required Minimum Space for Installation and Service
3-2. Preparation Before Installation
3-3. Suspending the Indoor Unit
3-4. Duct for Fresh Air
3-5. Shaping the Tubing
3-6. Installing the Drain Pipe
4. ELECTRICAL WIRING ........................... 11
4-1. General Precautions on Wiring
4-2. Recommended Wire Length and Wire Diameter
for Power Supply System
4-3. Wiring System Diagrams
5. HOW TO PROCESS TUBING . . . . . . . . . . . . . . . . . . . . . 15
5-1. Connecting the Refrigerant Tubing
5-2. Connecting Tubing Between Indoor and
Outdoor Units
5-3. Insulating the Refrigerant Tubing
5-4. Taping the Tubes
5-5. Finishing the Installation
6. FINAL PROCEDURE ............................ 17
7. HOW TO INSTALL TIMER REMOTE CONTROLLER
OR HIGH-SPEC WIRED REMOTE CONTROLLER
(OPTIONAL PART) ............................. 17
N OT E
Refer to the Operating Instructions attached to the optional
Timer Remote Controller or optional High-spec Wired Remote
Controller.
8. HOW TO INSTALL WIRELESS REMOTE
CONTROLLER RECEIVER . . . . . . . . . . . . . . . . . . . . . . . 17
N OT E
Refer to the Operating Instructions attached to the optional
Wireless Remote Controller Receiver.
9. APPENDIX .................................... 18
■ Care and Cleaning
■ Troubleshooting
■ Tips for Energy Saving
IMPORTANT INFORMATION REGARDING THE
REFRIGERANT USED ...........................20
Page Page
CONTENTS
II_F616392_EU_L.indb 4 2013-12-16 15:24:39

5
ENGLISH
1. GENERAL
This booklet briefly outlines where and how to install the
air conditioning system. Please read over the entire set of
instructions for the indoor and outdoor units and make sure all
accessory parts listed are with the system before beginning.
1-1. Tools Required for Installation (not supplied)
1. Flathead screwdriver
2. Phillips head screwdriver
3. Knife or wire stripper
4. Tape measure
5. Carpenter’s level
6. Sabre saw or keyhole saw
7. Hacksaw
8. Core bits
9. Hammer
10. Drill
11. Tube cutter
12. Tube flaring tool
13. Torque wrench
14. Adjustable wrench
15. Reamer (for deburring)
1-2. Accessories Supplied with Unit
The accessory parts are supplied inside the indoor unit.
Open the air-intake grille of the indoor unit and take out a
package of accessories.
See the section “3-2. Preparation Before Installation”.
Table 1-1 ( Ceiling )
Part Name Figure Q’ty Remarks
Special
washer 4For temporarily
suspending indoor unit
from ceiling
Drain insulator 2 For drain hose joint
Flare insulator
1 For gas tube joint
1 For liquid tube joints
Clamper 6For flare insulator and
wiring
Full-scale
installation
diagram 1For positioning
installation
Drain hose 1For main unit + PVC pipe
joints
Hose band 1For drain hose
connection
Side cover (R) 1(Packed in carton box)
For right side
Side cover (L) 1(Packed in carton box)
For left side
Screw 2 For side cover (L/R)
Operating
Instructions 1
Installation
Instructions 1
1-3. Type of Copper Tube and Insulation Material
If you wish to purchase these materials separately from a local
source, you will need:
1. Deoxidized annealed copper tube for refrigerant tubing.
2. Foamed polyethylene insulation for copper tubes as
required to precise length of tubing. Wall thickness of the
insulation should be not less than 8 mm.
3. Use insulated copper wire for field wiring.
Wire size varies with the total length of wiring.
Refer to 4. ELECTRICAL WIRING for details.
CAUTION
Check local electrical codes and regulations before
obtaining wire.
Also, check any specified instructions or limitations.
1-4. Additional Materials Required for Installation
1. Refrigeration (armored) tape
2. Insulated staples or clamps for connecting wire (See your
local codes.)
3. Putty
4. Refrigeration tubing lubricant
5. Clamps or saddles to secure refrigerant tubing
6. Scale for weighing
II_F616392_EU_L.indb 5 2013-12-16 15:24:41

6
2. SELECTING THE INSTALLATION SITE
2-1. Indoor Unit
AVOID:
● areas where leakage of flammable gas may be expected.
● places where large amounts of oil mist exist.
● direct sunlight.
● locations near heat sources which may affect the
performance of the unit.
● locations where external air may enter the room directly.
This may cause “condensation” on the air discharge ports,
causing them to spray or drip water.
● locations where the remote controller will be splashed with
water or affected by dampness or humidity.
● installing the remote controller behind curtains or furniture.
● locations where high-frequency emissions are generated.
DO:
● select an appropriate position from which every corner of the
room can be uniformly cooled.
● select a location where the ceiling is strong enough to
support the weight of the unit.
● select a location where tubing and drain pipe have the
shortest run to the outdoor unit.
● allow room for operation and maintenance as well as
unrestricted air flow around the unit.
● install the unit within the maximum elevation difference
above or below the outdoor unit and within a total tubing
length (L) from the outdoor unit as detailed in the Installation
Instructions packed with the outdoor unit.
● allow room for mounting the remote controller about 1 m off
the floor, in an area that is not in direct sunlight or in the flow
of cool air from the indoor unit.
Ceiling
Ceiling
Wall
Front view
min. 25 cm min. 25 cm
N OT E
The rear of the indoor unit can be installed flush against
the wall.
Air intake
Air
discharge
min. 50 cm
Side view Max. 25 cm
Obstacle
Fig. 2-1
II_F616392_EU_L.indb 6 2013-12-16 15:24:42

