Panasonic GP-US932CSXE User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
Operating Instructions
HD Camera Control Unit
Model No. GP-US932CSXE
ON
OFF
Camera head: Option
Camera cable: Option
ENGLISHDEUTSCH
FRANÇAISESPAÑOL
ITALIANO

2
ENGLISH VERSION
WARNING:
• To prevent fire or electric shock hazard, do not expose this
apparatus to rain or moisture.
• The apparatus should not be exposed to dripping or splash-
ing and that no objects filled with liquids, such as vases,
should be placed on the apparatus.
• The connections should comply with local electrical code.
The lightning flash with arrowhead sym-
bol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
Before attempting to connect or operate this product, please
read the label on the bottom.
The exclamation point within an equilat-
eral triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
We declare under our sole responsibility that the product to which this
declaration relates is in conformity with the standard or other normative
document following the provisions of Directive 2004/108/EC.
Wij verklaren als enige aansprakelijke, dat het product waarop deze
verklaring betrekking heeft, voldoet aan de volgende norm of ander
normatief dokument, overeenkomstig de bepalingen van Richtlijn
2004/108/EC.
Vi erklærer os eneansvarlige for, at dette produkt, som denne deklaration
omhandler, er i overensstemmelse med standard eller andre normative
dokumenter i følge bestemmelserne i direktiv 2004/108/EC.
Vi deklarerar härmed vårt fulla ansvar för att den produkt till vilken denna
deklaration hänvisar är i överensstämmelse med standarddokument eller
annat normativt dokument som framställs i direktiv 2004/108/EC.
Ilmoitamme yksinomaisella vastuullamme, että tuote, jota tämä ilmoitus
koskee, noudattaa seuraavaa standardia tai muuta ohjeellista asiakirjaa,
jotka noudattavat direktiivin 2004/108/EC säädöksiä.
Vi erklærer oss alene ansvarlige for at produktet som denne erklæringen
gjelder for, er i overensstemmelse med følgende norm eller andre
normgivende dokumenter som følger bestemmelsene i direktiv
2004/108/EC.

3
ENGLISH
Contens
Important safety instructions.....................................................................................................................................................4
Limitation of liability...................................................................................................................................................................5
Disclaimer of warranty...............................................................................................................................................................5
Preface ......................................................................................................................................................................................6
Trademarks and registered trademarks.....................................................................................................................................6
Precautions ...............................................................................................................................................................................7
Major operating controls and their functions ............................................................................................................................9
Camera head (Option)............................................................................................................................................................9
Camera control unit (CCU).....................................................................................................................................................9
Precautions for installation......................................................................................................................................................13
How to install...........................................................................................................................................................................14
How to mount lens...............................................................................................................................................................15
Setup through the SETUP Menu.............................................................................................................................................16
About the setup menus........................................................................................................................................................16
Basic operation....................................................................................................................................................................17
Default restoring...................................................................................................................................................................17
qCamera title setting [CAMERA ID]...................................................................................................................................18
wELC setting [ELC] ............................................................................................................................................................19
eElectronic shutter setting [SHUTTER] .............................................................................................................................20
rGain adjustment [GAIN]...................................................................................................................................................21
tElectronic sensitivity enhancement setting [SENS UP]...................................................................................................21
yBinning setting [BINNING]...............................................................................................................................................21
uRGB/YPbPr output signal setting [OUTPUT SEL]...........................................................................................................21
iHDMI output signal setting [HDMI OUTPUT] ..................................................................................................................21
oScene file setting [SCENE FILE] ......................................................................................................................................22
!0 White balance setting [WHITE BAL] ................................................................................................................................27
!1 Black balance setting [BLACK BAL]................................................................................................................................28
!2 Synchronization setting [SYNC] ......................................................................................................................................28
When connecting this unit mutually.....................................................................................................................................29
When inputting the synchronization signal from another device to this unit .......................................................................29
!3 Configure the settings relating to the electronic zoom [ELECTRIC ZOOM]....................................................................29
!4 Image freezing [FREEZE].................................................................................................................................................29
!5 Setting of vertical flip function [FLIP ENABLE]................................................................................................................30
!6 Setting of horizontal flip function [MIRROR ENABLE].....................................................................................................30
!7 Status display setting of vertical and horizontal flip function [STATUS DISPLAY] ..........................................................30
!8 Setting of the display format for the SD format [SD ASPECT]........................................................................................30
SEL menu ................................................................................................................................................................................31
How to display/operate the SEL menu ................................................................................................................................31
Button assignment...............................................................................................................................................................31
How to assign settings.........................................................................................................................................................31
Troubleshooting.......................................................................................................................................................................32
Specifications..........................................................................................................................................................................33
Standard accessories..............................................................................................................................................................34
Optional accessories...............................................................................................................................................................34

