Panasonic DP-130P User manual

Digital Copier
Model No.
DP-130P/135P/150P/150PA
DP-135FP/150FP/150FX
Operating Instructions
Before operating this equipment, please read
these instructions completely and keep these
operating instructions for future reference.
Before UsePrinter Section
Class 2 Fax Modem
Section
(For Printer, Document Management System)
English
Options (Available separately)
DA-DS150
Document Management
System Section

2
Energy Star
The DP-130/135/150 copier complies with Tier 2 of the Environmental Protection Agency's
Energy Star Program. This voluntary program specifies certain energy consumption and usage
standards for copiers. These copiers will automatically “power down” after a specified period of
non-use.
The use of these Energy Star compliant copiers will reduce energy consumption and ultimately
benefit the environment.
The default functions can be adjusted depending on your office requirements. Please see your
authorized Panasonic copier dealer for more details.
The following trademarks and registered trademarks are used throughout this manual:
Microsoft,MS-DOS,Windows and Windows NT are registered trademarks of Microsoft Corporation
in the USA and other countries.
i386,i486 and Pentium are trademarks of Intel Corporation.
Centronics is a registered trademark of Centronics Data Computer Corporation.
TrueType is a registered trademark of Apple Computer,Inc.
All other trademarks identified herein are the property of their respective owners.
Copyright c 2000 by Matsushita Graphic Communication System,Inc.
All rights reserved.Unauthorized copying and distribution is a violation of law.
Printed in Japan.
The contents of these Operating Instructions are subject to change without notice.

3
Table of Contents
External View and
Control Panel
External View ............................................................................ 6
Control Panel 7
Installation and Configuration (Windows 95/98)
Installing the Printer Driver ........................................................
Installation and Configuration (Windows NT 4.0)
Installation and Configuration (Windows 2000)
Print Operation Printing from Windows Applications ......................................... 59
Printing on Network ................................................................. 60
Before Use
Printer Section
.............................................................................
9
Configuring the Printer Driver Settings (Administrator) ............. 25
Configuring the Printer Driver Settings (User) .......................... 34
Configuring the Printer Driver Settings (Administrator) ............
Configuring the Printer Driver Settings (User) ...........................
44
53
Troubleshooting Starting with: .............................................................................
..............................................
Document is not printed correctly
...................................
Error messages displayed on computer
61
62
64
Printing/Scanning Area ............................................................
..............................................
Pararell Interface Connector
65
66
Precautions .................................................................................................................... 5
Appendix
Configuring the Printer Driver Settings ................................... 12
Installing the Printer Driver ........................................................ 21
Installing the Printer Driver ........................................................ 39
Class 2 Fax Modem Section
Installing the Panasonic Class 2 Fax Modem
Installing (Windows NT 4.0) .....................................................
Installing (Windows 2000) .........................................................
74
77
Installing (Windows 95/98) ........................................................ 68

4
Table of Contents
Document
Manager
Main Window .........................................................................
Basic Operations ......................................................................
Document
Scanner
Document View
Status Monitor Task Bar Display ..................................................................... 129
Task Bar Menu ........................................................................ 130
Document Management System Section
86
88
Main Window ......................................................................... 100
Tool Menu ................................................................................ 104
Image Scanning ........................................................................ 106
Main Window ............................................................................
Basic Operations .......................................................................
108
110
Setting Plug-in ......................................................................... 90
File Menu ................................................................................. 92
Edit Menu ................................................................................ 97
View Menu ............................................................................... 98
Annotation Function ..................................................................
File Menu ...................................................................................
111
112
Edit Menu .................................................................................
Page Menu ...............................................................................
116
117
Annotation Menu ......................................................................
Image Menu ..............................................................................
118
125
View Menu .............................................................................. 128
Display Status Details ............................................................... 130
Configuration
Editor
Main Window ............................................................................
User Parameters Folder ............................................................
134
136
Fax Parameters Folder ..............................................................
Copier Settings Folder.................................................................
137
138
Print Out ....................................................................................
Journal Folder ............................................................................
140
139
Phone Book Settings Shortcut Activation Folder ...................... 141
Phone Book
Editor Activation Procedure ............................................................... 144
Retrieve/Write .........................................................................
Open/Save File ........................................................................
145
147
Insert Entry ................................................................................
Delete Entry ............................................................................
149
150
Document Menu ...................................................................... 99
Features ................................................................................. 142

5
Precautions
For U.S.A.
You need to read the software license agreement before setting up the Printer Driver.
You need to read the following precautions which is described in the Copier Operating Instructions.
Installation
Ventilation
Handling
Toner and Paper
For your safety
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interence in which case the user will be required to correct the
interference at his/her own expense.
Any unauthorized changes or modifications to this equipment would voide the users authority to operate
this device.

