Panasonic WORKIO DP-130 User manual

Digital Copier
Model No.
DP-130/130P
DP-150/150A/150PA
Operating Instructions (For Copier)
2
DP-130
DP-130P
DP-150
DP-150A
DP-150PA
DA-DS150
(Option)
Before operating this copier, please read
these instructions completely and keep this
operating instructions for future reference.
Making CopiesMaintenanceChecking Before OperatingOthers
DP-130/130P except U.S.A.
Option
DA-DS150/DA-SM16B

2
INVOICE
LETTER R
LEGAL
INV
LTR
LGL
INV
LTR
LGL
2SIDED
AUTO
DARKER
LIGHTER
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65% INVOICE
LEGAL
61% INVOICE
100%
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
ON LINE
2
Select“100%” 3 Number of
copies
(Up to 99)
: 1 to 9
: 10 to 90
NOTE
4
Press Start
100%
1
10
Power Switch
On OFF
1
Place the
Original
Load Paper
(See page 15)
ExitTray
Pull out it when
copying
Control Panel
■■
■■
■Full Size Copying
Operation Chart
INVOICE
LETTER R
LEGAL
INV
LTR
LGL
INV LTR LGL
■■
■■
■Position of the Original
Original Guide
Place original
against guide.
If the original is not
positioned properly, a
portion of the original
may not be copied.
Face DOWN on Platen Face UP on ADF (DP-150A/150PA)
CUp to 30 originals (20 lbs)
Inappropriate originals for use with the ADF
CPaper with a smooth surface such as glossy and coated papers
CTransparencies
CPaste-ups
COriginals with a lead edge that is “creased”,“folded”, “punched”or “glued”
CPressure sensitive or carbon backed papers
CPaper with excessive curl
CStapledoriginals
COriginals with oil on them
CRemove stacked copies from the exit tray every 200 sheets.

3
AUTO
DARK
LIGHT
■■
■■
■When manually selecting exposure control
CThe copier has auto exposure control and adjustments
are rarely required.
Select Photo to copy photos and halftones.
Select Auto to copy with Auto exposure control.
Select Dark to copy light image originals.
Select Light to copy colored background originals.
Normal Position
Operation Chart
■■
■■
■Features List
Reduction or Enlargement Copying (See page 19) Copying with preset ratios.
Zoom Copying (See page 20) Copying with variable zoom ratios.
■■
■■
■System Configuration
DP-130/150 DP-130P DP-150A/150PA
None None Yes
Not Available Not Available Optional
Not Available Standard Standard
(DP-150PA)
Sorting
2ndPaperFeed Module
Scanner
None None YesDigital Skyshot Mode
Not Available Not Available StandardADF
Not Available Standard Standard
(DP-150PA)
Printer
Operation Chart
Not Available Optional Optional
Sort Memory
(DA-SM16B)

4
Energy Star
For your safety
The DP-130/130P/150/150A/150PA copier complies withTier 2 of the Environmental Protection
Agency’s Energy Star Program.This voluntary program specifies certain energy consumption and
usage standards for copiers.This copier will automatically“power down”after a specified period of
non-use.
The use of these Energy Star compliant copiers will reduce energy consumption and ultimately
benefit the environment.
The default functions can be adjusted depending on your office requirements.Please see your
authorized Panasonic copier dealer for more details.

5
Making Copies
Common Features ■Full Size Copying..................................................................................2
■Reduction or Enlargement Copying ....................................................19
■Zoom Copying ....................................................................................20
■Using the Sheet Bypass .....................................................................21
Maintenance
Handling ■Adding Paper......................................................................................24
■Changing Paper Size..........................................................................25
■ChangingToner Cartridge...................................................................26
■Changing Drum Unit ...........................................................................27
■Removing a Misfed Paper...................................................................28
Mode Functions ........................................................................................................................... 18
Checking
Others
Troubleshooting ........................................................................................................................... 32
Specifications/Consumables List ............................................................................................... 35
Energy Star Table of Contents
Installation
Instructions ■Before Installation ..............................................................................12
■Release Scanner/Remove shipping materials ....................................13
■InstallToner Cartridge.........................................................................14
■Install paper........................................................................................15
■DA-DS150 (Option) ............................................................................16
Table of Contents
Before Operating
Precautions .................................................................................................................................... 6
Components ■External/Internal ...................................................................................9
■Control Panel ......................................................................................10
Creative Features ■Digital Skyshot Copy (DP-150A/150PA)..............................................22
■Sorting (DP-150A/150PA) ...................................................................23

