Panasonic FP-D355 User manual

Digital Copier
Model No.
FP-D355/D355DC
FP-D455/D605
Options
FA-A355/A888/F320/F350/F355/F365/FK35/FK36/TR350/TR355/RU350/RU355
FA-DS725/DS825/MA301/MADM8
Operating Instructions (For Copier)
Before operating this copier, please read
these instructions completely and keep these
operating instructions for future reference.
FP-D350
The digital copier with options
(See P.56)
Table of Contents Operation Chart
J
?
I
Before operatingMaking CopiesOptions
Troubleshooting Specifications
English

2
Energy Star
The FP-D355/D355DC/D455/D605 series copiers comply with Tier 2 of the Environmental
Protection Agency’s Energy Star Program.This voluntary program specifies certain energy
consumption and usage standards for copiers.These copiers will automatically “power down”
after a specified period of non-use.The use of these Energy Star compliant copiers will reduce
energy consumption and ultimately benefit the environment.
The default functions can be adjusted depending on your office requirements. Please see your
authorised Panasonic copier dealer for more details.

3
■Control Panel ........................................................................................ 9
■Touch Panel Display ..........................................................................10
Making Copies
Basic Menu ■Full Size Copying ................................................................................12
■Reduction or Enlargement Copying .................................................... 13
■Using the Sheet Bypass .....................................................................14
Duplex/Original
HH
HH
HCopy ■1 \2 Copy / 2 \1 Copy / 2 \2 Copy ............................................ 16 ■Book \2 Copy ..................................................................................17
■2 Page Copy ......................................................................................18
■N in 1 Copy.........................................................................................19
■1 to N Copy ........................................................................................25
■SADF Mode ........................................................................................ 26
Zoom/Effects ■Zoom Copying ....................................................................................28
■Centering/Mirror/Inverse copy.............................................................29
■Edge/Margin/Book Mode ....................................................................30
■Page numbering ................................................................................. 31
Insertion Job ■Cover/Page Insertion .......................................................................... 33
■OHP Interleaving/Presentation ........................................................... 34
Other Features ■Job Memory ...................................................................................... 35
■Sky Shot Modes .................................................................................36
■Energy Saver/Interrupt........................................................................38
■Combining Function Table ..................................................................39
User Preset ................................................................................................................................... 40
■General Functions ..............................................................................41
■Copier Settings ................................................................................... 42
■General Functions for Key Operator ...................................................44
■Copier Settings for Key Operator ........................................................49
Options
■Options ..............................................................................................56
■ADF (FA-A355)/i-ADF (FA-A888) ........................................................ 57
■3 Bin Finisher, Exit Guide Unit (FA-F350/F355/FK35/FK36) ..............59
■2 Bin Finisher, Exit Guide Unit (FA-F365/FK36/SP30) .......................62
■2 Bin Finisher, Exit Guide Unit (FA-F320/FK35/FK36) .......................67
■Inverting Shift Tray (FA-TR350/TR355) ...............................................72
Maintenance
Handling ■Adding Paper ...................................................................................... 73
■Adding Toner....................................................................................... 75
■Replacing the Waste Toner Bottle ...................................................... 76
■Removing the Punch Dust .................................................................77
■Removing a Paper Misfeed ................................................................. 78
Checking ■Troubleshooting .................................................................................. 93
Specifications .............................................................................................................................. 95
System Information ..................................................................................................................... 99
Table of Contents
Control Panel
Table of Contents
Before Operation
Operation Chart ■Common features and usage ...............................................................4
■Function Categories ............................................................................5
Precautions .................................................................................................................................... 6
Options