6
Power switch
Usually set to ( ) position.
External View and Control Panel
External View
Parallel interface connector
Connect to PC
Parallel interface cable
Obtain a cable conforming to a PC separately.
(A cable does not come with the unit.) Use a cable of
IEEE1284 specifications, with a maximum length of
6 ft (2m). Consult a service provider for details.
Paoer Exit Tray
(Face Down)
Pull out when printing
Paper Tray 1
Sheet Bypass Tray
Paper Feed Cover (2nd Paper Feed Module)
When removing a misfed paper.
Front Cover
When replacing the Drum
Unit/Toner Cartridge or
removing a misfed paper.
2nd Paper Feed Module
(Option/Paper Tray 2)
Right Cover
Control Panel
When replacing the Drum
Unit/Toner Cartridge or
removing a misfed paper.

External View and Control Panel
7
Control Panel
ON LINE LED
Paper is misfed.
Paper is empty.
Displays Printer condition
If a error code/message is indicated, please refer to the
"Troubleshooting" section for correctly action.
No. FunctionName
2SIDED DP-150FX
START
12
45
78
0
3
6
9
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
PAPER TRAY
SELECT FUNCTION
CLEAR/STOP
SET
2 in 1
ZOOM
(50~200%) SEARCH
DIRECTORY
abc..
DATA
COPY
FAX PHOTO
AUTO
SORT REDIAL
PAUSE/
FLASH/
MONITOR
SAVER
ENERGY RESET
DARKER
LIGHTER
ON LINE
SUB-ADDR
+-
2 SIDED
TONE
-/()
2SIDED
AUTO
DARKER
LIGHTER
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
ON LINE
For DP-130P/150P/150PA
For DP-135FP/150FP/150FX
1
2
123
1
2
For DP-150PA
Flashes : Printer receives a print data from PC.
Lights up: Printer is waiting.
Paper Misfeed/
Add Paper LED
3
3
3 Digits LED
(DP-130P/150P)
Message Display
(DP-135FP/150FP
150FX)

Printer Section
Digital Copier
Printer Section
Printer Section

9
Installation and Configuration (Windows 95/98)
Installing the Printer Driver
Next
Next
Click the key.
3
1Open the Printers dialog box.
Click the Start key.
Place the cursor on Settings and click Printers.
2Double-click the Add Printer
icon.
4Select Local printer and click
the key.
Network printer is specified when a printer on the
network is installed.
Refer to the Windows 95/98 users' manual for
details.

Installation and Configuration (Windows 95/98)
10
Next
Next
OK
Have Disk...
5Insert the CD-ROM containing the printer driver.
Click the key.
6Specify the drive name and type
D:\Driver\Win9x.
(When drive D is CD-ROM drive.)
Click the key.
7Select the device (Panasonic DP-###).
Panasonic DP-150).
Click the key.
8Select LPT1.
Click the key.

Installation and Configuration (Windows 95/98)
11
9
In response to Do you want your Windows-
based programs to use this printer as the
default printer?, select Yes or No.
Click the key.
10
The required files are copied.
The Printers Icon is now displayed in the Printers
folder.
Be sure to delete the drivers of earlier version before updating drivers.
Restart Windows after updating drivers.
NOTE
Finish

12
Installation and Configuration (Windows 95/98)
NOTE
To change the printer settings, open the dialog box for the printer properties by the following steps.
Upon printing, changing properties Paper/Layout, Handling, Quality and Device
Options is allowed by clicking Properties in the print dialog box of an application.
Management tab of the color of property dialog box is not used on DP-130/135/150.
Sharing Tab in property dialog box is not displayed unless printer sharing has not
been specified.
1Click the Start key, place the cursor on Settings, and then click Printers.
2Right-click the printer icon in the printers window, and select Properties in the dropdown menu.
The dialog box for the printer properties appears.
Configuring the Printer Driver Settings

Installation and Configuration (Windows 95/98)
13
Browse...
Print Test Page
General Tab
Comment
If another user sets up this printer on his or her computer when sharing the printer, the comment specified
here will also appear on that computer. However, the comment displayed for an already set-up user will
remain unchanged even if the comment is modified later.
Separator page
Inserts a separator page for every document to be printed. This feature is useful when multiple users
share the same printer or when printing multiple documents at one time. The user can choose between
Full, which is adorned with graphics, and Simple which consists of only text.
To use a specific separator page, click on
be used as the separator page.
key
Prints a test page. This allows the user to verify if the printer is installed properly.
Enter comments to the properties, if any.
and then specify any Windows metafile (.WMF) to