6
Precautions
For your safety
■■
■■
■Laser Safety
Caution
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
■■
■■
■Caution Labels
Product complies with DHHS Rules 21
CFR Subchapter J in effect at date
of manufacture.
Utsunomiya, Tochigi, Japan
Product complies with DHHS Rules 21
CFR Subchapter J in effect at date
of manufacture.
Taytay, Rizal, Philippines
Matsushita Business Machine Corporation of the Philippines
FFPTE2479
DANGER-Invisible laser
radiation when open and
interlock defeated.
AVOID DIRECT EXPOSURE
TO BEAM.
Label when manufactured in Japan.
Label when manufactured in Philippines.

7
Precautions
Precautions
Handling
■Do not look directly at exposure lamp when copying.
■Do not turn the power switch off or open the front
panel during copying.(See page 9)
CDo not drop paper clips or other metal objects into
the copier.
Toner and Paper
■Store toner cartridge and paper in cool areas with
low humidity.
CHigh quality paper of 16 lbs.- 24 lbs.(15 –34 lbs.
via sheet bypass) may be used.
CFor optimum performance, it is recommended that
only Panasonic Brand supplies be used in the
copier.
Ventilation
■The copier should be installed in a well-ventilated
area to minimize the ozone density in the air.

8
Installation
■The copier should not be installed in areas with the
followingconditions:
CExtremely high or low temperature and humidity.
Proper ambient conditions
Temperature: 50°F –86°F
Relative humidity: 30% –80%
CWhere temperature and humidity can change
rapidly, causing condensation.
CDirect exposure to sunlight.
CDirectly in air conditioning flow.
CIn areas of high dust concentration.
CIn areas of poor ventilation.
CIn areas with chemical fume concentration.
CIn areas with extreme vibration.
CWith unstable or uneven conditions (floors, etc.).
■The power consumption is 1.0 kW.
A properly wired (with ground), dedicated, 15A, 120V AC outlet is required.Do not use an
extension cord.
The main plug on this equipment must be used to disconnect main power.Please ensure that the
socket outlet is installed near the equipment and shall be easily accessible.
For U.S.A.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his/her own expense.
Any unauthorized changes or modifications to this equipment would void the users authority to
operate this device.
Precautions

9
Components
Using the Sheet Bypass
Control Panel ADF (Automatic Document Feeder)
(DP-150A/150PA)
■■
■■
■External
External/Internal
Sheet Bypass
PaperTray
(See page 24, 25) Front Cover
Right Cover
On
Button
Off
Power Switch
Precautions Components
■■
■■
■Internal
Knob
(See page 29)
Drum Surface
CDo not touch it!
Drum Unit
(See page 27)
Toner Cartridge
(See page 26)
Fuser Cover
(See page 28)
Transfer Roller
CDo not touch it!
2nd Paper Feed
Module
(Option)
ExitTray
Pull out the tray
when copying.
Push here when closing
Right Cover.

10
2SIDED
AUTO
DARKER
LIGHTER
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
Components
Control Panel
Auto/Photo Mode Indicator
(See page 2) Auto/Photo Select Key
(See page 2)
Exposure Indicator
(L:Normal position)
(See page 3)
Exposure Control
Key
(See page 3) % Select Key
(See page 19)
PaperTray Key
Press to select
paper tray or
sheet bypass
By pressing Exposure Control key, the Exposure Indicator will be indicated as
follows.
DARK
LIGHT
Normal
Position Dark Darker Lighter Light
Sort Key
(DP-150A/150PA)
(See page 23)

11
Symbol Marks
#Change Drum Unit (See page 27)
$ChangeToner Cartridge (See page 26)
%Add Paper (See page 24)
&Paper Misfeed(See page 28, 29)
(See page 30:DP-150A/PA)
(See page 31:DA-DS150)
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
ON LINE
Components
Copy Count Display
Indicates number of copies
or machine condition codes
etc. (See page 32)
Energy Saver Key (See page 18)
Clear/Stop Key
Press to stop copy run or clear
copy count in display.
Zoom Keys
(See page 20)
“10”Key
Components
“1”Key
Start Key
Note: The Control Panel shown above is a representative sample of the model DP-150PA.
Each models Control Panel may be slightly different depending on its functionally.

