Panasonic S-60PF1R5A User manual

Operating Instructions
Air Conditioner
Low Silhouette Ducted
(Type F1)
Model No.
INDOOR UNIT
Low Silhouette Ducted (Type F1)
S-60PF1R5A
S-71PF1R5A
S-100PF1R5A
S-125PF1R5A
S-140PF1R5A
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
OUTDOOR UNIT
Single Split (Single-phase)
U-60PE1R5A
U-71PE1R5A
U-100PE1R5A
U-125PE1R5A
U-140PE1R5A
Single Split (3-phase)
U-100PE1R8A
U-125PE1R8A
U-140PE1R8A
F569974
F569974_L.indb 1 2015-1-22 10:12:23

2
Conrm to authorized dealer
or specialist on usage of
specied refrigerant type. Using
of refrigerant other than the
specied type may cause product
damage, burst and injury etc.
This air conditioner has no
ventilator for intaking fresh air
from outdoors. You must open
doors or windows frequently
when you use gas or oil heating
appliances in the same room,
which consume a lot of oxygen
from the air.
Otherwise there is a risk of
suffocation in an extreme case.
Never use or store gasoline or
other ammable vapor or liquid
near the air conditioner — it is
very dangerous.
Do not use this appliance in a
potentially explosive atmosphere.
Never touch the unit with wet hands.
Do not insert your ngers or
other objects into the air
conditioner indoor or
outdoor unit, rotating parts may
cause injury.
If the refrigerant comes in contact
with a ame, it produces a toxic
gas.
For safety, be sure to turn the
air conditioner off and also to
disconnect the power before
cleaning or servicing.
Pull off the power plug from
a receptacle, or switch off
the breaker, or switch off the
power disconnecting mean to
isolate the air conditioner from the
main power supply in case of
emergency.
Do not clean inside the indoor and
outdoor units by users. Engage
authorized dealer or specialist for
cleaning.
In case of malfunction of this
appliance, do not repair by yourself.
Contact to the sales dealer or
service dealer for a repair.
WARNING
 Safety Precautions ........................................................... 2
 Precautions for Use ......................................................... 4
 Names of Parts ................................................................. 5
• Operation Mechanism ................................................... 5
 Maintenance ..................................................................... 6
• Before Requesting Services ......................................... 6
 Troubleshooting ............................................................... 7
 Specications ................................................................... 8
• Indoor unit ...................................................................... 8
• Outdoor unit ................................................................... 9
Contents
Thank you for purchasing this Panasonic product.
This product is a commercial
air conditioner indoor unit.
Installation Instructions attached.
Safety Precautions
Product Information
If you have problems or questions concerning your Air
Conditioner, you will need the following information. Model and
serial numbers are on the nameplate on the side of the unit.
Model No.
Serial No.
Date of purchase
Dealer’s address
Phone number
The following symbols used in this manual, alert you to
potentially dangerous conditions to users, service personnel or
the appliance:
WARNING This symbol refers to a hazard or
unsafe practice which can result in
severe personal injury or death.
CAUTION
This symbol refers to a hazard or
unsafe practice which can result
in personal injury or product or
property damage.
Prohibited matters Matters to be
observed
• Read these Operating Instructions carefully before using this
air conditioner. If you still have any difculties or problems,
consult your dealer for help.
• This air conditioner is designed to give you comfortable
room conditions. Use this only for its intended purpose as
described in these Operating Instructions.
F569974_L.indb 2 2015-1-22 10:12:24