4
Important safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
10) Only use attachments/accessories specified by the manufacturer.
11) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
12) Unplug this apparatus during lightning storms or when unused for long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the appa-
ratus has been exposed to rain or moisture, does not operate normally, or has been dropped.
S3125A

5
Limitation of liability
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY, FITNESS FOR ANY
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF
THE THIRD PARTY’S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL
INACCURACIES OR TYPOGRAPHICAL ERRORS.
CHANGES ARE ADDED TO THE INFORMATION HEREIN,
AT ANY TIME, FOR THE IMPROVEMENTS OF THIS
PUBLICATION AND/OR THE CORRESPONDING PRODUCT
(S).
Disclaimer of warranty
IN NO EVENT SHALL Panasonic System Networks Co.,
Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON,
EXCEPT FOR REPLACEMENT OR REASONABLE
MAINTENANCE OF THE PRODUCT, FOR THE CASES,
INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY DAMAGE AND LOSS, INCLUDING WITHOUT
LIMITATION, DIRECT OR INDIRECT, SPECIAL,
CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF
OR RELATING TO THE PRODUCT;
(2) PERSONAL INJURY OR ANY DAMAGE CAUSED BY
INAPPROPRIATE USE OR NEGLIGENT OPERATION
OF THE USER;
(3) UNAUTHORIZED DISASSEMBLE, REPAIR OR
MODIFICATION OF THE PRODUCT BY THE USER;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN
IMAGES ARE NOT DISPLAYED, DUE TO ANY REASON
OR CAUSE INCLUDING ANY FAILURE OR PROBLEM
OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE,
OR LOSS OR DAMAGE, ARISING OUT OF THE
SYSTEM COMBINED BY THE DEVICES OF THIRD
PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT
BY ANY PERSON OR ORGANIZATION BEING A
PHOTOGENIC SUBJECT, DUE TO VIOLATION OF
PRIVACY WITH THE RESULT OF THAT
SURVEILLANCE-CAMERA’S PICTURE, INCLUDING
SAVED DATA, FOR SOME REASON, BECOMES
PUBLIC OR IS USED FOR ANY PURPOSE.

6
Preface
This system is a compact and light type HD camera control unit (hereafter called CCU) with high image quality and multiple
functions by introducing digital signal processing.
GP-US932CSXE: HD Camera Control Unit•
This product is used in combination with the optional 3MOS HD camera head (hereafter called camera head).
GP-US932HXE: 3MOS HD Camera Head•
The multi-format output that is compatible with 1080p, 1080i, 720p, 576p and 576i is available.•
Signal transmission without signal degradation has been achieved thanks to the HDMI or SDI output connector.•
The dynamic range expansion function allows users to shoot even images with a wide range of brightness contrast and•
improve their visibility.
The descriptions in this book are predicated on a system with the camera head.
Trademarks and registered trademarks
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.