12
Copier For DP-130/150/150A:
Operating Instructions
(1 piece)
For DP-130P/150PA:
CFor Copier (1 piece)
CCD-ROM (1 piece)
CInstallationInstructions
(1 piece)
Toner Cartridge
(1 piece)
ATTENTION
■■
■■
■Unpack and install on a stable flat surface.
Note: Do not plug the copier until directed to do so.
Installation Instructions
Installation
CTo maintain optimum performance, we recommend only using genuine Panasonic
supplies and parts.
CDrum unit already comes installed in copier.
CToner Cartridge is packed in carton box.
■■
■■
■Set up the main unit with following procedure
#Remove all shipping tape and styrofoam.
$Release the scanner/Remove shipping materials (See page 13)
%Installation of theToner Cartridge (See page 14)
&Loading paper (See page 15)
(Install the copier in an area that means or exceeds the minimum space requirement
(see diagram below).
Copier Sheet BypassExitTray
30 cm 70 cm
10 cm

13
Installation Instructions
ATTENTION
Release Scanner/Remove shipping materials
1Remove the fixing screw for the
optics unit.
2Pull paper tray out of copier and
secure the screw to the bottom of
the paper tray.
Note: When moving the copier reinstall
the fixing screw.
■■
■■
■Reminder: Do not plug the copier until directed to do so.
3#Completely remove the paper
tray from the copier.
$Release the shipping tapes
(2 pieces) from the bottom.
%Push the bottom plate lock
button.
Bottom view
4Remove the shipping tapes from
the bottom plate.(2 pieces)
5
CDo not plug in copier until set-up is complete.
CDo not open the front panel first.It can not be opened unless you open the
covers shown in procedure 5.
#Remove the shipping tape.
$Open the sheet bypass.
%Push the button.
&Open the right cover.
Installation Instructions

14
Installation Instructions
Remove shipping materials/InstallToner Cartridge
Remove the shipping material of
fuser unit.
#Remove the tapes.
(2 pieces)
$ Pullout the shipping materials (white string
with2 bluestoppers)fromthe fuser unit.
6
7Open the front panel.
Do not open the front panel first. It can
not be opened unless you open the
covers shown in procedure 5.
8#Shake the toner cartridge
several times.
$Take off the toner cartridge
cover (white plastic) and
discard.
9
Do not touch the magnetic roller!
Do not stand the toner cartridge on end!
Install the toner cartridge.
10
#Push the toner cartridge until it
stops.
$ Push the green handle until it locks.
%Close the front panel.
& Close the right cover. (See page 9)
(Close the sheet bypass.
ATTENTION
CTo maintain optimum performance, we recommend only using genuine Panasonic
supplies and parts.Store toner cartridge in a cool dark place.Install toner cartridge
immediately after unsealing.
Handle

15
Installation Instructions
ATTENTION
Install paper
Lift slightly and pull paper tray out
of copier until it stops.
1
2Push the bottom plate down until it
locks.
3Install the paper guide into the
holes that correspond to the paper
size you plan to load.
4Place paper.
Up to 250 sheets.
Donotfill above.
5#Slide the paper guide (front) to
the paper edge.
$Push the paper tray back into
copier.
Overfill Indicator
1-sided copy
Set-up is completed.Now ready to make a copy.
■■
■■
■ Push the paper tray into copier. Plug in the unit and turn on the power.When
the Add Paper Indicator (JJ
JJ
J) lights, install paper using the following procedure.
CWhen it is necessary to make 2 sided copies, place the output from side 1
face up on the sheet bypass tray then print the second side.
CIf the paper tray is not closed completely, the Add Paper Indicator in the
control panel will light up. In that case, please close the paper tray
completely.
CFor changing paper size, see page 25.
Installation Instructions

16
Installing 2nd Paper Feed Module (For DP-150A/150PA)
Installation Instructions for Option
■■
■■
■Unplug the power cord when installing the 2nd Paper Feed module
CUnplug the power cord when installing each unit.
1Remove all packing tape.
2Remove the tape as shown.
Check that the Half Moon Paper
Feed Rollers are in the up position
as illustrated on the left.
If they are out of position turn
them with your fingers ccw until
they are in the correct position.
3Lift the copier on its side to gain
access to the bottom of the unit,
then remove the white cover and
discard.
4Lift the copier carefully and place
on to the top of the 2nd paper
feed module as illustrated.
Right Position Wrong Position
ATTENTION