7
ENGLISH
(2) Refrigerant tubing • drain hose position
39
39
90 90
86
187
267
267
196
196
131
70
216
Fig. 3-2
Rear (Figure shows view from front)Left side
Left drain position
Closed with rubber stopper
at time of shipment.
Left drain position Right drain position
(Liquid tubing •
Gas tubing)
Right side
Gas tubing
Liquid tubing
Right drain position
(3) Unit opening position (Refrigerant tubing • drain hose • power inlet port • remote control wiring inlet port)
74
R50
*1
*1
*1
*2 88
104
*1
90
61
120
123
123
114 104
185
131
196
105
Left-side drain hose
outlet port
Top outlet port
Right-side drain
hose outlet port
Side cover
Outside air intake duct
connection port
(ø100, cutout)
Rear outlet port (Figure shows view from front)
Remote control wiring
and inter-unit wiring inlet port
Left-rear side drain
hose outlet port
(cutout)
Cover of tubing hole
Power inlet port
*1 Use a compass saw, jig saw or similar tool and cut along
the indented portion of the side cover and make a hole
inside the cover.
*2 When removing the refrigerant tubing from the upper
side, cut along the indented portion and pass the tubing
through the hole.
N OT E
Be sure to use sealing putty to seal off the opening to
prevent dust.
Fig. 3-3
3. HOW TO INSTALL THE INDOOR UNIT
■ Ceiling Type (T2 Type)
3-1. Required Minimum Space for Installation and
Service
(1) Dimensions of suspension bolt pitch and unit
Length
Type ABC
36, 45, 56 911 960 235
73 1226 1275 235
106, 140 1541 1590 235
Unit: mm
Fig. 3-1
A
265
190
24.5 24.5
B
690
C
Air intake
Air discharge
(Suspension bolt pitch)
(Suspension
bolt pitch)
Unit: mm
Unit: mm
Unit: mm
II_F616392_EU_L.indb 7 2013-12-16 15:24:45

8
3-2. Preparation Before Installation
(1) Remove the bracket (for suspending the indoor unit).
Loose the M8 suspension bolts.
Then remove the bracket. (Fig. 3-4)
N OT E
Loosen the M8 suspension bolts and expose the axis of
bolts less than 8 mm.
M4 screw for preventing
bracket from taking off
M8 suspension bolts for
suspending the indoor unit
Bracket
Less than 8 mm
Fig. 3-4
(2) Remove the air-intake grille before suspending the indoor
unit. First, remove 2 attachment screws fixed with the
latches. Open the air-intake grille and hold the claws of
the hinges on both sides. Then remove the air-intake grille
and suspension lug located on the left and right side of the
indoor unit.



1
1
2
Slide
Latch
claws
Screw
Air-intake grille
Fig. 3-5
Air-intake grille
Remove
Remove
Fig. 3-6
(3) Remove the side plate to the tubing side.
Rear & upper side
tubing connection
Remove 2 screws.
Slide the side plate in the direction of
the arrow and remove it.
Right side tubing
connection Do not remove the side plate.
Remove
Screw
Side plate
Fig. 3-7
(4) Remove the center bracket.
When wiring, remove the center bracket if necessary.
When wiring is completed, reinstall the center bracket in its
original position.
Center bracket
Fig. 3-8
3-3. Suspending the Indoor Unit
N OT E
Since the diagram is made of paper, it may shrink or stretch
slightly because of high temperature or humidity. For this
reason, before drilling the holes maintain the correct dimensions
between the markings.
(1) If the full-scale installation diagram is placed on the ceiling,
the locations of each suspension bolt can be chosen.
Take a pencil and mark the drill holes (Fig. 3-9).
Full-scale installation diagram
Ceiling
Wall
Full-scale installation diagram
Fig. 3-9
(2) If the full-scale installation diagram is bent at right angle
to the ceiling and wall, the locations of the inlet for indoor
tubing and wiring are chosen and the locations of each
suspension bolt can also be chosen.
Take a pencil and mark the drill holes (Fig. 3-10).
Full-scale installation diagram
Ceiling
Wall
Full-scale installation diagram
Fig. 3-10
N OT E
The dimension when the indoor unit is placed tightly
against the wall.
When installing away from the wall, drainage gradient
should be taken into consideration.
(3) Drill holes at the 4 points indicated on the full-scale
diagram.
(4) Depending on the ceiling type:
a) Insert suspension bolts (Fig. 3-11).
or
b) Use existing ceiling supports or construct a suitable
support (Fig. 3-12).
Hole-in-anchor
Hole-in-plug
Suspension bolt (M10 or 3/8”)
(not supplied)
Insert
Ceiling tiles
Ceiling support
Concrete
Fig. 3-11 Fig. 3-12
II_F616392_EU_L.indb 8 2013-12-16 15:24:52