7
Precautions
Stop the operation immediately when something is
wrong with this product.
When smoke goes up from this product or the smell of
smoke comes from this product, stop the operation imme-
diately and contact your dealer.
Turn the power off immediately and contact qualified service
personnel for service.
Do not attempt to disassemble or modify this product.
Failure to observe this may cause fire or electric shock.
Consult the dealer for the repair or inspections.
Do not insert any foreign objects.
This could permanently damage this product.
Unplug the power plug immediately and contact qualified
service personnel for service.
Do not use the product in an atmosphere of flamma-
ble gases.
Failure to observe this may cause an explosion resulting in
injury.
Avoid installing this bracket in the locations where
salt damage occurs or corrosive gas is produced.
Otherwise, the mounting portions will deteriorate and acci-
dents such as a fall of this product may occur.
Select an installation area that can support the total
weight.
Selecting an inappropriate installation surface may cause
the product to fall down or topple over, resulting in injury.
Reinforce the mounting point to the appropriate level before
mounting.
Turn the power off when cleaning this product.
Failure to observe this may cause electric shock.
Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause a fall of the
product resulting in injury or accidents.
Consult the dealer for the inspections.
Avoid placing receptacles that contain liquids such as
water on or near the unit.
If liquid spills onto the unit, it may cause fire or an electric
shock.
Contact the dealer immediately.
Do not pull the cables.
Failure to observe this may cause injury.
Do not damage the cables.
Putting a heavy thing or pinching may damage the cables
and cause injury.
[Precautions for use]
To keep on using with stable performance
Parts of this product may deteriorate and it may shorten the
lifetime of this product when using in locations subject to
high temperatures and high humidity.
Use this product at temperatures between 0 °C to 40 °C.
Failure to observe this may adversely affect the components
inside or cause this product to malfunction. Use of this
product at temperatures of 30 °C or lower is recommended
without direct heat from heaters in consideration of heat
release at the product location.
Handle this product with care.
Do not drop this product, nor apply shock or vibration to the
product. It may cause a malfunction.
Do not aim this product at strong light sources.
A light source such as a spot light on a part of the screen
causes a blooming (light bleeding).
Cleaning this product body
Turn the power off, and then use a soft cloth to clean•
this product. When the dirt is hard to remove, use a mild
detergent and wipe gently.
Then, wipe off the remaining detergent with a dry cloth.
Do not use strong or abrasive detergents when cleaning•
the body.
When using a chemical cloth for cleaning, read the cau-•
tion provided with the chemical cloth product.
Blight subject
Blooming

8
Indication label
Refer to the indication label placed on the surface of the unit
as to the indications of equipment classification and power
source, etc.
This product is designed for normal uses as a general
electronic equipment.
Using the product for special purposes (such as traffic,
transportation and medical treatment) without taking the
necessary procedures according to the regulations relat-
ing to one’s country or field on one’s own responsibility
may be prohibited.

9
Major operating controls and their functions
Camera head (Option)
Important:
Be sure to turn off the power of the CCU before con-•
necting or disconnecting the camera cable.
Avoid bending excessively or breaking the camera•
cable.
Use the specific-camera head only.•
qLens mount section
eTripod mount base
wCamera cable
connector
Lens mount sectionq
A C-mount lens is mounted on this section. (☞Page
15)
Camera cable connectorw
The camera cable (option) is connected to this connec-
tor.
<HD Camera Cable>
GP-CA932/4E (4 m)•
GP-CA9320/6E (6 m)•
GP-CA932/10E (10 m)•
Tripod mount basee
The tripod socket hole is used when the camera head is
secured to the tripod.
The tripod mount base can be mounted on either top or
bottom of the camera head.
Tripod socket hole: 1/4-20 UNC
Camera control unit (CCU)
<Front>
u Freeze/menu button [FREEZE MENU ]
iSelection button [SEL]
oUp/Down/Left/Right button [g/h/e/f]
!2 Camera cable connector
yGain selection button [GAIN]
tScene file selection button [SCENE]
rPower switch [DC POWER]
!0 Color bar display/AWC button [BAR AWC ]!1 Dynamic range selection button [D RANGE]
Power switch [DC POWER]r
This switch toggles the power of the CCU and camera
head on and off. The switch lights green while the power
is turned on.
Scene file selection button [SCENE]t
The button selects a scene file from 1 to 3. Each scene
file should be set up beforehand using the SETUP
menu. (☞Page 22)
Selection of a scene file turns on the green indicator of
the selected file number.