4
A5 A4
A4R
FLS•B4
A3
A3
A4
B4
A4R
A5
A5
A4R
B4
A4
A3
MULTI-SIZE
FEED
USER
PRESET
SORT/
FINISH ENERGY
SAVER
INTERRUPTMANUAL RESET
1 32
4 65
7 98
＃0
A3
FLS•B4
A5
A4
A4
Operation Chart
Common features and usage
■■
■■
■Basic Operation
NOTE
∗While the copier is warming up, you may position your original on the copier, enter
your copy job selections and press the Print key. The wait indicator will flash until the
warm up cycle is completed and the copy job automatically start.
CWhen making 100 copies continuously or intermittently within 20 minutes, the fan
motor will start rotation.This is not irregular operation but just to cool off the machine.
CFor FP-D455/D605, at following condition Touch Panel Display may light but it will turn
off within 40 seconds.
1. After turning off the Power switch.
2. After connecting the power code to the plug.
Turn the Power
Switch on
(FP-D355/D355DC)
Turn Operation
Switch On
(FP-D455/D605)
1
Position original
2
Copy size
(reduction/
enlargement only)
3
Number of copies
(Up to 999)
4
Press Start*
■■
■■
■Position of the original
CPlace face down on platen and in ADF (FA-A355).
Face Up in i-ADF (FA-A888).
CIf the original is incorrectly placed on the platen glass,
part of the copy image may be missing.
CFor originals smaller than A5 size, align with center of
left original guide and select A5.
Original Guide See [ ]
■■
■■
■Memory capacity:
When the memory becomes full during the original scanning, the message of “Function not
available for lack of memory”will be displayed in the message display. In this case, follow the
operating instruction in the message display.
When the additional memory is required, consult with authorised dealer.
■■
■■
■Note on making multiple copies (For FP-D455/D605)
If the fusing temperature drops excessively during a multi-copy cycle, there is a possibility that
the copying speed will be reduced. The copying speed will automatically return to normal when
the fusing temperature rises enough to ensure good fusing performance.
FP-D455
FP-D605
FP-D355
FP-D355DC
Place paper

5
Touch Panel Display
■■
■■
■Function Categories
ABasic Menu (See page 12)
#Text, Text/Photo, Photo Mode Key
$Exposure Control Keys
%Auto Exposure Key
&Cassette Indication
(Cassette Selection Key
)Job Status Key
BDuplex/Original HH
HH
HCopy (See page 15)
#1 \2 Copy Key
$2 \1 Copy Key
%2 \2 Copy key
&Book \2 Copy Key
(2 Page Copy Key
)N in 1 Copy Key
*1 to N Copy Key
+SADF Key (See NOTE on page 15)
CZoom/Effects (See page 27)
#Zoom Key
$Centring Mode Key
%Page Numbering Mode Key
&Edge Mode Key
(Margin Mode Key
)Book Mode Key
*Mirror Mode Key
+Inverse Mode Key
DInsertion Job (See page 32)
#Cover Mode Key
$Page Insertion Mode Key
%OHP Interleaving Mode Key
&Presentation Mode Key
EJob Memory (See page 35)
#M1, M2, M3, M4, M5 Key
$Memory In Key
■Basic Menu Selection
CDisplays all functions when touching
Basic Menu Key.
CTouch Basic Menu Key again to return to
the basic screen.
Operation Chart
Operation Chart Touch Panel Display
Job memory
Basic Menu DUPLEX/
ORIG. --> COPY
ZOOM/EFFECTS INSERTION JOB
Job memory
AUTO
JOB STATUS TEXT TEXT/PHOTO
PAPER TRAY
BASIC MENU
ZOOM/
EFFECTS
INSERTION
JOB
JOB
MEMORY
LIGHT DARK
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
BASIC MENU
DUPLEX/
ORIG. --> COPY ZOOM/
EFFECTS INSERTION
JOB JOB
MEMORY
12
\\\ \
2 page
2122
Book
2
in
11
NN
to
Basic Menu
DUPLEX/
ORIG. --> COPY
ZOOM/EFFECTS INSERTION JOB
Job memory
BASIC MENU
ZOOM/
EFFECTS
INSERTION
JOB
JOB
MEMORY
Zoom
Centering
Page
Numbering
Edge
Margin Book Mirror Inverse
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
12
22
2
BOOK
ZOOM
CENTERING
PAGE
NUMBERING
ERASE
MIRROR
COVER
INTERLEAV.
PRESEN.
INSERTION
INVERSE
BASIC MENU ZOOM/
EFFECTS INSERTION
JOB JOB
MEMORY
DUPLEX/
ORIG. --> COPY
2 PAGE
N in 1
1 to N
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
BASIC MENU
DUPLEX/
ORIG. --> COPY ZOOM/
EFFECTS INSERTION
JOB JOB
MEMORY
Presentation
OHP interleaving
Page insertion
Cover
Basic Menu
DUPLEX
ORIG. --> COPY
ZOOM/EFFECTS INSERTION JOB
Job memory
Memory
in
Job memory
Select Mem. in or Mem. #
= more settings
100%