9
ENGLISH
WARNING
It is important that you use extreme care in supporting
the indoor unit from the ceiling. Ensure that the ceiling is
strong enough to support the weight of the unit. Before
hanging the ceiling unit, test the strength of each attached
suspension bolt.
(5) Screw in the suspension bolts, allowing them to protrude
from the ceiling (Figs. 3-11 and 3-12).
The distance of each exposed bolt must be of equal length
within 50 mm. (Fig. 3-13)
Ceiling surface
Within 50 mm
Unit
Bracket
Fig. 3-13
(6) Carry out the preparation for suspending the indoor unit.
The suspension method varies depending on whether
there is a suspended ceiling or not. (Figs. 3-14 and 3-15)
(7) Suspend the indoor unit as follows:
a) Install the bracket to the suspension bolt.
Stick it onto the ceiling surface. (Fig. 3-14~3-16)
Bracket
Suspension bolt
(not supplied)
Ceiling surface
Unit
Washer (supplied)
Double nut
(not supplied)
Fig. 3-14
Suspension bolt
(not supplied)
Washer
(not supplied)
Unit
Washer (supplied)
Double nut
(not supplied)
Fig. 3-15
Suspension bolt
Double nut
(not supplied)
Washer
(supplied)
Ceiling
surface
Approx. 25 mm
Fig. 3-16
b) Suspend the indoor unit to the bracket.
Tighten the M8 suspension bolts and fix the indoor unit
in place. (Fig. 3-17)
M4 screw for preventing
bracket from taking off
M8 suspension bolts
M8 suspension bolt
Fig. 3-17
N OT E
The ceiling surface is not always level. Confirm that the indoor
unit is evenly suspended. For the installation to be correct,
leave a clearance of about 10 mm between the ceiling panel
and the ceiling surface and fill the gap with an appropriate
insulation or filler material.
3-4. Duct for Fresh Air (Field supply)
There is a outside air intake duct connection port (cut out hole)
at the left-rear of the indoor unit for drawing in fresh air. If it is
necessary to draw in fresh air, remove the cover by opening
the hole and connecting the duct to the indoor unit through the
connection port. (Refer to Fig. 3-3)
3-5. Shaping the Tubing
● The positions of the refrigerant tubing connections are
shown in the figure below. (The tubing can be routed in
3 directions.) (Fig. 3-18)
* When routing the tubing out through the top or right sides,
cut out the cover of the top panel and cut notches in the side
panel (Refer to fig. 3-3).
Fig. 3-18
If the tubing is to be routed out
together, use a box cutter or
similar tool to cut out the part
of the cover indicated by
the marked area (Fig. 3-19),
to match the positions of the tubes.
Then draw out the tubing. Fig. 3-19
3-6. Installing the Drain Pipe
● Prepare hard PVC pipe for the drain and connect it to the
indoor unit drain pipe with the supplied hose band to prevent
water leaks.
● Measure the thickness of the wall from the inside to the
outside and cut PVC pipe at a slight angle to fit. Insert the
PVC pipe in the wall. (Fig. 3-21)
Cover
II_F616392_EU_L.indb 9 2013-12-16 15:24:55

10
N OT E
The hole should be made at a slight downward slant to the
outside.
Indoor
side Outdoor
side
Fig. 3-20
INSIDE
hard PVC pipe (not supplied)
Cut at slight angle
PVC pipe
Slight
angle
Wall OUTSIDE
Fig. 3-21
(1) Drain hose connection
● The drain hose is connected below the refrigerant tubing.
(2) Installing the drain hose
●
First insert the drain hose (supplied) to the hose band
(supplied) and then install the drain hose to the unit drain port.
● Insert until the drain hose bumps to the end.
●
Attach the hose band to make the fixed portion 45°upper
gradient according to a vinyl tape (not supplied) of the drain
hose (supplied). (Fig. 3-23)
● Hose band screw torque is 30 - 35N · cm.
● Wind the vinyl tape not to blow up the hose band.
● Connect both the drain hose and PVC pipe (VP20 or similar
material, not supplied). Insert until the PVC pipe bumps to
the end and adhere with PVC adhesive.
CAUTION
● Wrap the drain insulator (supplied) between the
connection of the drain hose and tubing not to expose
the copper tubing. Also, wrap the hose band together.
Wrap the hose band with the drain insulator, where
the screw is located facing upward (Fig. 3-23). Then,
tighten the insulator with a vinyl tape not to cause
the detachment. If the tubing parts remain exposed,
condensation may occur.
● Be sure to use the supplied drain hose.
● If other commercially available hose bands are used, the
drain hose may become pinched or wrinkled and there is
danger of water leakage.
Therefore be sure to use the supplied hose bands.
● Connect the drain pipe so that it slopes downward from the
unit to the outside. (Fig. 3-22)
Correct Incorrect
Downward
slant:
min. 1/100 Upward slant:
Fig. 3-22
● Never allow water traps to occur in the course of the piping.
● Insulate any piping inside the room to prevent dripping.
● After the drain piping, pour an appropriate amount of water
into the drain pan through the opening on the side of the air
discharge port. Check the water draining smoothly.
* If the drain hose is routed through the left side, refer to
Fig. 3-18, and follow the procedure above to install the hose.
Reattach the rubber stopper removed earlier onto the right
side.
The rubber stopper can be inserted easily by using a
screwdriver or similar tool to
press the stopper into the
drain port on the main unit.
Press the stopper into the
main unit drain port as far
as it will go.
130
26 26
Hose band (supplied)
Do not use adhesive.
Adhere with PVC adhesive.
Hard PVC pipe
(VP20 not supplied)
Drain hose (supplied)
Unit drain port
Unit: mm
Drain insulator (supplied)
(
45°
)
Hose band
Vinyl tape
Drain insulator
Vinyl tape Drain insulator Hose band
Fig. 3-23
CAUTION
The indoor unit should be slightly tilted downward toward
the drain pipe connection side as shown in figure below
so that the wastewater can flow smoothly without being
trapped in the middle. (Fig. 3-24)
Ceiling
Approx. 1°
Approx. 2°
Ceiling
Diagonally right down (front view)
(Ex.: Diagonal-right-backwards)
Diagonally backward (side view)
Fig. 3-24
Rubber stopper
Screwdriver
Drain port
II_F616392_EU_L.indb 10 2013-12-16 15:24:57