3
This appliance is intended to be used
by expert or trained users in shops,
in light industry and on farms, or for
commercial use by lay persons.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety. Children should be
supervised to ensure that do not play
with the appliance.
Keep the re alarm and the air outlet
at least 1.5m away from the unit.
Do not cool or heat the room too
much if babies or invalids are
present.
Do not turn the air conditioner on
and off from the power mains switch.
Use the ON/OFF operation button.
Do not stick anything into the air
outlet of the outdoor unit. This
is dangerous because the fan
is rotating at high speed.
Do not touch the air inlet or the
sharp aluminum ns of the
outdoor unit. You may get
injured.
Do not stick any object
into the FAN CASE. You
may be injured and the
unit may be damaged.
Provide a power outlet to be used
exclusively for each unit, and a
power supply disconnect, Earth
Leakage Circuit Breaker (ELCB)
or Residual Current Device (RCD)
for overcurrent protection should
be provided in the exclusive line.
Provide a power outlet exclusively
for each unit, and full disconnection
means having a contact separation
in all poles must be incorporated in
the xed wiring in accordance with
the wiring rules.
To prevent possible hazards
from insulation failure, the unit
must be grounded.
Do not use modied
cord, joint cord,
extension cord or
unspecied cord to
prevent overheating and re.
Stop using the product when any
abnormality/failure occurs and
disconnect the power plug or turn
off the power switch and breaker.
(Risk of smoke/re/electric shock)
Examples of abnormality/failure
• The ELCB trips frequently.
• The product sometimes does not
start when turned on.
• The power is sometimes
disconnected when the cord is
moved.
• Burnt odor or abnormal noise is
detected during operation.
• The body is deformed or
abnormally hot.
• Water leaks from the indoor unit.
• Power cord or plug becomes
abnormally hot.
• Fan speed cannot be controlled.
• The unit stops running
immediately even if it is switched
on for operation.
• The fan does not stop even if the
operation is stopped.
Contact immediately your local
dealer for maintenance/repair.
WARNING
CAUTION
• The compressor may occasionally stop during thunderstorms.
This is not a mechanical failure. The unit automatically
recovers after a few minutes.
NOTICE
Important Information Regarding
The Refrigerant Used
This product contains uorinated greenhouse gases covered
by the Kyoto Protocol. Do not vent gases into the atmosphere.
Refrigerant type: R410A
GWP(1) value: 1975
(1) GWP = global warming potential
Periodical inspections for refrigerant leaks may be required
depending on European or local legislation. Please contact
your local dealer for more information.
Do not sit or step on the unit.
You may fall down
accidentally.
F569974_L.indb 3 2015-1-22 10:12:26

4
Precautions for Use
Installation
 This air conditioner must be installed properly by qualied
installation technicians in accordance with the Installation
Instructions provided with the unit.
 Before installation, check that the voltage of the electric sup-
ply in your home or ofce is the same as the voltage shown
on the nameplate.
WARNING
Avoid the following locations for installation.
 Locations where smoke or combustible gas exists.
Also locations of extremely high temperature such as a
greenhouse.
 Locations where excessively high heat-generating ob-
jects are placed.
Attention:
 Avoid installing the outdoor unit where salty sea water can
splash directly onto it or in sulphurous air near a spa.
(To protect the air conditioner from heavy corrosion)
Wiring
 All wiring must conform to the local electrical codes.
(Consult your dealer or a qualied electrician for details.)
 Each unit must be properly grounded with a ground (or
earth) wire or through the supply wiring.
 Wiring must be done by a qualied electrician.
Operation Preparation
Turn the power mains on 5 hours before
the start of operation.
(For warm-up)
 Leave the power mains ON for continuous use.
ON
NOTE
Pull off the power plug from a receptacle, or switch off the
breaker, or switch off the power disconnecting mean to isolate
the air conditioner from the main power supply when not in use
for a long time.
Operation Condition
Use this air conditioner under the following temperature range.
Indoor temperature range:
Cooling mode 14°C ~ 25°C (*WBT) / 18°C ~ 32°C (*DBT)
Heating mode 16°C ~ 30°C (*DBT)
Outdoor temperature range:
Cooling mode -15°C ~ 46°C (*DBT)
Heating mode -20°C ~ 18°C (*WBT) / -20°C ~ 24°C (*DBT)
*DBT: Dry bulb temperature
*WBT: Wet bulb temperature
Information for Users on Collection and Disposal of
Old Equipment and Used Batteries
[Information on Disposal in other Countries
outside the European Union]
These symbols are only valid in the European
Union. If you wish to discard these items,
please contact your local authorities or dealer
and ask for the correct method of disposal.
Pb
Note for the battery symbol (bottom two
symbol examples):
This symbol might be used in combination with
a chemical symbol. In this case it complies
with the requirement set by the Directive for
the chemical involved.
Tips for Energy Saving
Avoid
 Do not block the air intake and outlet of the unit.
(If either is obstructed, the unit will not function
well, causing malfunction.)
 During cooling operation, use sunshades, blinds or cur-
tains to prevent direct sunlight from entering the room.
Do
 Always keep the air lter clean.
(A clogged lter will impair the performance of the unit.)
→ “Maintenance” (P.6)
 To prevent conditioned air from escaping, keep win-
dows, doors and any other openings closed.
F569974_L.indb 4 2015-1-22 10:12:27

5
Names of Parts
Operation Mechanism
Heating performance
 Since this air conditioner utilizes outside air for heating,
its heating performance deteriorates as outside tempera-
ture decreases.
(Due to heat pump system)
→In that case, use another heating appliance.
Defrosting
 This appliance may start defrosting operation to melt
frost formed in the outdoor unit.