6
LASER KLASSE 1
LASER CLASSE 1
RANGO LASER 1
CLASS 1 LASER PRODUCT
(TO IEC 825)
FFPTE1539
CAUTION:
Invisible laser radiation when open
and interlocks defeated.
AVOID EXPOSURE TO BEAM.
VARNING:
OSYNLIG LASER-
STRALNING NÄR DENNA
DEL ÄR ÖPPNAD OCH
SPÄRRAR ÄR
URKOPPLADE.
STRALEN ÄR FARLIG.
VARNING:
OSYNLIG LASER-
STRALNING NÄR DENNA
DEL ÄR ÖPPNAD OCH
SPÄRREN ÄR
URKOPPLAD.
BETRAKTA EJ STRALEN.
VARO!:
NÄKYMÄTÖN AVATTAESSA
JA SUOJALUKITUS
OHITETTAESSA OLET
ALTTIINA LASERSÄTEIL
YLLE.
ÄLÄKATSO SÄTEESEN.
VORSICHT:
Unsichtbare Laserstrahlung, wenn
Abdeckung geöffnet und
Sicherheitsverriegelung überbrückt.
NICHT DEM STRAHL AUSSETZEN.
ATTENTION:
Rayonnement laser invisible
dangereux en cas d'ouverture et
lorsque la sécuritéest neutralisée.
EXPOSITION DANGEREUSE AU
FAISCEAU.
PELIGRO:
Cuando se abre y se invalida el
bloqueo, se producen radiaciones
invisibles de láser.
EVÍTESE LA EXPOSICIÓN
DIRECTA A TALES RAYOS.
ADVARSEL:
USYNLIG LASERSTRALING
VED ABNING NAR
SIKKERHEDSAFBRYDERE ER
UDE AF FUNKTION.
UNDGA UDSÆTTELSE
FOR STRALING.
ADVARSEL:
USYNLIG LASERSTRALING
NAR DEKSEL APNES OG
SIKKERHEDSLAS BRYTES.
UNNGA EKSPONERING
FOR STRALEN.
FFPTE2412
Precautions
For your safety
■■
■■
■Laser Safety
LASER SAFETY
This unit employs a laser. Only qualified service personnel should
attempt to service this device due to possible eye injury.
Caution
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
■■
■■
■Caution Labels
DANGER
CAUTION
ATTENTION
VORSICHT
PRECAUTION
Invisible laser radiation when open.
Avoid direct exposure to beam.
Invisible laser radiation when open.
Avoid direct exposure to beam.
Rayonnement laser invisible si ouvert.
Dangereux de regarder a l'interieur.
Unsichtbare laserstrahlen wenn geöffnet.
Nicht hinensehen.
Peligro-Cuando la cubierta esté abierta se
podrá escapar radiación de rayo láser.
Evite la exposición directa al rayo láser.

7
Precautions
Handling
■Do not look directly at exposure lamp when copying.
■Do not turn the power switch off or open the front
panel during copying.
CDo not drop paper clips or other metal objects into
the copier.
Toner and Paper
■Store toner, developer and paper in cool areas with
low humidity.
CHigh quality paper of 60 –90 g/m2(55 –130 g/m2
via sheet bypass) may be used.
CFor optimum copy quality, it is essential that
Panasonic Brand Toner is used in the copier.
Ventilation
■The copier should be installed in a well-ventilated
area to minimize the ozone density in the air.
Before operating