11
ENGLISH
4. ELECTRICAL WIRING
4-1. General Precautions on Wiring
(1) Before wiring, confirm the rated voltage of the unit as
shown on its nameplate, then carry out the wiring closely
following the wiring diagram.
(2) Circuit breaker must be incorporated in the fixed wiring in
accordance with the wiring regulations. The circuit breaker
must be an approved 10-16 A, having a contact separation
in all poles.
(3) To prevent possible hazards from insulation failure, the unit
must be grounded.
(4) Each wiring connection must be done in accordance with
the wiring system diagram. Wrong wiring may cause the
unit to misoperate or become damaged.
(5) Do not allow wiring to touch the refrigerant tubing,
compressor, or any moving parts of the fan.
(6) Unauthorized changes in the internal wiring can be very
dangerous. The manufacturer will accept no responsibility
for any damage or misoperation that occurs as a result of
such unauthorized changes.
(7) Regulations on wire diameters differ from locality to
locality. For field wiring rules, please refer to your LOCAL
ELECTRICAL CODES before beginning.
You must ensure that installation complies with all relevant
rules and regulations.
(8) To prevent malfunction of the air conditioner caused by
electrical noise, care must be taken when wiring as follows:
● The remote control wiring and the inter-unit control wiring
should be wired apart from the inter-unit power wiring.
● Use shielded wires for inter-unit control wiring between units
and ground the shield on both sides.
(9) If the power supply cord of this appliance is damaged,
it must be replaced by a repair shop designated by the
manufacturer, because special-purpose tools are required.
CAUTION
Check local electrical codes and regulations before wiring.
Also, check any specified instruction or limitations.
4-2. Recommended Wire Length and Wire Diameter
for Power Supply System
Indoor unit
Type (B) Power supply Time delay fuse or
circuit capacity
2.5 mm2
T2 Max. 130 m 10-16 A
Control wiring
(C) Inter-unit
(between outdoor
and indoor units)
control wiring
(D) Remote control
wiring (E) Control wiring for group control
0.75 mm2
(AWG #18)
Use shielded wiring*
0.75 mm2
(AWG #18) 0.75 mm2 (AWG #18)
Max. 1,000 m Max. 500 m Max. 200 m (Total)
N OT E
* With ring-type wire terminal.
II_F616392_EU_L.indb 11 2013-12-16 15:24:57

12
4-3. Wiring System Diagrams
U2
U1
R2
R1
L
N
R2
R1
R2
R1
R2
R1
2
1
2
1
U2
U1
L
N
U2
U1
L
N
U2
U1
L
N
2
1
2
1
2
1
D
E
C
B
L
N
L
N
L
N
L
N
2
1
B
B
B
C
D
D
C
2
1
L1
L2
L3
N
2
1
L1
L2
L3
N
CL1
L2
L3
N
L1
L2
L3
N
U2
U1
Power supply
220/230/240V ~ 50/60 Hz
Remote
controller
Remote
controller
Remote
controller
WHT
BLK
WHT
BLK
WHT
BLK
Power supply
220/230/240V ~ 50/60 Hz
Power supply
220/230/240V ~ 50/60 Hz
Power supply
220/230/240V ~ 50/60 Hz
Ground
Ground
Ground
Ground
Ground
Ground
Inter-outdoor-unit control wiring
Ground
Ground Ground
Outdoor unit
INV unit
Power supply
380/400/415V, 3 N~, 50 Hz
Power supply
380/400/415V, 3 N~, 50 Hz
Outdoor unit
INV unit
Ground
Ground
Ground
Ground
Ground
Ground
Indoor unit
(No. 1)
Indoor unit
(No. 2)
Indoor unit
(No. n)
Indoor unit
(No. 3)
Group control:
ex.) MF2 Type
Fig. 4-1
N OT E
(1) Refer to Section 4-2. “Recommended Wire Length
and Wire Diameter for Power Supply System” for the
explanation of “B”, “C”, “D” and “E” in the above diagram.
(2) The basic connection diagram of the indoor unit shows the
terminal boards, so the terminal boards in your equipment
may differ from the diagram. (Fig. 4-2)
(3) Refrigerant Circuit (R.C.) address should be set before
turning the power on.
(4) Auto address setting can be executed by remote controller
automatically. Refer to the Installation Instructions supplied
with the remote controller (optional).
WARNING
This equipment must be properly earthed.
L N U1 U2 R1 R2
6P terminal board
T2 Type
Power
supply Remote control
line
Unit
control
line
Fig. 4-2
II_F616392_EU_L.indb 12 2013-12-16 15:24:57