10
Gain selection button [GAIN]y
Selects the gain from OFF, LOW and HIGH.
Selection of a gain turns on the green indicator of the
selected gain. No indicator is turned on when the gain is
set to off.
Selectable gain varies depending on the setting in the
SETUP menu (☞page 21).
When “AUTO” is selected for “GAIN” and “OFF” is
selected for “SENS UP”: Fixed to “HIGH”
Freeze/menu button [FREEZEu MENU ]
Pressing this button: Displays the current image as a still
image when “FREEZE” in the SETUP menu is set to
“ON”.
Note:
Pressing a button other than the [• g]/[h] button pro-
vides freeze cancellation.
When the electronic zoom function or vertical/horizontal•
flip function is assigned to the [e]/[f] button, the image
can be scaled up/down or flipped in the image freezing
state. Refer to page 31 for function assignment to but-
tons.
Pressing for 2 seconds or more: Displays the SETUP
menu.
Selection button [SEL]i
Pressing this button while the SETUP menu is displayed
determines the setting.
Pressing this button except while the SETUP menu is
displayed calls up the SEL menu. (☞Page 31)
Up/Down/Left/Right buttono
Up button [g]
This button moves the cursor upward to change a set-
ting item while the SETUP menu is displayed.
When “FLIP ENABLE” or “MIRROR ENABLE” in the
SETUP menu is set to “ON” (☞page 30), the image can
be flipped vertically or horizontally.
Down button [h]
This button moves the cursor downward to change a
setting item while the SETUP menu is displayed.
When “FLIP ENABLE” or “MIRROR ENABLE” in the
SETUP menu is set to “ON” (☞page 30), the image can
be flipped vertically or horizontally.
Left button [e]
This button moves the cursor leftward or selects a set-
ting while the SETUP menu is displayed.
This button moves the cursor in the minus direction on
the level adjustment scale or selects a setting item while
the SEL menu is displayed.
A function of the SEL menu can also be assigned to this
button. (☞Page 31)
Right button [f]
This button moves the cursor rightward or selects a set-
ting while the SETUP menu is displayed.
This button moves the cursor in the plus direction on
the level adjustment scale or selects a setting item while
the SEL menu is displayed.
A function of the SEL menu can also be assigned to this
button. (☞Page 31)
!0 Color bar display/AWC button [BAR AWC ]
Pressing this button: Calls up the color bar on the
screen while an image is displayed. The color bar
becomes a blue back display while the SETUP menu is
displayed.
Pressing for 2 seconds or more: Starts up AWC while
an image is displayed if “WHITE BAL” in the SETUP
menu is set to “AWC” (☞page 27).
Important:
When the camera head is not connected, pressing the•
[BAR AWC ] button does not activate any operation.
!1 Dynamic range selection button [D RANGE]
This button toggles the dynamic range between
NORMAL and EXPAND. The button lights green when
“EXPAND” is selected.
“EXPAND” shall be selected when dark portions are less
viewable because too bright portions are present in a
screen.
Note:
The dynamic range can be set in the scene file. (• ☞Page
23)
!2 Camera cable connector
The camera cable (option) is connected to this connec-
tor.