17
-1 -2
Installing 2nd Paper Feed Module
Installation Instructions for Option
To secure the 2nd paper feed
module to the copier, turn the
locking gears as indicated.Their
are 4, two on each side of the unit.
Caution
If the 2nd paper feed module is not fixed
securely, it may fall and hurt you.
5
6Remove the rear cover of the 2nd
cassette module.
#Pull out the hook.
$Open the cover slightly, and
remove it.
7Plug the harness of the 2nd paper
feed module into the machine
connector.
8#Reinstall the rear cover.
$Insert the hook untill it locks.
9Slide out the paper tray and
remove the shipping materials.
(See steps 3, 4 on page 13)
ATTENTION
Select paper size by Paper Tray
Key and “1”Key.
(See page 25)
10
CUnplug the power cord when installing.
Do not touch the gear area of the 2nd paper
feed module.
Reinstall the rear cover and insert the hook
then plug the power cord into the wall outlet.
Installation Instructions for Option

18
Mode Functions
■■
■■
■Energy Saver Mode/Sleep Mode
Energy Saver Mode
#To enter this mode
Press Energy Saver key.The indicator will flash.
Automatically enters after 15 minutes from the last copy.
$To cancel this mode
Press Energy Saver key again.
Sleep Mode
#Automatically enters after 30 minutes from the last copy.
Power consumption will drop and the Energy Saver key indicator will light.
$To cancel this mode.
Press Energy Saver key.
If you wish to change the above settings or if you need more information, call your Panasonic
authorized dealer.
Power Consumption Recovery warm up time
Normal Operation Approximately 60Wh None
Energy Saver mode Approximately 35Wh 5 seconds
Sleep Mode Approximately 1.5Wh 20 seconds
■■
■■
■Toner Saver Mode
#To enter this mode.
Press and hold % Select key, then press Paper Tray key.
$To cancel this mode.
Press and hold % Select key, then press PaperTray key.
ThisToner Saver Mode is to save toner consumption by copying dark originals lighter.
The exposure indicator“LIGHTER”flashes when Toner Saver Mode is on.
■■
■■
■Auto Start function
While the copier is warming up, you may position your original on the copier, enter your copy job
selections and press the Start key.The Wait indicator (Start key) will flash until the warm up
cycle is completed, then the copy job will automatically start.
Note:Please enter your copy job, when “1”appears in the display.
■■
■■
■Total Counter
The total counter in this copier is electronic. It can be read from the Control Panel. To read the
counter follow these steps:
#Press and hold the % Select Key, then press the Clear/Stop Key.
The Control Panel will display the first set of 3 digits, then it will display the second set of 3
digits.
$When placed next to each other, you have your reading.
Example: 1st set 012, then the 2nd set 345. You have made 12,345 copies.

19
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65% INVOICE
LEGAL
61% INVOICE
100%
AUTO
DARKER
LIGHTER
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
ON LINE
Common Features
Reduction or Enlargement Copying
■■
■■
■There are 3 preset reduction and 1 preset enlargement modes.
1
Place the
Original 2
Select the copy
ratio/size
Select paper tray
or sheet bypass*
NOTE
(3) 4
Number of
copies 5
Press Start
Example:Reduction
Original Size Copy Size
LEGAL LETTER
The correct ratio is automatically selected.
% Select Key
Mode Functions
CTo change the paper size of the paper tray, see page 25.
Common Features
∗Usage of PaperTray Key
When copy size is different from paper size in paper tray, select sheet bypass by pressing
PaperTray key and place the paper into the sheet bypass.(See page 21)
CYou can scroll through the magnification defaults by
pressing the % Select Key;keep pressing the key until the
desired ratio light is illuminated.

20
10
ZOOM
(50~200%)
ON LINE
Common Features
Zoom Copying
■■
■■
■A zoom ratio can be selected from 50% to 200% in 1% increments.
NOTE
1
Place the Original
% Select Key*2
AUTO
DARKER
LIGHTER
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
ON LINE
%
Select paper tray
or sheet bypass*1
(2)
∗1Usage of PaperTray Key
When copy size is different from paper size in paper tray, select sheet bypass by pressing
Paper Tray key and place the paper into the sheet bypass.(See page 21)
CTo change the paper size of the paper tray, see page 25.
∗2 Clear/Stop key has no function to reset the zoom ratio. To cancel the zoom
ratio, please press , then the ratio will default back to full size (100%).
3
Select Zoom Ratio
4
Number of
Copies 5
#Press and hold the key or key.
$Select zoom ratio.
Zoom Ratio: 50% - 200%
Press Start
For enlargement
For reduction