13
ENGLISH
CAUTION
(1) When linking the outdoor units in a network, disconnect the terminal extended from the short plug from all outdoor units
except any one of the outdoor units.
(When shipping: In shorted condition.)
For a system without link (no wiring connection between outdoor units), do not remove the short plug.
(2) Do not install the inter-unit control wiring in a way that forms a loop. (Fig. 4-3)
Outdoor unit Outdoor unit Outdoor unit
Indoor unit Indoor unit Indoor unit Indoor unit
Prohibited
Prohibited
Indoor unit
Fig. 4-3
(3) Do not install inter-unit control wiring such as star branch wiring. Star branch wiring causes mis-address setting. (Fig. 4-4)
Outdoor unit Indoor unitIndoor unit
Indoor unitIndoor unit
NO
Branch point
Fig. 4-4
(4) If branching the inter-unit control wiring, the number of branch points should be 16 or fewer.
Central Controller
Outdoor unit
Outdoor unit
Indoor unit
Indoor unit
Indoor unit Indoor unit Indoor unit
Indoor unit Indoor unit
Indoor unit Indoor unit
Outdoor unit
: Branch point
More than 2m required
Fig. 4-5
(5) Use shielded wires for inter-unit control wiring (c) and
ground the shield on both sides, otherwise
misoperation from noise may occur. (Fig. 4-6)
Connect wiring as
shown in Section
“4-3. Wiring System
Diagrams”.
Fig. 4-6
(6) • Connecting cable between indoor unit and outdoor
unit shall be approved polychloroprene sheathed 5 or
3 *1.5 mm2 flexible cord. Type designation 60245 IEC
57 (H05RN-F, GP85PCP etc.) or heavier cord.
• Use the standard power supply cables for Europe
(such as H05RN-F or H07RN-F which conform to
CENELEC (HAR) rating specifications) or use the
cables based on IEC standard. (60245 IEC57, 60245
IEC66)
Shielded wire
Ground Ground
WARNING
Loose wiring may cause the terminal to overheat or result
in unit malfunction. A fire hazard may also occur. Therefore,
ensure that all wiring is tightly connected.
When connecting each power wire to the terminal, follow the
instructions on “How to connect wiring to the terminal” and
fasten the wire securely with the terminal screw.
II_F616392_EU_L.indb 13 2013-12-16 15:24:58

14
Stranded wire
Ring
pressure
terminal Screw and
Special washer
Ring
pressure
terminal
Terminal board
Ring pressure
terminal
Screw
Special
washer
Wire
Wire
Strip 10 mm
Fig. 4-7 Fig. 4-8
How to connect wiring to the terminal
■ For stranded wiring
(1) Cut the wire end with cutting pliers,
then strip the insulation to expose the
stranded wiring about 10 mm and
tightly twist the wire ends. (Fig. 4-7)
(2) Using a Phillips head screwdriver,
remove the terminal screw(s) on the
terminal board.
(3) Using a ring connector fastener or pliers,
securely clamp each stripped wire end
with a ring pressure terminal.
(4) Place the ring pressure terminal, and
replace and tighten the removed terminal
screw using a screwdriver. (Fig. 4-8)
■ Examples of shield wires
(1) Remove cable coat not to scratch braided shield. (Fig. 4-9)
(2) Unbraid the braided shield carefully and twist the
unbraided shield wires tightly together. Insulate the shield
wires by covering them with an insulation tube or wrapping
insulation tape around them. (Fig. 4-10)
(3) Remove coat of signal wire. (Fig. 4-11)
(4) Attach ring pressure terminals to the signal wires and the
shield wires insulated in Step (2). (Fig. 4-12)
Insulation tape
8 mm
Insulation tape
Shield mesh
Shield mesh
Fig. 4-9
Fig. 4-10
Fig. 4-11
Fig. 4-12
How to carry out power supply wiring
(1) Wiring connection ports
The power inlet port is located at the rear.
The remote control wiring inlet port is located at the rear (for
use with the wired remote controller). For details, refer to
Fig. 3-3.
(2) How to carry out wiring
● Insert the power wiring into the indoor unit through the
rubber at the side of the electrical component box.
● For wiring connection to the outdoor unit and remote
control wiring, open the elongated hole of the piping cover
and pass the wires through the hole.
N OT E
Be sure to use sealing putty to seal off the opening to
prevent dust.
■ Wiring
T2 type
Protective ground screw
Use this screw when connecting the shield
for the Inter-unit control wiring to ground.
Functional ground screw (Schedule Timer)
Inter-unit Control Wiring
Remote Control Wiring
Remote control wiring and inter-unit control wiring inlet port
* Insert the remote control wiring and
inter-unit control wiring into the electrical
component box from the inlet port as shown
in the figure. This is done regardless of
whether the wiring was inserted from the
top, rear, or left side of the main unit.
Power wiring
Clamp
Clamp
Power inlet port
II_F616392_EU_L.indb 14 2013-12-16 15:25:00

