Panasonic NC-DF1 User manual

English Deutsch FrançaisNederlands Italiano Español
Operating Instructions
Bedienungsanleitung
Gebruiksaanwijzing
Mode d’emploi
Istruzioni operative
Instrucciones de funcionamiento
Coffee Maker (Household Use)
Kaffeemaschine (Hausgebrauch)
Kofezetapparaat (voor huishoudelijk gebruik)
Machine à café (usage domestique)
Macchina da caffè americano (utilizzo domestico)
Cafetera (uso doméstico)
Model No. NC-DF1
NC-DF1(CZ45E154).indb 1 2016/07/04 12:53:17

2
Contents Page
Safety Precautions 4
Electrical Requirement (For UK market only) 11
Important Information 12
Parts Names and Handling Instructions 13
How to Use 14
How to Clean 16
Troubleshooting 18
Replacement Part 18
Specifications 19
Thank you for purchasing the Panasonic product.
This product is intended for household use only.•
Please read these instructions carefully to use the product correctly and safely.•
Before using this product•please give your special attention to “Safety Precautions” (Page 4~10).
Please keep this Operating Instructions for future use.•
Inhaltsverzeichnis Seite
Sicherheitsvorkehrungen 20
Wichtige Informationen 26
Teilenamen und Bedienungsanleitung 27
Bedienung 28
Reinigung 30
Fehlerbehebung 32
Ersatzteil 32
Technische Daten 33
Wir danken Ihnen für den Kauf des Panasonic-Produkts.
Dieses Produkt ist nur für den Haushaltsgebrauch vorgesehen.•
Bitte lesen Sie sorgfältig diese Anleitung, um einen korrekten und sicheren Betrieb der Maschine zu•
gewährleisten.
Bevor Sie dieses Produkt verwenden,•lesen Sie sich bitte aufmerksam die „Sicherheitsvorkehrungen“
(Seite 20-26) durch.
Bitte bewahren Sie diese Bedienungsanleitung für eine spätere Verwendung auf.•
Inhoud Pagina
Veiligheidsmaatregelen 34
Belangrijke informatie 40
Onderdeelnamen en bedieningsinstructies 41
De machine gebruiken 42
De machine schoonmaken 44
Problemen oplossen 46
Vervangend onderdeel 46
Specificaties 47
Hartelijk dank voor uw aankoop van dit Panasonic product.
Dit product is alleen bestemd voor huishoudelijk gebruik.•
Lees deze handleiding zorgvuldig door om het apparaat juist en veilig te gebruiken.•
Voordat u dit product gebruikt,•lees aandachtig de “Veiligheidsmaatregelen” (Pagina 34~40).
Bewaar deze gebruiksaanwijzing voor toekomstig gebruik.•
NC-DF1(CZ45E154).indb 2 2016/07/04 12:53:17