11
<Rear>
!3 HDMI output connector [HDMI]
This connector is used to connect to an HDMI-ready
monitor.
!4 SDI output connector [SDI]
This terminal provides HD-SDI or SD-SDI output signal.
Important:
Please use a high quality cable compatible with HD-SDI.•
!5 Video output connector [VIDEO]
This connector provides composite video output signal.
!6 Synchronizing signal output/input connector
[SYNC]
This connector provides external synchronizing output
or input signal.
When the synchronizing signal output/input selection
switch !7 is set to “IN”, this connector can provide the
synchronizing input signal. When the synchronizing sig-
nal output/input selection switch !7 is set to “OUT”, this
connector provides the synchronizing output signal.
(☞Page 28)
Important:
The video format shall be the same among the synchro-•
nized devices.
!7 Synchronizing signal output/input selection switch
[OUT/IN]
This switch toggles synchronizing signals between out-
put and input.
When the synchronizing signal output is selected, set
this switch to “OUT”. When the synchronizing signal
input is selected, set this switch to “IN”.
!8 Function setup switches
Switch No. 1 - 3 select a video format for RGB/YPbPr
output connector, SDI output connector, and HDMI out-
put connector.
Switch No. 4 selects the control method.
Switch
HDMI
Output
SDI
Output
RGB/
YPbPr
1
2
3
ON
−
ON
1080p
1080i
1080i
OFF
−
ON
1080p(sF)
1080p(sF)
1080p(sF)
ON
OFF
OFF
1080i
1080i
1080i
ON
ON
OFF
720p
720p
720p
OFF
−
OFF
576p
576i
576i
–: Either ON or OFF
Switch
OFF
ON
4
REMOTE
(External control)
FRONT SW
(Button operation via
front face)
Note:
When the REMOTE terminal is used, set Switch 4 to•
“OFF” after turning off the power.
When Switch 4 is set to “OFF”, button operations on the
front face are disabled.
!6 Synchronizing signal output/input connector [SYNC]
!7 Synchronizing signal output/input selection switch
[OUT/IN]
!8 Function setup switches
!9 12 V DC power terminal [DC 12V IN]
@0 Remote terminal [REMOTE]@1 S-video output connector [S-VIDEO]
!5 Video output connector [VIDEO]
!4 SDI output connector [SDI]
!3 HDMI output connector [HDMI]
@2 RGB/YPbPr output connector [RGB/YPbPr]

12
!9 12 V DC power terminal [DC 12V IN]
This connector is used to connect an external DC
power supply of 12 volts (3 A or more).
Compatible connector (as of September 2012): HR10A-
7P-4S (73) manufactured by HIROSE ELECTRIC
CO., LTD.
Pin array of the compatible connector
(Connector of the cable)
@0 Remote terminal [REMOTE]
This port is used to perform external control.
(D-sub 9-pin connector, male)
Pin No.
Signal
1
GND
2
TXD
3
RXD
4
DSR
5
GND
6
DTR
7
CTS
8
RTS
9
GND
@1 S-video output connector [S-VIDEO]
This connector provides the luminance signal (Y) output
with synchronizing signal and color signal (C) output.
@2 RGB/YPbPr output connector [RGB/YPbPr]
This connector provides the RGB signal (red, green, and
blue) output or the YPbPr signal (luminance, color differ-
ence B, and color difference R) output. The output sig-
nal can be set up with use of “OUTPUT SEL” in the
SETUP menu. (☞Page 21)
(D-sub 9-pin connector, female)
Pin No.
Output signal
1
GND
2
GND
3
R, Pr
4
G, Y
5
B, Pb
6
VIDEO
7
SYNC
8
GND
9
GND
1
2
4
3
15
69
5 1
9 6

13
Precautions for installation
The installation should comply with local electrical code.
This product is designed to be used indoors.
This product is not operable outdoors.
Do not expose this product to direct sunlight for hours and do not install the product near a heater or an air conditioner. It may
cause a drop or malfunction. Keep this product away from water and moisture.
Procure a tripod separately.
The tripod to mount the camera head is not supplied. Prepare it according to the area where the camera is to be installed.
Avoid moist or dusty places to install this system.
Otherwise, lifetime of the internal parts may be shortened.
Avoid installing or using this system in the following locations:
Locations where it may get wet from rain or water splash•
Locations where a chemical agent is used such as a swimming pool•
Locations subject to humidity, dust, steam and oil smoke•
Locations where a radiation, an X-ray, a strong radio wave or a strong magnetic field is generated•
Locations where corrosive gas is produced•
Locations where the temperature is not within 0 °C to 40 °C•
Locations subject to vibrations (This product is not designed for on-vehicle use.)•
Locations where the temperature may rapidly change such as the peripheral areas of the air outlets of air conditioners or•
doors facing outside
Radio interference
Images may be distorted near a transmitting antenna for TV or radio broadcasting signals or electric or magnetic fields (for
example, caused by a motor and a transformer).
Be sure to remove this product if it is not in use.