15
ENGLISH
5. HOW TO PROCESS TUBING
The liquid tubing side is connected by a flare nut, and the gas
tubing side is connected by brazing.
5-1. Connecting the Refrigerant Tubing
Use of the Flaring Method
Many of conventional split system air conditioners employ the
flaring method to connect refrigerant tubes that run between
indoor and outdoor units. In this method, the copper tubes are
flared at each end and connected with flare nuts.
Flaring Procedure with a Flare Tool
(1) Cut the copper tube to the required length with a tube
cutter. It is recommended to cut approx. 30 – 50 cm longer
than the tubing length you estimate.
(2) Remove burrs at each end of the copper tubing with a
tube reamer or file. This process is important and should
be done carefully to make a good flare. Be sure to keep
any contaminants (moisture, dirt, metal filings, etc.) from
entering the tubing. (Figs. 5-1 and 5-2)
AfterBefore
Deburring
Copper
tubing
Reamer
Fig. 5-1 Fig. 5-2
N OT E
When reaming, hold the tube end downward and be sure that
no copper scraps fall into the tube. (Fig. 5-2)
(3) Remove the flare nut from the unit and be sure to mount it
on the copper tube.
(4) Make a flare at the end of the copper tube with a flare tool.
(Fig. 5-3)
Flare nut
Copper
tubing
Flare tool
Fig. 5-3
N OT E
A good flare should have the following characteristics:
● inside surface is glossy and smooth
● edge is smooth
● tapered sides are of uniform length
Caution Before Connecting Tubes Tightly
(1) Apply a sealing cap or water-proof tape to prevent dust or
water from entering the tubes before they are used.
(2) Be sure to apply refrigerant lubricant (ether oil) to the
inside of the flare nut before making piping connections.
This is effective for reducing gas leaks. (Fig. 5-4)
Apply refrigerant lubricant.
Fig. 5-4
(3) For proper connection, align the union tube and flare tube
straight with each other, then screw on the flare nut lightly
at first to obtain a smooth match. (Fig. 5-5)
Flare nut
Union
Fig. 5-5
● Adjust the shape of the liquid tube using a tube bender at the
installation site and connect it to the liquid tubing side valve
using a flare.
Cautions During Brazing
● Replace air inside the tube with nitrogen gas to prevent
copper oxide film from forming during the brazing
process. (Oxygen, carbon dioxide and Freon are not
acceptable.)
● Do not allow the tubing to get too hot during brazing.
The nitrogen gas inside the tubing may overheat,
causing refrigerant system valves to become damaged.
Therefore allow the tubing to cool when brazing.
● Use a reducing valve for the nitrogen cylinder.
● Do not use agents intended to prevent the formation
of oxide film. These agents adversely affect the
refrigerant and refrigerant oil, and may cause damage or
malfunctions.
5-2. Connecting Tubing Between Indoor and
Outdoor Units
(1) Tightly connect the indoor-side refrigerant tubing extended
from the wall with the outdoor-side tubing.
Indoor Unit Tubing Connection
Indoor unit type 36 45 56 73 106 140
Gas tubing (mm) ø12.7 ø15.88
Liquid tubing (mm) ø6.35 ø9.52
(2) To fasten the flare nuts, apply specified torque.
● When removing the flare nuts from the tubing connections,
or when tightening them after connecting the tubing, be sure
to use 2 adjustable wrenches or spanners. (Fig. 5-6)
If the flare nuts are over-tightened, the flare may be damaged,
which could result in refrigerant leakage and cause injury or
asphyxiation to room occupants.
Outdoor unit
Torque wrench
Spanner
Indoor unit
Fig. 5-6
II_F616392_EU_L.indb 15 2013-12-16 15:25:00

16
● For the flare nuts at tubing connections, be sure to use the
flare nuts that were supplied with the unit, or else flare nuts
for R410A (type 2). The refrigerant tubing that is used must
be of the correct wall thickness as shown in the table below.
Tube diameter Tightening torque
(approximate) Tube thickness
ø6.35 (1/4") 14 – 18 N · m
{140 – 180 kgf · cm} 0.8 mm
ø9.52 (3/8") 34 – 42 N · m
{340 – 420 kgf · cm} 0.8 mm
ø12.7 (1/2") 49 – 61 N · m
{490 – 610 kgf · cm} 0.8 mm
ø15.88 (5/8") 68 – 82 N · m
{680 – 820 kgf · cm} 1.0 mm
Because the pressure is approximately 1.6 times higher than
conventional refrigerant pressure, the use of ordinary flare
nuts (type 1) or thin-walled tubes may result in tube rupture,
injury, or asphyxiation caused by refrigerant leakage.
● In order to prevent damage to the flare caused by over-
tightening of the flare nuts, use the table above as a guide
when tightening.
● When tightening the flare nut on the liquid tube, use an
adjustable wrench with a nominal handle length of 200 mm.
5-3. Insulating the Refrigerant Tubing
Tubing Insulation
● Thermal insulation must be applied to all units tubing,
including distribution joint (field supply).
* For gas tubing, the insulation material must be heat
resistant to 120°C or above. For other tubing, it must be
heat resistant to 80°C or above.
Insulation material thickness must be 10 mm or greater.
If the conditions inside the ceiling exceed DB 30°C and RH
70%, increase the thickness of the gas tubing insulation
material by 1 step.
Insulation of the flare nuts
Attach the flare insulator (supplied) just like wrapping around
the flare nut (supplied). Match the both slits of flare insulators
for gas and liquid tubes facing upward. Tightly attach the end of
the flare insulators to the tube cradle without any space. Then
clamp the flare insulator with the clampers about 20 mm away
from both ends.
Flare insulator (for gas tube)
Flare insulator
(for liquid tube)
Facing upward
Gas tubing
Liquid tubing
Tube cradle
Clamper Flare nut
(supplied) Clamper
Insulator (not supplied)
Indoor unit
side
Outdoor unit
side
Tube cradle
Without any space
About 20 mm About 20 mm
Fig. 5-7
N OT E
Tighten the clampers to prevent any condensation that may
occur as the copper tubing is exposed.
Insulation material
The material used for insulation must have good insulation
characteristics, be easy to use, be age resistant, and must not
easily absorb moisture.
CAUTION
After a tube has been insulated, never try to bend it into
a narrow curve because it can cause the tube to break or
crack.
Never grasp the drain or refrigerant connecting outlets
when moving the unit.
5-4. Taping the Tubes
(1) At this time, the refrigerant tubes (and electrical wiring
if local codes permit) should be taped together with
armoring tape in 1 bundle. To prevent condensation from
overflowing the drain pan, keep the drain hose separate
from the refrigerant tubing.
(2) Wrap the armoring tape from the bottom of the outdoor
unit to the top of the tubing where it enters the wall. As you
wrap the tubing, overlap half of each previous tape turn.
(3) Clamp the tubing bundle to the wall, using 1 clamp approx.
each meter. (Fig. 5-9)
Two tubes arranged together
Liquid tubing
Gas tubing
Insulation
Fig. 5-8
Insulated tubes Drain hose
Clamp
Fig. 5-9
CAUTION
If the exterior of the outdoor unit valves has been finished
with a square duct covering, make sure you allow sufficient
space to access the valves and to allow the panels to be
attached and removed.
N OT E
Do not wind the armoring tape too tightly since this will
decrease the heat insulation effect. Also ensure that the
condensation drain hose splits away from the bundle and drips
clear of the unit and the tubing.
II_F616392_EU_L.indb 16 2013-12-16 15:25:01