3
English
Table des matières Page
Consignes de sécurité 48
Information importante 54
Nom des pièces et consignes de manipulation 55
Mode d’emploi 56
Nettoyage 58
Problémes et solutions 60
Pièce de rechange 60
Spécifications 61
Nous vous remercions d’avoir choisi le produit Panasonic.
Ce produit est destiné à un usage domestique seulement.•
Veuillez lire attentivement ces consignes afin d’utiliser le produit de manière correcte et sécurisée.•
Avant d’utiliser ce produit,•veuillez porter une attention toute particulière à la section intitulée
“Consignes de sécurité” (Page 48~54).
Veuillez conserver ce mode d’emploi pour référence ultérieure.•
Indice Pagina
Precauzioni di sicurezza 62
Informazioni importanti 68
Nomi dei componenti e istruzioni per l’uso 69
Modalità d’uso 70
Pulizia della macchina 72
Risoluzione dei problemi 74
Componente di ricambio 74
Specifiche 75
Grazie per aver acquistato il prodotto Panasonic.
Questo prodotto è destinato esclusivamente a un uso domestico.•
Leggere attentamente queste istruzioni per utilizzare l’apparecchio in modo corretto e sicuro.•
Prima di utilizzare questo prodotto•prestare particolare attenzione alle “Precauzioni di sicurezza”
(Pagine 62~68).
Conservare queste istruzioni operative per la consultazione in futuro.•
Índice Página
Precauciones de seguridad 76
Información importante 82
Nombres de las piezas e instrucciones de uso 83
Modo de uso 84
Limpieza 86
Resolución de problemas 88
Pieza de recambio 88
Especificaciones 89
Gracias por comprar el producto de Panasonic.
Este producto se ha diseñado exclusivamente para un uso doméstico.•
Lea atentamente estas instrucciones para utilizar el aparato de forma correcta y segura.•
Antes de utilizar este producto,•preste especial atención a las “Precauciones de seguridad”
(páginas 76~82).
Conserve estas instrucciones de funcionamiento para su uso en el futuro.•
Deutsch FrançaisNederlands Italiano Español
NC-DF1(CZ45E154).indb 3 2016/07/04 12:53:17

4
Safety Precautions
In order to prevent accidents or injuries to the user, other people,
and damage to property, please follow the instructions below.
 The following charts indicate the degree of damage
caused by wrong operation.
WARNING:
Indicates serious injury or death.
CAUTION: Indicates risk of injury or property damage.
 The symbols are classified and explained as follows.
This symbol indicates prohibition.
This symbol indicates requirement that must be followed.
WARNING
Do not damage the mains lead or
q
mains plug.
Following actions are strictly prohibited.
Modifying, touching on or placing near
heating elements, bending,
twisting, pulling, pulled over sharp edges, putting heavy
objects on top, bundling the mains lead and carrying the
appliance by the mains lead.
(It may cause electric shock, or fire due to short circuit.)
Do not use the appliance if the mains lead or mains
q
plug is damaged or the mains plug is loosely
connected to the household mains socket.
(It may cause electric shock, or fire due to short circuit.)
 If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
person in order to avoid a hazard.
Please make sure to
follow these instructions.
Mains lead
Mains plug
NC-DF1(CZ45E154).indb 4 2016/07/04 12:53:18

5
English
WARNING
Do not plug or unplug the mains plug with wet hands.
q
(It may cause electric shock.)
Always ensure that hands are dry before handling the
●
mains plug or switching on the appliance.
Do not immerse the appliance in water or splash it
q
with water.
(It may cause electric shock, or fire due to short circuit.)
Do not allow infants and children to play with
q
packaging material.
(It may cause suffocation.)
Make sure the voltage indicated on the label of the
q
appliance is the same as your local supply.
(It may cause electric shock or fire.)
Also avoid plugging other devices into the same
household mains socket to prevent electrical over heating.
However, if you are connecting a number of mains plugs,
make sure the total wattage does not exceed the rated
wattage of the household mains socket.
Insert the mains plug firmly.
q
(
Otherwise it may cause electric shock and fire due to
heat that may be generated around the mains plug.
Clean the mains plug regularly.
q
(
Dust and moisture build-up on the mains plug may
cause insufficient insulation, which may cause a fire.
 Unplug the mains plug, and wipe with a dry cloth.
Keep the mains lead out of reach of children. Do not
q
let the mains lead hang over the edge of the table or
worktop.
(It may cause burns, injury or electric shock.)
)
)
NC-DF1(CZ45E154).indb 5 2016/07/04 12:53:18

6
Safety Precautions Please make sure to
follow these instructions.
WARNING
Do not disassemble, repair or modify this appliance.
q
(It may cause fire, electric shock or injury.)