Defrosting starts: The indoor unit fan stops (or the
speed becomes extremely slow).
→‘‘ ’’ (STANDBY) appears.

Heating operation resumes after several
minutes: The indoor unit fan remains stopped (or
it will run at a very slow speed) until the indoor heat
exchanger coil warms up sufciently.
→ ‘‘ ’’ (STANDBY) is shown.

Defrosting is complete: The indoor unit fan starts
operation.
→ ‘‘ ’’ (STANDBY) disappears.
INDOOR UNIT
‘‘DRY’’ operation
 Once the room temperature reaches the level that was
set, the outdoor unit repeats the cycle of turning on and
off automatically.
 When the outdoor unit is turned off, the indoor unit fan
will stop, too.
(To prevent the humidity in the room from rising again)
 When the room temperature is more likely to reach the
level that was set, the fan speed is set to ‘‘breeze’’ (light
wind) automatically.
 ‘‘DRY’’ operation is not possible if the outdoor tempera-
ture is 15 °C or less.
Should the power failure occurs while the
unit is running
When the unit automatically resumes operation after
temporary power failure, it uses the same settings before
the power was cut off.
OUTDOOR UNIT
Air intake
Air outlet
Air intake
Air outlet
Type 60, 71 Type 100, 125, 140
Model No.
CZ-RWSK2
Optional
Wireless Remote Controller
Model No.
CZ-RTC2
Timer Remote Controller
Read the operating instructions included with the Remote Controller.
Air outlet duct *
Bolt anchor *
Suspension bolt *
Indoor unit
Ceiling material *
Air-outlet grille *
* Field supplied
Type F1 (Low Silhouette Ducted)
Model No.
CZ-RWSC3
A
Model No.
CZ-RTC4
High-spec Wired Remote Controller
Model No.
CZ-RTC3
F569974_L.indb 5 2015-1-22 10:12:29

6
WARNING CAUTION
 For safety, be sure to turn the air conditioner off and dis-
connect the power before cleaning.
(Otherwise, electric shock or injury may result because
the fan is rotating at high speed.)
 Do not pour water on the indoor unit.
(This may damage the internal components and cause
an electric shock hazard.)
 Never use solvents or harsh chemicals. Also, do not wipe
plastic parts using very hot water.
(This may cause deformation or change in colour.)
 Some metal edges and ns are sharp. Be careful when
you clean those parts.
(Injury may result.)
 Use a rm stool or ladder when cleaning an indoor unit
installed in high locations.
Maintenance
Do not attempt to clean inside the unit by yourself.
Refer to the section “Care and Cleaning” in the Installation Instructions.
Symptom Cause Action
The air
conditioner does
not operate
although the
power is turned
on.
Power failure or after power failure Press the power ON/OFF button on the remote controller.
The operation (power) button is turned off.
• If the breaker is turned off, turn the power on.
• If the breaker has been tripped, consult your dealer
without turning it on.
Fuse blow out. Contact your dealer.
Poor cooling
or heating
performance
The air intake or air outlet of indoor and
outdoor units is clogged with dust. Remove the dust.
Improper temperature settings
See “Tips for Energy Saving”. (P.4)
The room is exposed to direct sunlight in
cooling mode.
Doors or windows are open.
The air lter is clogged. Contact your dealer.
Too many heat sources in the room in
cooling mode. Use minimum heat sources and in a short time.
Too many people in the room in cooling
mode. Lower the temperature setting.
If your air conditioner does not work properly even after checking each item of
“Before Requesting Services” and “Troubleshooting”
 Stop the operation immediately and turn the power off. Then contact your dealer and report the serial number and symptom.
You also report if the inspection mark and the letters E, F, H, L, P in combination with numbers appear on the LCD of the
remote controller.
 Never repair the air conditioner by yourself since it is very dangerous for you to do so.
Before Requesting Services
F569974_L.indb 6 2015-1-22 10:12:29

