Panasonic WORKIO DP-130 User manual

Digital Copier
Model No.
DP-130/135/150
Operating Instructions
Before operating this copier, please read
these instructions completely and keep this
operating instructions for future reference.
Making CopiesMaintenanceChecking Before OperatingOthers
2

2
INVOICE
LETTER R
LEGAL
INV
LTR
LGL
INV LTR LGL
AUTO
DARK
LIGHT
2SIDED
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
AUTO
SAVER
ENERGY
DARK
LIGHT
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
Common Features
■■
■■
■Full Size Copying
Turn the Power
Switch On Load the paper
(See page 18)
Control Panel
1
Position
original 2
Select“100%” 3 Number of
copies
(Up to 99)
NOTE
4
Press START
■■
■■
■Position of the original
■■
■■
■Original Guide
Place original against guide.
CFace DOWN on platen.
CIf the original is not positioned properly, a portion of the
original may not be copied.
■■
■■
■When manually selecting exposure control
CThe copier has auto exposure control and adjustments
are rarely required.
Select Photo to copy photos and halftones.
Select Auto to copy with Auto exposure control.
Select Dark to copy light image originals.
Select Light to copy colored background originals.
Normal Position
CRemove stacked copies from the exit tray every 200 sheets.
100%

3
Making Copies
Common Features ■Full Size Copying..................................................................................2
■Reduction or Enlargement Copying ....................................................15
■Zoom Copying ....................................................................................16
■Using the Sheet Bypass .....................................................................17
Maintenance
Handling ■Adding Paper ......................................................................................18
■Changing Paper Size..........................................................................19
■ChangingToner Cartridge...................................................................20
■Changing Drum Unit ...........................................................................21
■Removing a Paper Misfeed.................................................................22
Mode Functions ........................................................................................................................... 14
Checking
Others
Troubleshooting ........................................................................................................................... 24
Specifications/Consumables List ............................................................................................... 27
Table of Contents
Setup Procedure ■Before setting up ................................................................................10
■Release Scanner/Remove shipping materials ....................................11
■InstallToner Cartridge.........................................................................12
■Install paper........................................................................................13
Table of Contents
Before Operating
Precautions/Energy Star ............................................................................................................... 4
Components ■External/Internal ...................................................................................7
■Control Panel........................................................................................8

4
Precautions/Energy Star
For your safety
■■
■■
■Laser Safety
Caution
This product utilizes a laser.
Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
■■
■■
■Caution Labels
Product complies with DHHS Rules 21
CFR Subchapter J in effect of date
of manufacture.
Utsunomiya, Tochigi, Japan
Product complies with DHHS Rules 21
CFR Subchapter J in effect of date
of manufacture.
Taytay, Rizal, Philippines
FFPTE2479
DANGER-Invisible laser
radiation when open and
interlock defeated.
AVOID DIRECT EXPOSURE
TO BEAM.
Label when manufactured in Japan.
Label when manufactured in Philippines.
The DP-130/135/150 copier complies withTier 2 of the Environmental Protection Agency’s Energy
Star Program.This voluntary program specifies certain energy consumption and usage standards
for copiers.This copier will automatically“power down”after a specified period of non-use.
The use of these Energy Star compliant copiers will reduce energy consumption and ultimately
benefit the environment.
The default functions can be adjusted depending on your office requirements.Please see your
authorized Panasonic copier dealer for more details.

5
Precautions/Energy Star Precautions
Precautions
Handling
■Do not look directly at exposure lamp when copying.
■Do not turn the power switch off or open the front
panel during copying.(See page 7)
CDo not drop paper clips or other metal objects into
the copier.
Toner and Paper
■Store toner cartridge and paper in cool areas with
low humidity.
CHigh quality paper of 16 lbs.- 24 lbs.(15 – 34 lbs.
via sheet bypass) may be used.
CFor optimum performance, it is recommended that
only Panasonic Brand supplies be used in the
copier.
Ventilation
■The copier should be installed in a well-ventilated
area to minimize the ozone density in the air.