Consult the place of purchase or a Panasonic service centre.
Do not touch or get your face close to places where
q
steam is coming out.
(It may cause burns or injury.)
Especially keep the appliance out of reach of infants and
●
children.
Do not use the appliance without the jug or with other
q
jugs than the one provided.
(It may cause burns.)
This appliance can be used by children aged from
q
8 years and above if they have been given supervision
or instruction concerning use of the appliance in a
safe way and if they understand the hazards involved.
Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of
children aged less than 8 years.
Children shall not play with the appliance.
(It may cause burns, injury or electric shock.)
Appliances can be used by persons with reduced
q
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and if they understand the hazards involved.
(It may cause burns, injury or electric shock.)
Always keep the children away from the appliance.
q
(It may cause burns or injury.)
Children do not realise dangers that are likely to occur
●
because of improper use of appliances.
NC-DF1(CZ45E154).indb 6 2016/07/04 12:53:18

7
English
WARNING
Discontinue using the appliance immediately and
q
unplug in the unlikely event that this appliance stops
working properly.
(It may cause smoking, fire, electric shock or burns.)
e.g. for abnormal or breaking down
The mains plug and the mains lead become abnormally
●
hot.
The mains lead is damaged or the appliance power fails.
●
The main body is deformed, has visible damage or is
●
abnormally hot.
The handle of the jug is loosen.
●
There is another abnormality or failure.
●
 Unplug the appliance immediately and consult the
place of purchase or a Panasonic service centre for
inspection or repair.
CAUTION
Do not use the appliance for any purpose other than
q
those described in these instructions.
(It may cause burns or injury.)
Panasonic will not accept any liability if the appliance is
●
subject to improper use, or failure to comply with these
instructions.
Do not allow the mains lead to come into contact with
q
the plate.
(It may cause fire or injury)
Do not touch the hot surface such as the plate or top
q
surface of the main body while appliance is in use or
immediately after use.
Be careful with the residual heat source especially after
●
use.
(The surfaces get hot during use which cause burns.)
NC-DF1(CZ45E154).indb 7 2016/07/04 12:53:18

8
CAUTION
Do not move the appliance when the jug is in place.
q
(It may cause burns.)
Do not remove the jug while brewing.
q
(It may cause burns.)
Do not move the appliance by holding the water tank
q
lid or basket.
(It may cause burns or injury.)
Do not use the appliance (including the jug) on
q
following places.
On uneven surfaces, on non-heat-resistant carpet or
●
table cloths etc.
(It may cause fire or injury.)
Places where it may be splashed with water or near a
●
heat source.
(It may cause electric shock or electrical leakage.)
Near any open water such as bathtubs, sinks, or other
●
containers.
(It may cause electric shock or electrical leakage.)
Near a wall or furniture.
●
(It may cause discolouration or deformation.)
Places that could be damaged even by moderate heat.
●
(It may cause discolouration or deformation.)
Do not open the water tank lid while the coffee is
q
brewing.
(It may cause burns.)
Safety Precautions Please make sure to
follow these instructions.
NC-DF1(CZ45E154).indb 8 2016/07/04 12:53:18

9
English
CAUTION
Do not leave the appliance unattended when it is in
q
use.
(It may cause fire.)
When leaving it, turn the power off.
●
Do not insert any object in the gaps.
q
(It may cause electric shock.)
Especially metal objects such as pins or wires.
●
Make sure to hold the mains plug when unplugging
q
the mains plug.
Never pull on the mains lead.
(
Otherwise it may cause electric shock, or fire due to
short circuit.
Always ensure the appliance is switched off and
q
unplug the mains plug when the appliance is not in
use, before moving and before cleaning.
(
Otherwise it may cause electric shock, or fire due to
electric leakage.
Place the appliance on a firm, dry, clean flat heatproof
q
worktop.
(Otherwise it may cause burns or injury.)
Beware not to be tripped over or get caught in the
q
mains lead while in use.
(Otherwise it may cause burns or injury.)
Unplug and allow the appliance to cool down fully
q
before cleaning and storing away.
(It may cause burns.)
)
)
NC-DF1(CZ45E154).indb 9 2016/07/04 12:53:18