7
Troubleshooting
Symptom Cause / Action
Noise
Sound like streaming water is heard
during operation or after operation.
• Sound of refrigerant liquid owing inside unit
• Sound of drainage water through drain pipe
Cracking noise is heard during operation
or when operation stops. Sound due to temperature changes of parts
Discharged air smells during operation.
• Indoor odor components, cigarette odor and cosmetic odor
accumulated in the air conditioner and its air is discharged.
• The unit inside is dirty.
(Contact your dealer.)
Dewdrops accumulate near the air outlet
during cooling operation.
• Internal moisture is cooled by cool wind and accumulates as
dewdrops.
Fog occurs during cooling operation.
• If the air conditioner has been installed at places such as
restaurants where large amounts of oil mist exist, cleaning is
necessary because the unit inside (heat exchanger) is dirty.
(Contact your dealer.)
Fog occurs during heating operation. • Defrost operation is in process.
The fan is rotating for a while even though
operation stops.
• Fan rotation makes operation smooth.
• The fan may rotate to dry the heat exchanger depending on
the setting.
Dust is discharged. • Dust accumulated inside the indoor unit is discharged.
At the initial high-speed operation, the fan
sometimes rotates faster than the setting
speed.
(3 to 30 minutes)
• This is for operation check in order to conrm whether the fan
motor rotation is within the range of use.
No operation
(When the power is turned on immediately /
When operation is stopped and resumed
immediately)
• Operation is not activated for the rst approx. 3 minutes
because the compressor protection circuit is activated.
Noise occurs during heating operation.
• Defrost operation is in process.
Steam comes out during heating operation.
The fan continues to rotate even after the
operation is stopped using the remote
controller.
• This is for smooth operation.
Check before consulting or requesting services.
Indoor unit
Outdoor unit
F569974_L.indb 7 2015-1-22 10:12:29

8
Specications
Low Silhouette Ducted (Type F1)
Model Name S-60PF1R5A S-71PF1R5A S-100PF1R5A S-125PF1R5A S-140PF1R5A
Power source 230/240 V～ 50 Hz
Cooling capacity
kW 6.0 7.1 10.0 12.5 14.0
BTU/h 20,500 24,200 34,100 42,700 47,800
Heating capacity
kW 7.0 8.0 11.2 14.0 16.0
BTU/h 23,900 27,300 38,200 47,800 54,600
Sound pressure level
High dB(A) 35 35 38 39 40
Medium dB(A) 32 32 34 35 36
Low dB(A) 26 26 31 32 33
Sound power level
High dB(A) 58 58 61 62 63
Medium dB(A) 55 55 57 58 59
Low dB(A) 49 49 54 55 56
Unit dimensions (H×W×D) mm
290×1,000×700 290×1,000×700 290×1,400×700 290×1,400×700 290×1,400×700
Net weight kg 33 33 45 45 45
Indoor unit
F569974_L.indb 8 2015-1-22 10:12:30

9
Single Split Outdoor Unit
Model Name U-60PE1R5A U-71PE1R5A U-100PE1R5A U-125PE1R5A U-140PE1R5A
Power source 230/240 V～ 50 Hz
Cooling capacity
kW 6.0 7.1 10.0 12.5 14.0
BTU/h 20,500 24,200 34,100 42,700 47,800
Heating capacity
kW 7.0 8.0 11.2 14.0 16.0
BTU/h 23,900 27,300 38,200 47,800 54,600
Sound pressure level (C/H) dB(A) 48 / 50 48 / 50 52 / 52 53 / 53 54 / 55
Sound power level (C/H) dB(A) 65 / 67 65 / 67 69 / 69 70 / 70 71 / 71
Unit dimensions (H×W×D) mm 996×940×340 996×940×340 1,416×940×340 1,416×940×340 1,416×940×340
Net weight kg 68 69 98 98 98
Model Name U-100PE1R8A U-125PE1R8A U-140PE1R8A
Power source 400/415 V 3N～ 50 Hz
Cooling capacity
kW 10.0 12.5 14.0
BTU/h 34,100 42,700 47,800
Heating capacity
kW 11.2 14.0 16.0
BTU/h 38,200 47,800 54,600
Sound pressure level (C/H) dB(A) 52 / 52 53 / 53 54 / 55
Sound power level (C/H) dB(A) 69 / 69 70 / 70 71 / 71
Unit dimensions (H×W×D) mm 1,416×940×340 1,416×940×340 1,416×940×340
Net weight kg 98 98 98
Outdoor unit
F569974_L.indb 9 2015-1-22 10:12:30

10
MEMO
F569974_L.indb 10 2015-1-22 10:12:30

11
MEMO
F569974_L.indb 11 2015-1-22 10:12:30

F569974
DC0115-0
Panasonic Corporation
Website: http://www.panasonic.com
Printed in China
© Panasonic Corporation 2015
F569974_L.indb 12 2015-1-22 10:12:30