17
ENGLISH
5-5. Finishing the Installation
After finishing insulating and taping over the tubing, use sealing
putty to seal off the hole in the wall to prevent rain and draft
from entering. (Fig. 5-10)
Apply putty here
Tubing
Fig. 5-10
6. FINAL PROCEDURE
Reinstall the removed part to be placed in its original position.
(See the section “3-2. Preparation Before Installation”.)
Then install the accessory supplied side covers (L/R) on both
sides of the indoor unit.
● Attach the supplied side plates.
Insert the side plates in the direction of the arrow and fix
them with 2 screws once you’ve removed.
Side plate
Screw
Attach
● Attach the accessory supplied side covers.
Slide the covers from the front side and attach to the claws
of the latches.
Tighten the screws (accessory supplied).
Screw (accessory supplied)
Side cover (accessory supplied)
Fig. 6-1
● Attach the air-intake grille.
When attaching the air-intake grille, perform the reverse
procedure to removing the grille.
Refer to the section “3-2. Preparation Before Installation”.
Be sure to attach the safety string.
Close the air-intake grille and fix the claws of the latches with
the screws.
Safety string
Fig. 6-2
7. HOW TO INSTALL TIMER REMOTE
CONTROLLER OR HIGH-SPEC WIRED
REMOTE CONTROLLER (OPTIONAL
PART)
N OT E
Refer to the Operating Instructions attached to the optional
Timer Remote Controller or optional High-spec Wired Remote
Controller.
8. HOW TO INSTALL WIRELESS REMOTE
CONTROLLER RECEIVER
N OT E
Refer to the Operating Instructions attached to the optional
Wireless Remote Controller Receiver.
II_F616392_EU_L.indb 17 2013-12-16 15:25:07

18
9. APPENDIX
■ Care and Cleaning
WARNING
 For safety, be sure to turn the air conditioner off and
also to disconnect the power before cleaning.
 Do not pour water on the indoor unit to clean it. This will
damage the internal components and cause an electric
shock hazard.
Air intake and outlet side (Indoor unit)
Clean the air intake and outlet side of the indoor unit with a
vacuum cleaner brush, or wipe them with a clean, soft cloth.
If these parts are stained, use a clean cloth moistened with
water. When cleaning the air outlet side, be careful not to force
the vanes out of place.
CAUTION
● Never use solvents or harsh chemicals when cleaning
the indoor unit. Do not wipe plastic parts using very hot
water.
● Some metal edges and the fins are sharp and may cause
injury if handled improperly; be especially careful when
you clean these parts.
● The internal coil and other components of outdoor
unit must be cleaned regularly. Consult your dealer or
service center.
Air filter
It is recommended that the air filter be cleaned when the
(Filter) appears on the display.
● After Cleaning
1. After the air filter is cleaned, reinstall it in its original position.
Be sure to reinstall in reverse order.
2. Press the Filter reset button.
The (Filter) indicator on the display goes out.
Filter indicator
ex) Timer remote controller
Filter reset button
N OT E
Clean the filter frequently for best performance in the area of
dusty or oil spots regardless of filter status.
<How to clean the filter>
1. Remove the air filter from the air intake grille.
2. Use a vacuum cleaner to remove light dust. If there is sticky
dust on the filter, wash the filter in lukewarm, soapy water,
rinse it in clean water, and dry it.
<How to remove the filter>
Ceiling Type (T2)
1. Remove 2 attachment screws fixed with the latches.
Take hold of the finger-hold on the air intake grille and
press it to the rear, and the grille will open downward.
2. Take hold of the finger-hold on the air filter, pull it toward
you.
* Take hold of the finger-hold on the air filter,
pull it toward you.
Air filter finger-hold
Air filter finger-hold
Air intake grille
Screw
Latch
Slide
CAUTION
● Certain metal edges and the condenser fins are sharp
and may cause injury if handled improperly; special care
should be taken when you clean these parts.
● Periodically check the outdoor unit to see if the air outlet
or air intake is clogged with dirt or soot.
● The internal coil and other components must also be
cleaned periodically. Consult your dealer or service
center.
Care: After a prolonged idle period
Check the indoor and outdoor unit air intakes and outlets for
blockage; if there is a blockage, remove it.
Care: Before a prolonged idle period
● Operate the fan for half a day to dry out the inside.
● Disconnect the power supply and also turn off the circuit
breaker.
● Clean the air filter and replace it in its original position.
● Outdoor unit internal components must be checked and
cleaned periodically. Contact your local dealer for this
service.
II_F616392_EU_L.indb 18 2013-12-16 15:25:10