10
CAUTION
When handling the jug with hot coffee in, do not tilt or
q
open the jug lid. Hot liquid may spurt out or drop on
your hand.
(It may cause burns.)
Always hold the jug handle.
●
Make sure to clean the appliance after every use.
q
(
Otherwise it may cause burns due to overflow by
clogging the filter holder.
)
Safety Precautions Please make sure to
follow these instructions.
NC-DF1(CZ45E154).indb 10 2016/07/04 12:53:18

11
English
Electrical Requirement (For UK market only)
FOR YOUR SAFETY PLEASE READ THE FOLLOWING
TEXT CAREFULLY.
This appliance is supplied with a moulded three pin mains plug
for your safety and convenience. A 13-amp fuse is fitted in this
plug.
Should the fuse need to be replaced please ensure that the
replacement fuse has a rating of 13-amp and that it is approved
by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of
the fuse.
If the plug contains a removable fuse cover, you must ensure
that it is refitted when the fuse is replaced.
If you lose the fuse cover, the plug must not be used until a
replacement cover is obtained.
A replacement fuse cover can be purchased from your local
Panasonic Dealer.
If the fitted moulded plug is unsuitable for the socket outlet in
your home, then the fuse should be removed and the plug cut
off and disposed of safely. There is a danger of severe electrical
shock if the cut off plug is inserted into any 13-amp socket.
How to replace the fuse
The location of the fuse differs according to the type of AC mains
plug (figures A and B). Confirm the AC mains plug fitted and
follow the instructions below. Illustrations may differ from actual
AC mains plug.
Open the fuse cover with a screwdriver and replace the fuse and
close or attach the fuse cover.
Figure A Figure B
Fuse cover
NC-DF1(CZ45E154).indb 11 2016/07/04 12:53:18

12
Important Information
Do not fill the tank with milk, hot water etc. Only use cold water.•(It may cause malfunction.)
Do not place the jug on any heat sources or in a microwave.•(It may cause damage to the jug.)
Do not use the appliance outdoors.•
This symbol on the product indicates “hot surface
and should not be touched without caution”.
NC-DF1(CZ45E154).indb 12 2016/07/04 12:53:19

13
English
Parts Names and Handling Instructions
Clean the appliance by following the steps below
for the first time or when you have not used it for a
while.
1Wash all detachable parts. (P.16~17)
Set the filter holder and jug in place.
• Do not fill with ground coffee.
Fill water in the water tank up to 8 on the scale
and close the watertank lid.
Plug in and turn on the power switch.
When the water tank gets empty, turn off the
power switch and throw the hot water in the jug
away.
Before use
Water tank lid
Mains plug
* The shape of plug may be
different from illustration.
Mains lead
Basket
Water tank
Filter holder
To disassemble q
Anti-drip valve
1
1Pull the basket
out.
Remove the
filter holder.
To assemble q
1

1Insert the filter
holder into the
basket.
Close the
basket.
• Make sure it is
closed firmly.
Plate
* Plate has a
warming function.
Water level
(Inside)
Aroma control
Power
indicator
Power switch
Jug (Glass)
Jug lid
Mesh filter Measuring spoon
To replace the mesh filter. (•P.18)
Also you can use paper filters (1•4) sold in stores
instead of the mesh filter provided.
Accessories
NC-DF1(CZ45E154).indb 13 2016/07/04 12:53:19

14
How to Use
1Place the filter holder, mesh filter,
jug and add ground coffee to
taste.
When finely ground coffee is used with the•
mesh filter, it may become clogged. Please
use a paper filter.
2Set the aroma control as desired.