14
The following shows how to mount the camera on the tripod (locally procured).
<Sample of camera mounting on tripod>
Important:
The tripod and CCU shall be horizontally placed.•
The CCU shall be horizontally placed. Do not place the unit in an upright or tilted position.•
How to install

15
How to mount lens
Important:
A lens whose projection length of the lens mount section is 4 mm or less shall be•
used.
The recommended lens aperture ranges from F2.2 to F16. Selection of less than F2.2•
of the lens aperture may result in image blurring.
When a zoom lens is used, focus adjustment method varies with the lens. For further•
information, refer to the operating instructions for the lens to be used.
When the lens is removed, be sure to put the cap on the lens mount section of the•
camera head.
C mount:
4 mm or less
Step 1
Remove the cap from the lens mount section of the camera
head.
Important:
Check to see whether the surface of the optical filter is•
clean before mounting a lens. If the surface is dirty, use
a blower brush for general camera to remove dust.
Step 2
Turn a C-mount lens clockwise to engage the lens with the
lens mount section.
Recommended lenses (As of September, 2012)
Manufacturer
Product name
Model
FUJINON
High Definition Fixed Lens
HAF4.8DA-1
FUJINON
High Definition Zoom Lens
XA4x7.5DA-1
FUJINON
3CCD Camera Lens
TF2.8DA-8
FUJINON
3CCD Camera Lens
TF4DA-8
FUJINON
3CCD Camera Lens
TF8DA-8B
FUJINON
3CCD Camera Lens
TF15DA-8

16
Setup item
Description
Page
qCAMERA ID
Specifies the camera title. Through this item, a camera title is created with
alphanumerics and symbols and displayed on the screen.
18
wELC
Specifies the ELC function.
19
eSHUTTER
Specifies the electronic shutter speed.
20
rGAIN
Specifies the gain.
21
tSENS UP
Specifies electronic sensitivity enhancement.
21
yBINNING
Specifies the binning.
21
uOUTPUT SEL
The output signals of the RGB/YPbPr output connector are specified.
21
iHDMI OUTPUT
The output signals of the HDMI output connector are specified.
21
oSCENE FILE
Registers the settings of details, gamma, hue, etc.
22
DTL MODE
Specifies the details.
22
RED DTL
Adjusts the enhancement of red edge.
22
GAMMA
Specifies the gamma correction level.
23
KNEE
Adjusts the knee point.
23
BLACK STRETCH
Toggles the black stretch function on and off.
23
D-RANGE
Toggles the dynamic range between NORMAL and EXPAND.
23
WHITE CLIP
Adjusts the white clip level.
24
FLARE COMP
Toggles the flare compensation on and off.
24
DNR
Selects the level of the digital noise reduction function.
24
MATRIX
Adjusts the hue and chroma.
24
CHROMA GAIN
Adjusts chroma gain.
25
TOTAL PED
Adjusts the pedestal level.
25
FILE LABEL
Puts a label name instead of a scene file number.
26
AWC MEMORY
Specifies the destination where the AWC setting is saved.
26
!0 WHITE BAL
Specifies white balance adjustment.
27
!1 BLACK BAL
Adjusts the black balance.
28
!2 SYNC
Specifies the synchronization type.
28
!3 ELECTRIC ZOOM
Toggles the electronic zoom on and off.
29
!4 FREEZE
Toggles the freeze function on and off.
29
!5 FLIP ENABLE
Toggles vertical image flip on and off.
30
!6 MIRROR ENABLE
Toggles horizontal image flip on and off.
30
!7 STATUS DISPLAY
Toggles vertical and horizontal image flip status display on and off.
30
!8 SD ASPECT
Specifies the display format for the SD format.
30
Setup through the SETUP Menu
Performing each setting item in the SETUP menu should be completed in advance to use this unit. Perform the settings for
each item in accordance with the conditions of the camera shooting area.
Note:
In addition to the SETUP menu, this system has a simplified menu (SEL menu) that is displayed using the [SEL] button on•
the front face of the CCU. Refer to page 31 for further information about the SEL menu.
About the setup menus
The following items can be set with use of the SETUP menu.