6
Installation
■The copier should not be installed in areas with the
followingconditions:
CExtremely high or low temperature and humidity.
Proper ambient conditions
Temperature: 50°F – 86°F
Relativehumidity: 30% – 80%
CWhere temperature and humidity can change
rapidly, causing condensation.
CDirect exposure to sunlight.
CDirectly in air conditioning flow.
CIn areas of high dust concentration.
CIn areas of poor ventilation.
CIn areas with chemical fume concentration.
CIn areas with extreme vibration.
CWith unstable or uneven conditions (floors, etc.).
■The power consumption is 1.0 kW.
A properly wired (with ground), dedicated, 15A, 120V AC outlet is required.Do not use an
extension cord.
The main plug on this equipment must be used to disconnect main power.Please ensure that the
socket outlet is installed near the equipment and shall be easily accessible.
For U.S.A.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment.This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his/her own expense.
Any unauthorized changes or modifications to this equipment would void the users authority to
operate this device.
Precautions

7
Components
Using the Sheet Bypass
Control Panel Platen
■■
■■
■External
External/Internal
Button
PaperTray
(See page 13, 18, 19)
ExitTray
Front Panel
Right Cover
On
Sheet Bypass
Off
Power Switch
Precautions Components
Please push here when
closing Right Cover.
■■
■■
■Internal
Knob
(See page 23)
Drum Surface
CDo not touch it!
Drum Unit
(See page 21)
Toner Cartridge
(See page 12, 20)
Fuser Cover
(See page 22)
Transfer Roller
CDo not touch it!

8
2SIDED
AUTO
DARK
LIGHT
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
Components
Control Panel
Auto/Photo Mode Indicator
(See page 2) Auto/Photo Select Key
(See page 2)
Exposure Indicator
(L:Normal position)
(See page 2)
Exposure Control
Key
(See page 2) % Select Key
(See page 15)
PaperTray Key
Press to select
paper tray or
sheet bypass
By pressing Exposure Control key, the Exposure Indicator will be indicated as
follows.
DARK
LIGHT
Normal
Position Dark Darker Lighter Light

9
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
SAVER
ENERGY
Components
Components
Copy Count Display
Indicates number of
copies and error code
etc. (See page 24)
Energy Saver Key (See page 14)
Clear/Stop Key
Press to stop copy run or clear
copy count in display.
Zoom Keys
(See page 16)
Quantity Keys
Start Key
Symbol Marks
#Change Drum Unit (See page 21)
$ChangeToner Cartridge (See page 20)
%Add Paper (See page 18)
&Paper Misfeed (See page 22, 23)

10
Copier Operating Instructions
(1 piece)
Toner Cartridge
(1 piece)
ATTENTION
■■
■■
■Unpack and install on a stable flat surface.
Note: Do not plug the copier until directed to do so.
Setup Procedure
Before Setting Up
CUse only the setup units/parts designated by Panasonic.If the copier should be
damaged by using other setup units/parts, Panasonic will not bear any responsibility.
CDrum unit already comes installed in copier.
■■
■■
■Set up the main unit with following procedure
#Remove all shipping tape and styrofoam.
$Release the scanner/Remove shipping materials (See page 11)
%Installation of theToner Cartridge (See page 12)
&Loading paper (See page 13)
(Install the copier in an area that means or exceeds the minimum space requirement
(see diagram below).
Copier Sheet BypassExitTray
30 cm 70 cm
10 cm

11
Setup Procedure
ATTENTION
Release Scanner/Remove shipping materials
1Remove the fixing screw for the
optics unit.
2Pull paper tray out of copier and
secure the screw to the bottom of
the paper tray.
Note: When moving the copier reinstall
the fixing screw.
■■
■■
■Reminder: Do not plug the copier until directed to do so.
3#Completely remove the paper
tray from the copier.
$Release the shipping tapes
(2 pieces) from the bottom.
%Push the bottom plate lock
button.
Bottom view
4Remove the shipping tapes from
the bottom plate.(2 pieces)
5
CDo not plug in copier until set-up is complete.
#Remove the shipping tape.
$Open the sheet bypass.
%Push the button.
&Open the right cover.
Setup Procedure