8
■The copier should not be installed in areas with the
followingconditions:
CExtremely high or low temperature and humidity.
Ambient ConditionsTemperature:10°C – 30°C
Relative humidity:30% – 80%
CWhere temperature and humidity can change
rapidly, causing condensation.
CDirect exposure to sunlight.
CDirectly in air conditioning flow.
CIn areas of high dust concentration.
CIn areas of poor ventilation.
CIn areas with chemical fume concentration.
CIn areas with extreme vibration.
CUnstable or uneven floors.
FORYOUR SAFETY
The mains plug on this equipment must be used to disconnect mains power.Please ensure that the
socket outlet is installed near the equipment and shall be easily accessible.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience.
A 13 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 13
amps and that it is approved by ASTA or BSI to BS1362
Check for the ASTA mark 7or the BSI mark 6on the body of the fuse.
If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is
replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic Dealer.
IFTHE FITTED MOULDED PLUG IS UNSUITABLE FORTHE SOCKET OUTLET INYOUR OFFICE
THENTHE FUSE SHOULD BE REMOVED ANDTHE PLUG CUT OFF AND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IFTHE CUT OFF PLUG IS INSERTED
INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown below.
If in any doubt please consult a qualified electrician.
WARNING:THIS APPLIANCE MUST BE EARTHED.
IMPORTANT:The wires in this mains lead are coloured in accordance with the following code:
Green andYellow:Earth
Blue :Neutral
Brown :Live
As the colours of the wires in the main lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which
is marked by letter E or by the safety Earth symbol “L”or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked
with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in
the plug which is marked with the letter L or coloured RED.
How to replace the fuse.
Open the fuse compartment with a screwdriver and replace the fuse.
Caution Note: Disconnect from the mains supply before removing covers.
Installation
Precautions
For U.K.
N

9
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER
INTERRUPTMANUAL RESET
1 32
4 65
7 98
＃0
A3
FLS•B4
A5
A4
A4
Control Panel
Control Panel
Original Size
Keys Copy Size Keys Touch Panel Display Quantity Keys Start Key Ready Indicator
No Contents Refer to
#Multi-Size Feed Key
CWhen Multi-sized originals are copied using i-ADF/ADF (Option). P.58
$Sort/Finish Key
CWhen sorting and stapling with Finisher (Option).
%User Preset Key
CChanges default modes.
&Energy Saver Key
CCan save power while the copier is not in use.
(Manual Key
CAfter pressing this key, the original size can be selected manually.
)Interrupt Key
CInterrupts other copy or print jobs while making copies.
*Reset Key
CResets all features to the initial power-on state.
+Clear Key
CClears the copy count in the display.
-Stop Key
CStops the copy run.
NOTE
CThe Control Panel displayed above shows only copier functions. Please refer to the
proper operating instructions for Facsimile/Internet/Printer control panel functions.
# $ % &()* + -
P.59 –72
P.40 –55
P.38
P.12
P.38
———
———
———
Precautions Control Panel
.Operation Switch (FP-D455/D605 only)
CFor turning the power On/Off. ———
.

10
Job memory
Basic Menu ZOOM/EFFECTS INSERTION JOB Job memory
JOB STATUS
TEXT
PAPER TRAY
BASIC MENU
ZOOM/
EFFECTS
INSERTION
JOB
JOB
MEMORY
LIGHT DARK
Ready to Copy
AUTO 2
TEXT/PHOTO
DUPLEX/
ORIG. --> COPY
Control Panel
Touch Panel Display
CAdjusting the touch panel display contrast
Adjust brightness of the display by repeatedly pressing A3 or A5 original size key while
pressing and holding the Clear key.
To make the display brighter: A3 size key
To make the display darker : A5 size key
# $ % & ( ) *
+
-
/
0
12
3
4
6
7
ATTENTION
CUse soft finger pressure only to activate touch Screen panel. DO NOT USE SHARP
OBJECTS such as pens, fingernails etc., as this may damage the panel.
5.
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER
INTERRUPTMANUAL RESET
1 32
4 65
7 98
＃0
A3
FLS•B4
A5
A4
A4
100%