Installation and Configuration (Windows 95/98)
14
Capture Printer Port... End Capture...
Delete Port...
New Driver...
Details Tab
Print to the following port
Displays either the port to which the printer is connected or the path to the network printer.
To change the printing destination, either select the printing destination port from the list or enter the
network path here.
Print using the following driver
Displays the type of the printer driver. Specify the printer being used or a printer model which can be
emulated with the printer being used.
/ key
Assigns a port to the network drive or cancels a port assigned to the network drive.
Timeout settings - Not selected
Specify the amount of time (in seconds) allowed to elapse before the printer becomes online. If the printer
is not online within this duration, an error message will be displayed.
Timeout settings - Transmission retry
Specify the amount of time (in seconds) allowed to elapse before the printer is ready for printing. If the
printer is not ready for printing within this duration, an error message will be displayed.
Increase this value if a timeout error occurs when printing a large document.
/ key
Adds/deletes a new port or a new network path.
key
Updates or modifies the printer driver.
Add Port...

Installation and Configuration (Windows 95/98)
15
key
Specify the method of sending (spool) documents from the program to the printer.
Spool Data Type
Select spool data type (EMF format or RAW format). Specifying RAW format results in longer time before
placing an application operational after printing on the application.
Note: Spooling by EMF format (metafile compression) may cause the following problems on some
application software.
1) Printing result is different from the screen display.
2) Printing requires excessive time.
key
Modifies printer port settings.
Enable bidirectional support
Be sure to check the check box for "Enable bidirectional support" when installing the status monitor.
Printing may be disabled without checking it.
Spool Settings...
Port Settings...

16
NOTE
Sharing Tab
Sharing Tab in property dialog box is not displayed unless sharing of printer has been
specified.
Not Shared/Shared As
Select whether to display or use this printer with other computers.
Share Name
Specify the name of the shared printer. The displayed name can be used as it is or a new name may be
entered. The name specified at this time will be displayed when other users view information about the
printer on the network.
Comment
You can enter comment regarding a shared printer (such as the type of printer and the location where it is
installed). When other users view information about the printer on the network, the comment specified
here will be displayed.
Password
Specify a password when other users will connect to this printer.
Leave the box blank in order not to use any password.
Installation and Configuration (Windows 95/98)

17
Paper/Layout Tab
Paper Size
Select a document size.
Paper Source
Specify where the paper you want to use is located in the machine. If you choose Auto Selection, the
printer driver will automatically select an appropriate tray according to the Paper Size.
Orientation
Select the print orientation (Portrait/Landscape).
Copies
Specify the number of copies to be printed. If the number of copies to be printed can be specified within
the application, indicate one copy here and specify the number of copies in the Print dialog box of the
application.
Zoom
Specify an enlargement or reduction percentage when printing documents. If enlargement/reduction can
be set within the application, indicate 100% here and specify the enlargement/reduction percentage in the
Print dialog box of the application.
N in 1
For printing two or more pages on one sheet, specify a printing method.
Layout is selected by combining with "Orientation." Each layout is displayed with icon.
2 in 1: Print 2 pages of manuscripts zoomed out by 65 or 71% on one sheet.
4 in 1: Print 4 pages of manuscripts zoomed out by 50% on one sheet.
key
Return all items in Paper/Layout Tab to standard settings (default).
Restore Defaults
Installation and Configuration (Windows 95/98)

18
Handling Tab
Sorter
Select whether to Stack or Sort when printing multiple copies.
Duplex (DP-150FX only)
Select duplex printing for printing on both sides.
Note 1) Duplex Printing on Invoice/A5 is not allowed.
Note 2) Duplex Printing is allowed only DP-150FX.
Flipping Direction
Select binding side (Long Edge Binding/Short Edge Binding) for duplex printing.
Installation and Configuration (Windows 95/98)

19
NOTE
Restore Defaults
Quality Tab
dpi (dot per inch) means the number of dots contained in one inch. The higher the
value is, the higher the resolution becomes.
Halftone
Select method of expressing halftone. Select the setting according to the data to be printed and your
preference.
Normal: Select the halftoning method to be used. Select it according to the details of data and your
preference.
Line Art: Use when printing originals containing line drawings or text.
Resolution
Select the printer resolution (300dpi/600dpi).
Density
Adjust the printing density (Contrast and Brightness) as desired.
key
Return all items in the Quality Tab to standard settings (default).
Installation and Configuration (Windows 95/98)

20
NOTE
About
Device Options Tab
Number of Paper Tray
Select the number of available paper trays for the printer if an optional Paper Feed Module is installed.
key
Displays the version information about the printer driver.
Device Options Tab is specified on the printer properties.
Installation and Configuration (Windows 95/98)