12
Setup Procedure
Remove shipping materials/InstallToner Cartridge
Remove the shipping material of
fuser unit.
#Remove the tapes.
(2 pieces)
$ Pullout the shipping materials (white string
with2 bluestoppers)fromthe fuser unit.
6
7Open the front panel.
CDo not open the front panel first. It can
not be opened unless you open the
covers shown in procedure 5.
8#Shake the toner cartridge
several times.
$Take off the toner cartridge
cover (white plastic) and
discard.
9
Do not touch the magnetic roller!
Do not stand the toner cartridge on end!
Install the toner cartridge.
10
#Push the toner cartridge until it
stops.
$ Push the green handle until it locks.
%Close the front panel.
& Close the right cover. (See page 7)
(Close the sheet bypass.
ATTENTION
CFor optimum copy quality use the recommended Panasonic toner cartridge.Store
toner cartridge in a cool dark place.Install toner cartridge immediately after unsealing.
Handle

13
Setup Procedure
ATTENTION
Install paper
Lift slightly and pull paper tray out
of copier until it stops.
1
2Push the bottom plate down until it
locks.
3Install the paper guide into the
holes that correspond to the paper
size you plan to load.
4Place paper.
Up to 250 sheets.
Donotfillabove.
5#Slide the paper guide (front) to
the paper edge.
$Push the paper tray back into
copier.
Overfill Indicator
1-sided copy
Set-up is completed.Now ready to make a copy.
■■
■■
■ Push the paper tray into copier. Plug in the unit and turn on the power.When
the Add Paper Indicator (JJ
JJ
J) lights, install paper using the following procedure.
CWhen making 2-sided copies, use the sheet bypass.
CIf the paper tray is not closed completely, the Add Paper Indicator in the
control panel will light up. In that case, please close the paper tray
completely.
CFor changing paper size, see page 19.
Setup Procedure

14
Mode Functions
■■
■■
■Energy Saver Mode/Auto Off Mode
Energy Saver Mode
#To enter this mode
Press Energy Saver key.The indicator will flash.
Automatically enters after 15 minutes from the last copy.
$To cancel this mode
Press Energy Saver key again.
Auto Off Mode
#Automatically enters after 30 minutes from the last copy.
Power consumption will drop and the Energy Saver key indicator will light.
$To cancel this mode.
Press Energy Saver key.
If you wish to change the above settings or if you need more information, call your Panasonic
authorized dealer.
Power Consumption Warm Up Time
Normal Operation Approximately 60 Wh None
Energy Saver mode Approximately 35Wh 5 seconds
Auto Off Mode Approximately 1.5Wh 20 seconds
■■
■■
■Toner Saver Mode
#To enter this mode.
Press and hold % Select key, then press PaperTray key.
$To cancel this mode.
Press and hold % Select key, then press PaperTray key.
ThisToner Saving Mode is to save toner consumption by copying dark originals lighter.
The exposure indicator“LIGHT”flashes whenToner Saving Mode is on.
■■
■■
■Auto Start function
While the copier is warming up, you may position your original on the copier, enter your copy job
selections and press the Start key.The Wait indicator (Start key) will flash until the warm up
cycle is completed and the copy job will automatically start.
Note:Please enter your copy job, when “1”appears in the display.

15
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65% INVOICE
LEGAL
61% INVOICE
100%
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
AUTO
SAVER
ENERGY
DARK
LIGHT
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
Common Features
Reduction or Enlargement Copying
■■
■■
■There are 3 preset reduction and 1 preset enlargement modes.
1
Position original 2
Select the copy
ratio/size
Select paper tray
or sheet bypass*
NOTE
(3) 4
Number of
copies 5
Press Start
Example:Reduction
Original Size Copy Size
LEGAL LETTER
The correct ratio is automatically selected.
% Select Key
Mode Functions
CTo change the paper size of the paper tray, see page 19.
Common Features
∗Usage of PaperTray Key
When copy size is different from paper size of paper tray, select sheet bypass by pressing
PaperTray key and place the paper into the sheet bypass.(See page 17)

16
10
ZOOM
(50~200%)
Common Features
Zoom Copying
■■
■■
■A zoom ratio can be selected from 50% to 200% in 1% increments.
NOTE
1
Position original
% Select Key*2
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
AUTO
SAVER
ENERGY
DARK
LIGHT
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65%
INVOICE
LEGAL
61%
INVOICE
100%
%
Select paper tray
or sheet bypass*1
(2)
∗1Usage of PaperTray Key
When copy size is different from paper size of paper tray, select sheet bypass by pressing
Paper Tray key and place the paper into the sheet bypass.(See page 17)
CTo change the paper size of the paper tray, see page 19.
∗2 Clear/Stop key has no function to reset the zoom ratio. To cancel the zoom
ratio, please press , then the ratio will default back to full size (100%).
3
Select zoom ratio
4
Number of
Copies 5
#Press and hold the key or key.
$Select zoom ratio.
Zoom Ratio: 50% - 200%
Press Start
For enlargement
For reduction