17
Basic operation
This section explains how to display the SETUP menu on the monitor connected for adjustment and how to perform the basic
operations in the SETUP menu.
Important:
The following functions are not available when the camera head is not connected:•
AWC startup for white balance•
MATRIX•
ELECTRIC ZOOM•
FREEZE•
FLIP•
MIRROR•
Top screen of SETUP menu
** SET UP ** P1
CAMERA ID *OFF
ELC *OFF
SHUTTER OFF
GAIN OFF
SENS UP OFF
BINNING OFF
OUTPUT SEL RGB
HDMI OUTPUT YPbPr(422)
END
** SET UP ** P2
SCENE FILE *FILE1
WHITE BAL AWC
BLACK BAL *MANU
SYNC INT
END
** SET UP ** P3
ELECTRIC ZOOM ON
FREEZE ON
FLIP ENABLE OFF
MIRROR ENABLE OFF
STATUS DISPLAY OFF
SD ASPECT SIDE CUT
END
Step 1
Hold down the [FREEZE MENU ] button for 2 seconds or
more.
The top screen of the SETUP menu appears.→
Step 2
The SETUP menu consists of 3 pages of contents.
To turn a page, move the cursor to “P1” or “P2”, “P3” and
press the [e] or [f] button. In addition, when the cursor is
moved to “P1” and the [e] button is pressed or when the
cursor is moved to “P3” and the [f] button is pressed, the
“SCENE FILE” screen appears.
Note:
The cursor is a blinking part.•
The cursor is displayed with halftone in these instruc-
tions.
Step 3
Perform the settings for each item.
Selection of setting item:•
Press the [g] button or [h] button to move the cursor.
Change of settings:•
Press the [e] button or [f] button.
Display of advanced setup screen:•
Press the [SEL] button when “*” is attached to the target
item.
Return to previous setup screen:•
Move the cursor to “RET” and press the [SEL] button.
Step 4
To return to the camera image screen after saving the set-
ting contents, move the cursor to “END” and press the
[SEL] button.
The setting contents can be saved even if the power of the
CCU is turned off.
Default restoring
To restore the setting contents with level indicator in the SETUP menu or SEL menu to each default, hold down the [• e] and
[f] buttons simultaneously for 2 seconds or more.
To restore all the setting contents in the SETUP menu and SEL menu to default, move the cursor to “END” in the bottom•
line and hold down the [FREEZE MENU ] and [h] buttons simultaneously for 2 seconds or more.

18
qCamera title setting [CAMERA ID]
This item specifies the camera title. The camera title that indicates the camera location and other information about the camera
is created with alphanumerics, symbols and displayed on the screen. The camera title is named with up to 16 characters.
Follow the procedure below to specify the camera title.
Top screen of SETUP menu Title creation screen Display positioning screen
** SET UP ** P1
CAMERA ID *OFF
ELC *OFF
SHUTTER OFF
GAIN OFF
SENS UP OFF
BINNING OFF
OUTPUT SEL RGB
HDMI OUTPUT YPbPr(422)
END
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
0123456789
().,'":;&#!?=
+-*/%$ÄÜÖÆÑÅ
← → SPACE
*POSI RET END RESET
................
FLOOR 1
Step 1
Set “CAMERA ID” to “ON” and press the [SEL] button.
The title creation screen appears.→
Important:
When “CAMERA ID” is set to “OFF”, the camera title•
does not appear even after setting the camera title.
Note:
Even when “CAMERA ID” is set to “OFF”, pressing the•
[SEL] button allows the title creation screen to appear.
Step 2
Move the cursor to the target character by pressing the [g],
[h], [e] and [f] buttons, and press the [SEL] button.
The entered characters are displayed in the editing area.→
<Character entry>
To revise a character, move the cursor to “• ←” or “→”
and press the [SEL] button. Move the cursor to the
character to be revised in the entry range and reenter a
correct character.
To enter a blank, move the cursor to “SPACE” and press•
the [SEL] button.
To delete all the entered characters, move the cursor to•
“RESET” and press the [SEL] button.
Step 3
Move the cursor to “POSI” and press the [SEL] button after
title entry.
The display positioning screen appears and the entered→
camera title blinks.
Step 4
Use the [g], [h], [e] and [f] buttons to decide the title
position, and hold down the [FREEZE MENU ] button for 2
seconds or more.
The display position is determined and the title creation→
screen appears again.
Editing area