11
NOTE
■Touch Panel Display Indications
No Contents Refer to
#Warning indications
?: Add Toner J: Add Paper B: Replace waste toner bottle. 2: Call service
$SADF/Multi-size Feed Mode indication
%Original Image indication
&Rotate Mode indication*
(Copy paper indication
)Number of copies
*Machine/User Error Code indication (E1-01, U13, etc.,)
+Function Categories
-Copy Paper Size indication
.Finisher Functions indication
/
Selected Paper Tray and Paper status indication
2: Tray position G: Normal H: Low paper J: Add Paper
Sheet Bypass : Normal : Add Paper
0Cassette Selection Key
1Manual Exposure Select keys (Light and Dark)
2Original Mode Select key (Text/Text/Photo/Photo)
3Job Status Key
4Auto Exposure Key
5Exposure Indicator (7 steps)
6Copy Ratio indication
Control Panel
7Original Size indication
P.73 –77
P.93
P.26, 58
———
———
———
———
P.93
P.15 –39
———
P.59, 62, 67, 72
———
P.13
P.12
P.12
P.12
———
———
———
———
∗When making copies in A4 (B) if the cassette runs out paper, the copier will
automatically select the A4R (C) cassette and rotate the image to said.
However, the function is not available if any problem occurs by the image rotation
function in the middle of copy operation. (Duplex/Original →copy, Insertion job,
Sort/Finish mode, etc.)
Control Panel

12
Job memory
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
JOB STATUS
TEXT
PAPER TRAY
BASIC MENU
DUPLEX/
ORIG.-->COPY ZOOM/
EFFECTS INSERTION
JOB JOB
MEMORY
LIGHT DARK
Ready to Copy
1
AUTO
TEXT/PHOTO
2
AUTO
JOB STATUS
TEXT
PAPER TRAY
LIGHT DARK
TEXT/PHOTO
2
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER INTERRUPTMANUAL RESET
1 32
4 65
7 98
0
A3
FLS•B4
A5
A4
A4
ENERGY
SAVER INTERRUPT
CLEAR
MANUAL RESET
1 32
Basic Menu
Full Size Copying
■■
■■
■When copying the same size as the original (1:1)
Copy size and copy density are automatically selected.
NOTE
1
Position original
Original Size
Keys Touch Panel Display 2
Number of copies
(Up to 999) 3
Press Start
■■
■■
■Initial Screen
AUTO
JOB STATUS
TEXT
PAPER TRAY
LIGHT DARK
TEXT/PHOTO
2
When placing A4 size originals
CBenefits of QUARC (QUAlitative Reasoning based adaptive Controller).
The FP-D355/D355DC/D455/D605 series features exclusive new Panasonic imaging
technology which utilises an advanced form of artificial intelligence to ensure optimal
copy quality and performance under varying environmental conditions, from a wide
range of originals.
∗The Auto mode cannot be selected in following condition.
(1)The Photo mode is selected.
(2)The Photo mode or Text/Photo mode is selected when FA-A355 is used.
Select original size.
#Select original size with Original Size key.
Input the code number, if xappears.
Select exposure control
CPress the Light or Dark key.
The centre setting is the normal position.
CTouch the Auto key to change the Auto mode.*
$Job Status Key
CEach setting jobs will be indicated on the display.
■■
■■
■When manually selecting exposure control or original size:
#Select the original(s)
CText: Originals are mainly composed of text.
CPhoto: Originals are mainly composed of photo.
CText/Photo:Combined originals with text and photo.
Lights up (Manual mode)
Light turns off
Manual Key
$To cancel Manual mode
Press Key

13
A3
FLS•B4
A5
A4
A4
Job memory
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
JOB STATUS
TEXT
PAPER TRAY
BASIC MENU
DUPLEX/
ORIG. --> COPY
ZOOM/
EFFECTS
INSERTION
JOB
JOB
MEMORY
LIGHT DARK
65%
Ready to Copy
TEXT/PHOTO
2
AUTO
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER
INTERRUPTMANUAL RESET
1 32
4 65
7 98
＃0
A3
FLS•B4
A5
A4
A4
NOTE
ATTENTION
Reduction or Enlargement Copying
■■
■■
■When copying with preset ratios
There are 5 preset reduction and 5 preset enlargement modes.
Basic Menu
1
Position
original
2
Select the copy size
(Landscape for A4/A5 size)
3
Number of
copies
(Up to 999)
4
Press Start
Example: Reduction
Original size Copy size
A3 A4
Full Size Copying Reduction or Enlargement
CPart of the image may be deleted if the direction of the original and copy
paper do not correspond.
The correct ratio is automatically selected.
Reduction and enlargement ratios. (%)
Original
size
Copy size
A3 B4 A4 A5
A3 100 87 71 50
B4 115 100 82 58
A4 141 122 100 71
A5 200 173 141 100
CWhen changing the paper size, touch
PaperTray key.
PaperTray (CASSETTE) Key
CIf the copy size is different from the paper size you can use the sheet bypass.
This will save you having to change the setting of the paper trays.
65%