17
NOTE
Common Features
Using the Sheet Bypass
1Position original.
Select copy ratio/size.
(See page 15, 16)
2Open the sheet bypass.
3Open the tray.
■■
■■
■For 2-sided copying or to copy on letterhead, mailing labels, transparencies
and odd-size paper, etc., or to use the bypass as an additional paper source.
Tray
4#Place paper into the tray. (Up to
50 sheets)
Insert the paper until it stops.
Copy side down for copying
on letterhead paper and
mailing labels.
$Adjust the side guides to paper
width.
Incorrect adjustment may cause paper
to wrinkle, misfeed or skew.
Common Features
CWhen using 2-sided copies, do not set more than 25 (20 lbs.) sheets in bypass.
CSome types of mailing labels and transparency film may damage your
machine.Contact your service provider for advice regarding non-standard
paper types.
CWhen sheet bypass has no paper, “P” will appear on Copy Count Display.
5Select sheet bypass with Paper
Tray key.
Side Guides
Do not fill above.

18
Handling
Adding Paper
1Lift paper tray and pull out of the
copier until it stops.
2Push the bottom plate down until it
locks.
3Place paper into paper tray.
How to place paper:
Place the paper copy side up.
■■
■■
■Use the following steps to add paper.
NOTE
Do not fill above.
41-sided copy
Push paper tray back into copier.
CSpecial papers, like glossy paper, mailing labels and transparencies cannot be
used in the paper tray. Use bypass for special paper.
CWhen making 2-sided copies, use the sheet bypass.
CIf the paper tray is not closed completely, the Add Paper Indicator in the control
panel will light up. In that case, please close the paper tray completely.
5
Make sure paper is not loaded
above overfill indicator located in
the paper tray.
Overfill Indicator

19
10 1
ZOOM
(50~200%)
START
CLEAR/STOP
AUTO
SAVER
ENERGY
DARK
LIGHT
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65% INVOICE
LEGAL
61% INVOICE
100%
1: Letter
[
2: Legal
[
3: Invoice
[
4: A4
[
5: B5
[
6: A5
[
7: FLS1
[
8: FLS2
■■
■■
■The paper tray is designed to accommodate invoice, letter and legal size
paper.
Handling
Changing Paper Size
2Check paper size
(See table below)
PaperTray Key “1”Key
1
Press and hold Paper Tray key, then continue to
repeatedly press “1” key to scroll until the number
in the display matches the paper size required.
Use the chart on the right.
3#Lift paper tray and pull out of
the copier until it stops.
$Move paper guide ato the
paper length required.
4#Move paper guide bto the
paper width required.
Squeeze the stopper to move the
paper guide bto the desired paper
size.
$Push paper tray back into
copier.
Paper Guide bb
bb
b
Paper Guide aa
aa
a
Stopper
Handling

20
LEGAL
79%
INVOICE
LETTER
LETTER
129%
LETTER
65% INVOICE
LEGAL
61% INVOICE
100%
Handling
ChangingToner Cartridge
1#Open the sheet bypass.
$Push the button.
%Open the right cover.
?
ChangeToner Cartridge Indicator
The cartridge will have to be changed
shortly, when the indicator starts to flash.
When it stops flashing and is fully
illuminated, the cartridge must be replaced.
Button
Right Cover
Sheet Bypass
2#Open the front panel.
Do not open the front panel first. It can
not be opened unless you open the
covers shown in procedure 1.
$Pull the green hook of toner
cartridge.
3Remove the toner cartridge.
4#Shake the toner cartridge
several times.
$ Take off the toner cartridge cover
(white plastic) and discard.
ATTENTION
Do not stand the toner cartridge on end!
Do not touch the magnetic roller! (See page 12)
5#Install new toner cartridge.
$ Push the green handle until it locks.
%Close the front panel.
& Close the right cover. (See page 7)
(Close the sheet bypass.
CFor optimum copy quality use the recommended Panasonic toner cartridge.
Store toner cartridge in a cool dark place.Install toner cartridge immediately
after unsealing.
Hook
Handle