19
wELC setting [ELC]
Setting ELC (electronic light control) to ON provides automatic adjustment of the screen brightness. The convergence level of
ELC can be specified at “BRIGHTNESS” in the SEL menu (☞page 31).
If bright light such as a spotlight is present in the background behind a subject, the subject may appear dark. To eliminate this
phenomenon, masking bright areas allows users to perform backlight compensation to hide bright areas.
Top screen of SETUP menu “ELC CONT” screen
** SET UP ** P1
CAMERA ID *OFF
ELC *OFF
SHUTTER OFF
GAIN OFF
SENS UP OFF
BINNING OFF
OUTPUT SEL RGB
HDMI OUTPUT YPbPr(422)
END
** ELC CONT **
AREA ALL
PEAK/AVE ....
|
.... 4
P A
RET END
Step 1
Set “ELC” to “ON” and press the [SEL] button.
The “ELC CONT” screen appears.→
Step 2
Move the cursor to “AREA” and use the [e] or [f] button
to select an area.
The area is selectable from the following:
* The detection areas shown in the drawings below are not
displayed.
ALL (default): The detection target is the whole area
on the screen.
S CIRCLE: The detection target is the small circle area
in the center of the screen.
M CIRCLE: The detection target is the medium circle
area in the center of the screen.
L CIRCLE: The detection target is the large circle area
in the center of the screen.
MANU: The detection target is manually specified.
(☞Page 20)
AUTO: Dark areas are automatically masked, and only
bright areas are detected.
Step 3
Move the cursor to “PEAK/AVE” and use the [e] or [f] but-
ton to adjust the detection level.
When the cursor is moved in the “P” direction, the peak
value (maximum value) is detected. When the cursor is
moved in the “A” direction, the average value is detected.

20
Manual detection area setting
The detection area is manually specified.
“ELC CONT” screen Mask setting screen
** ELC CONT **
AREA *MANU
PEAK/AVE ....
|
.... 4
P A
RET END
Step 1
Select “MANU” in “AREA” on the “ELC CONT” screen and
press the [SEL] button.
The mask setting screen appears.→
Step 2
Move the cursor to the target character by pressing the [g],
[h], [e] and [f] buttons, and press the [SEL] button.
The masked area is displayed in white.→
Note:
Detection is performed only in the masked areas.•
To cancel a masked area, move the cursor to the area•
to be canceled and press the [SEL] button.
To cancel all the masked areas, hold down the [e] and
[f] buttons simultaneously for 2 seconds or more.
Step 3
Hold down the [FREEZE MENU ] button for 2 seconds or
more after completing masking areas.
The “ELC CONT” screen appears again.→
eElectronic shutter setting [SHUTTER]
Specifies the electronic shutter speed. The following are available for the speed:
OFF (default), 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000 and MANU
Selecting “MANU” and pressing the [SEL] button will display the “SHUTTER” screen for the detailed adjustment of shutter
speed.
The adjusting range is from 10/1350 to 1349/1350.
Note:
When “SHUTTER” is specified, set “ELC” and “SENS UP” to “OFF” respectively. (• ☞Pages 19 and 21)
“SHUTTER” screen
** SHUTTER **
MANU SET 1349/1350
RET END