14
1
2
NOTE
Basic Menu
Using the Sheet Bypass
■■
■■
■To copy on letterhead, mailing labels, transparencies and odd-size paper,
etc., or to use the bypass as an additional paper source.
1Position original.
2Open the Sheet Bypass.
Sheet Bypass
3Pull out the Sheet Bypass tray
until it stops.
4#Place approximately 50 sheets of
paper.
Do not fill above
Insert the paper until it stops.
$Adjust the side guides.
Incorrect adjustment may cause paper
to wrinkle, misfeed or skew.
Side Guides
5Press Start.
CThe bypass has priority over the paper trays.The copier automatically selects the
Sheet Bypass when paper is placed in the empty bypass tray.
CSome types of mailing labels and transparency film may damage your machine.
Please contact your service provider for advice regarding non-standard paper types.
CDo not feed curled paper through the bypass to avoid misfeed.

15
Duplex/Original HH
HH
HCopy
■■
■■
■Initial Screen
CTouch the desired key to select the function.
∗Displays when selecting “Yes” with the SADF function.(See P.49)
CTo copy double sided originals you can use the i-ADF (FA-A888) or place
double sided originals directly onto the original glass.
CADU (Automatic Duplex Unit) is required when making a double sided copy.
The ADU FP-D355DC/D455/D605 is standard.
CTo reset Duplex/Original HCopy mode, press Reset key.
1 \2 From single sided originals to double
sided copies. ⇒See P.16
2 \1 From double sided originals to single
sided copies. ⇒See P.16
2 \2 From double sided originals to double
sided copies. ⇒See P.16
Book \2 From book originals to double sided
copies ⇒See P.17
2 Page Copying two facing pages of an A3 size
original on two separate A4 size sheets. ⇒See P.18
N in 1 From two (or four or eight) single sided
originals onto side by side single sided
copies. ⇒See P.19
1 to N From one single sided original to two
(or four) single sided copies. ⇒See P.25
SADF A special original (like thin paper etc.,)
can be fed from the ADF/i-ADF original
tray. ⇒See P.26
Using the Sheet Bypass Duplex/Original HH
HH
HCopy
Basic Menu
ZOOM/EFFECTS INSERTION JOB
Job memory
DUPLEX/
ORIG.--> COPY ZOOM/
EFFECTS INSERTION
JOB JOB
MEMORY
BASIC MENU
12
\
21
\
22
\
Book
2
\
2 page in
N1
to
N
1
Select function
∗
NOTE

16
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER INTERRUPTMANUAL RESET
1 32
4 65
7 98
0
A3
FLS•B4
A5
A4
A4
1 \\
\\
\2 Copy / 2 \\
\\
\1 Copy / 2 \\
\\
\2 Copy
■1 \\
\\
\2 Copy
From single sided originals to double sided copies.
From Copier Platen & i-ADF/ADF
■2 \\
\\
\1 Copy
From double sided originals to single sided copies.
Using i-ADF
■■
■■
■Procedure
ADF FA-A355 i-ADF FA-A888
2
Place
originals 3
Count
originals
(1 \2 only)
(4)
Select original
size 1
Touch 1 \2,
2 \1 or
2 \2
5
Number of
copies
(Up to 999)
6
Press
Start
NOTE
CTo reset a mode selected using the menu, touch Cancel key on the touch panel.
CFA-A355 is only available for the model FP-D355/D355DC.
#For odd or even originals, touch the Odd or Even
key.
$If number of originals is unknown, touch Original
Count key.
%Touch OK key.
&Return Originals to the ADF/i-ADF.
Duplex/Original HH
HH
HCopy
■2 \\
\\
\2 Copy (FA-A888 is required)
From double sided originals to double sided copies.
Using i-ADF
Odd number
original
Even number
original
CANCEL
Original
count
Set number of originals
Press OK
Face-Down Face-Up