19
ENGLISH
■ Troubleshooting
If your air conditioner does not work properly, first check the following points before requesting service.
If it still does not work properly, contact your dealer or a service center.
● Indoor unit
Symptom Cause
Noise
Sound like streaming water during
operation or after operation
● Sound of refrigerant liquid flowing inside unit
● Sound of drainage water through drain pipe
Cracking noise during operation or
when operation stops. Cracking sound due to temperature changes of parts
Odor Discharged air is smelled during
operation.
Indoor odor components, cigarette odor and cosmetic odor accumulated
in the air conditioner and its air is discharged.
Unit inside is dusty. Consult your dealer.
Dewdrop Dewdrop gets accumulated near air
discharge during operation Indoor moisture is cooled by cool wind and accumulated by dewdrop.
Fog
Fog occurs during operation in
cooling mode.
(Places where large amounts of oil
mist exist at restaurants.)
● Cleaning is necessary because unit inside (heat exchanger) is dirty.
Consult your dealer as technical engineering is required.
● During defrost operation
Fan is rotating for a while even though operation
stops.
● Fan rotating makes operation smoothly.
● Fan may sometimes rotate because of drying heat exchanger due to
settings.
Wind-direction changes while operating.
Wind-direction setting cannot be made.
Wind-direction cannot be changed.
● When air discharge temperature is low or during defrost operation,
horizontal wind flow is made automatically.
● Flap position is occasionally set up individually.
When wind-direction is changed, flap operates
several times and stops at designated position.
When wind-direction is changed, flap operates after searching for
standard position.
Dust Dust accumulation inside indoor unit is discharged.
Poor cooling or heating
performance
The indoor unit is initially designed to control the indoor temperature
detected by the built-in room sensor inside the indoor unit.
Due to indoor unit installation position, however, the buit-in sensor may
occasionally sense temperature improperly; for example, temperature
difference between the ceiling and floor, lighting apparatus, electric fan,
windows or waist-high partition walls, etc.
In this case, the unit does not operate properly at the desired temperature.
You may change the use of the temperature sensor inside the indoor unit
to that of the remote controller.
Then the desired room temperature can be controlled properly.
For details, consult your dealer.
II_F616392_EU_L.indb 19 2013-12-16 15:25:10

20
● Check Before Requiring Services
Symptom Cause Remedy
Air conditioner does not run
at all although power is turned
on.
Power failure or after power failure Press ON/OFF operation button on remote
controller again.
Operation button is turned off.
● Switch on power if breaker is turned off.
● If breaker has been tripped, consult your dealer
without turning it on.
Fuse blow out. If blown out, consult your dealer.
Poor cooling or heating
performance
Air intake or air discharge port of indoor
and outdoor units is clogged with dust or
obstacles.
Remove dust or obstruction.
Wind speed switch is set to “Low”. Change to “High” or “Strong”.
Improper temperature settings
Refer to “ ■ Tips for Energy Saving”.
Room is exposed to direct sunlight in
cooling mode.
Doors and /or windows are open.
Air filter is clogged. Refer to “ ■ Care and Cleaning”.
Too much heat sources in room in
cooling mode. Use minimum heat sources and in a short time.
Too many people in room in cooling
mode.
Reduce temperature settings or change to “High” or
“Strong”.
If your air conditioner still does not work properly although you checked the points as described above, first stop the operation
and turn off the power switch. Then contact your dealer and report the serial number and symptom. Never repair your air
conditioner by yourself since it is very dangerous for you to do so. You also report if the inspection mark and the letters E, F, H,
L, P in combination with the numbers appear on the LCD of the remote controller.
■ Tips for Energy Saving
Avoid
● Do not block the air intake and outlet of the unit. If either is obstructed, the unit will not work well, and may be damaged.
● Do not let direct sunlight into the room. Use sunshades, blinds or curtains. If the walls and ceiling of the room are warmed by the
sun, it will take longer to cool the room.
Do
● Always try to keep the air filter clean. (Refer to “Care and Cleaning”.) A clogged filter will impair the performance of the unit.
● To prevent conditioned air from escaping, keep windows, doors and any other openings closed.
N OT E
Should the power fail while the unit is running
If the power supply for this unit is temporarily cut off, the unit will automatically resume operation once power is restored using the same
settings before the power was interrupted.
IMPORTANT INFORMATION REGARDING THE REFRIGERANT USED
This product contains fluorinated greenhouse gases covered by the Kyoto Protocol. Do not vent gases into the atmosphere.
Refrigerant type: R410A
GWP(1) value: 1975
(1)GWP = global warming potential
Periodical inspections for refrigerant leaks may be required depending on European or local legislation.
Please contact your local dealer for more information.
Regarding the amount of refrigerant, see the refrigerant charge label attached to the outdoor unit.
II_F616392_EU_L.indb 20 2013-12-16 15:25:10