1Set the filter
holder. (P.13)
Close the
basket.
Note: Make sure the basket is closed firmly
when closing it.
Preheating the jug
When you are brewing small amount of coffee or•
room temperature is low, preheat the jug by pouring
hot water to have hot and tasty coffee.
After preheat the jug, throw the hot water away.•
Do not use any heat source or microwave to•
preheat the jug.
Reference for amount of coffee
Brewed Coffee Fine Ground Coffee
(Approx.)
Medium Ground Coffee
(Approx.)
1 cup=Approx. 120 mL q
Measured by measuring spoon q
provided.
(Level off the top.)
*Use a paper filter for finely ground
coffee.
2 cups 4 scoops 5 scoops
4 cups 8 scoops 7½ scoops
6 cups 11 scoops 10 scoops
8 cups 14 scoops 12 scoops
Darker
Lighter
NC-DF1(CZ45E154).indb 14 2016/07/04 12:53:20

15
English
3Fill water in the water tank,
then plug in and turn on the
power switch. 4After brewing is completed, turn off
the switch and remove the jug.
Power indicator lights while the switch is on.•
Note
Do not fill the water tank with hot water.•
(A lot of steam may spurt out.)
Do not brew coffee when the water is below 2•
or more than the maximum 8 on the scale.
Do not add water while brewing.•
When water is added more than you desire,•
please remove it by using another container.
To brew coffee consecutively
Repeat step 1~3.
Wait for 5 minutes to add water in the water•
tank.
(
If water is added too soon, steam may spurt
out.
Note
Do not pull out the basket when jug is set on the plate.•
(Coffee will drip.)
Coffee is hot, remove the jug slowly.•
(Hot coffee may spill out.)
When the jug is removed immediately after brewing,•
coffee may drip. In that case, please wait to remove the
jug for a while after brewing.
When handling the jug with hot coffee in, do not open the•
jug lid. Hot liquid may spurt out or drop on your hand. (It
may cause burns.)
When removing the jug, pull it in line with the handle.•
To keep the coffee warm, leave the power switch in the•
on position. The appliance switch off automatically after
30 minutes from the power switch is turned on.
After use
Unplug the coffee maker after use.•
When you have remaining water in the water tank
Turn on the coffee maker and extract water completely•
into the jug, then throw it away.
)
NC-DF1(CZ45E154).indb 15 2016/07/04 12:53:20

16
How to Clean
Clean the appliance after every use.
Unplug and make sure that the appliance has coolled down before cleaning.
Note
Do not use benzine, thinner, alcohol, bleach, polishing powder, metal brush or nylon brush, otherwise the surface•
will be damaged.
Do not use a dishwasher.•
Do not clean the appliance with pointed object such as a toothpick or pin.•
Handle the jug with care.•
Do not use the jug if it is chipped or cracked.
Filter holder
Wash with diluted dish soap (neutral) and a soft sponge.
Anti-drip valve•
It is to prevent leakage of
the remaining drops from
the basket.
1Pour water in the filter
holder.
Push the anti-drip valve up
and shake it for 2~3 times. Anti-drip valve
Glass jug
Wash with diluted dish soap (neutral) and a soft
sponge.
Measuring spoon
Wash with diluted dish soap (neutral) and a soft
sponge.
Body / Plate
Wipe with a well-wrung cloth.
To avoid damaging surfaces of the body and the
plate.
Do not hit with hard objects or rub them with•
scouring pad.
NC-DF1(CZ45E154).indb 16 2016/07/04 12:53:20

17
English
Clean the water tank with citric acid
when brewing is slow
The brewing speed gets slow when the mineral
such as the calcium contained in water adheres to
the water pipe and the water tank.
*Scale buildup occur more in areas where the
water contains more minerals.
Set the basket and jug.
1
Fill the water tank with cold water up to 8 on
2 the scale and add approx. 20 g(2 tbsp) of citric
acid.
Mix well with a stick and then close the
watertank lid.
Plug in and turn on the power switch.
3
When the water tank gets empty, turn off the
4 power switch and throw hot water in the jug
away.
Repeat step 1~4 with only water to remove the
5 smell of the citric acid.
Mesh filter
Wash under running water.
Do not use the brush, dish soap or scouring pad.•
(
It may cause tearing off the filter or leaving the
smell of dish soap.
)
NC-DF1(CZ45E154).indb 17 2016/07/04 12:53:20