17
Duplex/Original
HH HH
HCopy
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER INTERRUPTMANUAL RESET
1 32
4 65
7 98
0
A3
FLS•B4
A5
A4
A4
NOTE
■Book \\
\\
\2 Copy
From book originals to double sided copies
A3 size originals only.
(Book Format) (Facing Pages)
1
Position original
on the Platen 2
Select the
copy size 3
Select Book \2
mode and Copy
format
4
Number of
copies
(Up to 999)
5
Press Start
CTo reset a mode selected using the menu, touch Cancel key on the touch
panel.
A3 size original
Centre
Centre book
by length
and width
according to
centre
marks.
Centre (Book) mark
CCopy last page first in Facing pages and
Book Format mode. CTouch OK key.
Duplex/Original HH
HH
HCopy
Book \\
\\
\2 Copy
2 side
2 page
Cancel
Select facing page or book format
Press OK
Facing pages
CANCEL
Book format

18
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER INTERRUPTMANUAL RESET
1 32
4 65
7 98
0
A3
FLS•B4
A5
A4
A4
■2-Page Copy
Copying two facing pages of an A3 size
original on two separate A4 size sheets.
A3 size originals only.
■■
■■
■Procedure
2
Place
originals
(3)
Select copy
size*1
Touch 2 Page
mode 4
Number of
copies
(Up to 999)
5
Press
Start
NOTE
∗For reduction or enlargement copy only.
CTo reset a mode selected using the menu, touch Cancel key on the touch panel.
Book on the platen
A3 size original
Centre
Centre (Book) mark
Centre book
by length and
width
according to
centre marks.
2 Page Copy
Duplex/Original HH
HH
HCopy

19
MULTI-SIZE
FEED USER
PRESET
SORT/
FINISH ENERGY
SAVER INTERRUPTMANUAL RESET
1 32
4 65
7 98
0
A3
FLS•B4
A5
A4
A4
N in 1 copy
■■
■■
■N in 1 copy
Fromtwo/four/eightsinglesidedoriginals, side
by side, to single sided copies.(See page 21-24)
NOTE
Duplex/Original HH
HH
HCopy
■■
■■
■Booklet
From four single sided originals, side by
side, to double sided copies.(See page 24)
Cancel
Number of Original
CANCEL
Number of
originals
Set number of originals
press OK
34
3
4
12
1
1
23
4
2
Using FA-F365 Others
■■
■■
■Procedure
ADF i-ADF
Face-Down Face-Up
2
Place originals 3
Count originals
(except Booklet)
Copy size*1
Touch N in 1 mode
and make selection 4
Number of
copies 5
Press Start
#Touch ADF key or input the number of originals with Key Pad.
$After originals are counted, touch the OK key.
%When the ADF key is touched in the step #, re-position originals in document
feeder.
∗Copy is automatically reduced.
(ex. A4 to A4 size)
CA4 Bsize originals only for Booklet.
CThe ADF/i-ADF is required for N in 1 copy.
CWhen using booklet, the maximum number of images that can be stored is
60.If the original capacity you are copying exceeds 50 (ADF capacity), a
user intervention screen will appear that will enable you to process more
originals.If this screen does not appear, see page 43.
Duplex/Original
HH HH
HCopy

20
Duplex/Original HH
HH
HCopy
N in 1 copy
■■
■■
■N in 1 copy
Combination for N in 1 copy operation.
Mode
1 2
Originals Layout Operation
1 2
1 2
1 2
1 2 3 4
1 2 3 4
1 2 3 4
1 2 3 4
1 2 8
1 2 8
1 2 8
1 2 8
1 2 8
8 2 1
21 12
1
2
43 21 42 31 34 12 24 13
21 12
43 21 42 31 34 12 24 13
43 21 42 31 34 12 24 13
1234
5678 1357 2468 4321 8765 7531 8642
12
34
56
78
15
26
37
48
21
43
65
87
51
62
73
84
5
1
2
3
4
6
7
8
1234
5678 1357 2468 4321 8765 7531 8642
5
1
23
4
6
78
2 in 1
4 in 1
8 in 1
Booklet
See page 21
See page 22
See page 23
See page 24
Note:
Center edge will
be lacked.