18
Please check the following points before arranging for service.
Problem Cause
Ground coffee is spilled
from the mesh filter.
More than maximum amount of ground coffee was added. q
Do not add more than maximum amount of ground coffee.
(P.14)
The mesh filter is torn off. q
Replace the mesh filter or use paper filter.
Finely ground coffee has been used with the mesh filter. q
Use a paper filter for finely ground coffee.
Brewing speed is slow or
coffee is not coming out.
Scale has built up in the water pipe and in the water tank. q
Clean the water tank with citric acid. (P.17)
Brewed coffee
temperature is low.
Preheat the jug by filling it with hot water, then emptying it q
before brewing. (P.14)
When coffee grounds
appear in a cup.
The Mesh filter has been used for finely ground coffee. q
Try using a paper filter instead of the mesh filter.
Troubleshooting
Replacement Part
Part name Part number
Mesh filter ACA43-153-K0
NC-DF1(CZ45E154).indb 18 2016/07/04 12:53:21

19
English
Power supply 230 - 240 V 50 - 60 Hz
Power consumption 900 - 980 W
Max. amount of water 1.1 L (8 cups)
Dimensions (W D H) (approx.) 293 167 346 mm
Weight (approx.) 2.9 kg
Length of the mains lead (approx.) 0.9 m
Disposal of Old Equipment
Only for European Union and countries with recycling systems
This symbol on the products, packaging, and/or accompanying documents means that used
electrical and electronic products must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products, please take them to applicable
collection points in accordance with your national legislation.
By disposing of them correctly, you will help to save valuable resources and prevent any potential
negative effects on human health and the environment.
For more information about collection and recycling, please contact your local municipality.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
Specifications
NC-DF1(CZ45E154).indb 19 2016/07/04 12:53:21

20
Sicherheitsvorkehrungen
Um Unfälle oder Verletzungen des Benutzers und anderer Personen
sowie Sachschäden zu vermeiden, befolgen Sie bitte die folgenden
Anweisungen.
 Die folgenden Symbole weisen auf das mögliche Ausmaß der
Folgen unsachgemäßer Bedienung hin.
WARNUNG:
Weist auf die Möglichkeit schwerer Verletzungen oder Tod hin.
ACHTUNG:
Weist auf die Möglichkeit von Verletzungen oder Sachschäden hin.
 Die Symbole werden wie folgt kategorisiert und erläutert:
Dieses Symbol weist auf ein Verbot hin.
Dieses Symbol weist auf eine erforderliche Anweisung hin, die befolgt werden muss.
WARNUNG
Beschädigen Sie nicht das Netzkabel
q
oder den Netzstecker.
Sie dürfen auf keinen Fall das Netzkabel
bzw. den Netzstecker modifizieren, auf
oder an Heizkörper legen, knicken,
verdrehen, über scharfe Kanten ziehen, durch schwere
Gegenstände quetschen oder das Gerät am Netzkabel
transportieren.
(Es besteht Brand- und Stromschlaggefahr durch Kurzschluss.)
Verwenden Sie das Gerät nicht, wenn das Netzkabel oder
q
der Netzstecker beschädigt ist bzw. der Netzstecker nur
lose in der Steckdose steckt.
(Es besteht Brand- und Stromschlaggefahr durch Kurzschluss.)
 Wenn das Netzkabel beschädigt ist, muss es vom Hersteller,
einem Servicemitarbeiter oder einer anderen qualifizierten
Person ersetzt werden, um Gefahren zu vermeiden.
Bitte befolgen Sie diese
Anweisungen.
Netzkabel
Netzstecker
NC-DF1(CZ45E154).indb 20 2016/07/04 12:53:21
